ZCS GREEN INNOVATION NEW SOLUTIONS FOR A NEW PERSPECTIVE.
CONTENTS
ZCS, CONNECTED TO THE FUTURE. PAG.2
MISSION & VISION 2
CORPORATE CULTURE & VALUES 2
FUTURE & GROWING DEVELOPMENT 3
GREEN INNOVATION DIVISION: 3
INNOVATION IN THE ENERGY WORLD
ZCS AZZURRO: THE SOLUTION FOR A GREEN WORLD. 4
PHOTOVOLTAIC INVERTERS 4
PHOTOVOLTAIC INVERTERS FOR ENERGY STORAGE 5
NEW SMART HOME AUTOMATION 6
ENERGY SOLAR PRODUCTION AND STORAGE 6
DISCOVER THE ZCS AZZURRO PRODUCT RANGE. 7
AZZURRO - SINGLE PHASE STRING INVERTER 8
AZZURRO - THREE PHASE STRING INVERTER 14
AZZURRO - INVERTERS FOR ENERGY STORAGE 26
Azzurro Customer Service. 29
ZCS, CONNECTED
TO THE FUTURE.
Founded in 1985 as a software application Combining creativity and technological
production company, the innovative imprinting innovation.
of its Chairman Fabrizio Bernini soon led it to
become a leader on the international markets CORPORATE CULTURE & VALUES
of robotics and automation. In 2000 it joined Innovation as culture The courage to conceive
Zucchetti SpA, the first Italian software group and realise an inexistent product, which could
in Europe. represent a solution to assist and simplify the
It is divided into five Business Units (Software, everyday activities of the customer. Ideas and
Automation, Healthcare, Robotics, Green projects are developed autonomously with
Innovation) conceived to meet the needs to the participation of all corporate divisions,
diversify and extend the know-how gained in
the management software design sector into
other complementary environments, with the
objective of guaranteeing the excellence of its
service at a much larger scale.
Today, the company distinguishes itself on the GROUP
markets in which it operates for its innovative, It is part of the Zucchetti group,
high-performing and competitive solutions which has over 3.500 employees and
that integrate state-of-the-art technologies. a turnover of 440 million (2017)
Mission & Vision ZCS INNOVATION SPECIALISTS
To conceive and realise innovative and More than 110 patents
performing solutions aimed at transversal (related to 50 inventions) 15 innovation awards*
*Its most prestigious award: the Innovation Award by the Presidency of the Council
markets searching for excellence, high of Ministers received in 2010 “for innovation of its products” and in 2014 for
“the approach and commitment of Management towards innovation and social
technology and a strong competitive advantage. accountability
2
in the “Ideas Laboratory”, the Research & FUTURE AND GROWING DEVELOPMENT
Development area opened in 2005 that is A 4.0 enterprise: innovative, future-
the fundamental driving force behind ZCS orientated, awareness of its origins and
and manned by exceptionally highly qualified territory, that continues to grow focusing
personnel: over 30 technicians, IT, electronic on technology, environmental sustainability
and mechanical experts and designers. The and energy savings.
human capital is the winning force of ZCS
driven by the sharing of corporate values:
creativity, enthusiasm, passion, occupational
responsibility, ethics and respect.
GREEN INNOVATION DIVISION:
INNOVATION
IN THE ENERGY WORLD
Given its long-standing focus on aspects related to the environment and energy savings, a
Business Unit was founded in 2016 dedicated to renewable energies and the most innovative
solutions conceived from the integration of ideas and technologies to improve the quality
of life, operational efficiency and energy savings for individuals and enterprises. The Green
Innovation Division presented itself to the main market players with ZCS Azzurro, gaining
instant international market recognition: the latest generation inverter that combines ZCS
bespoke “IT” and “smart” intelligence with advanced electronic technology to create a
new concept of photovoltaic inverter. This was quickly joined by accumulation systems,
solutions destined to the new domotic and energy saving sectors.
3
ZCS AZZURRO:
THE SMART SOLUTION
FOR A GREEN WORLD.
