Products & Services
2018
FIBERCORE FIBERCORE
Contents SECTION PAGE
6 PM Fiber for Fiber Optic Gyros, Sensors, Telecoms, 46
EDFAs and All Fiber Polarizers
SECTION PAGE Standard PM Fiber 48
Polyimide Coated PM Fiber 49
1 About Fibercore 6-9 Telecoms PM Fiber 50 - 51
PM Gyro Fiber 52 - 53
2 Sectors Pure Silica Core PM Fiber 54
Harsh Environment 10 - 11 Zing™ Polarizing Fiber 55
Aerospace & Defence 12 - 13
Energy & Infrastructure 14 - 15 7 Spun Fiber for Current Sensors, Current Transformers 56
Biomedical 16 - 17 and Faraday Effect Sensors
Telecommunication 18 - 19 Spun HiBi 58
Industrial (Process Monitoring) 20 - 21
Fiber Lasers and Amplifiers 22 - 23 8 Doped Fiber for Amplifiers and Lasers 60
Industry, Application and Product Guide 24 - 25 Erbium Doped Fiber IsoGain™ 62 - 63
Erbium Doped Fiber AstroGain™ 64
3 SM Fiber for Harsh Environments (Hermetic Carbon and High 26 PM Erbium Doped Fiber 65
Temperature), Ultra Bend Insensitive, RGB and Near Infra Red Triple-Clad Doped Fiber 66
SM Fiber For Visible RGB Through To Near IR 28 - 30 Dual Clad Erbium/Ytterbium Doped Fiber 68
High Temperature Acrylate Coated SM Fiber 31 Isolating Wavelength Division Multiplexer CP-IWDM 69
Polyimide Coated SM Fiber 32 - 33 Other Doped Fibers 70
Dual Band Carbon Coated SM Fiber 34 OEM Amplifier GainBlock 71
Dual Band Bend Insensitive Fiber 35
Pure Silica Core SM Fiber 36 - 37 9 Passive Cladding Pumped Fiber for Fiber Lasers, 72
Cladding Pump Amplifiers, Combiners and CATV/FTTx Systems
4 Photosensitive Fiber for FBGs for use in Temperature, Strain 38 Low Index Double Clad Passive Fiber 74
and Biomedical Sensors and Telecoms Components All Silica Double Clad Fiber 75
Boron Doped Photosensitive Fiber 40
Highly Germanium Doped Fiber 41
5 Multicore Fiber for Medical Shape Sensing, Data Center 42
Transmission Cables and Temperature/Strain Sensors
Multicore Fiber 44
Fan Outs 45
FIBERCORE
SECTION PAGE
10 Multimode Fiber for Harsh Environments (Hermetic Carbon 76
and High Temperature)
Graded Index Multimode Fiber 78
Graded Index Multimode Pure Silica Core Fiber 79
Large Core Fiber 80 - 81
11 Fiber Bragg Gratings 82
FBGs 83 - 84
12 Complementary Products 86
Fiber Optic Cables 88 - 93
• Downhole Fiber Optic Cable 89
• Slickline Fiber Optic Cable 90
• Wireline Fiber Optic Cable 91
• Fiber In Metal Tube 92
• Wire Armored Metal Tube 93
Ruggedized Sleeving and Buffering 94
Pigtails and Patchcords 95
Fibercore Fiber Cleavers 96
Coreless Fiber 97
Quarter Wave Plate Fiber 98
13 Additional Services 100
14 Fibercore's Commitment 102
15 A-Z of Acronyms 103
16 Global Representatives Inside Back
Cover
SECTION 1
About Fibercore Heritage
1982 Spun Low-Birefringence Fiber 2002 50µm, Low-Loss And Highly
Bend-Insensitive Single-Mode Fiber
Fibercore has delivered over 35 years of innovation 1983 Bow-Tie Polarization Maintaining Fiber 2009 Pure-Silica Core Single-Mode Fiber
and excellence at the top of its profession, developing And Zing™ Polarizing Fiber For Use In UV-Visible Applications
and manufacturing specialty optical fibers.
1987 Neodymium Doped Fiber 2010 Re-Introduction of Improved Zing™
Polarizing Fiber
The company continues to embody the spirit The applications include Oil & Gas, Fiber Optic
of innovation, technical excellence and quality, Gyroscopes (FOGs), fiber optic hydrophones, 1988 Erbium Doped Fiber 2012 Re-Introduction of Improved Spun
which has seen it flourish through the first three fiber lasers, fiber amplifiers (EDFAs), current Bow-Tie, Elliptically-Birefringent Fiber
decades of monumental changes in both sensors, embedded sensors, medical devices,
technology and its impact on society. government and corporate research agencies 1989 Spun Bow-Tie, 2013 High Temperature Coatings,
and fibers for next generation telecommunications Elliptically-Birefringent Fiber Pure Silica Core Fiber, Portfolio
Established in 1982, Fibercore was formed systems. The list just keeps on growing. for Oil & Gas Industry
as a spin-out from the world-renowned Optical 1993 Erbium-Ytterbium Co-Doped Fiber
Fiber Group of the University of Southampton, Fibercore’s acquisition of Fibertronix places 2014 Acquisition of Fibertronix.
