Confidence in the
 toughest conditions.
 ZEISS Sports Optics

ZEISS Hunting and Shooting Catalog

zeiss.com/us/sportsoptics
Confidence in the toughest conditions - ZEISS Sports Optics - ZEISS Hunting and Shooting Catalog
Confidence        Out in the field, hunting conditions are often harsh.
                      You need optics you can count on – in every challenging

    in the toughest   situation.

    conditions.       And that’s exactly what you’ll find at ZEISS. Our optics are
                      high-precision tools proven extremely reliable in the toughest
                      of conditions.

                      Our stringent testing procedures ensure faultless performance
                      in the most rugged hunting conditions imaginable, making it
                      possible for you to act and react with ultimate confidence in
                      every hunting situation. You can find additional information
                      about the endurance tests for ZEISS optics at
                      reallife-hunting.zeiss.com/us.

2 | ZEISS                                                                  Hunting and Shooting   ZEISS | 3
Confidence in the toughest conditions - ZEISS Sports Optics - ZEISS Hunting and Shooting Catalog
RIFLESCOPES     ZEISS                                                                                                                                                           RANGEFINDERS                            SPOTTING SCOPES
                                       FROM ZEISS     HUNTING APP                                                                                                                                                   AND BINOCULARS                            FROM ZEISS

                                          16          14                                                                                                                                                                                                      54
                                                                                                                                                                                                                         FROM ZEISS

                                                                                                                                                                                                                                  34

                                                      ZEISS PRECISION RINGS

                                                      62

        ZEISS – The Company                6        RANGEFINDERS AND BINOCULARS   34                                        SPECIALTY BINOS/MONOS                                                    52                        ACCESSORIES                                        62

        ZEISS – Optics and Benefits        8        Victory RF Rangefinder        34                                        Image Stabilization Binocular 20x60 S                                    52                        Riflescopes                                        62

        ZEISS – New for 2020              10        Victory SF                    40                                        Mono 3x12                                                                53                        Binoculars                                         64

        ZEISS – Hunting App               14        Victory HT                    44                                        Monoculars                                                               53                        Spotting Scopes                                    66

        RIFLESCOPES                       16        Victory FL                    45                                        SPOTTING SCOPES                                                          54                        Lens Care                                          67

        Victory V8                        16        Victory Pocket                45                                        Victory Harpia 95 / 85                                                   56                        SUPPORTING INFORMATION                             68

        Conquest V6                       22        Conquest HD                   46                                        Conquest Gavia 85                                                        58                        Reticles                                           68

        Conquest V4                       28        Terra ED                      50                                        Dialyt Field Spotter                                                     60                        Technical Specifications                           72

                                                    Terra ED Pocket               51                                                                                                                                           Product List and Order Numbers                     80

                                                                                                                                                                                                                               SERVICE POLICIES                                   82

4 | ZEISS                                                                          Hunting and Shooting   Carl Zeiss SBE, LLC is not responsible for typographical errors, and we make every effort to ensure the accuracy of the information at time of printing. Products and        ZEISS | 5
                                                                                                          specifications are subject to change without notice. Please visit zeiss.com/us/sports-optics for the most up-to-date product information.
Confidence in the toughest conditions - ZEISS Sports Optics - ZEISS Hunting and Shooting Catalog
GLASS TECHNOLOGY

ZEISS Optics and Benefits
Explained

                                                             Optical Innovation                                                                                                                             Precision Mechanics

                                                                                         SC H O
                                                dard glass

                                                                                               TT Glass
                                            Stan

    T-Star (T*) Six-layer Coating                               SCHOTT Glass                                        Fluoride Glass                              User-friendly Eyebox                               Ballistic Stop                              Lightweight Design
         For a brighter, clearer and            Optimum target identification, game                          Ensures a brighter viewing image              The generous size of the eyebox allows      An absolute and ultra-positive return to            ZEISS products are engineered with
          higher-contrast image.                 validation, resolution of target and                       that delivers absolute color fidelity,          for more comfortable observation, a         zero – every time. Select your zero, set          select materials and manufactured to
                                               maximum light transmission in low-light                    brightness, high contrast and the finest         higher tolerance on where to place the      the Ballistic Stop, and enjoy a lifetime of       exacting standards to produce a lighter
                                                                hours.                                             resolution of details.                     eye, and faster target acquisition.                      repeatability.                      weight sport optic with a focus on
                                                                                                                                                                                                                                                               precision and repeatability.
                                                                                   ZE
                                                                                      IS
                                                                                         S
                                                                                       Fie
                                                                                           ldF
                                                dard glass

                                                                                         lattener Tech
                                            Stan

                                                                                      no
                                                                                        log
                                                                                     y

                Lotutec®                                 FieldFlattener Technology                               Light Transmission         92%          European-Style Fast Focus Eyepiece                   Smart Reticle Design                                 Illuminated Reticle
   Makes lenses water- and dirt-repellent              Extreme edge sharpness, even with                    90% to the eye with Conquest V4                     Quick, easy and repeatable          Various relevant and intuitive reticle designs for        Illuminated reticle keeps you in the
            and easy to clean.                                wide fields of view.                          92% to the eye with Conquest V6                        diopter adjustment.              today‘s hunting and long-range hunting needs.                 hunt in prime time (optional).
                                                                                                             92% to the eye with Victory V8
8 | ZEISS                                                                                                                         Hunting and Shooting                                                                                                                                    ZEISS | 9
Confidence in the toughest conditions - ZEISS Sports Optics - ZEISS Hunting and Shooting Catalog
NEW FOR 2020
                                                             !
ZMOAi-T20 and ZMOA-T30                                    New
Thin Line Reticles
Designed for Long-Range Hunting and Precision Shooting.

• Thinner Reticle*                    • Faster Target Engagement
• Highly Intuitive                    • Second Focal Plane
• Precise Aiming Solution             *35-50% thinner than ZEISS ZMOA and ZBR series reticles

ZMOAi-T20                                                                                                        The ZMOAi-T20
(Illuminated)                                                                                                                                                             CONQUEST V4
                                                                                                                 illuminated reticle           RIFLESCOPE                               Standard Number Height H        0.75
                                                                                                                                                                          6-24x50
                                                                                                                 is available in the
                                                                                                                 Conquest V4 6-24x50           Magnification              @ 24x         10, 20 Number Height I          1.0

                                                                                                                                               UNIT OF MEASURE            MOA           Dot Size J                      0.12

                                                                                                                                               Line Thickness A           0.06          Dot Spacing K                   2.0

                                                                                                                                               Distance B                 0.5           Distance L                      1.5

                                                                                                                                               Distance C                 0.25          Distance M                      0.5

                                                                                                                                               Distance D                 1.0           Distance N                      0.5

                                                                                                                                               Distance E                 2.0           Distance O                      32

                                                                                                                                               Distance F                 1.0           Distance P                      1.0

                                                                                                                                               Distance G                 4.0           Spacing around center cross Q   0.5

ZMOA-T30                                                                                                         The ZMOA-T30                                             CONQUEST V4
(Non-Illuminated)                                                                                                reticle is available in the   RIFLESCOPE                               10, 20, 30 Number Height H      1.0
                                                                                                                                                                          4-16x44
                                                                                                                 Conquest V4 4-16x44
                                                                                                                                               Magnification              @ 16x         Dot Size I                      0.12

                                                                                                                                               UNIT OF MEASURE            MOA           Dot Spacing J                   2.0

                                                                                                                                               Line Thickness A           0.12          Distance K                      4.0

                                                                                                                                               Distance B                 0.5           Distance L                      0.5

                                                                                                                                               Distance C                 0.25          Distance M                      0.5

                                                                                                                                               Distance D                 1.0           Distance N                      1.5

                                                                                                                                               Distance E                 2.0           Distance O                      32

                                                                                                                                               Distance F                 1.0           Distance P                      1.0

                                                                                                                                               Standard Number Height G   0.75          Spacing Around Center Cross Q   0.5

10 | ZEISS                                                                                Hunting and Shooting                                                                                                                 ZEISS | 11
Confidence in the toughest conditions - ZEISS Sports Optics - ZEISS Hunting and Shooting Catalog
NEW FOR 2020
                                                                           !
                                                                        New
ZEISS Precision Rings
with Integral Anti-Cant Bubble Level
ZEISS ultralight 1913 Mil-Std, STANAG-compliant rings are manufactured to the highest of standards, from premium materials, and
with tight tolerances for your long-term safety and field applications. They are designed for optimal long-range shooting solutions and
allow for either right- or left-handed operations as well as eye dominance. The bubble level is easily viewed from the shooting position,
creating no disturbance in your shooting position. A smarter, sleeker, and ultralightweight ring design for all heavy-duty hunting and
shooting applications.

Bubble Level                                    Durable Material                             Cap Screws
Integral anti-cant bubble                       7075-T6 aluminum, Mil-Std, STANAG-           T15 Torx®, Type 303 stainless
level in top half of ring.                      compliant, Type III, 30-micron hard          steel top cap screws – with
                                                anodized finish – matte black.               black oxide finish.

Ring height
measurements
are determined
from top of
                                                                                                                              T25 Torx® Screw
mounting rail
to center line of
ring’s bore.

Machined                                    Ultralight                     Recoil Lug                       Refined Design
Leading Edges                               Approximately                  Integral bottom recoil lug       Compact and refined
Micro-radiused on all                       4.4 oz. with screws            for best alignment and           design, with low-profile,
machined leading edges to                   (pair 30mm low).               a secure zero under the          non-snagging hardware.
ensure a non-marring design.                                               harshest recoil.

