Table of Contents
Ki Pro FS 26 Control
3 Digital Recorders and Players 18 4K/2K/HD/SD Frame Sync and Conversion Control for ROI Mini-Converters.
File-based recording and playback devices that Hardware conversion in compact 1RU rack Frame Sync 26 HDBaseT Mini-Converters
create high-quality files on computer-friendly media units offering unrivaled flexibility and supporting the Solution for extending video signals up to 100 meters
via industry standard codecs and connections for latest connectivity, with models supporting 12G-SDI, over Cat 5 (or better) cable, utilizing the industry
on-set, postproduction, OTT, live events, and more. HDMI, and fiber I/O with extensive audio support. standard HDBaseT protocol.
HELO KUMO 27 Optical Fiber Mini-Converters
7 Streaming and Recording Appliance 21 Routers SDI/Optical Fiber converters for the transport of 12G/3G/
SDI and HDMI I/O in a single appliance with the ability Convenient dense routing solutions in lightweight form HD/SD-SDI or HDMI over distances up to 10km when us-
to simultaneously stream, encode and record beautiful factors for use in facilities, OB trucks, post suites, and ing standard Single-Mode or Multi-Mode fiber optic cable.
H.264 files. more. Available in multiple connector densities, with FiDO models support video formats all the way up to 8K/
Io 3G-SDI and 12G-SDI models. UltraHD2, model dependent.
8 Mobile I/O Mini-Converters Mini-Converter Accessories
Desktop-level functionality in portable form factors 22 Infrastructure Converters 30 Accessories
encompassing Thunderbolt™ standards all the way up to Options for common infrastructure and point of use Options for mounting and powering AJA Mini-Converters.
Thunderbolt 3 with 12G-SDI and HDMI v2.0, as well as needs. openGear
mobile USB 3 and PCIe devices. 23 HDMI Mini-Converters 31 openGear Compatible Rackframe Cards
KONA Converters offering support for raster sizes all the way Cards for infrastructure, HDMI/SDI conversion, scan
11 Desktop I/O from SD and HD to 4K/UltraHD, as well as connections for conversion, fiber conversion, scaling, for use in openGear
Powerful I/O solutions for the most demanding tasks from the latest 12G-SDI and HDMI 2.x standards. frames including the AJA OG-X-FR.
SD to 8K, Multi-Channel workflows, HDR, Streaming, and 24 Scan Converters SFP Options
Broadcast IP. Exceptional high quality conversion of computer 33 SFP Opitons
U-TAP and video sources signals with Region of Interest Optional SFP modules available for a range of AJA
15 USB 3.0 Powered 3G-SDI and HDMI Capture support to desired HD raster sizes and frame rates. Products
Professional connectivity and high quality video capture 25 Scaling Mini-Converters Corvid
to your laptop or workstation. Conversion for an entire source image from 4K to HD, 34 PCIe I/O
T-TAP up, down, or cross-conversion between SD and HD Proven video I/O devices available to AJA partners for
16 Thunderbolt™ Powered SDI and HDMI Output formats or even HD to DVI conversion for driving DVI development and support of integrated products with
Inexpensive and compact device that utilizes the power monitors from video sources. powerful SDK support.
of Thunderbolt™ to deliver high-quality 10-bit SD, HD, 25 IP Mini-Converters RovoCam HDBaseT Camera System
and 2K video and embedded audio output from any Rugged, compact, and reliable, providing the bridge
compatible Mac or PC. 35 HDBaseT Powered Camera and Receivers
between baseband and IP video for a range of
UltraHD/HD capture in a range of scenarios from Sports
HDR Image Analyzers applications.
venues to live events, facilities, and HOW use.
17 HDR Waveform, Histogram, and Vectorscope Monitoring 25 Analog Mini-Converters
Tools for the effective real time analysis of the latest HDR Solutions for Analog to Digital and Digital to Analog
standards from 8K/UltraHD2/4K/UltraHD/2K/HD content conversion for both Video and Audio, including
in stand-alone 1RU devices over 12G-SDI or 3G-SDI. composite, component and HD Analog to
HD Digital conversion.
26 LUT-box
In-line color transform for adjusting the color look for any
source signal with simultaneous outputs to HD HDMI and
SDI monitors from a single device.
12G Multi-Channel HD and 4K/UltraHD/2K/HD Recorder and Player
ULTRA 12G $3,995
12G I/O for up to UltraHD/4K 60p support
Ki Pro Ultra 12G is the latest digital video player and recorder to join the Ki Pro family and match codec profiles and user selectable audio channels. Configurable Matrix
of products. Ki Pro Ultra 12G builds upon its predecessor, the Ki Pro Ultra Plus Monitoring outputs on SDI and HDMI allows monitoring on one external display,
product, by adding 12G-SDI support as well as 12G compatible Optical Fiber SFP plus audio VU meters display levels for each of the channels being recorded.
cages. Ki Pro Ultra 12G offers HDR support via HDMI and SDI for both recording and The new enhanced super out functionality now adds VU meters and media status to
playout giving immense flexibility as both recorder and player for HDR material. the onscreen overlay output.
Multi-channel HD recording is available, offering versatile menu options to mix
AJA Pak Media
Available in 2TB, 1TB, 512GB and 256GB capacities Size (W x D x H): 219.46 x 268.60 x 84.08 mm
Powerful 12G I/O with Flexible SFP fiber High Quality Recording and Playback Intuitive Interface, Multi-Channel Monitoring
• 1x 12G-SDI input • H D ProRes multi-channel recording and single • HDMI and SDI multi-channel matrix monitoring
• 3x 3G-SDI inputs channel playback • Easy to use web UI, configure and control from
• 1x 12G-SDI output • Single channel recording up to 4K 60p standard web browsers anywhere
• 3x 3G-SDI outputs • Records and plays back up to ProRes 4444 XQ • Front panel button controls with integrated HD
• HDMI v2.0 in • Records and plays back up to Avid DNxHR HQX resolution screen
• HDMI v2.0 out • HDR recording and playback • Stand-alone operation
• SFP fiber cage I/O • YCbCr and RGB • Optional rack mount shelf (KPU-SHELF)
• Analog audio in (DB-25 loom connectivity) • RS-422 control • Three year warranty
• Analog audio out (DB-25 loom connectivity) • REST interface
www.aja.com |3
GO $3,995 ULTRA Plus $3,995
• Multi-channel H.264 recording • Genlock free inputs • 4K/UltraHD/2K/HD record and playback • Up to 64 Channels of Audio supported
• 5x USB recording media ports, compatible • HDMI and SDI multi-channel matrix monitoring • Multi-channel 2K/HD recording to Apple ProRes • Closed Caption recording
with off-the-shelf USB 3.2 Gen 1 media • Support for RP-188 Time Code inputs on SDI • Avid DNxHR and Avid DNxHD recording • Remote webUI operation
• Redundant recording to user • Balanced XLR analog audio inputs, mic/line/ and playback • 4x 3G-SDI I/O
selectable channels 48v switchable • Infinite Recording Mode • HDMI 2.0 I/O
• Up to 25Mbps bit rate • Front panel button controls with integrated • Rollover Recording Mode • Fiber SFP Cages for long cable runs
• Network file download HD resolution screen • Ki-Protect for recording • HDR10 and HLG capture and playback
• Enhanced Super Out • Optional rack mount shelf (KPU-SHELF) • 12-Bit support with ProRes XQ • Three year warranty
• Front panel audio monitoring • Easy to use web UI, configure and control • ExFAT and HFS+ supported
• LTC on analog audio input from standard web browsers
• Drive formatting • Stand-alone operation
• Three year warranty
Size (W x D x H): 219.46 x 268.60 x 84.08 mm AJA Pak Media Size : 219.46 x 237.24 x 84.08 mm
Available in 2TB, 1TB, 512GB and 256GB capacities
www.aja.com |4
Rack $1,995 Ki Pro Rack
• HD/SD recorder and player
• Record to Apple ProRes or Avid DNxHD
• SDI, HDMI and Component Video I/O
• AES (BNC) and analog (XLR) audio I/O
• 2x KiStor media bays with Ki Protect
• Up, down, cross-conversion built in
• Easy to use web UI, configure and control from standard web browsers
• REF, LTC and RS-422 support
• Three year warranty
AJA KiStor Media Size (W x D x H): 219.46 x 268.60 x 44.45 mm
Available in 1TB, 512GB SSD, 500GB HDD
and 256GB SSD capacities
www.aja.com |5
Pak Media Pak Dock Ki Pro Shelf
Pak Media is a high capacity solid state drive encased
External Dock for Pak Media with Thunderbolt and Ki Pro Ultra Plus, Ki Pro Ultra 12G, Ki Pro Ultra,
in a protective housing with a rugged connection
USB 3.0 connections for fast transfer of media to a host and Ki Pro GO feature a small footprint for desktop use
engineered to handle the rigors of repeated use in
computer. or can be mounted side by side using the additional
the field. Available in 2TB, 1TB, 512GB and 256GB
capacities. Designed for use with Ki Pro Ultra 12G and KPU-Shelf for rackmount applications.