to offer the specialty optical fibers developed emphasis on an extended range of MM and SM Multicore Fiber, Multimode Fiber,
at the University, commercially. fibers including graded index and pure silica core. 1998 Intrinsically Photosensitive Boron Through the Coating FBGs, Cables for
In addition, the development of new double clad Co-Doped Fiber Oil & Gas, Double Clad Passive Fiber
Since 2003, Fibercore has increased its and triple clad passive fibers extend our reach into
manufacturing capabilities ten-fold and the fiber laser and high power amplifier market. 1999 All-Silica, ‘Cladding Pump’ 2016 Completion Of Hydrogen Chamber
introduced ‘World-Class Manufacturing’ Continued advances in Fibercore’s Multicore fiber Rare-Earth Doped Fiber
philosophies to what was traditionally technology have resulted in the availability of new
viewed as a scaled-up laboratory process. Spun Multicore fiber for 3D shape sensing. 2017 Silicon Photonic Fiber
Our focus is firmly on the future, the recent Within FOG, further enhancements to birefringence TC Fiber
expansion of the sales, marketing and and coating package design have kept our High NA / High Bandwidth Fiber
development teams and the introduction of new market-leading HB-G range at the top of the
photonics engineers into our skill base enables performance tree.
us to continue our commitment to the specialty
fiber industry. For more information about Fibercore,
new products, career options visit us at
Fibercore products are used in an exceptionally Fibercore.com
broad and growing range of applications spread
throughout more than 50 countries.
6 WWW.FIBERCORE.COM WWW.FIBERCORE.COM 7
ABOUT FIBERCORE
Technical Partnership
The success of your project is all that Fibercore has the depth and breadth of experience and engineering expertise
in specialty fiber to make a real contribution to your project – from the very first
matters. Fibercore doesn’t just sell contact, through supporting you in the selection of exactly the right fiber, all the
way to on-time delivery and beyond. It is this exceptional level of intense, technical
specialty fibers - we’ll work with you, support that makes our customers return, year after year. We design the right
solution for your need beyond the 100+ pages of this brochure. And if we cannot
putting everything that we have learned assist you with anything, then we will say so and do our utmost to use our
unmatched knowledge to direct you towards someone who can.
in the Industry at your disposal.
1. Do you need 2. Discuss with our 3. Do you need 4. Finalize your 5. Is Fibercore the 6. What else do
specialty fiber? fiber engineers a sample? fiber selection right partner? you need?
• Have you got unanswered • Receive detailed feedback • Request a sample • SM Fiber • Over 30 years at the forefront • Fiber qualification
questions about fiber? and analysis • Request more in-depth data • Photosensitive of specialty fiber technology & reliability testing
• Would you like more support • Research in the industry's • Request a solution • Multicore Fiber • Purpose built state-of-the-art • Fiber test & measurement
from a fiber expert? online source of specialty • PM Fiber facilities • Fusion splicing
• Contact us fiber information - • Spun Fiber • ISO9001 quality • Hydrogen testing
Fiberpaedia™ • Doped Fiber • ISO14001 environment • Custom preform
• Passive Cladding Pumped • OHSAS18001 & fiber development
• Multimode Fiber health and safety • Custom & Multifiber
• Fiber Bragg Gratings • ISO10012 test and • Fiber calculator & EDF S/W
• Complementary measurement • Development projects
E: info@fibercore.com
T: +44 (0)23 8076 9893 www.fibercore.com/applications www.fibercore.com/ask
www.fibercore.com/ask www.fibercore.com/fiberpaedia www.fibercore.com/sample www.fibercore.com/products www.fibercore.com/facilities www.fibercore.com/calculator
8 WWW.FIBERCORE.COM WWW.FIBERCORE.COM 9
SECTION 2 - SECTORS SECTION 2 - SECTORS
Products ideally suited to O&G environments, Fibercore offers a variety of smaller clad diameter
Harsh Environment especially downhole, include single-mode and fibers with reduced diameter coatings with higher
multimode fiber with carbon high temperature numerical apertures to allow for superior
acrylate coating (pg. 78), pure silica core single- performance in these challenging devices; 50µm
mode and graded index pure core multimode with and 80µm single-mode fibers (pg. 30 & 33).
polyimide or carbon polyimide (pg. 36 & 79), fiber
Bragg gratings (FBGs) (pg.83) and fiber optic Chemical
cables (pg. 88-93). In some applications, optical fiber is conveyed into
The use of optical fiber sensors by the Oil & Gas, Nuclear, the area where optical sensing is desired. The fluid
Chemical Processing, Civil Engineering and Space Vehicle Cryogenic to convey the fiber can be detrimental to the optical
industries has grown dramatically over the past decade. For applications where temperatures will be below fiber coatings. Fibercore has suitable coatings
This growth can only accelerate and with it, the demand -60°C, standard telecommunications fiber will not to not only survive the conveyance of the fiber
for optical fibers capable of delivering their performance perform optically and a special polyimide coating but also to withstand the residual chemical
reliably in these challenging environments. is necessary. Liquid natural gas facilities environment that remains after the operation.