Industries
commercial and industrial applications. There
PHOTOVOLTAIC INVERTERS are over 50 models available, ranging from
Single-phase, Three-phase 1 to 6 Kw single-phase and from 10 to 70 Kw
and Storage three-phase, in addition to various different
equipment options, in terms of accessories
In the Internet of Things era, ZCS’ objective
available. The range is completed by the ZCS
is to offer a technically advanced, reliable
Azzurro modular solution for Storage of up to
and performing product, with the added
10 Kwh, dedicated to both newly built systems
plus of rendering the photovoltaic system
and retrofit services. The construction
part of a Smart Home, capable of improving
materials and IP65 protection rating make ZCS
the lifestyles, operational efficiency and
Azzurro a robust and superior quality product
the energy savings of those who choose
boasting a 10 year warranty. The extremely
ZCS technology.
simple installation and configuration steps,
ZCS Azzurro is the latest generation
combined with the efficiency of the user
inverter that combines inside ZCS
support team are conceived to improve the
bespoke “IT” and “smart” intelligence with
quality of life of our customers.
advanced electronic technology to create
a new concept of photovoltaic inverter.
ZCS Azzurro is synonymous of maximising RELIABILITY
efficiency and optimal yield, but also and Superior quality components,
above all improved connectivity. extended useful life
USER FRIENDLY
FOR EVERY SIZE Thanks to the multi-function graphic display
The vast range of ZCS Azzurro solutions
meets all energy demands for residential, SIMPLE
Quick and easy assembly and installation
4
Commercial Residential
SMART & INNOVATIVE generation steel-phosphate batteries (with
With ZCS Azzurro, in addition to verifying NMC lithium ion versions soon available),
the energy produced in a day, it is possible to tested and fully compatible with the functions
use a mobile network or Internet connection of the ZCS Azzurro inverters.
to autonomously decide when and which
domestic appliances to activate or deactivate.
ZCS’ wide range is completed by latest
PHOTOVOLTAIC INVERTERS
FOR ENERGY STORAGE
ZCS Azzurro Storage maximises autonomy and, thanks to its extreme flexibility, it is
suited for both new and retrofit installations: ideal for homes, residences and small
trade businesses. Quick and easy installation and automatic configuration. With a 3 Kw
nominal output and up to 10 Kwh storage capacity, it can operate in stand-alone mode
guaranteeing continuous energy supplies during a black-out.
IDEAL FOR RETROFIT OPTIONS EXCELLENT YIELD
NO CHANGES TO THE
EASY TO INSTALL
EXISTING SYSTEM REQUIRED
5
directly from your smart device, making your
NEW SMART day-to-day life easier and more functional.
HOME AUTOMATION
ZCSwitch is the innovative solution which ENERGY SOLAR PRODUCTION
uses an APP to remotely control all domestic AND STORAGE
utilities, without the need to make any
changes to the existing electrical system, ZCS Active Panel is the autonomous system
making it ideal for homes, companies, offices, used for the storage and production of solar
shops and showrooms. energy that allows users to disconnect their
The system consists of an App and one or electricity network supply and produce
more ZCSwitches, each of which can be energy even in remote areas. Connected to
added to or replace a push-button, a deviator an inverter, it is capable of supplying 220
or manual switch already used in the home. Vac energy and replace the current motor
In one touch ZCSwitch provides integrated generators. The output can also be expanded.
management of lighting options, opening of ZCS Active Panel is ideal for those searching
windows and doors, heating, air conditioning for an autonomous power supply, for all
and all other types of automation and utilities, electric power requirements in isolated or
temporarily unreachable zones, in agriculture,
on building sites, on commercial fishing boats
with net winding systems.
EFFICIENT
Optimised use and consumption of
utilities thanks to the continuous
monitoring option
MODULAR
The number of devices managed can
be adapted over time to suit individual ADAPTABLE
requirements To suit the demands of individual users
SECURE EFFICIENT
Monitoring from wherever you are, at The lithium-ion battery storage provides
any time of the day high system efficiency and guarantees
energy supplies even in periods with
SIMPLE insufficient sun hours
Management via the dedicated APP
PRACTICAL
Recharging via electric network power
and solar energy
6
DISCOVER
THE ZCS AZZURRO
PRODUCTS RANGE.