                    Hard Case
                    Included, with both T15
                    and T25 Torx® driver bits

                                                                               Image displayed above represents a 30 mm medium-height ring.
12 | ZEISS                                                                                                                Hunting and Shooting   ZEISS | 13
Confidence in the toughest conditions - ZEISS Sports Optics - ZEISS Hunting and Shooting Catalog
ZEISS HUNTING APP                                                                                                                                                                Multi-talented hunting buddy
                                                                                                                                                                                 The ZEISS Hunting App supports over 100,000
The App for expert hunters and shooters.                                                                                                                                         hunters and shooters around the world with its
                                                                                                                                                                                 many useful features. The ZEISS Hunting App
Now available from your desktop.                                                                                                                                                 is always ready to capture current events or
                                                                                                                                                                                 experiences while you are afield.

                                                                                                                                                                                 The new desktop version offers more convenience
                                                                                                                                                                                 for data entry and provides an additional portal for
                                                                                                                                                                                 data management and documentation. Automatic
                                                                                                                                                                                 synchronization ensures that data entries are
                                                                                                                                                                                 always available on all devices.

                                                                                                                                                                                            ZEISS Hunting App – now available
                                                                                                                                                                                            from your desktop.

                                                                                                                                                                                                 Connected Products
                                                                                                                                                                                                 Easy setup and configuration of
                                                                                                                                                                                                 the ZEISS Victory RF Rangefinder
                                                                                                                                                                                                 through the App. Sync your
                                                                                                                                                                                                 custom ballistic profiles to ensure
                                                                                                                                                                                                 precise shot placement.

                                                                                                                                                                                                 Hunting Grounds
                                                                                                                                                                                                 Create, manage and outline your
                                                                                                                                                                                                 hunting grounds directly from
                                                                                                                                                                                                 your desktop or smartphone.
                                                                                                                                                                                                 Mark stand locations and other
                                                                                                                                                                                                 important areas on the map.
                                                                                                                                                                                                 Never get lost in the field, thanks
                                                                                                                                                                                                 to the GPS-powered indicator of
                                                                                                                                                                                                 your current location.

       Dashboard                          News                              Field Notes                           Weather Data                     My Gear                                       Ballistic Calculator
       Provides a quick overview of the   Product news, promotions and      Document your hunting                 Weather forecast and real-time   Organized record-keeping of your              Precise calculations for the perfect
       information you use most often.    sweepstakes – an exclusive just   experiences by adding species,        location data for your hunting   hunting gear. Important product               shot. Includes an ammunition
                                          for ZEISS Hunting users.          shot placement, photos/videos         grounds.                         information securely stored in                database with over 7,000 loads.
                                                                            and much more.                                                         one place and always at your
                                                                                                                                                   fingertips.

14 | ZEISS                                                                                 Hunting and Shooting                                                                                                         ZEISS | 15
Confidence in the toughest conditions - ZEISS Sports Optics - ZEISS Hunting and Shooting Catalog
VICTORY

Z E I S S VI CTORY V8 RIF LESCOP ES
                                                                                                                    FEATURES:
The uncompromising pursuit of perfection.                                                                           Intelligent innovations for
                                                                                                                    exceptional results:
Hunting leaves no room for compromises. This is        The Victory V8 riflescopes also offer superb
why dedicated hunters around the world trust in        ergonomic handling. For instance, the world’s
ZEISS Victory® V8 – the most versatile riflescopes     finest and brightest illuminated dot can be precisely                SCHOTT Glass
from ZEISS.                                            adjusted and easily set, while the short and compact
                                                       construction ensures optimal firearm handling. In
                                                       addition, the large, generous eyebox ensures fast                    Fluoride Lenses (FL)
It is the sum of sophisticated features and how they   target acquisition and round, clear images at all
work together that makes riflescopes from ZEISS        powers. Their long-range hunting capabilities are
an indispensable hunting companion; scanning the       another unique feature of the V8 riflescopes. Thanks                 T* Six-Layer Lens
landscape delivers an image in extraordinarily sharp   to the BDC (ASV) and its large adjustment range, the                 Multi-Coating
detail, outstanding brightness and natural color       ZEISS Victory V8 stands at the pinnacle of modern
rendition. This is made possible only by the unique    riflescope technology.
interaction of transmission values of up to 92%, FL                                                                         LotuTec
lenses, SCHOTT HT glass and extremely wide fields
of view.
                                                                                                                            92% Light
                                                                                                                     92
                                                                                                                            Transmission

                                                                                                                            2nd Focal Plane

                                                                                                                    8       8x Zoom

                                                                                                                            Waterproof up to
                                                                                                                            400 mbar

                                                                                                                            Nitrogen Purged

                                                                                                                            Illuminated

                                                                                                                            Capped Turret

                                                                                                                            External Turret

                                                                                                                            Ballistic Stop

                                                                                                                     36
                                                                                                                     mm     36 mm Main Tube

16 | ZEISS                                                                                   Hunting and Shooting                     ZEISS | 17
Confidence in the toughest conditions - ZEISS Sports Optics - ZEISS Hunting and Shooting Catalog
VICTORY

PRODUCT HIGHLIGHT                                                                                                        RETICLE OPTIONS:

Victory V8
The most versatile riflescope from ZEISS.
                                                                                                                           #60 Illum.           #43 Illum.

    Larger Eyebox                                          Parallax Compensation                                              Performance-Oriented Design             More Powerful
    Achieve fast target acquisition and round,             Parallax compensation in all                                       The 36 mm main tube diameter provides   The combination of 92% light transmission,
    clear images at all powers, thanks to a large          high-magnification models                                          more room for optical excellence and    FL lenses and SCHOTT HT glass provides
    eyebox and maximum field of view.                      delivers ultra-crisp images at                                     generous reticle adjustment ranges.     the most outstanding image quality in the
                                                           all distances.                                                                                             super-zoom riflescope class.

    Cutting-Edge Technology                         More Versatile                                                       More Precise
    The multifunction button                        8x zoom for maximum flexibility: whether                             With an adjustment range of 100
    controls the brightness of the                  you are competition shooting, stand                                  clicks, the BDC/ASV allows for precise,
    fine, illuminated red dot, and                  hunting, spotting and stalking game, or                              accurate long-range shooting.
    the intelligent motion sensor                   taking long-distance shots – with the ZEISS
    automatically activates the                     Victory V8, you are perfectly prepared for
    illumination when the rifle is                  any hunting situation.
    brought into shooting position.

18 | ZEISS                                                                                        Hunting and Shooting                                                                                     ZEISS | 19
Confidence in the toughest conditions - ZEISS Sports Optics - ZEISS Hunting and Shooting Catalog
VICTORY

V8 1-8x30                     The V8 1-8x30 is considered the most powerful
                              close-range riflescope. At 1x magnification, it is
                                                                                   •
                                                                                   •
                                                                                       Close range to longer distances
                                                                                       Large, generous eyebox
                                                                                                                                                   V8 2.8-20x56                The 2.8-20x56 opens up more opportunities
                                                                                                                                                                               at low light. 92% light transmission ensures
                                                                                                                                                                                                                                    •
                                                                                                                                                                                                                                    •
                                                                                                                                                                                                                                         Low-light specialist
                                                                                                                                                                                                                                         92% light transmission
                              ideal for target acquisition with both eyes open,    •   92% light transmission                                                                  bright, high-contrast images. This model is          •    BDC/ASV LongRange standard
                              as well as quick shots at short distances. At 8x     •   Reticle: #60 (illuminated reticle)                                                      compact and easy to use, making it the perfect       •    Reticle: #60 (illuminated reticle)
                              magnification, the V8 allows for shots at mid- to    •   Available with ZEISS rail mount.                                                        match for even the highest performing rifles.        •    Available with ZEISS rail mount.
                              longer-range distances.

Firearm Application                                                                Target Usage Application                                        Firearm Application                                                              Target Usage Application

                                                              MODERN SPORTING                                                                         LO N G - R A N G E
  MOUNTAIN            CLASSIC               SAFARI               RIFLE                                                                                 HUNTING             CLASSIC           VARMINT           SPECIALTY

V8 1.8-14x50                  This compact model provides a wide range of
                              possible uses and maximum accuracy at any
                                                                                   •
                                                                                   •
                                                                                       Most versatile riflescope
                                                                                       92% light transmission
                                                                                                                                                   V8 4.8-35x60                 The benchmark model of the Victory V8
                                                                                                                                                                                product line. The 35x magnification combined
                                                                                                                                                                                                                                    •
                                                                                                                                                                                                                                    •
                                                                                                                                                                                                                                         BDC/ASV LongRange standard
                                                                                                                                                                                                                                         92% light transmission
                              distance. The large eyebox ensures fast and          •   Optional BDC/ASV LongRange                                                               with the BDC/ASV gives ultimate long-range          •    Reticles: #43 (illuminated reticle) /
                              reliable shots in any situation – from spotting      •   Reticle: #60 (illuminated reticle)                                                       hunting capability. The optical system impresses         #60 (illuminated reticle)
                              and stalking game to stand hunting at twilight.      •   Available with ZEISS rail mount.                                                         with maximum detail resolution, thanks to its
                                                                                                                                                                                combination of SCHOTT HT glass and fluoride (FL)
                                                                                                                                                                                lenses.

