Micro Engineering's newest injection-molded plastic structure kit is this "Doyle Distribution Center. " The 6x10-inch two
structure complex is $10.95 (an HO version is also a vailable at $12. 95).
r------,
The Micro Engineering structure kits
are designed so they can be built to
match the photo on the box, but the parts
can be easily cut (along the exterior
lines) with a razor saw, and there are
several windows and doors pre-punched
on the interior that are easy to open.
Shown here is a possible kit-conversion
of the larger N scale Murphy Manu
facturing building to reduce its area from
3x5% to about 2x4 inches. In truth, this is
the HO scale version of the kit, but only
that smaller-size rail would give it a way
- Micro Engineering's N scale kits have
details just as fine as the HO scale kits.
Con-Cor is offering its 50-foot flat cars with trailers (shown
in HO scale versions in the July issue) as N scale models.
There are minor detail differences between the HO and N
scale models, b u t the paint schemes are nearly iden
tical. There's a choice of WP (shown), Pennsylvania, Wabash,
Union Pacific, Great Northern, Illinois Central, Santa Fe and
New York Central markings - all based on trailers from the
Sixties.
.'
Con-Cor is now shipping these modern-era cupola ca
booses in N scale in a choice of road names that includes
Burlington Northern and Union Pacific. See your dealer.
Eastern Seaboard Models, P.D. Box 316, Little Ferry, NJ 07643-0318, is offering the N scale tank cars made by Rivarossi in
five lettering schemes including UTLX (circa 1967) $7. 50; Emery Chemicals, $8.25; Dow Chemicals, $ 7. 70; GATX (circa 1971,
shown here) $7.50; and Pan Pacific Commodities, $8.25 (shown). The models are lettered on both the sides and ends. The
September 1989 issue of the Journal will have color photographs of some similar prototype cars.