Ki Pro Ultra Plus.
KiStor Media KiStor Drive Reliable Storage Media
KiStor Media is a high capacity solid state drive encased External Dock for KiStor Media with Thunderbolt and Ki Pro Ultra 12G and Ki Pro Rack include Ki Protect,
in a protective housing with a rugged connection USB 3.0 connections for fast transfer of media to a host a feature that helps to ensure data integrity if a media
engineered to handle the rigors of repeated use in the computer. drive is accidentally removed or loses power during
field. Available in 1TB, 512GB and 256GB capacities. recording.
Designed for use with Ki Pro Rack.
The only loss that should be incurred is the last few
frames that were in transit to the media drive to be
recorded when the operation was interrupted, providing
greater peace of mind on set and in the studio.
www.aja.com |6
Stream, Record, Deliver H.264 at the Touch of a Button
HELO $1,295
Connect Encode Stream Record Web Server Built-In Scheduler and
Automation Control
Your projects vary, you Your goal is efficiency Streaming can be complex, Live means Now. You serve the web.
need flexible connectivity. with beautiful results. HELO makes it simple. Live means Pressure. HELO serves you. Point HELO to an event
HELO delivers with 3G-SDI HELO encodes to H.264/ A USB connection and web calendar for a set and forget
HELO offers a dedicated AJA eMini-Setup and
and HDMI video inputs and MPEG-4 ensuring bandwidth browser based UI allows recording and streaming
Record button right on HELO’s easy to use web
outputs. efficiencies with widely you to setup and configure experience.
the front of HELO’s small browser Interface make
24-bit audio at 48 kHz compatible files. From tablets your CDN connection before HELO simple to setup,
and mobile interface for For more complex situations,
embedded in the SDI or to smartphones, desktops you arrive at your event. configure and update
immediate recording. It achieve full automation with
HDMI signal ensures you to Smart TVs, no translation On site, simply press the firmware at any time and you
also provides simultaneous an easy to script control API.
never lose sync, plus Line necessary. Stream button and deliver can capture Logs for simple
your project across HELO’s redundant recording to two
Level, Unbalanced stereo media devices: CIFS/SMB, trouble shooting.
3.5mm TRS connectors Ethernet connection,
which supports RTMPE, NFS, SD, or USB. Connect to HELO either via
have you covered for live
audio capture. RTMP, RTSP and unicast or Simply plug in your exFAT its direct USB port to set
multicast RTP. or FAT32 formatted USB static/dynamic IP addresses
drive, SD card or connected though AJA eMini-Setup
HLS streaming adds direct
network storage and record software or over the
interoperability with Apple®
immediately. network using HELO’s web
iPads® and other consumer
server generated UI.
devices. AV Mute allows
for uploading your custom
graphic to your stream
before the event begins.
Size (W x D x H): 177.8 x 118.37 x 25.91 mm
www.aja.com LIVE |7
Powerful and Flexible Professional I/O
4K Plus $2,495 Io 4K Plus
• 12G-SDI and HDMI 2.0 I/O over Thunderbolt™ 3
• 4K/UltraHD/HD/SD capture and playback
• 12G-SDI and HDMI 2.0 I/O with HFR support up to 4K 60p
• 10-bit high quality 4:2:2, 4:4:4 and High Frame Rate workflow support
• Real time 4K/UltraHD to 2K/HD down-conversion over SDI Monitor Out
• HDR support: HDR-10, HLG (Hybrid Log Gamma)
• 16-channel embedded audio on SDI; 8-channel embedded audio on
HDMI; 8-channel analog audio in or out or 4-channel in and out via
DB-25 to XLR cable
• Downstream keyer
• Compatible with leading creative apps
• Three year warranty
3
Size (W x D x H): 222.0 x 206.0 x 41.9 mm
4K $1,995 Io 4K
• 3G-SDI and HDMI 1.4b I/O over Thunderbolt™ 2
• 4K/UltraHD/HD/SD capture and playback
• 3G-SDI and HDMI 1.4b I/O with HFR support up to 4K 60p
• 10-bit high quality 4:2:2, 4:4:4 and High Frame Rate workflow support
• Real time 4K/UltraHD to 2K/HD down-conversion over SDI Monitor Out
• HDR support: HDR-10, HLG (Hybrid Log Gamma)
• 16-channel embedded audio on SDI; 8-channel embedded audio on HDMI;
4-channel analog audio out via DB-25 to XLR cable
• Downstream keyer
• Compatible with leading creative apps
• Three year warranty
2
Size (W x D x H): 222.0 x 180.09 x 41.91 mm
www.aja.com |8
IP $2,495
Io IP
• IP Video and Audio I/O over Thunderbolt™ 3
• 4K/UltraHD/2K/HD/SD over 10 GigE up to 60/50p
• SMPTE ST 2110 and SMPTE ST 2022-6 supported
• Redundancy / High availability via SMPTE ST 2022-6/7 up to 2K/HD
• HDMI, 3G-SDI for local monitoring, plus Analog Audio I/O.
• HDR support: HDR-10, HLG (Hybrid Log Gamma)
• LLDP support
• Reference Input (Analog black or Tri-level for ST 2022-6 facilities)
• macOS, Windows compatibility
• Compatible with leading creative apps
• Three year warranty
Size (W x D x H): 222.0 x 206.0 x 41.91 mm 3
XT $1,495 Io XT
• 3G-SDI and HDMI I/O over Thunderbolt™
• HD/SD Video I/O up to 60p
• 3G-SDI, HDMI I/O and Component Out
• Analog Audio Out via DB-25 to XLR cable
• Downstream keyer
• Up, down, cross-conversion
• Ref/LTC and RS-422 ports
• macOS, Windows compatibility
• Compatible with leading creative apps
• Three year warranty
Size (W x D x H): 222.0 x 180.09 x 41.91 mm
www.aja.com |9
Express $995
Io Express
• HD-SDI, Component, and HDMI I/O over PCIe
• HD/SD Video I/O up to 60p
• HD-SDI, HDMI I/O and Component Out
• Ref/LTC and RS-422 ports
• 2-channel, 16 and 24-bit unbalanced audio (via RCA jack)
• PCIe connection port
• Compatible with leading creative apps
• Three year warranty
Size (W x D x H): 222.0 x 180.09 x 41.91 mm
Software Compatibility
Io products are cross-platform and compatible with a wide range
of professional macOS® and Windows® software applications.