Firearm Application                                                                Target Usage Application                                        Firearm Application                                                              Target Usage Application

  MOUNTAIN            CLASSIC               SAFARI            VARMINT

                                                                                                                                                      LO N G - R A N G E
                                                                                                                                                       HUNTING             VARMINT          SPECIALTY

  LONG- R A N G E     MODERN SPORTING
   HUNTING               RIFLE

20 | ZEISS                                                                                                                  Hunting and Shooting   See page 72 for technical specifications and pages 68-71 for detailed reticle information.                                         ZEISS | 21
CONQUEST

ZEISS CONQUEST V6 RIFLESCOPES
                                                                                                             FEATURES:
Exceptional Optics.                                                                                          Intelligent innovations for
                                                                                                             exceptional results:
Outstanding Performance.
Truly Lightweight Design.                                                                                            SCHOTT Glass

Since the introduction of these            The 30 mm main tube houses a                                              Fluoride Lenses (FL)
riflescopes in 2017, ZEISS has             premium optical platform that
established a new standard of design,      delivers outstanding to-the-eye light                                     T* Six-Layer Lens
quality and function. The ZEISS            transmission of 92%. ZEISS fluoride                                       Multi-Coating
Conquest® V6 riflescopes are designed,     (FL) lenses and SCHOTT glass, when
engineered and manufactured in             coupled with advanced T* multi-layer                                      LotuTec
Germany, and each offers leading-edge      light transmission coatings, ensure
optical and mechanical technology.         that the ZEISS Conquest V6 provides                                       92% Light
                                           outstanding image quality and clarity                                     Transmission
                                           every time. The objective and ocular
These riflescopes will impress you at      lenses are also treated with ZEISS                                        2nd Focal Plane
each turn, whether hunting or shooting,    LotuTec hydrophobic coatings to repel
on low power or in low light, on high
power or high on the mountain. The
                                           dirt, debris and water.
                                                                                                             6       6x Zoom
true 6x zoom delivers ideal power
                                                                                                                     Waterproof up to
ranges and allows ZEISS to offer three     Additionally, the 1-6x24 model offers
                                                                                                                     400 mbar
models: 1-6x24, 3-18x50 and 5-30x50        digital reticle illumination with an
configurations. ZEISS offers several       intelligent motion sensor to help
                                                                                                                     Nitrogen Purged
second focal plane reticle options, to     conserve battery life, and it allows you
include plex-style as well as MOA-         to program and set your preferred
based smart reticle designs.               level of illumination intensity. There                                    Illuminated
                                           are options for external or capped
                                           elevation and windage turrets,
If your adventures take you hunting or                                                                               Lightweight
                                           depending on model, with elevation
shooting in the dense canopy of the        and windage adjustment ranges up to
Southeast or the rolling mountains of      103 MOA. Finally, external elevation                                      Capped Turret
the Northeast, consider the 1-6x24 or      turrets incorporate ZEISS proprietary
the 3-18x50. If you are traversing the     Ballistic Stop feature, which ensures an
farmlands and river bottoms of the                                                                                   External Turret
                                           absolute return to zero – every time.
Midwest, the highly versatile 3-18x50
is your perfect hunting companion. If
                                                                                                                     Multi-Turn Turret
you’ve made it to the open fields and      The Conquest V6 models are backed by
rugged mountain ranges of the West         the ZEISS Limited Lifetime Transferable
and want to stretch your barrel for that   Warranty and Five-Year No-Fault Policy.                                   Ballistic Stop
long-range opportunity, the 5-30x50
is the ticket to a successful shot of a
                                                                                                                     1/4 MOA
lifetime.

                                                                                                                     1/2 MOA

                                                                                                              30
                                                                                                              mm     30 mm Main Tube

22 | ZEISS                                                                            Hunting and Shooting                   ZEISS | 23
CCONQUEST
                                                                                                                                                                                                              ONQUEST

PRODUCT HIGHLIGHT                                                                                                  RETICLE OPTIONS:

Conquest V6
The powerful scope for wide-open terrain.
                                                                                                                         #6              #60 Illum.                ZBR                   ZMOA

         True 6x Zoom                                  Fast and Precise                                                Made in Germany                            Industry Leading
         Powerful magnification with                   The external turret – with .25 MOA                              Extremely reliable                         Optical Performance
         a true 6x zoom ratio provides                 click adjustments (.50 MOA on                                   internal components                        SCHOTT glass, FL lenses, enhanced T*
         more versatility across a wide                1-6x24), Ballistic Stop feature, multiple                       and legendary precision                    multi-coating and LotuTec hydrophobic
         range of applications.                        revolutions and 80 clicks per rotation                          mechanics ensure                           coating produce 92% light transmission
                                                       – allows you to engage and stay on                              consistent and flawless                    and excellent target resolution across
                                                       target, even at the longest of distances.                       operation for decades.                     the entire magnification range, even in
                                                                                                                                                                  extreme low-light situations.

    VERY Generous Eyebox                                       Large Adjustment Range                                                            Second Focal Plane Reticle Options
    Setting up your shot has never been easier,                The 30 mm single-piece, machined,                                                 In addition to the plex-style #60 illuminated reticle
    thanks to the large, generous and forgiving                aircraft-grade aluminum tube is extremely                                         (fiber optic, fine red dot) and the plex-style #6, ZEISS
    eyebox. Once you position yourself behind                  rugged. The machined shoulder design                                              offers the ZBR and ZMOA ballistic reticles, which
    the riflescope, you will experience the reticle,           also allows for 62-103 MOA total elevation                                        are MOA-based smart reticles. All options feature
    target and full image faster.                              adjustment, depending on model, for                                               fine crosshairs in the second image plane to ensure
                                                               long-range hunting and shooting.                                                  minimum target coverage and maximum visibility.

24 | ZEISS                                                                                  Hunting and Shooting                                                                                                 ZEISS | 25
CCONQUEST
                                                                                                                                                                                                                                                                           ONQUEST

ZEISS Conquest V6
The high performance riflescope with a
6x zoom range.
                                                                                                                                             V6 3-18x50                        The most versatile of the V6 product line, this
                                                                                                                                                                               riflescope with 103 MOA elevation and 58 MOA
                                                                                                                                                                                                                                    •   Multi-turn elevation turret with Ballistic Stop
                                                                                                                                                                                                                                        (absolute and positive return to zero)
                                                                                                                                                                               windage adjustment is built to excel at mid- to      •   True 92% light transmission provides
                                                                                                                                                                               long-range shooting distances. It is the perfect         exceptional resolution and accuracy
                                                                                                                                                                               scope for the mobile Western hunter in pursuit       •   ZEISS FL lenses, enhanced T* coatings and
                                                                                                                                                                               of elk, mule deer, antelope or mountain sheep.           LotuTec coating
                                                                                                                                                                                                                                    •   Side parallax adjustment
                                                                                                                                                                                                                                    •   Reticles: ZBR-2 / ZMOA-2 / #6 (plex)

                                                                                                                                             Firearm Application                                                                    Target Usage Application

                                                                                                                                                MOUNTAIN               CLASSIC                VARMINT            SPECIALTY

                                                                                                                                                LO N G - R A N G E   LO N G - R A N G E       MODERN SPORTING
                                                                                                                                                 HUNTING                TARGET                   RIFLE

V6 1-6x24                 With true 6x magnification, this model is
                          built for extremely fast target acquisition.
                                                                              •   Lockable external turret option with Ballistic Stop
                                                                                  feature (absolute and positive return to zero)
                                                                                                                                             V6 5-30x50                        The most compact high-magnification riflescope
                                                                                                                                                                               in the V6 product line, the 5-30x50 is perfect for
                                                                                                                                                                                                                                    •   Maximum power with superior optical
                                                                                                                                                                                                                                        performance across zoom range
                          The large, generous eyebox, combined                •   Large, forgiving eyebox                                                                      mid- to long-range hunting and serious precision     •   Ballistic Stop (absolute and positive return to zero)
                          with a wide field of view, makes it                 •   ZEISS FL lenses, enhanced T* coatings and                                                    shooting. The wide magnification range provides      •   ZEISS FL lenses, enhanced T* coatings
                          extremely versatile in close encounters,                LotuTec coating                                                                              great flexibility for those shooting in vast open        and LotuTec coating
                          from dense cover and 3-Gun competitions             •   Intelligent motion sensor activates/deactivates                                              terrains or varmint and predator hunting.            •   Side parallax adjustment
                          to mid-range hunting conditions in open                 illuminated red dot                                                                                                                               •   Reticles: ZBR-1 / ZMOA-1 / #6 (plex)
                          terrain.                                            •   Reticles: #60 (plex) / ZMOA-4

Firearm Application                                                           Target Usage Application                                       Firearm Application                                                                    Target Usage Application

                                                            MODERN SPORTING                                                                     LO N G - R A N G E   LO N G - R A N G E
  MOUNTAIN            CLASSIC            SAFARI                RIFLE                                                                             HUNTING               TARGET                 VARMINT            SPECIALTY

26 | ZEISS                                                                                                            Hunting and Shooting   See page 73 for technical specifications and pages 68-71 for detailed reticle information.                                             ZEISS | 27
CCONQUEST
                                                                                                                     ONQUEST

Z E I S S CONQUE ST V4 RIFLESCOP ES
                                                                                                            FEATURES:
Performance oriented.                                                                                       Intelligent innovations for
                                                                                                            exceptional results:
Feature rich. Value packed.
The Conquest V4 riflescopes are for       There are several reticle options                                         T* Six-Layer Lens
hunters and shooters whose lifestyle      available. These include traditional                                      Multi-Coating
and adventures involve traditional        plex-style reticles, as well as the
and long-range hunting, as well as        newest ZMOA and ZBR MOA-based                                             LotuTec
shooting and long-range shooting.         smart reticles from ZEISS. Illuminated
These riflescopes were designed as        reticles are standard for the 4-16x50
                                                                                                                    90% Light
a lightweight, high-performance           models and optional for the 3-12x56                                90
                                                                                                                    Transmission
product line for various demanding        and 6-24x50 models. The 3-12x44
hunting and shooting applications.        model is non-illuminated.
They are by any standard best-in-class.                                                                             2nd Focal Plane