and pipelines, where temperatures can drop Pure silica core single-mode and graded index
to approximately -180°C, commonly use optical pure core multimode polyimide coated fiber
Typical telecommunications fiber is designed for communication links that go through such fiber for monitoring temperatures (DTS and/or DAS) (pg. 36-37 & 79) are ideally suited for harsh
benign environments in temperatures that range environments and are also used for a variety to look for signs of leakage. These optical fibers chemical environments. In addition, the single-
from -55°C to +85°C, degrading optically when of sensing applications such as distributed are housed in fiber optic cables to allow for mode fibers can have FBGs written into them
used outside of this temperature range temperature sensing (DTS) and strain sensing. protection of the fiber during placement of the as well and this area can be coated with chemically
and when in certain environments with hydrogen, Products ideal for a radiation environment include: cable. Deployment of optical fiber in cryogenic sensitive materials that will expand/contract in the
chemicals or radiation. Due to these factors, pure silica core single-mode (pg. 36-37) applications is typically in cable (pg. 88-93) presence of certain target chemicals. In this way,
special coatings are available to address a greater and graded index pure core multimode (pg. 79). and uses polyimide coated single-mode the fiber can become a distributed chemical
temperature range and to handle certain chemical and multimode fibers (pg.32 & 78). sensor. FBGs (pg. 83) and our pure silica core
environments. In addition, the glass chemistry Oil and Gas single-mode polyimide coated fiber (pg. 36-37)
must be modified to address environments The Oil and Gas (O&G) industry has been Acoustic/Seismic provide the components for this type of sensing.
with hydrogen or radiation. using downhole optical fiber in wells where In the O&G industry, fiber optic hydrophones
o
the temperatures can reach beyond 300 C and geophones are used to aid in the evaluation
Applications and where hydrogen is present. These fibers are of existing reservoirs and to search for new
used for distributed temperature (DTS) and reservoirs. In these devices, optical fiber is wound
Radiation (Nuclear and Aerospace) acoustic (DAS) sensing for frack monitoring and in a coil over a compliant mandrel at relatively small
There are multiple applications where optical fiber other process optimization, telemetry for downhole diameters, which is challenging if not impossible
is exposed to ionizing radiation such as nuclear tools, pressure sensing and for strain monitoring. for standard telecommunications fiber to maintain
power plants, nuclear storage facilities, space Fibercore offers coatings suitable for 150°C, 300°C guidance of the light. These sensors are either
applications and some research facilities like and beyond, along with a carbon coating over the lowered downhole into the oil or gas well for vertical
CERN’s Hadron collider or other high energy glass to prevent hydrogen ingress up to 150°C. seismic profiling (VSP), laid on the subsea floor for
physics/particle accelerators. Fibercore has both Above 150°C, Fibercore offers pure silica core ocean bottom seismic (OBS) or placed on the
single-mode and multimode fiber that has been single-mode fiber (pg. 36-37) and a graded index terrestrial surface for seismic profiling.
designed specifically to be minimally impacted by pure core multimode fiber (pg. 79) that has been
ionizing radiation. These optical fibers are used for designed and manufactured in a proprietary way
to minimize optical loss due to hydrogen exposure.
10 WWW.FIBERCORE.COM WWW.FIBERCORE.COM 11
SECTION 2 - SECTORS SECTION 2 - SECTORS
Space Environments Light Detection and Ranging (LiDAR)
Aerospace and Defence Space qualified FOGs: Primarily used for ultra-precise, 3-D distance
Radiation tolerant (RT) variants of both PM (pg. 52) measurement, LIDAR has many applications
and SM (pg. 36-37) fibers have been used in FOGs from atmospheric sensing, wind-shear detection,
deployed by most of the World's space agencies geological mapping, surveying in mines/quarries
for spacecraft and satellite use. The proprietary to obstacle detection in autonomous vehicles.
core and inner cladding formulation reduces Fibercore's EDF (pg. 62-67) and EYDF (pg. 68
radiation induced attenuation (RIA) by up to fifty & 70) active fiber products and matching passive
The fundamental benefits of lightweight, small size and times, when compared with conventional fibers. fibers (pg. 72) are ideally suited to use in LIDAR.
immunity from EMI have enabled optical fiber technology Fibercore products are delivering their performance
to gain widespread acceptance in Aerospace and Defence. in geostationary orbit, on the surface of Mars In-Flight Network and Entertainment Systems
Today, an ever growing list of applications for specialty and to the furthest reaches of our Solar System. Optical fiber has higher bandwidth and lower
fiber is topped by Fiber Optic Gyroscopes (FOG), Avionics, weight than copper cable and is ideally suited
LIDAR, Asset Monitoring, Sonar and Perimeter Security. Laser Communications: to avionics use, from flight systems through
Fiber lasers and amplifiers are now used to in-flight entertainment. Relatively short distances
increasingly in free-space inter-satellite and tend to favour the use of multimode (MM) fiber
The Aerospace and Defence (A&D) sectors were The sensing element in a FOG is typically satellite-to-ground communications. Fiber based (pg.76), including radiation resistant and bend
amongst the very first to embrace optical fiber a precision coil of PM fiber of between 100m Laser Communications Terminals (LCTs) offer insensitive variants. These fibers are ideal for the
technology. Originally this was for communications and 5,000m in length, depending on the degree reduced weight, lower power requirements tight bend-radii encountered in the increasingly
and now, increasingly for sensing. of precision required. FOGs can equal the and 100X faster data rates than comparable RF dense fiber environment of a typical airframe.