AJA drivers and plug-ins create a seamless integration between the native software
and AJA’s high quality hardware that lets you focus on the work, not the technology.
View our software compatibility chart for the following categories:
Audio | Color | Dailies | Editorial | Effects | Graphics | Ingest/Playout | Restoration
Streaming/Live Production | Test/Measure
View Compatibility Chart
www.aja.com | 10Professional Performance, Unparalleled Reliability
5 $2,995
KONA 5
• Supports 8K/4K/UltraHD ingest and output at frame rates up to 50/60 fps
• Supports 4:4:4 and 4:2:2 workflows
• 4x bidirectional 12G-SDI spigots
• 12-bit color support (application dependent)
• 8K support for Apple Final Cut Pro X and Adobe Premiere Pro
• 8K or multi-channel 4K support for OEM applications with AJA SDK
• HDMI 2.0 output, 4K/UltraHD HFR 4:2:2 10-bit, plus 8K to 4K downsampling
• HDR support: HDR-10, HLG (Hybrid Log Gamma)
• 8-ch AES/EBU, 8-ch embedded HDMI, and 16-ch embedded SDI digital audio I/O
• Reference Input on card (Analog black burst or Tri-level)
• Extend external connectivity with included breakout cable
• RS-422 support on 9-pin connector
• macOS, Windows and Linux support
• Compatible with leading creative apps
• Three year warranty
IP $2,495 KONA IP
• 4K/UltraHD/2K/HD/SD Video and Audio over 10 GigE up to 60/50p
• Both SMPTE ST 2110 and SMPTE ST 2022-6 supported
• Redundancy / High availability via SMPTE ST 2022-6/7 up to 2K/HD
• TR-01 compliant JPEG 2000 workflows support with optional license
• LLDP supported
• HDMI for local monitoring
• Compatible with leading creative apps
• Reference Input (Analog or Tri-level for ST 2022-6 facilities)
• macOS, Windows and Linux support
• Compatible with leading creative apps
• Three year warranty
www.aja.com | 114 $1,995
KONA 4
• Supports 4K and UltraHD ingest and output at frame rates up to 50/60p
• Real time up, down, cross-conversion with pristine 10-bit quality
• 3G-SDI and 1.5G-SDI formats supported
• HDMI 1.4b (UltraHD 50/60p 8-bit 4:2:0)
• HDR support: HDR-10, HLG (Hybrid Log Gamma)
• Supports 4:4:4 and 4:2:2 workflows
• 8-lane PCIe 2.0
• 8-ch AES/EBU, 8-ch embedded HDMI, and 16-ch embedded SDI digital audio I/O
• Extend external connectivity incl LTC, Ref and RS-422
with supplied breakout cable.
• macOS, Windows and Linux support
• Compatible with leading creative apps
• Three year warranty
K3G-Box $395
HDMI $895 KONA HDMI
• S upports simultaneous ingest of up to either 2x 4K/UltraHD, or 4x 2K/HD,
at frame rates up to 50/60p
• Simultaneously capture up to four 2K/HD 60p sources
• Four full-size HDMI Inputs
• HDMI 2.0 (port 1 & 2) and HDMI 1.4b (ports 3 & 4) )
• 8-lane PCIe 2.0
• Embedded HDMI audio in, up to 8 per channel (for a total of 32 possible
audio channels)
• Capture stunning HDR from cameras, game consoles, and more
• macOS, Windows and Linux support
• Video4Linux and DirectShow support
• Compatible with leading creative apps
• Three year warranty
www.aja.com | 121 $595
KONA 1
• Supports 2K and HD ingest and output at frame rates up to 50/60p
• 3G-SDI and 1.5G-SDI formats supported
• Compact PCIe 2.0 form factor
• 16-ch embedded SDI digital audio I/O
• RS-422 (for SDK developers there is also an option for low profile PCIe
with internal RS422 header, rather than external connector)
• macOS, Windows and Linux support
• Compatible with leading creative apps
• Three year warranty
LHi $1,495 KONA LHi
• Supports 2K and HD ingest and output at frame rates up to 60p
• Real time up, down, cross-conversion with pristine 10-bit quality
• 3G-SDI and 1.5G-SDI formats supported
• Component Video I/O, RS-422 Control on supplied breakout cable
• HDMI v1.3 (HD 50/60p)
• 2-ch AES/EBU, 8-ch embedded HDMI, and 8-ch embedded SDI digital audio I/O
• 2-ch balanced analog audio I/O
• Extend external connectivity incl LTC, Ref and RS-422
with supplied breakout cable.
• macOS, Windows and Linux support
• Compatible with leading creative apps
• Three year warranty
KLHi-BOX $349
www.aja.com | 13LHe Plus $995
KONA LHe Plus
• Supports HD and SD ingest and output at frame rates up to 30p
• Real time down-conversion
• HD-SDI I/O and Component Video I/O on supplied breakout cable
• 2-ch AES/EBU, 8-ch embedded SDI digital audio I/O on supplied breakout cable
• 2-ch balanced analog audio I/O on supplied breakout cable
• Extend external connectivity incl Ref and RS-42
with supplied breakout cable.
• macOS, Windows and Linux support
• Compatible with leading creative apps
• Three year warranty
KL-BOX-LH $299
Software Compatibility
KONA cards are cross-platform and compatible with a wide range
of professional macOS®, Windows®, and Linux® software applications.
AJA hardware is compatible with a wide range of professional software applications on macOS, Windows, and Linux.
AJA drivers and software create a seamless integration between best of class creative tools and AJA’s high quality
hardware that lets you focus on the work, not the technology.
View our software compatibility chart for the following categories:
Audio | Color | Dailies/Archiving | Editorial | Effects | Graphics/Virtual | Ingest/Playout | Restoration
SDI / IP Bridging | Streaming/Live Production | Test/Measure | VJ / Live Video Performance | Video Assist
View Compatibility Chart
www.aja.com | 14USB 3.0 Powered 3G-SDI and HDMI Capture
$345 U-TAP SDI
• 3G-SDI capture over USB 3.0
• 3G-SDI Input
• SDI Output (Looping)
• Bus powered from host
• HD/SD and scaled (USB) raster support
• 2-channel, Audio Input, 24-bit SDI embedded audio, 48 kHz sample rate
• UVC/UAC capture and wide application compatibility. No third party
driver required.
• macOS, Windows and Linux compatibility
USB 3.0 • Three year warranty
View Compatibility Chart
Size (W x D x H): 104.14 x 60.96 x 25.4 mm
LIVE
$345 U-TAP HDMI
• HDMI capture over USB 3.0
• HDMI Input
• Bus powered from host
• HD/SD and scaled (USB) raster support
• 2-channel, Audio Input, 24-bit SDI embedded audio, 48 kHz sample rate
• UVC/UAC capture and wide application compatibility. No third party
driver required.
