NUMBER 156 . March 2019 ISSN 1682-6116
CONCRETEBETON
1969-2019
Golden Jubilee
edition
PLATINUM MEMBERS
CONTENTS
Editor’s comment..................................................................................................................4
President’s message..............................................................................................................6
SOCIETY HISTORY
A Journey Through Time.................................................................................................7
FULTON AWARDS WINNER
Sol Plaatje University Library............................................................................................13
ACCREDITED TECHNICAL PAPERS
Precast Concrete Panels for Rapid Full-Depth Repair of CRCP........................................17
ASR expansion due to use of reactive fine and coarse aggregates,
and its effect on concrete compressive strength............................................................23
INDUSTRY NEWS
Growing readymix markets with Chryso technology......................................................29
Modern flooring products save time..............................................................................30
Chryso to expand concrete offering in 2019.................................................................31
Heritage and height mark Concor Western Cape’s landmark project.............................32
Metrorail safety wall built with Echo panels ................................................................34
Smart new floor for the Ekurhuleni Municipal Police Department..................................35
Afrisam takes leading role in SAFA’s youth soccer
development programme – Ima Nathi...........................................................................36
a.b.e. flooring system used for Douglas Green Winery walls..........................................37
Heritage and future......................................................................................................38
SIKA 2018 sales exceed CHF 7 billion for the first time..................................................40
Air-purifying concrete can reduce atmospheric pollution...............................................41
Ash is the 21st century’s next big thing.........................................................................42
Kaytech raises the B-BBEE bar......................................................................................43
Post-budget analysts at AfriSam gathering call for new beginnings...............................44
SOCIETY NEWS
University of Pretoria Civil Laboratory opens its doors to Inland Branch members..........45
Members visit the site of Deloitte’s stunning new R1 billion headquarters......................46
Fulton Awards 2019 attracts many iconic structures......................................................48
Bursaries awarded to celebrate the Society’s 50th Anniversary........................................49
Inland Branch Honours Construction Materials Executive...............................................50
ACTIVITIES CALENDAR...............................................................................................51
MEMBERSHIP DETAILS...............................................................................................53
CONCRETE BETON 3
editor’s comment
Welcome readers to this special Golden Jubilee issue of
Concrete Beton - we’ve published a bumper edition for you
in celebration of this great milestone in our history.
I
n these austere times it was difficult to justify major expense on celebrating this anniversary, but
we have embarked on some key initiatives to ensure a legacy.
As part of our celebrations this year, the Board of Directors decided to formally recognise the
loyal support that we have been afforded by the major Universities over many, many years. This
will be in the form of presentations to six universities of specially designed and produced concrete
seats to be installed on their campuses. Unveiling of these will take place at the universities in
April and members will be invited to the short ceremonies. The academic institutions involved
are the University of Johannesburg, University of Pretoria, WITS, University of KwaZulu-Natal,
Stellenbosch University and University of Cape Town.
Coupled with this is the awarding of two bursaries this year for students conducting research
in the field of cement‐based materials. More details of these can be viewed under the Society
News section.
My thanks to Hanlie Turner our Immediate Past President who has taken the time to research
and write a short history of the Concrete Society (see pages 7-12). Not an easy task when so
many of the older members are no longer with us, and the only written source of information has
been the 155 issues of this journal published since March 1976. Anyway, it is a factual yet fairly
light-hearted article, so enjoy the read.
Now turning to the issue of consolidation of the various concrete-related organisations.
I reiterate what I said in my e-mail to members late last year when I advised that it has been
decided that before any consolidation can take place, a strategy for the whole industry should
be formulated and agreed.
From this, consolidation of the industry service offerings may be required based on a strategic
approach that maximises value creation for members and other key stakeholders.
Under the auspices of two independent professional facilitators, separate meetings have now
taken place with TCI, CSSA, SARMA and CMA, where the needs and wants of the various bodies
were aired and discussed. The combined outcomes of these discussions will be made available
shortly, and these will be communicated to members.
With any exercise of this nature, there is bound to be uncertainty and speculation, but I
implore you as loyal members, to support us through this period, and enjoy the current benefits
that the Society has to offer.
For the love of Concrete,
John Sheath
Editor