                                          A magnification throw lever and
The Conquest V4 family is based           ZEISS precision rings are available as                            4       4x Zoom
on a 4x zoom ratio, incorporates          optional accessories for the Conquest
a 30 mm main tube, and consists           V4 riflescopes.                                                           Waterproof up to
of the 3-12x44, 3-12x56, 4-16x44,                                                                                   400 mbar
4-16x50 and 6-24x50 models. Each
model delivers 90% to-the-eye light       The Conquest V4 models are backed
                                          by the ZEISS Limited Lifetime                                             Nitrogen Purged
transmission, offers .25 MOA or .50
MOA click values, capped windage          Transferable Warranty and Five-Year
adjustment, second focal plane            No-Fault Policy. These riflescopes serve
                                          a wide range of hunting and shooting                                      Illuminated
reticle designs, and a large range of
total elevation and windage travel        applications, are packed with unique
adjustment.                               features, perform beyond expectations
                                                                                                                    Lightweight
                                          in their price range and provide
                                          exceptional value. These features and
The 3-12x44 and 3-12x56 versions          options, combined with price, make                                        Capped Turret
come standard with capped elevation       this the most popular riflescope model
and windage turrets. The 4-16x44,         for ZEISS to date.
4-16x50 and 6-24x50 models have                                                                                     External Turret
external elevation turrets. Within the
Conquest V4 product line, all external
elevation turrets also include ZEISS                                                                                Multi-Turn Turret
Ballistic Stop feature to ensure an
absolute and positive return to zero
under any conditions.                                                                                               Ballistic Stop

                                                                                                                    1/4 MOA

                                                                                                             30
                                                                                                             mm     30 mm Main Tube

28 | ZEISS                                                                           Hunting and Shooting                   ZEISS | 29
CCONQUEST
                                                                                                                                                                                                                ONQUEST

PRODUCT HIGHLIGHT                                                                                               RETICLE OPTIONS:

Conquest V4
Heavy-duty optics for the demands of
hunting and shooting.                                                                                              Z-PLEX                     #60                    ZBR                    ZMOA                   ZMOAi-T

      Designed and Engineered                          Side Parallax Adjustment                                                             Optical Performance
      in Germany                                       For applicable models, 50 yards                                                      Higher definition glass, enhanced with T* light
      Absolute reliability: the mechanical             to infinity to ensure absolute best                                                  transmission coatings and LotuTec protective lens coating,
      systems stand the test of harsh recoil,          images and most accurate shooting                                                    produces 90% to-the-eye light transmission, great low-
      extreme temperatures and abusive                 solutions.                                                                           light performance and excellent target resolution across
      field conditions.                                                                                                                     the entire magnification range. When combined, these
                                                                                                                                            features and benefits create a best-in-class experience.

        Generous Eyebox                         Proven 4x Zoom                                                  External Elevation Turret                           Second Focal Plane Reticle Options
        The friendly and forgiving eyebox,      Relevant magnification                                          Easy to manipulate, positive, tactile and           Available with the traditional plex-style #60 illuminated
        coupled with abundant eye relief        ranges, with a 4x zoom                                          highly repeatable turret, with Ballistic            reticle and Z-Plex #20. Other reticles include the ZEISS
        and the wide field of view, affords     ratio, provide a high level                                     Stop and large range of adjustment,                 MOA-based smart reticles: ZBR and ZMOA. ZEISS has
        the shooter fast and full target        of versatility across a wide                                    provides the shooter with maximum                   introduced the newer ZMOAi-T20 and ZMOA-T30 thin
        acquisition, which helps to enable      array of applications.                                          flexibility needed for challenging                  line reticles. These reticles feature fine line subtensions
        swift and accurate shot placement.                                                                      targets, no matter how far down range.              to ensure minimum target coverage and maximum
                                                                                                                                                                    target visibility.

30 | ZEISS                                                                               Hunting and Shooting                                                                                                          ZEISS | 31
CCONQUEST
                                                                                                                                                                                                                                                                      ONQUEST

ZEISS Conquest V4
A lightweight, highly versatile riflescope
with a 4x zoom range.
                                                                                                                                           V4 4-16x44                      The balance between wide field of view and
                                                                                                                                                                           magnification range makes these compact
                                                                                                                                                                                                                               •
                                                                                                                                                                                                                               •
                                                                                                                                                                                                                                   Large elevation and windage adjustment range
                                                                                                                                                                                                                                   Multi-turn elevation turret with Ballistic Stop
                                                                                                                                              4-16x50                      riflescopes ideal for all types of hunting              (absolute and positive return to zero)
                                                                                                                                                                           and shooting. Offers mid- to long-range             •   Side parallax adjustment
                                                                                                                                                                           versatility.                                        •   Reticles: #20 Z-Plex (plex-style) / ZBR-2 / ZMOA-2 /
                                                                                                                                                                                                                                   ZMOAi-1 / ZMOA-T30 (respective to model)

                                                                                                                                           Firearm Application                                                                 Target Usage Application

                                                                                                                                              MOUNTAIN            CLASSIC                 VARMINT            SPECIALTY

                                                                                                                                              LO NG - R A NG E   LO NG - R A NG E        MODERN SPORTING
                                                                                                                                              HUNTING              TARGET                   RIFLE

V4 3-12x44               This riflescope is suitable for stand hunting
                         and for long-range shots. The large objective
                                                                            •
                                                                            •
                                                                                44 mm and 56 mm objective lens diameter
                                                                                Large elevation and windage adjustment range
                                                                                                                                           V4 6-24x50                      Offering up to 24x magnification and side
                                                                                                                                                                           parallax adjustment, this riflescope is ideal for
                                                                                                                                                                                                                               •
                                                                                                                                                                                                                               •
                                                                                                                                                                                                                                   Large elevation and windage adjustment range
                                                                                                                                                                                                                                   Multi-turn elevation turret with Ballistic Stop
   3-12x56               lens diameter and (optional) illuminated reticle   •   Capped elevation and windage turrets (multi-turn)                                          hunting, precision shooting and long-range              (absolute and positive return to zero)
                         guarantee aiming accuracy, even in low light.      •   Fixed parallax                                                                             applications.                                       •   Side parallax adjustment
                                                                            •   Reticles: #20 Z-Plex (plex-style) / #60 (illuminated                                                                                           •   Reticles: ZBR-1 / ZMOA-1 / ZMOAi-1 / ZMOAi-T20
                                                                                center dot) (respective to model)

Firearm Application                                                         Target Usage Application                                       Firearm Application                                                                 Target Usage Application

                                                                                                                                                                                         MODERN SPORTING
                                                                                                                                               CLASSIC            VARMINT                   RIFLE            SPECIALTY

   CLASSIC     VARMINT

                                                                                                                                              LO NG - R A NG E   LO NG - R A NG E
                                                                                                                                              HUNTING              TARGET

32 | ZEISS                                                                                                          Hunting and Shooting   See page 74 for technical specifications and pages 68-71 for detailed reticle information.                                         ZEISS | 33
VICTORY

                                    ZE I S S V I CTO RY BI N O C U LAR S
                                                                                                                      FEATURES:
                                    For the visionary.                                                                Intelligent innovations for
                                                                                                                      exceptional results:

                                    Discover new perspectives where             Even in the most challenging          Ultra-FL lens system:
                                    others see only limits. Demand              conditions, the construction of       Ensures natural color
                                    only the best from yourself, and            the Victory line of binoculars from   fidelity, high contrast,
                                    accept nothing less.                        ZEISS is amazingly robust.            brilliance and finest detail
                                                                                                                      rendition.
                                    These are our benchmarks for the            With ZEISS Victory binoculars in
                                    Victory line of binoculars from             your hands, you have everything       ZEISS FieldFlattener
                                    ZEISS.                                      in sight, whether in the darkest      technology:
                                                                                hours of night or at the most         Extreme edge sharpness,
                                    Once you’ve held a ZEISS Victory            extreme distances. The Victory        even with a wide field of
                                    binocular in your hands, you will           line offers the performance you       view.
                                    never want to give it back. Minute          expect from ZEISS while delivering
                                    details are perfected and thought           to you the optic experiences you      LotuTec coating:
                                    through to excellence. Innovative           demand.                               The dust-, dirt- and
                                    optical and mechanical systems                                                    water-repellent coating
                                    combine with superior ergonomics                                                  guarantees a permanently
                                    to deliver the uncompromising                                                     clear view.
                                    image that you expect: sharp,
                                    precise, clear.                                                                   Magnesium materials:
                                                                                                                      The combination of
                                                                                                                      extremely lightweight
                                                                                                                      and strong materials
                                                                                                                      guarantees quality that
                                                                                                                      lasts for generations.

                                                                                                                      *Smart Focus:
                                                                                                                      Optimum location of the
                                                                                                                      focusing wheel ensures
                                                                                                                      intuitive, fast and precise
                                                                                                                      focusing.

                                                                                                                      *ErgoBalance:
                                                                                                                      Perfectly balanced weight
                                                                                                                      distribution guarantees
                                                                                                                      fatigue-free observation.

                                                                                                                      *Triple-link bridge:
                                            Ultra-Fluoride                                                            Constructional stability
                                                                                                                      and robustness that stand
                                          and Fluoride Glass                                                          up to even the harshest
                                        Ensures a brighter viewing image                                              conditions.
                                       that delivers absolute color fidelity,
                                        brightness, high contrast and the
                                            finest resolution of details.

34 | ZEISS                          *Available in select Victory products.                                                           ZEISS | 35
             Hunting and Shooting
VICTORY

PRODUCT HIGHLIGHT

Victory RF Rangefinder
Range 11 - 2,500 yards right out of the box – and
into the field.

Ballistic Information System II
Store up to nine custom ballistic profiles. Onboard
sensors provide exact results for distance,
temperature, air pressure and angle to give you an
accurately compensated shooting solution.                   Angle   Temperature   Pressure

Compact Design, Better Ergonomics
Carry with comfort: only 32 oz (42 mm) / 39 oz
(54 mm). No humps or indentions. Large buttons,
located right where you need them, with R/L
switchable functionality. Focus wheel, close to the
index finger, allows you to focus with ease – even
with gloved hands.