• macOS, Windows and Linux compatibility
• Three year warranty
USB 3.0
View Compatibility Chart
LIVE
www.aja.com
Size (W x D x H): 83.82 x 60.96 x 25.4 mm
| 15® ®
Thunderbolt™ Powered SDI and HDMI Output
®
$295 T-TAP
• 3G-SDI and HDMI output over Thunderbolt™
• Supports 2K/HD/SD 10-bit output over SDI and HDMI at frame rates up to HD 60p
• 8-channel, 24-bit SMPTE-259 SDI embedded audio, 48 kHz sample rate,
synchronous
• 8-channel, 24-bit HDMI embedded audio, 48 kHz sample rate, synchronous
HDMI • Connect to Mac and PC with Thunderbolt
• Compact and pocketable at 0.2 lb (0.1 kg)
• No power cable required; 5V Thunderbolt bus powered; 6.5W max
• macOS and Windows support
• Three year warranty
SDI
LIVE
®
Size (W x D x H): 74.93 x 17.78 x 57.92 mm
®
Software Compatibility
T-TAPs are cross-platform and compatible with a wide range
of professional macOS® and Windows® software applications.
AJA hardware is compatible with a wide range of professional software applications on
macOS and Windows.
AJA drivers and software create a seamless integration between best of class creative tools
and AJA’s high quality hardware that lets you focus on the work, not the technology.
View our software compatibility chart for the following categories:
Audio | Color | Dailies/Archiving | Editorial | Effects | Graphics/Virtual | Ingest/Playout
SDI / IP Bridging | Streaming/Live Production | Test/Measure | VJ / Live Video Performance | Video Assist
View Compatibility Chart
www.aja.com | 16HDR Waveform, Histogram HDR Image Analyzer and HDR Image Analyzer 12G
and Vectorscope Monitoring • U ltraHD UI for native-resolution picture display including PQ support for HDR
capable displays.
• Configurable layouts allow you to put the tool you need, in the window you
need it
HDR Image Analyzer fuses AJA’s proven audio and video I/O technology with Colorfront’s • Support for display referred SDR (Rec.709), HDR ST2084/PQ and HLG analysis
powerful Colorfront Engine™. The sleek 1RU device delivers a comprehensive toolset for • Support for scene referred ARRI, Canon, Panasonic, RED and Sony camera
monitoring and analyzing HDR standards including Hybrid Log Gamma (HLG) and Perceptual color spaces
Quantizer (PQ) for up to 8K/UltraHD2 workflows. • Precision CIE graph, vectorscope, waveform, and histogram support
• False color mode to easily spot out of gamut/out of brightness pixels
Available in two models, the HDR Image Analyzer 12G and the HDR Image Analyzer, with a • NIT levels and audio phase metering
choice of 4x 12G-SDI bi-directional I/O or 4x 3G-SDI inputs and 4x 3G-SDI outputs, and Dis- • Line mode to focus a region of interest onto a single horizontal or vertical line
• File base error logging with timecode
playPort output connections with up to UltraHD resolution for the PQ high-resolution GUI.
• Three year warranty
$19,995 Size (W x D x H): 436.88 x 429.26 x 43.18 mm
4x 12G-SDI bidirectional I/O for up to 8K/UltraHD2 or four 4K/UltraHD 60p Inputs
$15,995 Size (W x D x H): 436.88 x 429.26 x 43.18 mm
4x 3G-SDI inputs and outputs for up to 4K/UltraHD 60p Input and Pass-through
www.aja.com | 17Real Time HDR/WCG Transformations,
Multi-Channel Converter and Frame Sync $7,995
Powered by Colorfront Engine™ proprietary video processing algorithms, with real time parametric controls for HDR transforms, color correction and
SDR Preview of HDR transforms for Single Master HDR workflows; FS-HDR also serves as a full, 1-channel up, down, cross-converter for 4K/UltraHD/2K/HD and in 4-channel mode,
offers four simultaneous and independent channels of 2K/HD HDR and SDR transformations. FS-HDR offers ganged operational control of multiple FS-HDRs supporting up to
8K/UltraHD2, Colorfront Engine Film mode Film mode, Dynamic Multi-Channel LUT capabilities, ACES support, the ability to upload custom 3D LUTs, and more.
Rear
Front
Size (W x D x H): 444.5 x 406.4 x 44.45 mm
Dynamic Range/Color Gamut Input Formats HDR Workflows for UltraHD/HD Output Formats
Rec 709 color space Rec 2020 color space
0.9 0.9
Input Formats: • S ingle channel mode for 4K/UltraHD/2K/ From multi-channel HD to true 4K, FS-HDR
HD including down-conversion to HD HDR carries your HDR / SDR video over 3G-SDI,
520 520
• SDR BT.709 100 Nits
0.8 0.8
540 540
y y
0.7
or SDR optional fiber or 12G-SDI to wherever
• PQ BT.2020 1000 Nits
0.7
• Four channel mode for multi-channel 2K/HD it needs to go; from switchers, routers,
560 560
0.6 0.6
500 500
• PQ P3D65 1000 Nits
HDR processing simultaneously monitors, to huge LED displays and more.
580 580
0.5 0.5
• Hybrid Log Gamma BT.2100
• Colorfront Engine Live, Film, and TV Modes You can even convert your source to
0.4 600 0.4 600
• Hybrid Log Gamma BT.709
D65 620 D65 620
0.3 0.3
• BBC HLG LUT support S-Log3, ARRI Log C and even ACEScct for
700 700
490 490
• HLG Extended BT.2100
0.2 0.2
480 480
Dynamic LUT mode for third party software use further along the chain.