7
AZZURRO - SINGLE-PHASE
STRING INVERTERS
1100TL/1600TL/2200TL
2700TL/3000TL
Azzurro ZCS technology
Performance optimisation
WiFi integration on the ZCS platform
for stable, effective and intelligent
The TL series single-phase ZCS Azzurro connectivity
inverters are the ideal solution for small
residential type PV systems. Maximum Energy
They are available in versions from 1 to 3 Kw Efficiency
Maximum performance 97.2%
and are small, easy to manage and simple Stable efficiency in all working
to install. Their wide input range makes conditions
them easy to congure and are suitable for Rapid and accurate MPPT algorithm
all requirements on both new and retrot
A Flexible,
installations on existing systems. Economic and Easy
The multi-function graphic display provides Installation solution
instant viewing of all data and the WiFi IP65 Protection rating
connection provides zero cost remote Rapid and secure installation with all
monitoring. required parts included
“Plug & Play” AC and DC side
connections
Wireless communication with
integrated Web Server
4” LCD display
Standard or fast Enel Autotest versions
Updates and diagnostics
through SD Card
Reliability, Sturdiness
and Flexibility
External enclosure in rust-proof,
corrosion-proof and UV-ray proof
aluminium
Natural ventilation cooling
Fast and flexible management of
operating parameters
Simple and user-friendly monitoring
10 year ZCS warranty
Intelligent Grid
Management
Dynamic management of delivery
to the grid
“Zero Delivery”* grid function
Remote control over
deliverable active/reactive output limit
Ideal For Retrofit
Options
Wide operating input range
from 90V to 550V
Compact size
Simple and user-friendly installation
and configuration
*Possible through current sensor (ZST-ACC-TA)
8FLOW CHART
EFFICIENCY CURVE
9DATI TECNICI 1100TL 1600TL 2200TL 2700TL 3000TL
Input (DC)
Rated input DC power 1200W 1800W 2400W 2900W 3300W
MPPT number/String for MPPT 1/1
Maximum Input Voltage 450V 500V
Input Voltage at Startup 100V 120V
Rated Input Voltage 360V
MPPT Rated Voltage 80-450V 100-500V
Rated DC voltage at full load 110-450V 165-450V 170-500V 200-500V
Max Input Current 10A 13A 13.5A 15A
Output (AC)
Rated AC Power 1000VA 1550VA 2100VA 2600VA 3000VA
Maximum AC Power 1000VA 1550VA 2100VA 2600VA 3000VA
Maximum AC Current 4.5A 7A 9.5A 11.5A 13A
Rated Mains Voltage L/N/PE 220,230,240V
Mains Voltage Range 180~270V (According to the local network standard)
Rated Mains Frequency 50/60Hz
Output Frequency Range 45~53 / 57~63 Hz (According to the local network standard)
Total current harmonic distortion 99.5%
Standard
EMC EN 61000-6-1,EN 61000-6-2,EN 61000 6-3, EN 61000-6-4
Safety Certificates CE,IEC 62109-1,IEC 62109-2, IEC 62116, IEC 61727, IEC 60068(1,2,14,30)
Mains Certificates AS 4777,VDE V 0124-100, VDE V 0126-1-1, VDE-AR-N 4105, ENS0438, G83/2, CEI 0-21, C10/11, RD1699
Protection
Anti-Islanding Protection Yes
Reverse Polarity Protection Yes
Overheating Protection Yes
Current Dispersion Protection Yes
Overload protection Yes
Surge Protection Yes
Grounding Faults Protection Yes
Communication
Standard Communication Mode wifi (optional) + RS485 + SD card (optional)
Data storage 25 years
Interface Yes
I/O Yes
General Information
DC Switch Opzionale
Ambient temperatures -25°C...+60°C
Insulation level Transformerless
Cooling system Natural convection
Relative humidity 0…95% Without Condensation
Maximum operating altitude 2000m
Noise levelAzzurro - SINGLE-PHASE
STRING INVERTERS
3000TLM/3680TLM/4000TLM
4600TLM/5000TLM/6000TLM
Azzurro ZCS technology
Performance optimisation
WiFi integration on the ZCS platform
for stable, effective and intelligent
connectivity
The TLM series single-phase ZCS Azzurro Maximum Energy
inverters are the ideal solution for residential Efficiency
or commercial type PV systems. They are Maximum performance 97.6%
