WAT E R M A N AGE M E N T
MEADRAIN TRAFFIC
DRAINAGE SYSTEMS
FOR ROAD AND
HIGHWAY CONSTRUCTION
H I G H Q U A L I T Y P O LY M E R C O N C R E T E D R A I N A G E S Y S T E M S
P R O F E S S I O N A L D R A IN A G E S O L U T I O N S F O R R O A D A ND T R A F F I C A P P L I C AT I O N S
ME A D R A IN D M / M E A K E R B
MEADRAIN TRAFFIC DRAINAGE SYSTEM 03
MEADRAIN TRAFFIC
MONOLITHIC DRAINAGE CHANNEL
FOR HEAVY TRAFFIC AREAS
MEADRAIN TRAFFIC DM
SYSTEM OVERVIEW
Clear width: 100 mm Channel section without fall
Total width: 133 mm Monolithic construction
Total height: 225 mm Loading class A 15 to D 400**
MEADRAIN DM CITY (LIGHT) 1000
Clear width: 100 mm Channel section without fall
Total width: 154 mm Monolithic construction
Total height: 265 mm Loading class A 15 to F 900 for standard variant
Loading class A 15 to D 400** with side inlets for use
MEADRAIN DM 1010 in open porous asphalt
Clear width: 150 mm Channel section without fall
Total width: 204 mm Monolithic construction
Total height: 280 mm Loading class A 15 to F 900 for standard variant
Loading class A 15 to D 400** with side inlets for use
MEADRAIN DM 1500 in open porous asphalt
Clear width: 200 mm Channel section without fall
Total width: 254 mm Monolithic construction
Total heights: 320 / Loading class A 15 to F 900 for standard variant
420 / 520 / 570 mm Loading class A 15 to D 400** with side inlets for use
in open porous asphalt
MEADRAIN DM 2000/ 2020/ 2040/ 2050
** From loading class D 400 not suitable for the cross drainage of high speed
roads and motorways.
MEADRAIN TRAFFIC SYSTEM OVERVIEW 05
MEADRAIN TRAFFIC
MEAKERB 320 AND 500
SYSTEM OVERVIEW
Clear width: 100 mm Monolithic drainage system with
Total width: 154 mm top kerb profile, without fall
Total heights: from 195 Monolithic construction
to 375 mm Loading class A 15 to D 400**
MEAKERB 320
Clear width: 100 mm Monolithic drainage system with
Total width: 154 mm top kerb profile, without fall
Total height: from 375 Monolithic construction
to 555 mm Loading class A 15 to D 400**
MEAKERB 500 ** From loading class D 400 not suitable for the cross drainage of high speed
roads and motorways.
MEADRAIN DM
For the drainage of motorways and highways
MEAKERB
Combines a channel and kerb profile in a sing-
le element for the drainage of roads, car parks
and the streetscaping of urban areas
MEADRAIN TRAFFIC
PIONEERING DRAINAGE SOLUTIONS
FOR MOTORWAYS AND CITIES
MEA offers you pioneering solutions for the reliable and expertise in professional surface drainage for every
cost-effective drainage of all the world's roads. Our conceivable application. Optimize your planning with
product range contains clearly designed and innovative flexibility through innovative modular systems, a free
solutions made of polymer concrete. technical support and advisory service and the out-
standing physical and chemical properties of polymer
No matter which channel system you use for the task concrete. Work with less weight, do away with heavy
in hand, MEADRAIN TRAFFIC delivers decades of MEA lifting equipment for installation and benefit from the
durability and reliability of our products.
MEADRAIN DM 07
MEADRAIN DM
THE HIGH-END MONOLITHIC
DRAINAGE SOLUTION
MONOLITHIC POLYMER CONCRETE DRAINAGE CHANNEL Fields of application:
MEADRAIN DM Motorways
The monolithic high performance MEADRAIN DM has Highways
been designed to resist perfectly and on the long run Airports
to maximum traffic load. The monolithic construction of the MEADRAIN DM
As an alternative to our heavy duty DM channels our NEW guarantees:
MEADRAIN DM CITY (LIGHT) 1000 has been designed for Maximum acceptance and transfer of high dynamic
urban areas (Loading class D 400**, wheelchair compa- loads
tible). Total compliance with safety and security standards
Best possible value for money
** From loading class D 400 not suitable for the cross drainage of
high speed roads and motorways.