• Sony® S-Log3 S-Gamut3
0.1 0.1
integration • SDR BT.709 100 Nits
470 470
460 0.0 460
0.0
0.1 380 0.2
• Sony S-Log3 S-Gamut3 Cine
0.0 0.3 0.4 0.5 0.6 0.7 0.8 0.0 0.1 380 0.2 0.3 0.4 0.5 0.6 0.7 0.8
• User LUT mode for importing 3D .cube LUTs • PQ BT.2020 1000 Nits
x x
Modern cameras are inherently HDR • Sony S-Log3 BT.2020
• ASC CDL support • PQ P3D65 1000 Nits
capable with their wide dynamic ranges • ARRI Log C Wide Gamut
• Auto HDR Signaling over SDI for • Hybrid Log Gamma BT.2100
available from the sensor on, and for • Panasonic® V-Log
SDR/PQ/HLG • Hybrid Log Gamma BT.709
live events and broadcasts, it’s crucial to • RED Log3G10 Wide Gamut
• PQ output control from 48 to 4000 Nits • HLG Extended
translate their Log and Gamut capabilities • Canon Log 2
• Sony SLog3 S-Gamut3
to the accepted standards • Canon Log 3
• Sony SLog3 BT.2020
• ACEScct
• ARRI Log C Wide Gamut
www.aja.com
• ACEScct | 18ULTRA Plus
4K/2K/HD/SD Frame Sync and Conversion
FS HDR
FS4
FS 4 $4,995 QUAD • Four Independent 2K, HD, or SD Video Processors
• One 4K, UltraHD, 2K, HD, or SD Video Processor
3 Down, Cross-ConverterMINI
4-Ch 2K/HD/SD or 1-Ch 4K/UltraHD Frame Sync • Up, down, cross-conversion
FS
• 4x 3G-SDI In and 4x 3G-SDI Out
and Up, • 12G-SDI (HD-BNC) I/O with Optional SFPs
ULTRA Plus
• 12G-SDI Fiber I/O with Optional SFPs
RACK
• Quadrant (Square Division) or 2SI (Two Sample Interleave) 4K/UltraHD
input pixel mapping
FS 2
• 1x 3G-SDI and 1x HDMI Monitor Outputs
FS HDR • 16-channel embedded audio over SDI per port, 8-ch AES In and Out,
64-ch MADI Fiber and 64-ch MADI Coax I/O
• Five year warranty
FS
FS 1
4 KONA IP
QUAD
FS 1-X MINI
KONA IP
FS 3
Size (W x D x H): 444.5 x 406.4 x 44.45 mm
RACK
KONA LHi
FS 2 $3,995 FS2
HELO
2-Ch HD/SD Frame KONA LHe
Sync and Up, Down,Plus
Cross-Converter • 2x 3G-SDI Inputs
FS 1
• 2x Fiber 3G-SDI Inputs (optional)
KONA IP •
•
•
HD component YPbPr, SMPTE-274 (3x BNC) Input
HDMI I/O
2x 3G-SDI Outputs
FS4K1-X
Io KUMO CP • 2x Fiber 3G-SDI Outputs (optional)
KONA IP
• HD component YPbPr, SMPTE-274 (3x BNC) Output
• Up, down, cross-conversion
• 16-channel, 24-bit SMPTE-272/299 SDI embedded audio, 48 kHz sample
Io 4K Plus KUMO CP2
rate, synchronous I/O
KONA LHi
• 16-channel, 24-bit AES/EBU audio, 48 kHz sample rate, synchronous
or nonsynchronous, internal sample rate conversion (8x XLR via 25-pin
breakout cable)
HELO
• Five year warranty
Io Express KUMO 1604Plus
KONA LHe Size (W x D x H): 438.15 x 368.3 x 44.45 mm
www.aja.com | 19FS 1 KONA IP
FS 1-X $3,495
KONA IP FS1-X
HD/SD Frame Sync and Up, Down, Cross-Converter • 2x 3G-SDI Inputs
KONA ULTRA Plus
LHi
• 2x Fiber 3G-SDI Inputs (optional)
with linear Frame Rate Converter •
•
HD component YPbPr, SMPTE-274 (3x BNC) Input
HDMI I/O
FS HDR
HELO
• 2x 3G-SDI Outputs
KONA LHe Plus
• 2x Fiber 3G-SDI Outputs (optional)
• HD component YPbPr, SMPTE-274 (3x BNC) Output
• Composite SD Analog I/O
QUAD
• 64-ch MADI Fiber and 64-Ch MADI Coax I/O
FS 4 • 8 -channel balanced analog I/O, DB-25F 25-pin Power
connector (Tascam pinout)
Io 4K KUMO CP • 16-channel AES/EBU I/O (BNC), DB-25F 25-pin connector
MINI
• Five year warranty
FS 3
Io 4K Plus KUMO CP2
RACK
Size (W x D x H): 482.6 x 406.4 x 44.45 mm
FS 2
Io Express KUMO 1604
FS 1 KONA IP FS1
1616-12G
$2,995
Io1-ChXT KUMO
HD/SD Frame Sync and Up, Down, Cross-Converter
• 2x 3G-SDI Inputs
FS 1-X
• 2x 3G-SDI Outputs
KUMO IP
KONA • HD/SD component YPbPr, SMPTE-274 (3x BNC) I/O
3232-12G •
•
•
Y/C (S-Video) I/O
Composite SD Analog I/O
Up, down, cross-conversion
KONA LHi
• 8 -channel, 24-bit D/A analog audio, 48 kHz sample rate,
KUMO 6464
balanced (8x XLR via 25-pin breakout cable) In
• 8 -channel, 24-bit D/A analog audio, 48 kHz sample rate, balanced
HELO KONA LHe Plus
(8x XLR via 25-pin breakout cable) out
• Five year warranty
Io 4K KUMO CP Size (W x D x H): 438.1mm x 317.5mm x 44.4mm
| 20
Io 4K Plus KUMO CP2
www.aja.comCompact 12G-SDI and 3G-SDI Routers
KUMO compact routers offer flexible video configuration with ease of control with KUMO routers can be configured for ganged dual and quad port routing, allowing users
the CP range of control panels or via the network. Adapt as your needs expand, to group together multiple inputs and outputs for dual-link, 4K/UltraHD, and with 12G-SDI
from 3G-SDI and 12G-SDI and up to 64 inputs and outputs. models, 8K workflows.
KUMO 6464-12G $8,995 Size (W x D x H): 441.96 x 39.12 x 177.8 mm KUMO 6464 $7,995 Size (W x D x H): 441.96 x 39.12 x 177.8 mm
KUMO 3232-12G $3,995 Size (W x D x H): 441.96 x 39.12 x 88.9 mm KUMO 3232 $3,495 Size (W x D x H): 441.96 x 39.12 x 88.9 mm
KUMO 1616-12G $2,495 Size (W x D x H): 441.96 x 39.12 x 44.45 mm KUMO 1616 $1,995 Size (W x D x H): 441.96 x 39.12 x 44.45 mm
KUMO 1604 $1,395 Size (W x D x H): 441.96 x 39.12 x 44.45 mm
KUMO CP2 $895 Size (W x D x H): 441.96 x 33.02 x 88.9 mm
KUMO CP $595 Size (W x D x H): 441.96 x 33.02 x 44.45 mmMini-Converters
The Power to Convert and Deliver
From broadcast, production, to post and live events,
AJA Mini-Converters offer the most complete range of compact,
stand-alone conversion and infrastructure solutions, designed to
the highest standards in reliability and quality. Our converters cover
a full range of 4K, HD, and SD capabilities to meet your needs.