available in versions from 3 to 6 Kw and are Stable efficiency
in all working conditions
small, easy to manage, simple to install and all Rapid and accurate MPPT algorithm
equipped with double MPPT channel. Dual input section with
independent MPPT
Their wide input range makes them easy to
A Flexible,
configure and are suitable for all requirements Economic and Easy
on both new and retrofit installations on Installation solution
existing systems. IP65 Protection rating
“Plug & Play” AC and DC
The multi-function graphic display provides side connections
Wireless communication with
instant viewing of all data and the WiFi integrated Web Server
connection provides zero cost remote 4” LCD display
monitoring. Standard or fast
Enel Autotest versions
Updates and diagnostics
through SD Card
Reliability, Sturdiness
and Flexibility
External enclosure
in rust-proof, corrosion-proof
and UV-ray proof aluminium
Natural ventilation cooling
Fast and flexible management
of operating parameters
Simple and user-friendly monitoring
10 year ZCS warranty
Intelligent Grid
Management
Dynamic management
of delivery to the gride
“Zero Delivery” grid function*
Remote control over deliverable
active/reactive output limit
Ideal For Retrofit
Options
Wide operating input range
from 100V to 550V
Compact size
Simple and user-friendly
installation and configuration
Dual MPPT channel
*Possible through current sensor (ZST-ACC-TA)
11FLOW CHART
EFFICIENCY CURVE
12DATI TECNICI 3000TLM 3680TLM 4000TLM 4600TLM 5000TLM 6000TLM Input (DC) Rated input DC power 3300W 4000W 4400W 5000W 5500W 6600W Maximum DC power for each MPPT 2000(200V-500V) 2400(200V-500V) 2600(200V-500V) 3000(200V-500V) 3150(250V-520V) Number of independent MPPTs 2 Number of DC Inputs 1 for each MPPT Maximum Input Voltage 600V Activation voltage 100V 120V Rated Input Voltage 360V MPPT DC Voltage range 80V-580V 100V-580V DC voltage range at full load 160V-520V 165V-520V 175V-520V 250V-520V Max Input current per MPPT 10A/10A 12A/12A 13A/13A 15A/15A Short Circuit Current for each MPPT 12A 14A 16A 18A Output (AC) Nominal AC power (@ 230V, 50Hz) 3000VA 3680VA 4000VA 4600VA 5000VA 6000VA Maximum AC Power 3000VA 3680VA 4000VA 4600VA 5000VA 6000VA AC Rated Voltage L/N/PE, 220,230,240V Rated AC Voltage Range 180V-270V (According to the local network standard) Mains frequency 47~53 / 57~63 Hz (According to the local network standard) Active Power Adjustment Range 0~100% Maximum AC Current 13A 16A 17.5A 20A 22A 26A Total current harmonic distortion
Azzurro - THREE-PHASE
STRING INVERTERS
4.4KTL/5.5KTL/6.6KTL
8.8KTL/11KTL/12KTL
Azzurro ZCS technology
Performance optimisation
WiFi integration on the ZCS platform
for stable, effective and intelligent
connectivity
The compact three-phase ZCS Azzurro Maximum Energy
inverters are the ideal solution for small Efficiency
Maximum performance 98.3%
to medium size PV systems for residential, Stable efficiency
commercial and small industrial applications. in all working conditions
Rapid and accurate MPPT algorithm
Dual input section with
The Italian technology developed by ZCS independent MPPT
makes the Azzurro series efficient, versatile
and high-performing. A Flexible,
Economic and Easy
Their wide input range makes them easy to Installation solution
IP65 Protection rating
configure and suitable for all requirements on Integrated string combiner
both new and retrofit installations on existing with different configuration options
systems. Power Management Unit
4” LCD display
Updates and diagnostics
through SD Card
Reliability, Sturdiness
and Flexibility
External enclosure
in rust-proof, corrosion-proof
and UV-ray proof aluminium
Natural ventilation cooling
Flexible and user-friendly
management of operating parameters
Optional class II power surge