performance of the very best ring laser (RLGs) systems and are therefore ideally suited for satellite
A broad spectrum of A&D applications use and iron ('spinning mass') gyros, used in submarine and spacecraft deployment. Fibercore's Erbium Acoustic and Seismic Sensors
specialty optical fibers to enhance performance navigation. This offers reduced manufacturing Doped Fiber AstroGain™active fiber range (pg. 64) Fiber based 'listening devices', hydrophones and
and reliability from fiber optic gyroscopes (FOGs), costs, delivering true 'solid state' reliability of up has been developed specifically for this task. geophones are being used increasingly in marine,
through hydrophones, geophones, phased array to thirty times that of these competing technologies. submarine and terrestrial security. High strength
radar, avionics, perimeter and asset security Embedded Sensors / Asset Monitoring (300+ kpsi), very highly bend insensitive fibers
and LiDAR to inter-satellite communications. The entire optical circuit of a high precision FOG By embedding optical fibers into an airframe (pg. 28 & 41), often combined with FBGs (pg. 83)
may be formed using a range of fibers that have or other structure (with or without the inclusion are ideally suited to this class of sensor.
Applications been developed in unison to be fully compatible, of fiber Bragg gratings (FBGs) (pg. 83) that
delivering optimal performance with minimal effort. structure becomes 'smart', capable of sensing Perimeter and Border Security
Fiber Optic Gyroscope (FOG) its environment with respect to temperature, Both distributed acoustic sensors (DAS) and 3-axis
FOGs are interferometric sensors that make use FOG specific Fibercore products include: vibration, pressure, strain, shape etc. point sensing can deliver exceptional perimeter and
of the Sagnac effect to detect and measure • PM Gyro Fiber (pg. 52): Reduced diameter for These techniques were pioneered in the 1980s, border security. These are capable of detecting
rotation. They are used in navigation, stabilization sensing coils, delivering enhanced mechanical notably by McDonnell Douglas Aircraft Corporation and analysing footfall and pinpointing tunnelling
and positioning applications including ship and reliability and reduced package size and were also used by NASA in the development activity in real time. A number of police stations
aircraft navigation, helicopter, missile and gun-sight • Zing™ Polarizing Fiber (pg. 55): Single of adaptive wing aircraft. Fibercore's low have already been equipped with these systems,
stabilization, precision positioning of artillery polarisation fiber to increase PER and ultra-low profile fibers (pg. 30 & 52) with excellent results.
and satellite receivers to name but a few. • Erbium Doped Fiber IsoGain™ I-25H (pg. 63): are ideally suited to embedded use, particularly
High absorption EDF for ASE light sources when combined with specialized, harsh Fibercore has developed both cable (pg. 88)
• Fiber coils (upon request): Ultra high precision, environment coatings. and fiber solutions that are now being deployed
quadrupole-wound sensor coils in these applications.
12 WWW.FIBERCORE.COM WWW.FIBERCORE.COM 13
SECTION 2 - SECTORS SECTION 2 - SECTORS
Details of Current Sensor Architecture
Energy and Infrastructure Modulator
Delay Coil
Polarizer
Quarter
Wave Plate Spun HiBi
Light
Source
45o Splice 45o Splice
Coupler
The entire World is critically dependent upon the security
Mirror
and integrity of its transport, data and energy infrastructures.
Increasingly, it is fiber optic sensing technologies using
Detector
specialty optical fibers that are responsible for monitoring
these infrastructures to ensure their smooth running.
Infrastructure
This applies equally to the supply of energy, point within the network. These fiber optic current With optical fiber having the ability to be used 4. Embedding optical fiber into dams to monitor
distribution of internet data and the transportation sensors (FOCS), also known as optical current as a sensor or have sensors written into the fiber leakage via distributed temperature sensing
of people and goods. Optical fibers are widely transformers, are for optimizing the fiber optic directly, information can be gained on the health and monitoring strain either through
used throughout these industries with a growing Faraday effect to allow monitoring of current of a component or system remotely and over long FBGs or through Brillouin scattering
use of fiber optic monitoring of electrical power in high voltage power lines and transformers. lengths. Some examples are: for distributed strain.
distribution, structural health monitoring Fibercore’s spun fiber (pg. 58) is at the heart
and intrusion sensing. of products where high stability fiber design 1. Embedding optical fiber into power cables to 5. Using optical fiber at critical junctures on bridges
is critical to enable high accuracy current sensing. look for hot spots along the cable, which would to monitor movement and strain through
Applications The fibers allow highly sensitive and accurate indicate insulation breakdown or cable damage the use of FBGs (pg. 83) or Brillouin (pg. 29-30)
current sensing over a wide range of environmental and to maximize the potential of the insulated scattering for distributed strain.
Energy (for Oil & Gas see pg. 10) conditions, including: temperature variation and power cable by allowing increased current flow
As the smart grid develops, accurate and instant vibration, suitable for the rigors of real life up to the temperature rating of the cable. 6. Small fiber optic cables can be embedded into
information on the electrical power loading applications. In addition to the spun fiber within concrete structures allowing for monitoring of the
is required. Subsequently, fiber optic current the product, Fibercore’s PM fiber (pg. 48) for delay 2. Embedding fiber Bragg gratings (FBGs) (pg.83) concrete curing process via temperature (DTS)
sensors have been developed, which allow almost lines and Zing™ (pg. 55) for polarization control into wind turbine blades to monitor strain and (pg. 78) and strain (Brillouin (pg. 29-30)
instant measurement of the electrical current at any are used in combination to result in world-class to count the number of flex cycles to evaluate or FBG’s (pg. 83)) allowing the user to optimize
current sensors. component fatigue. the process.