AJA Mini-Matrix: Converter Search Software
www.aja.com/software/mini-matrix
INFRASTRUCTURE INFRASTRUCTURE INFRASTRUCTURE INFRASTRUCTURE
12G-AMA $995 12G-AMA-T $1295 12G-AMA-R $1295 12G-AMA-TR $1395
12G-SDI Analog Audio 12G-SDI Analog Audio 12G-SDI Analog Audio 12G-SDI Analog Audio Embedder/
Embedder/Disembedder Embedder/Disembedder, Embedder/Disembedder, Disembedder with LC Fiber TR SFP
with LC Fiber Tx SFP with LC Fiber Rx SFP
INFRASTRUCTURE INFRASTRUCTURE INFRASTRUCTURE INFRASTRUCTURE
12G-AMA-T-ST $1395 12G-AMA-R-ST $1395 12GDA $495 12GM $895
12G-SDI Analog Audio 12G-SDI Analog Audio 1x6 12G-SDI Reclocking 12G-SDI to/from Quad 3G-SDI,
Embedder/Disembedder, Embedder/Disembedder, Distribution Amplifier Multiplexer
with ST Fiber Tx SFP with ST Fiber Rx SFP
www.aja.com | 22INFRASTRUCTURE INFRASTRUCTURE INFRASTRUCTURE INFRASTRUCTURE
3G-AM $795 3G-AMA $795 3GDA $395 3GM $495
3G-SDI 8-Channel AES 3G-SDI Analog Audio 1x6 3G/HD/SD Reclocking 3G/1.5G HD-SDI Multiplexer
Embedder/Disembedder Embedder/Disembedder Distribution Amplifier
INFRASTRUCTURE INFRASTRUCTURE INFRASTRUCTURE INFRASTRUCTURE
ADA4 $390 C10DA $175 GEN10 $345 HD5DA $195
4-Channel Bidirectional 1x6 Analog Video Distribution Amplifier HD/SD Sync Generator 1x4 HD/SD-SDI
Audio A/D and D/A Converter Distribution Amplifier
INFRASTRUCTURE HDMI HDMI HDMI
FS-Mini $695 Hi5-12G $795 Hi5-12G-R $995 Hi5-12G-TR $1195
3G/HD/SD-SDI Utility Frame Synchronizer 12G-SDI to HDMI 2.0 Mini-Converter 12G-SDI to HDMI 2.0 Mini-Converter, 12G-SDI to HDMI 2.0 Mini-Converter,
with LC Fiber Rx SFP with LC Fiber TR SFP
HDMI HDMI HDMI HDMI
Hi5-12G-R-ST $1095 Hi5-4K-Plus $595 HA5-12G $795 HA5-12G-T $995
12G-SDI to HDMI 2.0 Mini-Converter, 4K/UltraHD (4x 3G-SDI) HDMI 2.0 to 12G-SDI Mini-Converter HDMI 2.0 to 12G-SDI Mini-Converter,
with ST Fiber Rx SFP to full HDMI 2.0 Mini-Converter with LC Fiber Tx SFP
www.aja.com | 23HDMI HDMI HDMI HDMI
HA5-12G-T-ST $1095 HA5-4K $595 Hi5-Plus $395 HA5-Plus $395
HDMI 2.0 to 12G-SDI Mini-Converter, HDMI 2.0 to 4K/UltraHD 3G-SDI to HDMI Mini-Converter HDMI to 3G-SDI Mini-Converter
with ST Fiber Tx SFP (4x 3G-SDI) Mini-Converter with Embedded Audio with Embedded Audio
HDMI HDMI HDMI HDMI
Hi5-3G $595 Hi5-3D $495 Hi5-Fiber $695 HA5-Fiber $695
3G-SDI/Dual Link SDI to HDMI 1.3a Dual HD-SDI Multiplexer to HDMI 1.4a 3G-SDI over Fiber to HDMI HDMI to 3G-SDI over Fiber
Mini-Converter with Embedded Audio Mini-Converter with Embedded Audio Mini-Converter with Embedded Audio Mini-Converter with Embedded Audio
HDMI HDMI
Hi5 $345 HA5 $345
HD/SD-SDI to HDMI Mini-Converter HDMI to HD-SDI Mini-Converter
with Embedded Audio with Embedded Audio
SCAN CONVERT SCAN CONVERT SCAN CONVERT SCAN CONVERT
ROI-DVI $995 ROI-HDMI $995 ROI-DP $995 ROI-SDI $995
DVI to 3G-SDI Scan Converter with HDMI to 3G-SDI Scan Converter with Display Port to 3G-SDI Scan Converter with 3G-SDI to HDMI/3G-SDI Scan Converter with
Region of Interest and Frame Synchronizer Region of Interest and Frame Synchronizer Region of Interest and Frame Synchronizer Region of Interest and Frame Synchronizer
www.aja.com | 24SCALING SCALING SCALING SCALING
UDC $695 4K2HD $795 HD10MD4 $995 HDP3 $695
Up, Down, Cross Mini-Converter HD/SD-SDI to SDI/Analog Down Mini-Converter HD/SD-SDI to SDI/Analog Down Mini-Converter 3G-SDI to DVI-D Mini-Converter
with Embedded Audio with Embedded Audio
IP IP IP IP
IPT-10G2-HDMI $1295 IPT-10G2-SDI $1295 IPR-10G2-HDMI $1295 IPR-10G2-SDI $1295
HDMI Video and Audio to SMPTE ST 2110 IP 3G-SDI Video and Audio to SMPTE ST 2110 IP SMPTE ST 2110 IP Video and Audio to HDMI SMPTE ST 2110 IP Video and Audio to
Converter with Hitless Switching (ST 2022-7) Converter with Hitless Switching (ST 2022-7) Converter with Hitless Switching (ST 2022-7) 3G-SDI Converter with Hitless Switching
IP IP IP IP
IPT-1G-HDMI $995 IPT-1G-SDI $995 IPR-1G-HDMI $795 IPR-1G-SDI $795
HDMI Video and Audio to 3G-SDI Video and Audio to JPEG 2000 IP Video and Audio JPEG 2000 IP Video and Audio
JPEG 2000 IP Converter JPEG 2000 IP Converter to HDMI Converter to 3G-SDI Converter
ANALOG ANALOG ANALOG ANALOG
HD10A-Plus $695 HD10AVA $695 HD10CEA $695 V2Analog $345
HD Analog to HD-SDI Mini-Converter HD/SD Analog Composite or Component HD/SD-SDI to Analog Audio/Video HD/SD-SDI to Analog Audio/Video
Video and 4-Channel Analog Audio to Mini-Converter Mini-Converter
SD/HD-SDI with Embedded Audio
www.aja.com | 25ANALOG LUT-box Control V2Digital $345 LUT-box $695 Mini-Connect $345 Analog Video to HD/SD-SDI Mini- Analog Video to HD/SD-SDI Mini-Converter Control AJA ROI Mini-Converters Converter via Ethernet HDBaseT HDBaseT HDBaseT HDBaseT HB-R-SDI $595 HB-T-SDI $595 HB-R-HDMI $395 HB-T-HDMI $395 HDBaseT to 3G-SDI Mini-Converter 3G-SDI to HDBaseT Mini-Converter HDBaseT to HDMI Mini-Converter HDMI to HDBaseT Mini-Converter HDBaseT HDBaseT RovoRx-SDI $995 RovoRx-HDMI $495 HDBaseT to 6G/3G-SDI and HDMI HDBaseT to HDMI Converter with PoH Converter with POH, Genlock www.aja.com | 26
FiDO – Optical Fiber Converters The Power to Convert and Deliver FiDO Mini-Converters offer unmatched flexibility and cost efficiency for 12G-SDI, 6G-SDI, and 3G-SDI Fiber conversion, allowing for long cable runs up to 10km for single mode FiDOs and up to 700 m (2296 ft) for OM4 and 300 m (984 ft) for OM3 multi-mode fiber optic cables when using Multi-Mode models or SFPs. Choose LC, ST, or SC connectors, depending on the converter model. FiDO converters use compact, low profile, rugged enclosures that work well in tight spaces around and behind equipment racks, displays, in trucks and on camera. AJA Mini-Matrix: Converter Search Software www.aja.com/software/mini-matrix OPTICAL FIBER OPTICAL FIBER OPTICAL FIBER OPTICAL FIBER FiDO-T-12G-ST $895 FiDO-R-12G-ST $895 FiDO-T-12G $785 FiDO-R-12G $785 1-Channel 12G-SDI to Single Mode 1-Channel Single Mode ST Fiber to 1-Channel 12G-SDI to Single Mode 1-Channel Single Mode LC Fiber to ST Fiber Transmitter, with SDI Loop Out 12G-SDI Receiver, with Dual SDI Outputs LC Fiber Transmitter, with SDI Loop Out 12G-SDI Receiver, with Dual SDI Outputs OPTICAL FIBER OPTICAL FIBER OPTICAL FIBER FiDO-2T-12G $1,325 FiDO-2R-12G $1,325 FiDO-TR-12G $1,325 2-Channel 12G-SDI to 2-Channel Single Mode LC Fiber 1-Channel 12G-SDI/LC Single Mode Single Mode LC Fiber Transmitter to 12G-SDI Receiver LC Fiber Transceiver www.aja.com | 27
