Technology Roadmap Smart Grids 2050
Foreword
Current trends in energy supply and use                                  This roadmap focuses on smart grids – the
are patently unsustainable – economically,                               infrastructure that enables the delivery of power
environmentally and socially. Without decisive                           from generation sources to end-uses to be
action, increased fossil fuel demand will heighten                       monitored and managed in real time. Smart grids
concerns over the security of supplies and energy-                       are required to enable the use of a range of low-
related emissions of carbon dioxide (CO2) will more                      carbon technologies, such as variable renewable
than double by 2050. We can and must change                              resources and electric vehicles, and to address
our current path, but this will take an energy                           current concerns with the electricity system
revolution and low-carbon energy technologies                            infrastructure, such as meeting peak demand with
will have a crucial role to play. Energy efficiency,                     an ageing infrastructure. Unlike most other low-
many types of renewable energy, carbon                                   carbon energy technologies, smart grids must
capture and storage, nuclear power and new                               be deployed in both existing systems (which in
transport technologies will all require widespread                       some cases are over 40 years old) as well as within
deployment if we are to reach our greenhouse-gas                         totally new systems. Smart grid technologies
emission goals. Every major country and sector                           must also be installed with minimum disruption
of the economy must be involved. The task is also                        to the daily operation of the electricity system.
urgent if we are to make sure that investment                            These challenges do not detract, however, from
decisions taken now do not saddle us with                                the opportunity to gain significant benefits from
sub‑optimal technologies in the long term.                               developing and deploying smart grids.

There is a growing awareness of the urgent need                          Nevertheless, significant barriers must be
to turn political statements and analytical work                         overcome in order to deploy smart grids at the
into concrete action. To spark this movement, at                         scale they are needed. Governments need to
the request of the G8, the International Energy                          establish clear and consistent policies, regulations
Agency (IEA) is developing a series of roadmaps                          and plans for electricity systems that will allow
for some of the most important technologies.                             innovative investment in smart grids. It will also be
These roadmaps provide solid analytical footing                          vital to gain greater public engagement, and this
that enables the international community to move                         will be helped educating all relevant stakeholders
forward on specific technologies. Each roadmap                           – but especially customers and consumer
develops a growth path for a particular technology                       advocates – about the need for smart grids and
from today to 2050, and identifies technology,                           the benefits they offer. Achieving the vision of
financing, policy and public engagement                                  smartening the grid between now and 2050
milestones that need to be achieved to realise the                       requires governments, research organisations,
technology’s full potential. Roadmaps also include                       industry, the financial sector and international
a special focus on technology development and                            organisations to work together. This roadmap
diffusion to emerging economies. International                           sets out specific steps they need to take over the
collaboration will be critical to achieve these goals.                   coming years to achieve milestones that will allow
                                                                         smart grids to deliver a clean energy future.
To date, much of the of low-carbon technology
analysis in the energy sector has focused on                                                                           Nobuo Tanaka
power generation and end-use technologies.                                                                      Executive Director, IEA

ERRATA
Figure 4, page 11: the values for Africa and Central South America in 2050 have been corrected to 25% and 18% respectively.
Page 20: the following paragraph was inserted under the heading “Smart grid demonstration and deployment efforts” following the
second paragraph and preceding the third paragraph:
The Telegestore project, launched in 2001 by ENEL Distribuzione S.p.A. (i.e. prior to the current smart grids stimulus funding) addresses
many of these issues. The project installed 33 million smart meters (including system hardware and software architecture) and automated
100 000 distribution substations, while also improving management of the operating workforce and optimising asset management policies
and network investments. The project has resulted in fewer service interruptions, and its EUR 2.1 billion investment has led to actual cost
savings of more than EUR 500 million per year. Today an active small and medium scale industry is developing technologies for smart grids
and ENEL is continually enhancing the system by introducing new features, technologies and flexibility. The project clearly demonstrates the
value of a large-scale, integrated deployment of smart grid technologies to solve existing problems and plan for future needs.
Page 21: A row has been added to Table 5 (Italy).

 This roadmap was prepared in April 2011. It was drafted by the International Energy Agency’s Energy Technology Policy Division.
 This paper reflects the views of the International Energy Agency (IEA) Secretariat, but does not necessarily reflect those of IEA
 member countries. For further information, please contact the author at: david.elzinga@iea.org.
