THE WORLD OF LAPP
Innovations 2013
Welcome
To contact your local Lapp Group
representative please visit
www.lappgroup.com/worldwide
This catalogue is valid
as from April 2013.
Image source title: iStockphoto, Fotolia
Content
Informations about the company 2
ÖLFLEX® Power- and control cables 8
UNITRONIC® Data communication systems 14
ETHERLINE® Data communication systems
for ETHERNET-Technology 22
HITRONIC® Optical transmission systems 29
EPIC® Industrial connectors 42
SKINTOP® Cable glands 47
SILVYN® Protective cable conduit-
and cable carrier systems 52
FLEXIMARK® Marking systems 58
Cable Accessories 62
1
Brand quality from Stuttgart
ÖLFLEX® EPIC®
Power- and control cables Industrial connectors
The world’s first brand cable is available in The brand for strong and reliable connec-
the most varied of versions to match maxi- tions.
mum requirements. Key features: Robust square and circular
Key features: Oil-resistant, flexible and connectors. Flexible system consisting of
available to match almost any requirement housings, inserts, contacts and accessories
or environmental condition – also free of – for every requirement, the tailor-made
halogens. solution. Similarly, EPIC® SOLAR plugs for
Fields of application: Multipurpose. Spe- photovoltaics are also part of the extensive
cial variants are more and more in demand product range.
in the area of renewable energies. Fields of application: Mechanical and
systems engineering, drive technology,
Automation.
UNITRONIC® SKINTOP®
Data communication systems Cable glands
The ideal brand for fast, trend-setting and The brand for multipurpose cable entries in
reliable data transfer. line with the following: quickly fastened,
Key features: UNITRONIC® are not only centred and hermetically sealed.
data lines, but also bus lines, which together Key features: Large clamping areas,
with active sensor/actuator modules or optimum strain reliefs, the most diverse of
gateways provide a perfect system for auto- versions such as SKINTOP® CLICK, COLD or
mation. CUBE.
Fields of application: Measurement, con- Fields of application: Everywhere, where
trol, regulation, bus or LAN networks. cables must be fastened reliably and quickly.
ETHERLINE® SILVYN®
Data communication systems Protective cable conduit-
for ETHERNET-Technology and cable carrier systems
The brands for network solutions, safety The brand for all-round cable protection.
systems and firewalls in the industrial net- Key features: The product range includes
working sector. SILVYN® cable protection hoses for perfect
Key features: System solutions consisting protection against mechanical and chemical
hardware, software, consulting, network loads, along with SILVYN® CHAIN energy
design and support. supply chains for highly-dynamic appli-
Fields of application: Factory automation, cations.
Renewable Energy, Building technology, Fields of application: Everywhere that
Structured cabling. cables have to be additionally protected or
routed.
HITRONIC® FLEXIMARK®
Optical transmission systems Marking systems
The brand for split-second, fault-free, inter- The brand for permanent, clearly-arranged
cept-free data transport. cable markings.
Key features: The HITRONIC® product ran- Key features: Comprehensive range – from
ge includes fibre optic cables in the most manual labelling solutions onto digital
varied of versions, along with suitable identification. Withstands high chemical,
accessories such as splice boxes, wall thermal and mechanical loads.
distributors or couplings. Fields of application: All cable, single
Fields of application: Office and industrial cores, control cabinets.
sector, Renewable Energy.
2
eCAD Solutions
In the mechanical and plant engineering Current product data are available in the download centre
sectors, up-to-date, complete and correct on our homepage:
data have become an important part of the
electrics design with the aim of optimising
the engineering process.
As one of the leading providers of cable,
connections and cable accessories, Lapp
offers you the possibility of accessing con-
stantly updated product data in 10 langu-
ages:
EPLAN Electric P8 Aucotec EB
• Chinese • Russian www.lappgroup.com/eplan www.lappgroup.com/aucotec
• Polish • French www.eplan.de www.aucotec.com
• German • Spanish
• Portuguese • Italian
• English • Czech We look forward to your feedback via: info@lappkabel.de (Subject: eCAD solutions)