Faraday Effect Current Sensor Schematic 3. Using radiation resistant optical fiber 7. LIDAR, Light Detection and Ranging, uses
(pg. 52-54 & 79), for use in communication specialty optical fiber for the transmission
and sensing (distributed temperature, of the light. LIDAR is being used for driverless
strain and point sensors) in nuclear storage cars and aerial mapping (pg. 62-63 & 66).
and operations facilities.
14 WWW.FIBERCORE.COM WWW.FIBERCORE.COM 15
SECTION 2 - SECTORS
Biomedical
The use of optical fiber in the Biomedical industry
has grown rapidly from simple light and image guides
and power delivery for cutting and cauterizing through
to next generation imaging, advanced diagnostics,
‘smart’ catheters and robotics. This escalation
in sophistication requires a greater need for more
refined specialty optical fibers.
With a full range of ultra violet (UV) (pg. 36), Applications Haptic Sensing Spectroscopy
visible and near-IR single-mode (SM) fibers Haptic sensing, or the ability to give touch feedback Spectroscopy is the technology of the dispersion
(pg. 28) in both polarization maintaining (PM) 3D Shape Sensing remotely, allows robotic surgery tools and of an object’s light into its component colours
(pg. 48) and non-PM variants, multicore (MCF) Vascular and interventional radiology (VIR) non-direct mechanically coupled tools to be used (i.e. energies). By performing this dissection
fiber (pg. 42), fiber Bragg gratings (FBGs) (pg. 83), requires imaging systems, such as X-rays with a greater dexterity. The use of Fibercore's and analysis of an object’s light, we are able to infer
small clad, high numerical aperture (NA) (pg. 30), or CT scanners, to assist with the guidance reduced cladding diameter fibers with FBGs allows the physical properties of that object such
and side hole fiber (upon request), Fibercore’s of angioplasty and catheter delivered stents. miniature strain sensors to be embedded within as luminosity, temperature, mass and composition.
range of advanced optical fibers are suitable However, through the use of Fibercore’s multicore the tool, which enables a signal to be returned This technology can be used in medical
for a wide range of biomedical applications. fiber with FBGs inscribed along the length, and converted into a mechanical feedback at the diagnostics such as blood sugar, pulse oximetry,
These fibers find use within in vivo and in vitro the need for constant imaging using these surgeon’s hands. This gives surgeons a natural feel neonatal research, urology, neurology and many
applications, ranging from medical probes techniques can be removed. The fiber is able when using such tools as if they were touching other biomedical applications.
to advanced microscopy techniques. to sense its own shape, enabling a 3D the soft tissue of the body directly.
Fibercore can offer coatings suitable for both reconstruction of the path it is taking within
EtO (ethylene oxide), autoclave and other the body in real time. Optical Coherence Tomography (OCT)
sterilization techniques. OCT is an optical imaging acquisition technique
Pressure Sensing that uses light waves to form images of translucent
The use of optical fiber in biomedical applications Twin hole (or side hole) fibers can be optimized or opaque materials. Images appear as either 2D
such as vascular intervention, ophthalmology, to be sensitive to the hydrostatic pressures or 3D layered cross-section of an optical scattering
cosmetic procedures and dentistry is increasing experienced within the body. This opens up various media. One of the most well known areas of OCT
with ever evolving, custom designed optical fibers. biomedical applications such as the precise imaging is for ophthalmology for retinal mapping.
Fibercore’s culture is to partner with our customers location and measurement of pressure fluctuations In ophthalmology, OCT measurements allow
to find creative solutions to provide the optical within an artery, which can be an indicator an ophthalmologist to thoroughly map and
performance desired in the most difficult of coronary artery disease (atherosclerosis). measure the thickness of the retina as well
of applications. as aide in the early detection, diagnosis and
treatment for retina disease and other conditions.
16 WWW.FIBERCORE.COM WWW.FIBERCORE.COM 17SECTION 2 - SECTORS SECTION 2 - SECTORS
fiber with a circular outer cladding and a petal Fused Taper Coupler Fibers
Telecommunication structure inner cladding (pg. 68). The all-silica Fused taper coupler performance and
design means it can be stripped, cleaved, spliced manufacturing yields can be optimized by utilizing
and recoated like a standard optical fiber, without Fibercore’s SM step index fibers, which do not
the need for low index recoat material. The circular have a fluorine ring, often used in telecoms fibers,
cladding ensures the fiber sits within V-grooves The 0.22 NA variant displays improved bend
centrally, avoiding problems associated with losses in comparison with the 0.15 NA version.
competing octagonal cladding structures.