protection devices (AC and DC)
Topology without transformer
10 year ZCS warranty
Intelligent Grid
Management
Dynamic management
of delivery to the grid
“Zero Delivery” grid function*
Reactive output management feature
Remote control over deliverable
active/reactive output limit
Ideal For Retrofit Options
Wide operating input range
from 160V to 960V also suitable
for small size string systems
Compact size
Simple and user-friendly
installation and configuration
Dual MPPT channel
*Possible through current sensor (ZST-ACC-TA)
and anti-reverse power controller (ZSM-OINJ)
14FLOW CHART
EFFICIENCY CURVE
15DATI TECNICI 4.4KTL-X 5.5KTL-X 6.6KTL-X 8.8KTL-X 11KTL-X 12KTL-X
Input (DC)
Maximum input power 4800W 6000W 7200W 9600W 12000W 14400W
Maximum DC power for each MPPT 4800W (440V-850V) 6000W (545V-850V) 7200W (660V-850V) 8800W (800V-850V) 8800W (800V-850V) 8800W (800V-850V)
Number of independent MPPTs 2
Number of DC Inputs 1 for each MPPT
Maximum absolute DC input voltage 1000V
Input activation voltage 180V
Rated input DC 600V
MPPT DC Voltage range 160V-960V
DC voltage range at full load 190V-850V 240V-850V 290V-850V 380V-850V 480V-850V 575V-850V
Max DC Input current per MPPT 11A/11A
Input short circuit current for each MPPT 14A
Output (AC)
Rated AC Output Power 4000W 5000W 6000W 8000W 10000W 12000W
Maximum AC Power 4400VA 5500VA 6600VA 8800VA 11000VA 13200VA
Maximum AC Current 6.4A 8.0A 9.6A 12.8A 15.9A 19.1A
AC Rated Voltage 3/ N/ PE,220/380 3/N/PE,230/400 3/N/PE,240/415
Rated AC Voltage Range 184V-276V (According to the standard of local networks)
Rated Output Frequency 50/60Hz
Mains frequency 5OHz,+/-5Hz (According to the standard of local networks)
Active Power Adjustment Range 0-100%
Total current harmonic distortionAzzurro - THREE-PHASE
STRING INVERTERS
10000TL/15000TL/17000TL/20000TL
Azzurro ZCS technology
Performance optimisation
WiFi integration on the ZCS platform
for stable, effective and intelligent
connectivity
The Three-phase ZCS Azzurro inverters are
Maximum Energy
the ideal solution for medium size PV systems
Efficiency
for commercial or industrial applications. Maximum performance 98.2%
Stable efficiency
The Italian technology developed by ZCS in all working conditions
Rapid and accurate MPPT algorithm
makes the Azzurro series efficient, versatile Dual input section with
and high-performing. independent MPPT
Their wide input range from 10 to 20kW makes A Flexible,
them easy to configure and are suitable for Economic and Easy
Installation solution
all requirements on both new and retrofit IP65 Protection rating
installations on existing systems. Integrated string combiner
with different configuration options
Power Management Unit
4” LCD display
Updates and diagnostics
through SD Card
Reliability, Sturdiness
and Flexibility
External enclosure
in rust-proof, corrosion-proof
and UV-ray proof aluminium
Natural ventilation cooling
Flexible and user-friendly
management of operating parameters
Optional class II power surge
protection devices (AC and DC)
Topology without transformer
10 year ZCS warranty
Intelligent Grid
Management
Dynamic management
of delivery to the grid
“Zero Delivery” grid function*
Remote control over deliverable
active/reactive output limit
Ideal For Retrofit Options
Wide operating input range
from 250V to 960V also suitable
for small size string systems
Compact size
Simple and user-friendly
installation and configuration
Dual MPPT channel
*Possible through current sensor (ZST-ACC-TA)
and anti-reverse power controller (ZSM-OINJ)
17FLOW CHART
EFFICIENCY CURVE
18DATI TECNICI 10000TL 15000TL 17000TL 20000TL
Input (DC)
Rated input DC power 11000W 16500W 18700W 22000W
Maximum DC power for each MPPT 6750W (450V-850V) 10500W (500V-850V) 10500W (500V-850V) 12000W (500V-850V)
Number of independent MPPTs 2
Number of DC Inputs 2 for each MPPT