Range Faster and Further
Fast, one-touch ranging – with either left or
right hand. Ranges upon release of the ranging
button, which ensures the utmost accuracy in
your rangefinding results.Features Scan and
Target modes. Displays holdover in inches/cm,
MOA, MIL and clicks.

Automatic LED Brightness Adjustment
The Victory RF features 11 brightness curves, which
adapt automatically to the exterior light conditions. Use
the standard setting, or increase/decrease the brightness
of the internal LED display based on your preference.

Bright, High-Resolution Images
Maximum optical performance thanks to Abbe-
Köenig prims, FL glass, ZEISS T* coating and LotuTec
Hydrophobic coating.

36 | ZEISS                                                                                   Hunting and Shooting        ZEISS | 37
VICTORY

                                                                                                                                             Victory RF
                                                                                                                                             Accurately engage your target.
                                                                                                                                             With an array of innovative features and unmatched optical performance, the Victory RF with Bluetooth
                                                                                                                                             technology presents the new benchmark in optoelectronic and connected range-finding binocular technology.

                                                                                                                                             •   Bluetooth connectivity                                                            •   User-programmable control buttons and display
                                                                                                                                             •   Range 11 to 2,500 yards                                                           •   One-touch ranging (right or left hand)
                                                                                                                                             •   Custom ballistic input via smartphone or tablet                                   •   Syncs personal settings and ballistic profiles to and from the RF
                                                                                                                                             •   B.I.S. II – Onboard ballistic calculator with integrated sensors                  •   Superior image quality, enhanced by FL glass, ZEISS T*
                                                                                                                                                 and ballistic profiles                                                                and LotuTec coatings
                                                                                                                                             •   Measures angle, temperature and air pressure                                      •   Compact, lightweight and user-friendly ergonomics
                                                                                                                                             •   Calculates accurate shooting solutions                                            •   Large focusing wheel for minimal rotation
                                                                                                                                             •   Displays holdover in inches/cm, MOA, MIL and clicks                               •   High-grade magnesium frame with double-link bridge
                                                                                                                                             •   Features Scan and Target modes                                                    •   Rugged and waterproof
                                                                                                                                             •   Automatic LED brightness adjustment (11 brightness curves)                        •   Remote software updates via Bluetooth and ZEISS Hunting App

PRODUCT HIGHLIGHT                                                                                                                            Visual representation
                                                                                                                                             of the Victory RF                  con_                           conn
                                                                                                                                                                                                                                                                            427
Victory RF and ZEISS Hunting App                                                                                                             (VRF) display.

Customize it and take it to the next level.                                                                                                                          VRF is attempting to connect to
                                                                                                                                                                         the ZEISS Hunting App.
                                                                                                                                                                                                              VRF is paired
                                                                                                                                                                                                       to the ZEISS Hunting App.
                                                                                                                                                                                                                                              VRF ranging.               Range result.

Utilizing its Bluetooth capability to synchronize with the ZEISS
Hunting App, the Victory RF creates the perfect range-finding
                                                                       The Bluetooth feature enables automatic factory device updates,
                                                                       which always ensures the highest performance, based upon the
                                                                                                                                             RF 8x42                     The lightweight and compact 42 mm rangefinder
                                                                                                                                                                         models allow maximum mobility with connectivity.
system. Nine custom ballistic profiles can be transferred from the     latest state-of-the-art research and development at ZEISS.              10x42                     The real-time ballistics system of the Victory RF can
app and stored onboard the Victory RF binocular. The user can                                                                                                            be synchronized with the ZEISS Hunting App via
then define and set their personal preferences for the ranging and                                                                                                       Bluetooth. The 42 mm represents the ideal carry size.
ballistic data output on the LED display. The app is also useful for
configuring other features, such as right- or left-handed operation
or adjusting the display brightness.

ZEISS HUNTING APP
                                                                                                                                             RF 8x54                     In addition to the above features, this rangefinder
Features at a glance.                                                                                                                          10x54
                                                                                                                                                                         comes with a larger 54 mm objective diameter. This
                                                                                                                                                                         model is for users who demand the highest light
                                                                                                                                                                         transmission in extreme low-light conditions.
       News                                                Field Notes                                    My Gear

       Dashboard                                           Weather Data                                   Hunting Grounds

       Ballistic Calculator                                Connected Products

38 | ZEISS                                                                                                            Hunting and Shooting   See page 75 for technical specifications.                                                                                                    ZEISS | 39
VICTORY

                                    ZEISS VICTORY SF

                                    Our best binoculars
                                    for hunting and shooting.
                                    There is something legendary about ZEISS binoculars.                        The Victory SF allows you to experience the most exciting
                                    Founded on exceptional optical performance,                                 hunting moments as never before. The optical perfection,
                                    outstanding ergonomics and robust construction, our                         the unparalleled field of view, the revolutionary ergonomics
                                    innovations have constantly expanded the limits of                          and the ultra-light design make these the best all-purpose
                                    what’s technically possible.                                                binoculars ever built by ZEISS.

                                    No wonder generations of hunters and shooters swear by their                Experience the ZEISS Victory SF as the most versatile
                                    ZEISS binoculars. ZEISS binoculars are heirloom-quality products            premium binoculars in the company’s 165-year history.
                                    that are passed down from generation to generation, together
                                    with the stories that came with them.

                                    Time never stands still.

                                    SF 8x42                     • Perfect ergonomics
                                                                • Lightweight – only 27.5 oz
                                      10x42                     • Unparalleled field of view:
                                                                  444 ft (8x) / 360 ft (10x) at 1,000 yds
                                                                • Ultra-FL lens system

                                    ErgoBalance                                                             Ideal Weight Distribution

                                    The Victory SF anatomy takes into account human anatomy,                  less weight      weighted light
                                    which allows for our best fatigue-free binocular design. Its unique                                         heavy
                                    ErgoBalance concept provides the ideal weight distribution
                                    and balance. The perfect ergonomics allow for hours of steady
                                    observation without fatiguing the arms and eyes.

                                                                                                                            Beim ZEISS VICTORY SF wurde der Schwerpunkt des Glases be-    Dank ErgoBalance-Concept liegt das Fernglas
                                                                                                                            wusst zugunsten einer besseren Ergonomie und eines besseren   der Hand und gestattet ein langes, ruhiges B
40 | ZEISS   Hunting and Shooting   See page 76 for technical specifications.                                               Tragekomforts in Richtung Okulare verschoben.   4                ZEISS | 41werden dabei wen
                                                                                                                                                                                          und Unterarmmuskeln    6
VICTORY

PRODUCT HIGHLIGHT

Victory SF
The most premium binoculars in the
history of ZEISS.
                                                          More Portable
                                                          Feather-light design
  More Robust                                             and ultra-light
  Robust construction and ergonomic                       magnesium materials.
  design: TripleLink bridge. Unmatched
  craftsmanship and optical design:
  made in Germany.

  Wider
  Widest field of view in
  its class: 444 ft or 360
  ft at 1,000 yds.

                                                                                                                                                                  Closer
                                                                                                                                                                  Never miss a detail:
                                                                                                                                                                  5 foot close-range focus.
                                                                                                                                                                  4-click eyecup adjustment.
      Sharper
      Natural colors and brilliant
      details: Ultra-FL concept.
                                                                                                                                               More Ergonomic
                                                                                                                                               Hours of fatigue-free observation:
                                                                                                                                               lightweight at 27.5 oz. Ideal weight distribution
                                                                                                                                               for a steady hand: ErgoBalance concept.

             Brighter                                                                                   Faster
             Maximum brightness that extends your                                                       Focus at varying distances quickly
             day in the field: 92% light transmission.                                                  and intuitively: SmartFocus
             Outstanding image quality: fluoride lenses                                                 concept. Precise operation and
             made with SCHOTT glass.                                                                    natural grip in ideal hand position:
                                                                                                        anti-slip focusing wheel.

42 | ZEISS                                                                       Hunting and Shooting                                                                                              ZEISS | 43
VICTORY

                                                                                                        HT 8x54                     ZEISS Victory HT binoculars with 54 mm objective
                                                                                                                                    lenses are among the most powerful low-light
                                                                                                          10x54                     hunting binoculars from ZEISS. With 95% light
                                                                                                                                    transmission, these binoculars guarantee maximum
                                                                                                                                    performance at dusk and dawn.

                                                                                                                                    • SCHOTT HT glass with 95% light transmission
                                                                                                                                      provides a significant increase in image
                                                                                                                                      brightness.
                                                                                                                                    • FL concept ensures maximum image sharpness.
                                                                                                                                    • Comfort-Focus concept yields perfect ergonomics
PRODUCT HIGHLIGHT
                                                                                                                                      with effortless use.

ZEISS Victory Binoculars
Dominate the twilight hours.                                                                            FL 8x32                     Fluoride lenses (FL) minimize color fringing and
                                                                                                                                    ensure superior edge sharpness. The user enjoys a
                                                                                                          10x32                     sharp image with the finest resolution of details. In
                                                                                                                                    addition, the compact size and lightweight design
                                                                                                                                    make them ideal for prolonged observation.
Victory HT
                                                        Form Follows Function                                                       • FL glass produces superb images with neutral
                                                        The large focusing wheel of the Comfort-Focus                                 color rendition.
                                                        concept ensures superior handling ergonomics,                               • Amazing low-light performance
                                                        even when wearing gloves.                                                   • Wide field of view: 360 ft at 1,000 yds

     A Brighter
     Outlook
     The ZEISS Victory HT is
     not simply bright; the
     integration of FL lenses
     brings outstanding
                                                                                                        Pocket                      The Victory Pocket promises high performance
                                                                                                                                    in all kinds of outdoor applications. Despite the
     brilliance to the                                                                                    8x25                      incredible lightweight construction, their high
     viewing image.
                                                                                                         10x25                      magnification and FL lenses with the ZEISS T*
                                                                                                                                    multi-layer coating help them to deliver brilliant
                                                                                                                                    image quality. The asymmetrical folding makes it
                                                                                                                                    particularly compact.