The continual growth in bandwidth required to meet For mode mixing, the petal structure gives efficient Fused Taper Coupler Fibers
the increasing demands of an internet connected coupling of the pump light into the core of the fiber. Fused taper coupler performance and
society drives technical developments at the device For the new generation of even higher power manufacturing yields can be optimized by utilizing
and component levels. amplifiers, around 5W, Fibercore provides Fibercore’s SM step index fibers, which do not
a specialized fiber (pg. 66) also with a circular have a fluorine ring, often used in telecoms fibers,
These devices are required to become more Mini and micro EDFAs are popular for small clad design. which can introduce instabilities in the coupler
efficient, smaller in size and have wider bandwidth, package size C-band amplifiers, which requires manufacturing process.
whilst still driving performance forward. highly doped fibers, such as the I-15(980/125)HC, OEM Amplifier GainBlock Fibercore’s SM980(5.8/125) (pg. 28) dual window
Such requirements have driven specialty optical dramatically reducing the coil lengths.Higher As the splice recoating technology required fiber and SM1500 (pg. 29) fiber range are ideally
fibers into volume telecommunications markets. absorption and reduced cladding diameter fibers for double and triple clad fibers is different suited for coupler manufacturing.
such as I-25H(1480/80) give improved mechanical to a standard core pump fiber, Fibercore offers
Erbium Doped Fiber Amplifiers reliability, short lengths and excellent bend loss. a pre-assembled unit called an OEM Amplifier PM Fiber for Coherent
(EDFAs) GainBlock (pg. 71). This unit incorporates a WDM, Communications and Lyot
Erbium doped fibers (pg. 62-68) are the standard To address the needs of satellite-to-satellite and high power splices, cladding pumped gain fiber Depolarizers
choice for optical amplification. However, their satellite-to-ground communication, space grade and heat sinking to allow easy upgrade of lower Polarization maintaining (PM) (pg. 48) fiber is used
demands vary depending upon the application of erbium doped fibers have been developed: power amplifiers to higher power levels, without for coherent communications where the bandwidth
the amplifier. Low cost, C-band, low signal power, AG980H and AG980L (pg. 64). significant engineering investment. of a fiber is increased 100% by utilizing two
high efficiency amplifiers typically utilize erbium polarization states. Fibercore’s Telecoms PM Fiber
doped core pump fiber, such as the IsoGain™ High Power Amplifiers – Ytterbium Silicon Photonics (pg. 50) is designed to offer outstanding core
I-4(980/125) and I-6(980/125) (pg. 62). As power Erbium Doped Fiber Amplifiers Fibercore have developed extremely small core circularity and concentricity for excellent splice
level requirements increase, for example >400mW (YEDFAs) diameter fibers at 1550nm which are optimized for performance, whilst also ensuring low crosstalk
core pump power, high cut-off wavelength fibers direct coupling to silicon waveguides. These result between the polarization states. This range offers
provide better efficiency, such as I-4(980/125)HC. in 1550nm SM fibers with MFDs down to 3μm and PM fibers for 1550nm, 14XXnm, 1310nm
NAs up to 0.42, significantly reducing the insertion and 980nm.
With a growing demand to push the spectral losses between fiber and chip (pg. 29).
bandwidth of amplifiers, L-band amplifiers are Conversely, PM fibers are also used as Lyot
becoming more common. These would require High power amplifiers for telecoms and CATV Multimode Large Core Fibers depolarizers for depolarizing Raman amplifier
very long lengths of standard erbium doped fibers require double or triple cladding fibers, which Multimode pumps typically use fiber with a 105µm pumps. By splicing two specific lengths of PM
to be used. Where reduction of the total length allow the pump light directly into the cladding of the core diameter and a 125µm cladding diameter. fibers together with the stress axis offset by 45°,
is required, Fibercore offers highly doped fibers fiber, increasing its utilization. This in turn increases Fibercore offers three variants (pg. 80) of this an all-fiber depolarizer can be manufactured.
including: I-12(980/125)HC and I-15(980/125)HC the signal power level, allowing signals in excess standard pump fiber: MMSC(105/125)0.15 with The HB14XXT (pg. 51) fiber has been specifically
(pg. 63). of 1W to be used. Unique to the industry, a 0.15 NA, MMSC(105/125)0.22 with a 0.22 NA designed to offer the best-in-class birefringence,
Fibercore manufacture an all-silica double clad and MMSC(102/125)0.26 with a 0.26 NA. allowing short length depolarizers to be achieved.
18 WWW.FIBERCORE.COM WWW.FIBERCORE.COM 19SECTION 2 - SECTORS SECTION 2 - SECTORS
Fiber Bragg gratings (FBGs) (pg. 83) provide Temperature sensing
Industrial (Process Monitoring) a method of monitoring vibrations on mechanical Multimode (MM) and single-mode (SM) optical
structures, which can be indicative of wear or even fiber are used for continuous distributed
manufacturing error. These vibrations can be temperature sensing (DTS) to provide constant
monitored live and automatic warnings triggered thermal monitoring. Multimode based systems
when an abnormal vibration occurs. For mass have a sensing reach of ~30km, while single-mode
transportation devices, such as trains and aircrafts, have a reach of ~100km. To help improve the
this can save lives. For difficult to access industrial temperature range of the sensing, high temperature
Small size, lightweight, immunity from electromagnetic equipment, such as subsea pumps, this can acrylate coatings can offer continuous use
interference (EMI), high bandwidth and the ability to provide ensure repairs are scheduled only when they up to 150°C and polyimide coatings offer use
truly distributed measurements make fiber optic sensing the are due, avoiding costly recovery processes. up to 300°C. For more extreme temperature
optimum technology for many aspects of process monitoring. ranges, metal coatings such as gold can be used
Specialty fibers simply boost sensor performance and Structure of Interest to push beyond 300°C, for example in turbines.