Maximum Input Voltage 1000V
Activation voltage 350V
Rated Input Voltage 600V
MPPT DC Voltage range 250V-960V
DC voltage range at full load 350V-850V 370V-850V 420V-850V 430V-850V
Max Input current per MPPT 15A/15A 21A/21A 21A/21A 24A/24A
Short Circuit Current for each MPPT 20A 27A 27A 30A
Output (AC)
Nominal AC power (@ 230V, 50Hz) 10000W 15000W 17000W 20000W
Maximum AC Power 10000VA 15000VA 17000VA 20000VA
3/N/PE,220/380V
AC Rated Voltage 3/N/PE,230/400V
3/N/PE,240/415V
Rated AC Voltage Range 180V-270V (According to the local network standard)
Mains frequency 47~53 / 57~63 Hz (According to the local network standard)
Active Power Adjustment Range 0~100%
Maximum AC Current 15A 22A 25A 29A
Total current harmonic distortionAzzurro - THREE-PHASE
STRING INVERTERS
30000TL/33000TL/40000TL
Azzurro ZCS technology
Performance optimisation
WiFi integration on the ZCS platform
for stable, effective and intelligent
connectivity
The Three-phase ZCS Azzurro inverters are
Maximum Energy
the ideal solution for medium and large size Efficiency
PV systems for roof or ground installations. Maximum performance 98.7%
Stable efficiency
The advanced ZCS technology makes the in all working conditions
Rapid and accurate MPPT algorithm
Azzurro series efficient, versatile and high- Dual input section with
performing. independent MPPT
Their wide input range from 30 to 40kW with A Flexible,
dual MPPT channels makes them easy to Economic and Easy
configure and are suitable for all requirements Installation solution
IP65 Protection rating
on both new and retrofit installations on Integrated string combiner
existing systems. with different configuration options
Power Management Unit
4” LCD display
Updates and diagnostics
through SD Card
Reliability, Sturdiness
and Flexibility
External enclosure
in rust-proof, corrosion-proof
and UV-ray proof aluminium
Flexible and user-friendly
management of operating parameters
Optional class II power surge
protection devices (AC and DC)
Topology without transformer
10 year ZCS warranty
Intelligent Grid
Management
Dynamic management
of delivery to the grid
“Zero Delivery” grid function*
Reactive output management feature
Remote control over deliverable
active/reactive output limit
Ideal For Retrofit Options
Wide operating input range
from 250V to 960V also suitable
for small size string systems
Compact size
Simple and user-friendly
installation and configuration
Dual MPPT channel
*Possible through current sensor (ZST-ACC-TA)
and anti-reverse power controller (ZSM-OINJ)
20FLOW CHART
EFFICIENCY CURVE
21DATI TECNICI 30000TL 33000TL 40000TL
Input (DC)
Rated input DC power 33000W 36300W 44000W
Maximum DC power for each MPPT 15360W (480V-800V) 17000W (480V-800V) 20400W (570V-800V)
Number of independent MPPTs 2
Number of DC Inputs 4 for each MPPT
Maximum Input Voltage 1000V
Activation voltage 350V
Rated Input Voltage 600V 600V 700V
MPPT DC Voltage range 250V-960V
DC voltage range at full load 480V-800V 480V-800V 570V-800V
Max Input current per MPPT 64A(32A/32A) 70A(35A/35A) 70A(35A/35A)
Max Input Current per String 12A
Output (AC)
AC rated power (@ 230V, 50Hz) 30000W 33000W 40000W
Maximum AC Power 30000VA 33000VA 40000VA
3/N/PE, 277/480V
AC Rated Voltage 3/N/PE, 3/PE, 230/400V
o 3/PE, 277/480V
310V-480V 422V-528V (According to
Rated AC Voltage Range
(According to the local network standard) the local network standard)
Mains frequency 47~53 / 57~63 Hz (According to the local network standard)
Active Power Adjustment Range 0~100%
Maximum AC Current 43A 48A 48A
Total current harmonic distortionAzzurro - THREE-PHASE
STRING INVERTERS
50000TL/60000TL/70000TL
Azzurro ZCS technology
Performance optimisation
WiFi integration on the ZCS platform
for stable, effective and intelligent
connectivity
The Three-phase ZCS Azzurro inverters are