Suitable for use in highway construction:
resistant to aggressive abrasion, prema-
ture ageing and de-icing salt. Completely
Made from high compres- frost-proof and very hardwearing
sive- and tensile-strength
polymer concrete
100% traffic safe: no
loose components such Eco- and climate-friendly,
as bolts or metal parts as the material used
contains approximately
MEADRAIN DM CITY (LIGHT)1000 90% mineral aggregates
Loading class to D 400**
Loading classes
up to D 400**
Kerb-face inlets
Clear width: 100 mm
MEAKERB
THE KERB WITH INTEGRATED
WATER DRAINAGE FACILITY
The new MEAKERB generation benefits from the profound Drop-kerb and centre stone units for access roads, plus a
knowledge of our engineering department and is now available complete range of accessories make the MEAKERB module
in a monolithic construction making it not only sturdier but in conjunction with the MEA Planning Service a perfect all in
also more economical. one solution for fast and professional installation.
The MEAKERB has been designed for following applications: Last but not least: If a single kerbstone becomes damaged,
Major highways it can be replaced individually – without costly groundwork
Rural and urban roads operations.
Roundabouts
Property access roads ELEMENTS:
Flyovers Bus stop kerb unit
Car parks Standard kerb unit
Lay-bys Centre stone unit
Bus stations Road level compensation
** From loading class D 400 not suitable for the cross drainage of high speed roads and motorways.
MEADRAIN RAIL SOLUTION 09
MEA RAIL SOLUTION
CUSTOM MADE SOLUTIONS
FOR RAIL PROJECTS
Efficient and flexible solutions for tramway projects. Comprehensive project support by experienced MEA
Customised and professional solutions for your technicians
specific applications MEA is the specialist for all TRAM projects whatever the
MEADRAIN ENS 2010 and MEARIN EXPERT 200 power supply system used (over the ground (APS), or
channels and cover gratings in special lengths over headlines)
designed to be installed across tramways
POLYMER CONCRETE
THE QUALITY MATERIAL
MEA POLYMER CONCRETE MATERIAL CHARACTERISTICS
The special polymer concrete from MEA is remark- Compressive strength > 90 N/mm2
able for its outstanding physical and chemical Flexural tensile strength > 22 N/mm2
properties. This material is extremely sturdy, reliable Water adsorption Below 0.05%
and versatile making it the material of choice for drai- Modulus of elasticity 25-35 kN/mm2
nage channels. MEA polymer concrete channels are Density 2.1 - 2.3 kg/dm2
particularly eco-friendly. Mostly made out of minerals, Water ingression depth 0 mm
polymer concrete channels are easy to recycle. Becau- Material structure Capillary-free – ideal for
se of the quality material channels have a particularly the rapid discharge of water
long lifetime, saving future investments and unneces- and dirt particles
sary new building sites. Polymer concrete channels Channel body weight Significantly lighter than
are the more extremely resistant to liquid chemicals conventional concrete
and acids, making them the perfect protection devices channels
for the environment and ground waters. Workability Suitable for grinding disks,
Last but not least, polymer concrete channels are rock drills and chisels
significantly lighter than comparable concrete Environmental compatibility Eco-friendly building
channels, making them considerably easier to install. material with mineral
admixtures
Ageing resistance Entirely frost proof,
wear-resilient, and
maintenance-free.
Highly resistant to liquid
chemicals (pH range 3 to 9)MEA PRODUCT RANGE 11
THE ADDITIONAL
PRODUCT PORTFOLIO OF
MEA WATER MANAGEMENT
MEARIN PG EVO
Drainage system for
multi-storey car parks
MEATEC
Professional drainage system for
façades and terraces
MEARIN
Professional lightweight
drainage system made of GRP
MEADRAIN
Professional drainage systems
for challenging projects010264145 | GB | 04.2021
MEA Bautechnik GmbH Sudetenstraße 1 D-86551 Aichach www.mea-group.com