                                                                                                                                    • Exceptionally compact and robust
                                                                                                                                    • Excellent optical performance
                                                                                                                                    • Modern and ergonomic design

             Built to Last a Lifetime
             The use of magnesium alloys,
             combining low weight with high
             rigidity, guarantees a long and reliable                                                                                                          Illustration represents      Illustration represents product
                                                                                                                                                               product in use.              folded for transport.
             service life.

44 | ZEISS                                                                  Hunting and Shooting        See page 76 for technical specifications.                                                                   ZEISS | 45
CONQUEST

                                    PRODUCT HIGHLIGHT

                                    Conquest HD
                                    Optical excellence for your success.
                                    Nature never stops. And neither does ZEISS. This is especially true with Conquest binoculars – a revolution in
                                    design, ergonomics and optics. Made in Germany, these rugged binoculars combine traditional ZEISS quality with
                                    state-of-the-art technology. What does HD stand for: heavy duty or higher definition? At ZEISS, the answer is both.

                                                                         Compact & Lightweight                            Brilliant Close Focus
                                                                         Easy to use and comfortable in the hands         Precise focusing – even with gloves on

                                        LotuTec Lens
                                        Coating                                                                                    Best Ergonomics
                                        Sheds water, dirt, grease                                                                  Unique shape with special
                                        and grime – lenses clean                                                                   grip area for stability
                                        easily without smearing
                                                                               Razor-Sharp
                                                                               HD lens system with
                                                                               T* and dielectric prism
                                                                               coatings for clear,
                                                                               natural colors

46 | ZEISS   Hunting and Shooting                                                                                                                                  ZEISS | 47
CONQUEST

HD 8x32        Thanks to the extra-wide field of view of the HD
               lens systems, compact dimensions, low weight and
  10x32        carrying comfort, the Conquest HD 8x32 / 10x32
               is the ideal high-performance companion for every
               situation.

               • Compact and lightweight – perfect ergonomics
               • HD lens system
               • Fast and precise focusing – even with gloves on

HD 8x42      Made in Germany, these HD binoculars with 42
             mm objective diameter offer exceptional quality
  10x42      and performance. They are ideal for users who are                            HD 8x56                     The 56 mm models are the specialists for
                                                                                                                      situations in low-light conditions. They
             looking for sharpness, high resolution of details,
             natural color rendition and outstanding quality in
                                                                                            10x56                     impress with a bright, high-contrast viewing

             the close-focusing range.                                                      15x56                     image. The 15x56 is supplied standard with a
                                                                                                                      tripod adapter.

             • All-purpose binoculars
                                                                                                                      • Performs in extremely low light
             • HD lens system
                                                                                                                      • HD lens system
             • Designed and engineered in Germany
                                                                                                                      • Tripod adapter included with 15x model

48 | ZEISS                                                         Hunting and Shooting   See page 77 for technical specifications.                                       ZEISS | 49
TERRA

PRODUCT HIGHLIGHT
                                                                                                                        ED 8x32     Impressive images, precise focusing and compact

Terra ED                                                                                                                  10x32
                                                                                                                                    size are the main features of the 32 mm version of
                                                                                                                                    the Terra ED.

Perfect for every adventure.                                                                                                        • Award-winning German design and engineering
                                                                                                                                    • SCHOTT ED glass and ZEISS MC coatings
                                                                                                                                    • Compact and lightweight
Lightweight, compact and rugged – that’s the Terra® from ZEISS. Experience the legendary
ZEISS quality in a form focused on the essentials: ease of use, sturdiness and optical performance.

                                                               Ergonomic Handling
                                                               The large, smooth and easy-to-grip focus
                                                               wheel makes it incredibly fast and simple
                                                               to bring nature into focus.                              ED 8x42     A bright image, outstanding resolution of details,
                                                                                                                                    comfortable viewing characteristics and optimum
                                                                                                                          10x42     ease of handling make the Terra ED 42 mm
                                                                                                                                    outstanding in its class.

                                                                                                                                    • Bright, crisp image, even in low light
                                                                                                                                    • Quick and smooth focusing from 5.2 ft to infinity
                                                                                                                                    • SCHOTT ED glass and ZEISS MC coatings

Compact, Light
and Robust
With a fiberglass-                                                                                                      ED Pocket   In its class, the extremely lightweight and compact
                                                                                                                                    Terra ED Pocket delivers an outstanding viewing
reinforced, waterproof                                                                                                       8x25   experience and impresses with intuitive handling.
housing, ZEISS Terra ED
is built to withstand the
                                                                                                                            10x25
                                                                                                                                    • Extremely compact and lightweight
toughest conditions.                                                                                                                • Large field of view
                                                                                                                                    • 100% waterproof housing

     Proven Excellence
     SCHOTT ED glass with a
     hydrophobic multi-coating
     provides optical clarity and
     precision in all situations.
                                                                                                                                       Illustration represents product in use.            Illustration represents product folded for transport.

50 | ZEISS                                                                                       Hunting and Shooting                                                                                                                   ZEISS | 51
SPECIALTY

                                                                                                                                 Mono                          The 3x12 is a powerful mini-telescope with 3x
                                                                                                                                                               magnification. It transforms Victory* and Conquest
                                                                                                                                 3x12                          binoculars with objective lens diameters of 30
                                                                                                                                                               millimeters and larger into high-performance
                                                                                                                                                               spotting scopes just by attaching it to the eyepiece
                                                                                                                                                               with an adapter ring. Can also be used separately
                                                                                                                                                               as a magnifier in the close focus range.
                                                                                                                                                               *Not compatible with SF.

20x60 S         Superlative binoculars in every respect: these image-stabilizing binoculars were developed for the longest
                distances and used on missions to the International Space Station (ISS). The exceptional light transmission
                                                                                                                                 Monoculars                    For a precisely detailed view at sporting events, in
                                                                                                                                                               the theater or at longer distances outdoors, the
Image           of the Porro prism system guarantees the brightest images with outstanding resolution of details even at                                       Monos with ZEISS T* multi-coating impress with
                20x magnification. The technically unique mechanical image stabilization system of the 20x60 T* S ensures                                      a bright and clear image. Some models can also
Stabilization   a perfect optical experience; the unavoidable shake always encountered when observing with handheld                                            be used as stand-alone magnifiers for detailed,
                binoculars can be eliminated easily at the press of a button.                                                                                  close-up views.

52 | ZEISS                                                                                                Hunting and Shooting   See pages 78-79 for technical specifications.                                              ZEISS | 53
VICTORY

                                    ZEISS SPOTTING SCOPES

                                    Leading optical technology                                                          FEATURES:
                                                                                                                        Intelligent innovations
                                    to reveal the world around us.                                                      for exceptional results:

                                                                                                                        FL lenses:
                                    Curiosity. Passion. Pursuit.                                                        Natural color fidelity,
                                    The world of hunting and shooting          along with wide fields of view, reveal   high contrast, brilliance
                                    is about passion, no matter where          the world around us in extraordinary     and the finest detail
                                    you happen to be – in extreme              detail. Breathtaking magnification       rendition.
                                    environments like the Antarctic            brings your work close at hand.
                                    or the Amazon Basin and even in                                                     LotuTec coating:
                                    your own backyard. This is why so          These are the features that make         The dust-, dirt- and
                                    many people have discovered their          ZEISS spotting scopes favorites          water-repellent
                                    devotion for shooting and hunting.         around the globe. ZEISS provides         coating guarantees a
                                    It also explains why there are so          the quality that makes it easier for     permanently clear view.
                                    many different demands on the              people to engage the outdoors and
                                    optical equipment being used.              experience more moments of true          Dual-Speed Focus
                                                                               fulfillment every day.                   system:
                                    Spotting scopes from ZEISS fulfill                                                  Precise focusing with
                                    these demands in a variety of              Our online product guide will lead       automatic switch
                                    ways: the natural reproduction of          you step-by-step to the perfect ZEISS    between fast- and fine-
                                    colors, the finest rendition of details,   observation optics for your specific     focusing drive.
                                    outstanding brightness and contrast,       needs.
                                                                                                                        Magnesium materials:
                                                                                                                        The combination of
                                                                                                                        extremely lightweight
                                                                                                                        and strong materials
                                                                                                                        guarantees quality that
                                                                                                                        lasts for generations.

                                                                                                                        Objective body
                                                                                                                        magnification:
                                                                                                                        Unique to ZEISS
                                                                                                                        is relocating the
                                                                                                                        magnification ring from
                                                                                                                        the eyepiece to the
                                                                                                                        spotting scope body,
                                                                                                                        alongside the focus
                                                                                                                        wheel.

54 | ZEISS   Hunting and Shooting                                                                                                      ZEISS | 55
VICTORY

PRODUCT HIGHLIGHT

Victory Harpia                                                                                                                                 Elaborate Optical Design
                                                                                                                                                                                                                                    ComfortVision Concept
                                                                                                                                                                                                                                    An apparent field of view of 72° across the entire
                                                                                                                                                                                                                                    zoom range provides a noticeably larger overview

The most powerful performance.                                                                                                                 FL lenses and other specialty
                                                                                                                                               manufactured glass types ensure
                                                                                                                                                                                                                                    in the field.