Maximum Energy
the optimum solution for medium and large size Efficiency
PV systems for roof or ground installations. Maximum performance 98.9%
Stable efficiency
The advanced ZCS technology makes the in all working conditions
Rapid and accurate MPPT algorithm
Azzurro series efficient, versatile and high- Triple input section with
performing. independent MPPT
Wide input voltage range, triple MPPT A Flexible,
channel, DC and AC switch, on board DC and Economic and Easy
AC surge protection devices make them easy Installation solution
IP65 Protection rating
to configure, suitable for all requirements, safe Integrated string combiner
and robust. with different configuration options
Power Management Unit
4” LCD display
Updates and diagnostics
through SD Card
Reliability, Sturdiness
and Flexibility
External enclosure
in rust-proof, corrosion-proof
and UV-ray proof aluminium
Flexible and user-friendly
management of operating parameters
Optional class II power surge
protection devices (AC and DC)
Topology without transformer
10 year ZCS warranty
Intelligent Grid
Management
Dynamic management
of delivery to the grid
“Zero Delivery” grid function*
Reactive output management feature
Remote control over deliverable
active/reactive output limit
Ideal For Retrofit Options
Wide operating input range
from 250V to 960V also suitable
for small size string systems
Compact size
Simple and user-friendly
installation and configuration
Triple MPPT channel
*Possible through current sensor (ZST-ACC-TA)
and anti-reverse power controller (ZSM-OINJ)
23FLOW CHART 24
DATI TECNICI 50000TL 60000TL 70000TL
Input (DC)
Typical photovoltaic plant power 60000W 70000W 80000W
Number of independent MPPTs 3
Number of DC Inputs 2x3 + 1x4 3x4 3x4
Maximum Input Voltage 1000V
Activation voltage 350V
Rated Input Voltage 600V 600V 700V
MPPT DC Voltage range 250V-960V
DC voltage range at full load 500V-800V 530V-800V 660V-800V
Max. Input current per MPPT 100A(40A/30A/30A) 120A(40A/40A/40A) 120A(40A/40A/40A)
Max. Input Current per String 12A
Output (AC)
Nominal AC power (@ 230V, 50Hz) 50000W 60000W 70000W
Maximum AC Power 50000VA 60000VA 70000VA
AC Rated Voltage 3/N/PE, 3/PE, 230/400V 3/N/PE, 277/480V o 3/PE, 277/480V
"180V-270V "245V-305V (According to the
Rated AC Voltage Range
(According to the local network standard)" local network standard)"
Mains frequency 47~53 / 57~63 Hz (According to the local network standard)
Active Power Adjustment Range 0~100%
Maximum AC Current 80A 90A 90A
Total current harmonic distortionAZZURRO - ENERGY
STORAGE INVERTER
3000SP
Simple and reliable
Energy exchange directly in AC,
with no interface systems or external
control required.
LCD display for local monitoring
The storage solution Inverter ZCS Azzurro
Remote monitoring system via APP to
is ideal to achieve optimum energy
view consumptions,
independence in the residential sector. With a PV production, energy stored and
rated power of 3 kW and a storage capacity of exchange with the grid
up to 20 kWh, it suits all types of requirements
in new systems. Simple installation
Compatible with all existing inverters
In addition, thanks to the AC connection, already connected to the grid
Azzurro is compatible with any type of No interventions required on the
technology (solar, wind, etc.) and with any existing electrical system, thanks to the
type of inverter; it is therefore the ideal use of a split core current sensor
solution for updates and the optimisation of
existing systems. Flexible
discharge solution
Flexible management of charging/
discharging in accordance with local
regulations
Maximisation of self-consumption of
up to above 80%
Suitable for installation on single-
phase and three-phase systems alike.
Unit compatible with lithium batteries
as well as other 48V technologies (lead,
gel, salt water, etc.)