OPTICAL FIBER OPTICAL FIBER OPTICAL FIBER OPTICAL FIBER
FiDO-T-SC $445 FiDO-R-SC $445 FiDO-T-ST $445 FiDO-R-ST $445
1-Channel 3G-SDI to Single Mode 1-Channel Single Mode SC Fiber to 1-Channel 3G-SDI to Single Mode 1-Channel Single Mode ST Fiber to
SC Fiber Transmitter, with SDI Loop Out 3G-SDI Receiver, with Dual SDI Outputs ST Fiber Transmitter, with SDI Loop Out 3G-SDI Receiver, with Dual SDI Outputs
OPTICAL FIBER OPTICAL FIBER OPTICAL FIBER OPTICAL FIBER
FiDO-T $445 FiDO-R $445 FiDO-2T $645 FiDO-2R $645
1-Channel 3G-SDI to Single Mode 1-Channel Single Mode LC Fiber to 2-Channel 3G-SDI to Single Mode 2-Channel Single Mode Mode LC Fiber
LC Fiber Transmitter, with SDI Loop Out 3G-SDI Receiver, with Dual SDI Outputs LC Fiber Transmitter to 3G-SDI Receiver
OPTICAL FIBER OPTICAL FIBER OPTICAL FIBER OPTICAL FIBER
FiDO-T-MM $690
FiDO-TR $645 FiDO-2T-MM $890 FiDO-2R-MM $890 1-Channel 3G-SDI to Multi-Mode
1-Channel 3G-SDI/LC Single Mode 2-Channel 3G-SDI to Multi-Mode 2-Channel Multi-Mode LC Fiber LC Fiber Transmitter, with SDI Loop Out
LC Fiber Transceiver LC Fiber Transmitter to 3G-SDI Receiver
OPTICAL FIBER OPTICAL FIBER
FiDO-R-MM $690 FiDO-TR-MM $890
1-Channel Multi Mode LC Fiber to 1-Channel 3G-SDI/LC Multi-Mode
3G-SDI Receiver, with Dual SDI LC Fiber Transceiver
Outputs
www.aja.com | 28OPTICAL FIBER OPTICAL FIBER OPTICAL FIBER OPTICAL FIBER FiDO-4T $1,495 FiDO-4R $1,495 FiDO-4T-ST $1,495 FiDO-4R-ST $1,495 4-Channel 3G-SDI to Single Mode 4-Channel Single Mode LC Fiber 4-Channel 3G-SDI Single Mode 4-Channel 3G-SDI Single Mode LC Fiber Transmitter to 3G-SDI Receiver ST Fiber Transmitter ST Fiber to 3G-SDI Receiver OPTICAL FIBER OPTICAL FIBER FiDO-4T-MM $1,985 FiDO-4R-MM $1,985 4-Channel 3G-SDI to Multi-Mode 4-Channel Multi-Mode LC Fiber LC Fiber Transmitter to 3G-SDI Receiver www.aja.com | 29
Mini-Converter Accessories
ACCESSORIES ACCESSORIES ACCESSORIES ACCESSORIES
CMP $99 DRM $590 DRM FCP $100 DRM- P/S ASSY $250
Converter Mounting Plate Mini-Converter Rackmount Frame Faceplate for DRM DRM Spare 50W Power Supply
with 50W Power Supply
ACCESSORIES ACCESSORIES ACCESSORIES ACCESSORIES
RMB $7 AJA Mini-Config DWP-U-R1 $40 PWR-CABLE $65
Rackmount Bracket Free Visual Configuration Universal Power Supply P-TAP to 2x AJA Mini-Converter
and Control Software Power Connectors
ACCESSORIES ACCESSORIES
P-TAP-CBL $45 AJA Mini-Matrix
P-Tap to AJA Mini-Converter Find the Right AJA Converter
Power Cable for Any Situation
www.aja.com | 30openGear Cards and Rackframe For critical broadcast applications, AJA openGear compatible converter cards, with DashBoard support, provide the highest levels of quality and reliability for use in OG frames including the AJA OG-X-FR. OG-X-FR $1449 openGear Compatible Rackframe SCAN CONVERT SCAN CONVERT HDMI HDMI OG-ROI-DVI $995 OG-ROI-HDMI $995 OG-Hi5-4K-Plus $595 OG-HA5-4K $595 openGear DVI to 3G-SDI Scan Converter openGear HDMI to 3G-SDI Scan Converter openGear 4K/UltraHD (4x 3G-SDI) openGear 4K/UltraHD HDMI to 4K/UltraHD with Region of Interest and Frame Synchronizer with Region of Interest and Frame Synchronizer to full HDMI 2.0 Converter (4x 3G-SDI) Converter SCALING SCALING INFRASTRUCTURE INFRASTRUCTURE OG-4K2HD $795 OG-UDC $695 OG-FS-Mini $695 OG-3G-AMD $795 openGear 4K/UltraHD to 3G-SDI openGear HD/SD Up, Down, Cross-Converter openGear 3G/HD/SD-SDI openGear 3G-SDI 8-Channel 24-bit AES and HDMI Down-Converter and Frame Synchronizer Utility Frame Synchronizer Embedder/Disembedder www.aja.com | 31
INFRASTRUCTURE INFRASTRUCTURE INFRASTRUCTURE INFRASTRUCTURE
OG-12GDA-2x4 $695 OG-3GDA-1x9 $495 OG-3GDA-2x4 $550 OG-3G-AMA $795
openGear Dual 2x4 12G-SDI Reclocking DA openGear 1x9 3G-SDI Reclocking DA openGear 1x8 or Dual 2x4 3G-SDI openGear 3G-SDI Analog Audio
Reclocking DA Embed/Disembed
OPTICAL FIBER OPTICAL FIBER OPTICAL FIBER OPTICAL FIBER
OG-FiDO-T $445 OG-FiDO-R $445 OG-FiDO-TR $645 OG-FiDO-2T $645
openGear 1-Channel 3G-SDI to Single Mode LC openGear 1-Channel Single Mode openGear 1-Channel 3G-SDI/LC openGear 2-Channel 3G-SDI to
Fiber Transmitter, with SDI Loop Out LC Fiber to 3G-SDI Receiver Single Mode LC Fiber Transceiver* Single Mode LC Fiber Transmitter
OPTICAL FIBER OPTICAL FIBER OPTICAL FIBER OPTICAL FIBER
FPO
OG-FiDO-2R $645 OG-FiDO-T-MM $690 OG-FiDO-R-MM $690 OG-FiDO-TR-MM $890
openGear 2-Channel 3G-SDI to openGear 1-Channel 3G-SDI to openGear 1-Channel Multi-Mode openGear 1-Channel 3G-SDI/LC
Single Mode LC Fiber Receiver Multi-Mode 3G-SDI Transmitter LC Fiber to 3G-SDI Receiver Multi-Mode LC Fiber Transceiver
OPTICAL FIBER OPTICAL FIBER
OG-FiDO-2T-MM $890 OG-FiDO-2R-MM $890
openGear 2-Channel 3G-SDI to openGear 2-Channel Multi-Mode
Multi-Mode LC Fiber Transmitter LC Fiber to 3G-SDI Receiver
| 32SFP | Options
SFP Options Start at $195
AJA provides a range of products and optional SFP modules to allow you to make the most of your fiber infrastructure. You have the flexibility in many cases to order your
AJA model variant with an SFP already installed at time of purchase, and in other cases you may wish to order additional optional SFPs alongside your initial purchase or post purchase.