                                                                                                                                               a razor-sharp viewing image with
                                                                                                       Objective Body                          natural color fidelity, even at
                                                                                                       Magnification                           maximum magnification.
                                                                                                       Subjective angle of view                                                             LotuTec Coating
                                                                                                       of 72° throughout the                                                                LotuTec hydrophobic lens
                                                                                                       entire zoom range for a                                                              coating provides a clear view
                                                                                                       noticeably greater overview                                                          in all weather conditions.
                                                                                                       of the terrain.                                                                      Raindrops and dirt simply roll
High-Performance                                                                                                                                                                            off the lens.
Eyepiece                                                                                                                                                                                                                            Field of view comparison between a spotting scope
Slim construction for a comfortable                                                                                                                                                                                                 set to the lowest magnification of 30x (inner circle)
viewing experience. Secure and                                                                                                                                                                                                      and the Harpia, set to the lowest magnification of
lockable bayonet mount.                                                                                                                                                                                                             23x (outer circle).

                                                                                                                                                                                                                                     ZEISS Victory Vario Eyepiece

                                      3x Power Zoom
                                      Smoothly change the magnification
                                      from 22-65x (Harpia 85) and 23-70x
                                      (Harpia 95).
                                                                                                                                                                                                                                     Designed to deliver an exceptionally wide field
                                                                                                                                                                                                                                     of view at all magnifications, the ZEISS Victory
                                                                                                    Dual-Speed Focus
                                                                                                                                                                                                                                     Vario Eyepiece, when paired with either the
                                                                                                    Precise focusing with automatic
                                                                                                                                                                                                                                     85 mm or 95 mm Victory Harpia spotting scope,
                                                                                                    gear switch between fast- and                                                                                                    presents users with a clear and crisp panoramic
                                                                                                    fine-focusing drive.                                                                                                             view from the predawn hours to well past dusk.

Harpia 95              The revolutionary optical system features a 3x wide-angle zoom, up to 70x magnification and an objective lens
                       diameter of 95 millimeters. The extremely wide fields of view prove their worth in every situation. The Harpia
                                                                                                                                           Harpia 85                   The Harpia 85 features many of the same advantages of the Harpia 95, but it has a lighter and slightly more
                                                                                                                                                                       compact chassis. The use of FL lenses and other specially formulated glass types allows the Harpia 85 to deliver
                       95 also features precise focusing. Convenient automatic transition from rapid- to fine-focus adjustment, even at                                an absolutely sharp viewing image with natural color fidelity – even at maximum magnification of 65x. The
                       high magnification, sets the Victory Harpia apart and places it well ahead of other premium spotting scopes.                                    subjective angle of view of 72° throughout the entire zoom range provides a noticeably greater overview of
                                                                                                                                                                       the terrain.

56 | ZEISS                                                                                                          Hunting and Shooting   See page 78 for technical specifications.                                                                                        ZEISS | 57
CONQUEST

PRODUCT HIGHLIGHT

Conquest Gavia 85
The explorer’s companion.
                                                                                       High-Detail Resolution
                                                                                       HD lens system for a bright and
                                                                                       clear viewing image.
                                                                                                                         Gavia 85
                                                                                                                         This spotting scope with an 85 mm objective
                            Ergonomic                                                                                    lens is particularly lightweight and compact.
                            Large focusing ring
                                                                                                                         This makes it the ideal instrument for close
Brilliant                   for precise handling.
                                                                                                                         and long-range observation, especially in
Roof prism system
                                                                                                                         difficult-to-access regions. A unique feature
designed for high
                                                                                                                         is the close-focus range, which makes the
optical precision.
                                                                                                                         observation of small, nearby targets an easy
                                                                                                                         task, while maintaining incredible image
                                                                                                                         quality.

Light
Magnesium body and
compact dimensions for
outdoor adventures.

                                                                                                                               Retractable
                                                                                                                               Sunshade

58 | ZEISS                                          Hunting and Shooting   See p. 78 for technical specifications.                                        ZEISS | 59
SPOTTING
                                                                                                                                                                                                     SPECIALTY
                                                                                                                                                                                                            SCOPE

PRODUCT HIGHLIGHT

Dialyt 18-45x65                                                                                                                                             Fast Target Acquisition
                                                                                                                                                            Enables observers to position, view
                                                                                                                                                            and focus instantly.
Dialyt       This light, compact field spotter was developed for
             fast and precise target identification at extreme
                                                                              Rugged Housing
                                                                              Waterproof, dustproof
18-45x65     distances. A waterproof, non-fogging construction,               and nitrogen filled to
             reliable functioning and simple handling make it the             prevent internal fogging
             ideal companion for hunting in flat, open country or
             in rugged, mountainous terrain.

                                   Compact Construction                                                              Tripod Connection                      Multi-layer Lens Coating
                                   Lightweight, compact design allows the                                            Dialyt can be mounted on a tripod      High light transmission for brigher, sharper
                                   Dialyt to fit comfortably in a backpack.                                          for comfortable, stable observation.   images, even in low light situations.

60 | ZEISS                                                                                    Hunting and Shooting                                                                                         ZEISS | 61
ACCESSORIES
                                                                            Image illustrates mounting of
                                                                            Conquest V4 riflescope with rings

          Bubble level                                        Aerial view                                   Product view by set

ACCESSORIES FROM ZEISS                                                                                                                    Rings – 36 mm Detachable
With Precision in Mind:                                                                                                                   For the Victory V8 riflescopes.
                                                                                                                                          Talley Signature Rings - 36 mm Low
                                                                                                                                                                                                     Order Number
                                                                                                                                                                                                       58 47 65

ZEISS Accessories for Riflescopes                                                                                                         Talley Signature Rings - 36 mm Med
                                                                                                                                          Talley Signature Rings - 36 mm High
                                                                                                                                                                                                       58 47 66
                                                                                                                                                                                                       58 47 68

ZEISS Precision Rings
ZEISS Precision Rings are manufactured to the highest of standards,                                                                       Throw Lever for Conquest V4 and V6
from premium materials, and with tight tolerances for your long-term                                                                      For fast magnification changes when speed is a critical factor.
safety and field applications.
                                                                                                                                          Throw Lever for                                            Order Number
                                                                                                                                          Conquest V4                                                  2224 168
Ultralight 1913 Mil-Spec Rings with Integral                                                                                              Conquest V6                                                  2224 899
Anti-Cant Level – Aluminum 7075-T6                     Order Number
For 30 mm tubes - Low (.850 in / 21.6 mm)                2309 905
For 30 mm tubes - Medium (1.0 in / 25.4 mm)              2309 906
                                                                                                                                          Flip-Up Cover for the Victory V8
For 30 mm tubes - High (1.18 in / 30 mm)                 2309 907
                                                                                                                                          This high-quality, extremely durable front lens cap is screwed into
For 30 mm tubes - X-High 1.375” / 34.9mm)                2345 660
                                                                                                                                          the lens filter thread and offers perfect protection in any weather
For 30 mm tubes - XX-High (1.5” / 38.1 mm)               2345 661
                                                                                                                                          conditions. It can be fixed in any position and is suitable for use by
For 34 mm tubes - Low (1.0” / 25.4 mm)                   2345 663
                                                                                                                                          left- and right-handed shooters. The field of view is not impaired,
For 34 mm tubes - Medium (1.125” / 28.5mm)               2345 664
                                                                                                                                          and handling while hunting is unimpeded.
For 34 mm tubes - High (1.375” / 34.9 mm)                2345 665
For 34 mm tubes - X-High (1.5” / 38.1 mm)                2345 666                                                                         Flip-Up Cover                                              Order Number
For 36 mm tubes - Medium (1.06 in / 27 mm)               2309 918                                                                         Victory V8 Flip-Up Cover 30 mm                               2152 898
For 36 mm tubes - High (1.22 in / 31 mm)                 2309 919                                                                         Victory V8 Flip-Up Cover 50 mm                               2105 737
                                                                                                                                          Victory V8 Flip-Up Cover 56 mm                               2105 798
                                                                                                                                          Victory V8 Flip-Up Cover 60 mm                               2173 926

62 | ZEISS                                                                                                         Hunting and Shooting                                                                                    ZEISS | 63
ACCESSORIES

ACCESSORIES FROM ZEISS

Binocular Accessories

Tripod Adapter 1/4”
                                                                                                                                Field Case for                     Order Number
This ZEISS tripod adapter is made to mount the Conquest HD or
                                                                                                                                Victory SF                           2060 069
Terra ED binoculars to a tripod. It is constructed from high-grade
                                                                                                                                Terra ED 32                          2196 165
magnesium and has a 1/4-20 female threaded connector on its
                                                                                                                                Terra ED 42                          2196 167
base.
                                                                                                                                Terra Pocket                         2197 806
Tripod Adapter                                               Order Number
                                                                                                                                                                                                                    Field Case for Terra ED
Tripod Mount 1/4“                                              52 83 88
                                                                                                                                                                                   Field Case for Victory SF
                                                                                     Tripod Adapter

Binofix Universal Tripod Mount
The universal adapter ensures that the ZEISS binoculars of 30 mm
objective sizes or larger can be mounted quickly and easily on
                                                                                                                                Cordura Bag                        Order Number
any type of tripod. This enables stable observation over longer
                                                                                                                                Conquest HD and Terra ED – 32 mm    2070 548
periods of time, even at extremely high magnifications. When
                                                                                                                                Conquest HD and Terra ED – 42 mm    1976 008
you use a tripod-mounted binocular with the triple boost of the
Mono attachment, you can enjoy a visual experience similar to that
provided by a spotting scope.
                                                                                                                                                                                  Field Case for Terra Pocket            Cordura Bag
Tripod Mount                                                 Order Number
Binofix Tripod Fixture – Suitable for All Binocular Models     52 83 87
                                                                            Binofix Universal Tripod Mount

                                                                                                                                Carrying Strap                     Order Number
Adapter for Magnification Attachment                                                                                            Air Cell Comfort Carrying Strap     52 91 13
In order to use the Mono 3x12 T* as a booster for your binoculars,
you need to attach it with an adapter.