Functions when
disconnected from
the grid
Stand Alone support mode guarantees
continuity of operation during power
black-outs
26FLOW CHART
ACCUMULATION SHEET
27DATI TECNICI - 3000SP
AC Output
Rated power 3kVA
Peak power 1.5*Pnom, 10S: 1.2*Pnom, 30S
Operating voltage range 180-270V
Frequency range 44~55Hz / 54~66Hz
Rated Voltage 230V
Harmonic Distortion (THD) DC) 94,1%
Maximum discharge efficiency (DC-> AC) 94.5%
Consumption in standbyAZZURRO
CUSTOMER SERVICE
29Azzuro customer service is available in all Installation and commissioning
countries where ZCS operates through a Would you like to receive help for the correct
local service center network. dimensioning of your new photovoltaic
ZCS Azzurro provides its customers with system or for the retrofit of existing systems?
service through: Do you have problems configuring your ZCS
Azzurro Inverter?
VIA E-MAIL at Do you have doubts about its correct use and
service.inverter@zcscompany.com installation?
Contact our Customer Service via mail at
ZCS Azzurro Customer Service will handle service.inverter@zcscompany.com
your request for assistance within 24 hours
of your communication. Our customer service is able to offer support
regarding pre-sales and post-sales requests,
so our customers can receive all the
information they need.
Training and Instruction
ZCS offers various training and instruction
programs on various aspects related to solar
energy. Training and instruction sessions are
organised both at ZCS offices and outside,
at our distributors’ offices and in hotel halls
or conference centers.
ZCS encourages all its customers to invest
30part of their time in one or more training Contact our offices for an estimate.
courses because it is possible to greatly During each inspection, the good
increase efficiency during an installation operation of the inverter will be checked
through these courses and, at the same time, by measuring the efficiency and checking
make it perfectly compliant with current all the parameters useful for the life of the
regulations. unit. In addition, the machine software will
ZCS training courses of normally include be updated, if the unit software is not the
both general and theoretical presentations latest release and a report will be issued
aimed at the technical knowledge of the that certifies the result of the inspection
inverters and practical exercises with “open visit.
inverter” aimed at the explanation of all
product features, the various applications, Repair and replacement
the installation and commissioning Faulty inverters can be replaced by a new
procedures, programming, maintenance inverter or a reconditioned inverter.
and fault identification. ZCS uses partner companies to bring the
The courses are open to all operators in Azzurro inverters back to their original
the sector and are not limited to technical conditions.
professional figures. This process, which we call reconditioning,
brings the inverter back to the original
Spare Parts and Accessories conditions of performance and efficiency.
The general settings, meaning the normal Reconditioning includes a total inspection of
procedure in the event of a fault, for the the machine, complete cleaning, inspection,
ZCS Azzurro inverter is to change the analysis and replacement of the components
faulty inverter and replace it with a new or to be replaced. The reconditioned inverter
regenerated one. is subjected to a complete test cycle and is
However, there may be cases where it is supplied with the remaining warranty at the
easier to change some accessories to restart end of the ten year period of the original
the whole system. This is the case of the fan inverter.
tray in three-phase inverters or of the battery
connection cables in the accumulation Service Partners
systems. ZCS can intervene within 24 hours in any
The list of available accessories and spare region of Italy and in any country in Europe.
parts is available in our price lists and the ZCS favours a confidential relationship with
parts can be ordered from our distributors the installers called to call on its customers
in the same way that the inverters are in the field, in the absence of an installer
ordered. ZCS keeps all accessory and responsible for the plant, ZCS guarantees
replacement parts in stock and, therefore, customer service through its own direct staff
they are normally available for immediate or through local service partners.
shipment.
Maintenance - Warranty Extension
- Updates - Retrofit
The ZCS Azzurro string inverters do not
require any particular maintenance work
since, in general, a faulty inverter is always
replaced by a new inverter.
However, as the expected inverter service life
is around 20 years, an annual inspection of
the general conditions of each inverter may
be advisable.
ZCS offers this type of service at very low
prices and conditions both during and after service.inverter@zcscompany.com
the warranty period.
31Those who choose ZCS green Innovation technology, choose to change perspective.
THE INVERTER THAT LOOKS AT THE FUTURE
Zucchetti Centro Sistemi S.p.A. - Green Innovation Division
Via Lungarno, 305/a
52028 Terranuova Bracciolini - Arezzo, Italy
tel. +39 (0)55 - 91971 - fax. +39 (0)55 - 9197515
innovation@zcscompany.com
zcscompany.comYou can also read