AJA SFP Configurator Single-Mode LC SFP Modules 12G SFP Modules
The AJA SFP configurator is the fastest way to ensure Single and Dual Channel LC Fiber Single and Dual Channel 12G LC, ST, HD-BNC
that you accurately select the most appropriate SFP for Transmitters and Receivers Fiber Transmitters, Receivers and Trancievers
your workflow needs for the appropriate AJA product
you wish to integrate into your facility infrastructure. Model Price Description Model Price Description
1-Channel 3G-SDI Single 1-Channel 12G-SDI Single
FIBERLC-1-TX $195 FIBERLC-1TX-12G $295
AJA SFP Configurator Mode LC Fiber Transmitter Mode LC Fiber Transmitter
1-Channel 3G-SDI Single 1-Channel 12G-SDI Single
FIBERLC-1-RX $195 FIBERLC-1RX-12G $295
Mode LC Fiber Receiver Mode LC Fiber Receiver
2-Channel 3G-SDI Single 1-Channel 12G-SDI Single
FIBERLC-2-TX $295 FIBERLC-TR-12G $445
Mode LC Fiber Transmitter Mode LC Fiber Transceiver
2-Channel 3G-SDI Single 2-Channel 12G-SDI Single
FIBERLC-2-RX $295 FIBERLC-2TX-12G $445
Mode LC Fiber Receiver Mode LC Fiber Transmitter
2-Channel 12G-SDI Single
FIBERLC-2RX-12G $445
Mode LC Fiber Receiver
1-Channel 12G-SDI Single
Single-Mode SC SFP Modules Multi-Mode LC SFP Modules FIBERST-1TX-12G $395
Mode ST Fiber Transmitter
Single Channel SC Fiber Single and Dual Channel LC Fiber FIBERST-1RX-12G $395
1-Channel 12G-SDI Single
Mode ST Fiber Receiver
Transmitters and Receivers Transmitters and Receivers
2-Channel 12G HD-BNC
Model Price Description HDBNC-2TX-12G $445
Model Price Description Coax Transmitter
1-Channel 3G-SDI Single 1-Channel 3G-SDI Multi- 2-Channel 12G HD-BNC
FIBERSC-1-TX $195 FIBERLC-1TX-MM $295 HDBNC-2RX-12G $445
Mode SC Fiber Transmitter Mode LC Fiber Transmitter Coax Receiver
1-Channel 3G-SDI Single 1-Channel 3G-SDI Multi-
FIBERSC-1-RX $195 FIBERLC-1RX-MM $295
Mode SC Fiber Receiver Mode LC Fiber Receiver
2-Channel 3G-SDI Multi-
FIBERLC-2TX-MM $345
Mode LC Fiber Transmitter
2-Channel 3G-SDI Multi-
FIBERLC-2RX-MM $345
Mode LC Fiber Receiver
www.aja.com | 33CORVID
PCIe I/O Solutions for
Development Partners
The Corvid lineup offers OEM Developer partners a wealth
of options when used with AJA’s powerful SDK on Windows,
macOS, and Linux.
AJA’s KONA, Io and T-TAP products are also compatible
with the SDK, opening even more I/O choices.
Learn More: www.aja.com/category/developer
Apply today: www.aja.com/developer/request
Corvid 88 $2,795 Corvid 44 12G $2,995 Corvid 44 12G BNC $2,895 Corvid 44 $1,895
8-lane PCIe 2.0 card for 8/10-bit YCbCr or 8-lane PCIe 3.0 for 8/10-bit YCbCr or 12-bit 8-lane PCIe 3.0 for 8/10-bit YCbCr or 12-bit 8-lane PCIe 2.0 for 8/10-bit YCbCr or 12-bit
12-bit RGB with simultaneous 4K in and out RGB with 8K in or out or 4K independent RGB with 8K in or out or 4K independent mixed RGB with four independent mixed channel I/O
or eight independent mixed channel I/O. mixed channel 12G-SDI I/O. HD-BNCs. channel 12G-SDI I/O. Full-sized BNCs. or single 4K I/O.
Low Profile and Fanless versions available. Low Profile and Fanless versions available. Fanless version available. Low Profile and Fanless versions available.
Corvid 44 BNC $1,895 Corvid 22 $1,395 Corvid 24 $1,895 Corvid HEVC $4,995
8-lane PCIe 2.0 for 8/10-bit YCbCr or 12-bit RGB 4-lane PCIe 2.0 for 8/10-bit uncompressed 4-lane PCIe 2.0 8/10-bit for four 3G-SDI 4K or multi-channel HD, 8-lane PCIe 2.0
with four independent mixed channel I/O or single with two channels I/O digital 3G-SDI I/O. channels of digital I/O, bypass relays for HEVC encoding card supporting up to
4K I/O. Full-sized BNCs continuation of SDI input signal to SDI output 4K 60p video input as well as file to file
Fanless version available. in event of signal failure. encoding. Slot and ATX6 powered
versions available.
www.aja.com | 34HDBaseT Camera System
$2,495 RovoCam Features
Integrated UltraHD/HD Camera with HDBaseT • ltraHD up to 29.97p or high frame rate HD support up to 60p
U
• Sony back illuminated 1/2.3 type 8.9 megapixel CMOS sensor
• Video, audio, control, and power over standard Cat 5e/6 cable
• Three year warranty
RovoControl Software Features
• Control and configure software for Rovocam
• When RovoCam is in UltraHD Mode, RovoControl’s unique ePTZ feature
allows the user to select a 1080p HD ROI (Region of Interest) frame from
the UltraHD raster for 1080p 50 or 1080p 59.94 output with full Pan,
Tilt and Zoom capabilities.
• Exposure control for simple camera control in the GUI
• Preset command and control with global, camera and ePTZ
• Import/Export of settings for sharing setups and configurations
• High DPI UI mode for GUI on high rez displays
• Crosshair selector for refined Spot AE and Spot Focus control
• Zoom control
Size (W x D x H): 71.12 x 149.86 x 91.44 mm
RovoRx SDI $995 RovoRx HDMI $495
UltraHD/HD HDBaseT Receiver to 6G/3G-SDI UltraHD/HD HDBaseT Receiver to HDMI with PoH
and HDMI Frame Sync w/ PoH, Genlock
RovoRx-SDI Features RovoRx-SDI Features
• 4x 6G/3G-SDI UltraHD/HD HDMI outputs • 1x UltraHD/HD HDMI output
• 1x UltraHD/HD HDMI output • 1x RCA stereo audio output
• DA Mode for distribution needs of HDBaseT sources • 1x USB for firmware upgrades
• 1x RCA stereo audio output • 1x RS-232 for RovoCam control
• 1x USB for firmware upgrades • 1x HDBaseT connector (RJ-45)
• 1x RS-232 for RovoCam control • Five year warranty
• 1x HDBaseT connector (RJ-45)
• Five year warranty
www.aja.com | 35About AJA Video Systems, Inc Since 1993, AJA Video has been a leading manufacturer of video interface and conversion solutions, bringing high quality, cost effective digital video products to the professional, broadcast and postproduction markets. AJA products are designed and manufactured at our facilities in Grass Valley, California, and sold through an extensive sales channel of resellers and systems integrators around the world. For further information, please see our website at www.aja.com. 07132020 verB AJA Video Systems, Inc. Grass Valley, California www.aja.com • sales@aja.com • support@aja.com www.aja.com
You can also read