Magnification Attachment Adapter                             Order Number
Victory FL/RF/HT & Conquest HD – Adapter for 3x12
      ®                       ®
                                                                                                                                Binocular Harness                  Order Number
                                                              52 83 77       Adapter for Magnification
Mono – Tripler – 32 & 42 mm                                                                                                                                                       Air Cell Comfort Carrying Strap   Binocular Harness
                                                                                                                                Binocular Harness (Standard)        49 00 90
Conquest® HD – Adapter for 3x12 Mono – 56 mm                  52 83 79             Attachment                                                                                                                           (Premium)
                                                                                                                                Binocular Harness (Premium)         52 91 15

64 | ZEISS                                                                                               Hunting and Shooting                                                                                                    ZEISS | 65
ACCESSORIES

ACCESSORIES FROM ZEISS

Spotting Scope                                                                                                                                                                                                             Carbon Fiber Tripod
                                                                                                                                                                                                                           The ZEISS tripod professional fulfills the most demanding
Accessories                                                                                                                                                                                                                requirements with regard to compatibility and loading weight,
                                                                                                                                                                                                                           and it enables smooth panning and tilting. It is particularly suitable
                                                                                                                                                                                                                           for use with our Victory products and for digiscoping.

                                                                                                                                                                                                                           Maximum Height                                   72.4 in
                                                                                                                                                                                                                           Minimum Height                                   24.8 in
                                                                                                                                                                                                                           Length (unextended)                              27.5 in
                                                                                                                                                                                                                           Weight                                           5.4 lb

                                                                                                                                                                                                                                                                                       Order Number
                                                                                                                                                                                                                           ZEISS Tripod Professional                                    21 69 972

Stay-On Case for Victory Harpia                                         1.25“ Astro Adapter                                                                                                                                Long Balance Plate                                           21 69 974

The case offers reliable protection against all kinds of weather and    For mounting standard astro eyepieces.
wet conditions, is comfortable to carry, and enables fast access
to the spotting scope for use. The caps for the eyepiece and the                                                                Order Number

objective lens can be securely attached to the case to prevent loss.    Conquest Gavia 85 Astro Adapter                          52 83 45

                                                         Order number
Victory Harpia 85 Stay-On Case                             2169 977
Victory Harpia 95 Stay-On Case                             2169 976
                                                                                                                                                                               ZEISS Tripod Professional                                               Long Balance Plate
Victory Harpia Eyepiece Pouch, Neoprene                    2164 352

                                                                                                                                                Cleaning Products
                                                                                                                                                ZEISS premium lens care products

                                                                        ZEISS Photo Adapter
                                                                        Whether for still photos or film, the photo adapter (for M49, M52
                                                                        or M58 filter threads) enables direct attachment of a digital camera
Stay-On Case for Conquest Gavia                                         to transform the spotting scope into a powerful telephoto lens.
Developed especially for the Conquest Gavia, this case protects the
spotting scope against environmental influences, such as moisture       Spotting Scope                                          Order Number

                                                                        Conquest Gavia 85 Photo Lens Adapter M49               52 83 48 9901
                                                                                                                                                ZEISS Lens Care Kit                              ZEISS Lens Cleaning Kit                                ZEISS 60 ct.
and dirt. In addition, optimum carrying comfort, fast access to the
                                                                                                                                                Compact enough to store in almost any            Bellows, dust brush, optic cleaning                    Box Lens Wipes
spotting scope for use, and an option for attaching the eyepiece        Conquest Gavia 85 Photo Lens Adapter M52               52 83 48 9902
                                                                                                                                                bag, this kit comes with a 2-ounce lens          solution (1 oz), microfiber cloth (18x18               Includes: 60 individually packaged
and objective lens cap to the case make it an invaluable part of the    Conquest Gavia 85 Photo Lens Adapter M58               52 83 48 9903    cleaning spray bottle and a microfiber           cm) and 10 wet wipes.                                  pre-moistened lens cleaning wipes.
equipment.                                                              Victory Harpia Photo Lens Adapter M49                  52 83 57 9901    cloth.
                                                                        Victory Harpia Photo Lens Adapter M52                  52 83 57 9902                                 Order Number                                           Order Number                                       Order Number
                                                         Order number
Conquest Gavia 85 Stay-On Cover                            2169 979     Victory Harpia Photo Lens Adapter M58                  52 83 57 9903    Lens Care Kit – 2 oz          2127 990           ZEISS Lens Cleaning Kit             2096 685           ZEISS 60 ct. Box Lens Wipes      2127 721

66 | ZEISS                                                                                                               Hunting and Shooting                                                                                                                                         ZEISS | 67
RETICLES

ZEISS RETICLES                                                                                                                                                                       RETICLE TYPE                                         RETICLE #

Second Focal Plane                                                                                                                                       E                           ZBR-1                                                        91
                                                                                                                                                                                 A
                                                                                                                                                                                     NON-ILLUMINATED
Reticles                                                                                                                                                 C                           RIFLESCOPE(S)       CONQUEST
                                                                                                                                                                                                         V6 5-30x50
                                                                                                                                                                                                                       CONQUEST
                                                                                                                                                                                                                       V4 3-12x44
                                                                                                                                                                                                                                           CONQUEST
                                                                                                                                                                                                                                           V4 6-24x50
                                                                                                                                                                                     Magnification       @ 25x         @ 12x               @ 24x
                                                                                                                                                   A B                                                   MOA           MOA                 MOA
                                                                                                                                                                       D             Distance A          1             1                   1
                                                                                                                                                                                     Distance B          5             5                   5
                                                                                                                                                                                     Distance C          20            20                  20
                                                                                                                                                                                     Distance D          4             4                   4
                                                                                                                                                                                     Line Thickness E    0.14 @ 25x    0.14 @ 12x          0.14 @ 24x

                                         RETICLE TYPE                                     RETICLE #                                                                                  RETICLE TYPE                                         RETICLE #
                                                                                                                                                                                 A
                                         Plex-Style                                                6                                                     E                           ZBR-2                                                       92
                     A
                                         NON-ILLUMINATED                                                                                                                             NON-ILLUMINATED
                                                                                                                                                             C                       RIFLESCOPE(S)       CONQUEST V6             CONQUEST V4
                                                            CONQUEST V6           CONQUEST V6
                                         RIFLESCOPE(S)
                                                            3-18x50               5-30x50                                                                                A                               3-18x50                 4-16x44
                                                                                                                                                                                     Magnification       @ 18x                   @ 16x
                                         Magnification      @ 18x                 @ 30x
                                                                                                                                                     B               D                                   MOA                     MOA
                         D       B                          MOA                   MOA
                                                                                                                                                                                     Distance A          2                       2
                                         Line Thickness A   0.21                  0.10
                                                                                                                                                                                     Distance B          10                      10
                                         Bar Thickness B    0.96                  0.58
                                                                                                                                                                                     Distance C          20                      20
                                         Dot Size C         N/A                   N/A                                                                                                Distance D          4                       4
                                         Opening D          13.41                 8.08                                                                                               Line Thickness E    0.19 @ 18x              0.19 @ 16x

                                         RETICLE TYPE                                      RETICLE #                                                                                 RETICLE TYPE                                         RETICLE #
                                                                                                                                                                                 C
                                         Z-Plex                                                   20                                                                                 Mil-Dot                                                     43
                                                                                                                                                                                     RIFLESCOPE(S)                     VICTORY V8
                                         NON-ILLUMINATED                                                                                                                                                               4.8-35x60
                                         RIFLESCOPE(S)      CONQUEST      CONQUEST        CONQUEST                                                                                   Magnification                     @ 30x
                                                            V4 3-12x44    V4 3-12x56      V4 4-16x44                                                     A
                     A                                                                                                                                                                                                 cm / 100 m
                                         Magnification      @ 12x         @ 12x           @ 16x
                                                                                                                                                                                     Line Thickness A                  0.3 @ 30x
                             D   B                          MOA           MOA             MOA                                                                    D           B       Bar Thickness B                   1.7
                                         Line Thickness A   0.17          0.17            0.13
                                                                                                                                                                                     Distance Between Dots             10
                                         Bar Thickness B    0.95          0.95            0.71
                                                                                                                                                                                     Dot Size C                        1.3
                                         Dot Size C         N/A           N/A             N/A                                                                                        Opening D                         50
                                         Opening D          16.6          16.6            12.5                                                                                       Illuminated Center Dot            0.24

                                         RETICLE TYPE                                     RETICLE #                     (continued from page 68)                 RETICLE #
                                     C                                                                                                                                                                                                C
                                         Plex-Style w/ Dot                                        60                                                                  60
                     A                   ILLUMINATED                                                                                                                                                    A
                                         RIFLESCOPE(S)      VICTORY V8            VICTORY V8            VICTORY V8   VICTORY V8      CONQUEST V6         CONQUEST V4
                                                            1-8x30                1.8-14x50             2.8-20x56    4.8-35x60       1-6x24              3-12x56
                                         Magnification      @ 8x                  @ 14x                 @ 20x        @ 35x           @ 6x                @ 12x
                         D       B                          MOA                   MOA                   MOA          MOA             MOA                 MOA
                                                                                                                                                                                                              D              B
                                         Line Thickness A   0.45                  0.24                  0.17         0.10            0.58                0.34

                                         Bar Thickness B    1.86                  1.07                  0.76         0.41            2.85                1.72

                                         Dot Size C         0.31                  0.17                  0.12         0.07            0.41                0.24

                                         Opening D          30.08                 17.19                 12.03        6.88            40.05               24.07

68 | ZEISS                                                                       Hunting and Shooting                                                                                                                                     ZEISS | 69
You can also read