enhance functionality over other technologies. These coatings, with the exception of metal
coatings, can also be used in conjunction with
Existing technologies today suffer from do not degrade the accuracy of the measurement. Fibercore’s femtosecond laser written high
electromagnetic interference (EMI), temperature PM fibers are available from visible to near infrared temperature FBGs, which give extended thermal
limitations or size constraints, all of which limit the (IR) wavelengths, offering various options range beyond standard FBGs.
accuracy or usability of such sensors. By utilizing depending on whether the application is an
optical fibers, these challenges can be avoided, interferometric, time of flight or other methodology. Interrogator
bringing additional sensing opportunities Sensing Cable
to industrial processes. Visible wavelength PM fibers, for example
HB450 and HB600 (pg. 48), are often used within Wind turbines provide an interesting example
Metrology interferometers where the distance measurement of using FBGs for not only condition and vibration
accuracy is better than the wavelength of the monitoring of the rotating parts, but also strain
light used. sensing along the blades. This allows active
feedback to correlate the blade pitch with the strain
For ultra-small probes, 80µm and 60µm cladding on the blades to enable optimized energy
diameter PM fibers are available in our PM Gyro conversion in light or heavy wind.
Fiber range (pg. 52). These allow for smaller cross
sections and improved mechanical lifetime when
deployed with extremely tight bends.
Image courtesy of Mahr
Condition Monitoring
Polarization Maintaining (PM) fibers, for example Movable parts are prone to wear and tear, which
Fibercore's HB range of highly birefringent fibers can result in catastrophic failure if they are not
(pg. 48), are extremely useful for measuring small repaired or replaced when damage is induced.
distances with high accuracy. The Bow-Tie stress Statistical distributions can be used to give
applying parts (SAPs) ensure the input polarization a probabilistic approach to maintenance but this
state is kept stable under vibration and temperature method would not avoid a catastrophic failure
changes, ensuring polarization dependant effects in the case of abnormal wear.
20 WWW.FIBERCORE.COM WWW.FIBERCORE.COM 21SECTION 2 - SECTORS SECTION 2 - SECTORS
The TC1060Y(10/125)0.08HD (pg. 66) Multimode Large Core Fibers
Fiber Lasers and Amplifiers is a ytterbium doped fiber designed for use Multimode pumps typically use fiber with a 105µm
in pulsed and CW fiber lasers. The composition core diameter and a 125µm cladding diameter.
is optimized to avoid the effects of photodarkening Fibercore offers three variants (pg. 80) of this
to ensure long lifetime and high reliability. standard pump fiber: MMSC(105/125)0.15 with
a 0.15 NA, MMSC(105/125)0.22 with a 0.22 NA
Passive Double Cladding Fibers and a MMSC(102/125)0.26 with a 0.26 NA.
Passive double cladding fibers (pg. 72) are The 0.22 NA standard variant displays improved
With the growing range of fiber lasers and high power designed to transport the single-mode (SM) signal bend losses in comparison with the 0.15 NA
amplifiers available today, there is a greater need for in the core and the pump light in the cladding from version, offering versatility to the fiber
specialty fibers, ranging from high power double or triple one location to another. These fibers are typically routing design.
cladding fibers through to highly complex polarizing, utilized in multimode pump combiners where the
Zing™ fibers. combined power of multiple multimode pumps Pre-Amplifier Fibers
are combined into the passive double cladding Depending on the fiber laser architecture,
These products require high quality manufacturing Fibercore’s triple-clad erbium/ytterbium fiber and transported to the active double or triple pre-amplifiers are often used to reduce the gain
to ensure outstanding reliability when used doped fibers (TC1500YHD) (pg. 66) cladding fiber. level required from the power amplifier in a MOPA
at extreme optical power levels and reassurance are designed as single-mode, high-power system. Fibercore offers a ytterbium doped,
that the manufacturing processes can scale CATV and telecommunications amplifier fibers. For the fiber laser industry, Fibercore has core pump fiber (pg. 70), DF1100 for a 1060nm
to meet the global demand of the market. The TC1500Y(6/125)HD offers a smaller developed the DC1060(10/125)0.08HD, which pre-amplifier and a full range of erbium doped
Fibercore’s position as the highest volume Mode Field Diameter (MFD) for higher efficiency offers a 10µm core diameter and a low NA of 0.08 fibers in the IsoGain™ range (pg. 62),
specialty fiber manufacturer enables us to address levels at output signal power around 1W. to enable compatibility to high power ytterbium but specifically I-15(980/125)HC offers a high
the fiber laser and amplifier market with high The TC1500Y(11/125)HD is designed for output doped fibers. For the telecoms industry, the absorption level to enable short fiber lengths.
quality technical products to enable the next signal power at 5W and above. DC1500(11/125)0.12HD and DC1500(6/125)0.21HD
generation of fiber lasers to ramp to high volumes. enable compatibility to 11µm and 6µm MFD PM and Polarizing Fibers
erbium/ytterbium doped active fibers. Fibercore offers a polarization maintaining (PM)
Triple Cladding Ytterbium/Erbium Single-mode doped core erbium doped fiber (pg. 65), DHB1500 with the
Doped Fibers To enable successful integration into components, ability to amplify and maintain polarization for PM
Low Index Coating
Fibercore’s new range of triple cladding fibers the passive double clad fibers have been fiber laser applications. As well as the doped fibers,
(pg. 66) are designed for fiber lasers and high designed to be compatible with pump combiner Fibercore offers passive PM fibers within the
First Cladding:
power CATV and telecoms amplifiers. Their unique Pure fused silica
manufacturing technology and have a germanium Telecoms PM Fiber range (pg. 50), suitable
triple cladding structure is designed to encapsulate doped core, making the fibers photosensitive for wavelengths from 980nm though to 1550nm
the mode mixing octagonal pump guide within Second Cladding: for fiber Bragg grating (FBG) inscription. and beyond. For applications that require a single
Fluorine doped fused silica
a circular outer cladding, enabling lower splice Subsequently, these fibers may be used polarization state, the HB-Z Zing™ (pg. 55)
losses and lower splice variability associated with Core as part of the main gain stage cavity of a laser polarizing fiber range can act as an all-fiber
Inner cladding
fibers with octagonal outer regions. This triple or as part of a Master Oscillator Power Amplifier distributed polarizer with variants at 1060nm
Index profile
Outer cladding
cladding structure also gives an additional mode Low index coating (MOPA) design. and 1550nm. To avoid Polarization Dependant
confinement structure to reduce the amount Gain (PDG), particularly in laser diode seeded
of pump light at the cladding-coating interface Fiber axis MOPA systems, Telecoms PM Fiber makes
to aid coating reliability. an excellent choice for use in Lyot depolarizers.
22 WWW.FIBERCORE.COM WWW.FIBERCORE.COM 23Multicore Fiber
Photosensitive
Pumped Fiber
Doped Fiber
Industry, application and product guide
Spun Fiber
Multimode
Cladding
SM Fiber
PM Fiber
Passive
(pg. 26)
(pg. 38)
(pg. 42)
(pg. 46)
(pg. 56)
(pg. 60)
(pg. 76)
(pg. 82)
(pg. 72)
FBGs
Fiber
Fiber
Oil and Gas Distributed Acoustic Sensing (DAS)
Distributed Strain Sensing (DSS)
Distributed Temperature Sensing (DTS)
Distributed Pressure Sensing (DPS)
Fiber Bragg Grating (FBG) Sensing
Cable and Umbilical Integrity Sensing
Telemetry Fibers
Chemical Sensing
Geophones
Hydrophones
Biomedical 3D Shape Sensing
Confocal Microscopy
DNA Sequencing
Flow Cytometry
Illumination
Medical Probes
Optical Coherence Tomography (OCT)
Spectroscopy
Telecommunications and CATV Erbium Doped Fiber Amplifiers (EDFAs)
High Power Erbium Doped Fiber Amplifiers (EDFAs)
Cable Television (CATV)
Raman Amplifiers
Active Optical Cables (AOC)
Data Transmission Cables
Quantum Cryptograph
Radiation Tolerant Erbium Fiber Amplifiers (EDFAs)
Space Division Multiplexing (SDM)
Components and Devices Couplers
PM Couplers
ASE Light Sources
Delay Lines
Lyot Depolarizers
Laser Diode Pigtails
Quarter Wave Plates
Modulators
Pump Combiners
Fiber Bragg Gratings (FBGs)
LIDAR
Industrial Faraday Effect Current Sensors
Embedded Sensors
Chemical Sensing
Temperature Sensing
Pressure Sensing
Lithography
Metrology
Remotely Operated Vehicles (ROVs)
Phase Doppler Anemometry (PDA)
Defence Fiber Optic Gyroscopes (FOGs)
Hydrophones
Perimeter Security Sensing
Aerospace
Tethered PlatformsSECTION 3 - SM FIBER
For ultraviolet, visible and near The SM range of fibers are offered with a range
IR transmission, EDFA pigtailing,
SM Fiber
of numerical apertures from 0.11 to 0.31.
sensors & tethered platforms The high NA variants reduce bend-induced loss
to levels dramatically below those of standard
The single-mode (SM) range of fibers has telecommunication fibers. Thus, allowing them
been designed to perform in a wide range to be used in diameters of 10mm or smaller.
For Harsh Environments, Ultra Bend of challenging applications offering wavelengths
between 488nm and beyond 1650nm. The high germania content fibers have
Insensitive, RGB and Near Infra Red considerably enhanced photosensitivity,
The SM-SC range of fibers both extends the making them ideal for the fabrication
range into the UV and also enables use in harsh of fiber Bragg gratings (FBGs).
environments. The fiber offers minimal photo-
darkening and reduced susceptibility to the A range of harsh environment coatings
effects of hydrogen ingression when compared are available, including carbon, polyimide
with conventional, germanosilicate cored fibers. and high temperature acrylate.
Ranges of specialty single-mode optical fiber:
SM Fiber For Visible RGB Through Dual Band Carbon Coated SM Fiber:
To Near IR: For harsh environments with medium to high
For visible and near IR transmission, EDFA temperature applications
pigtailing, acoustic sensors and depolarized
FOGs Dual Band Bend Insensitive Fiber:
Telecoms style bend insensitive fibers with
High Temperature Acrylate Coated specialty coatings
SM Fiber:
For medium to high temperature applications Pure Silica Core SM Fiber:
For hydrogen, radiation and UV applications
Polyimide Coated SM Fiber:
For embedded and high temperature applications
WWW.FIBERCORE.COM 27SECTION 3 - SM FIBER SECTION 3 - SM FIBER
Specifications continue
SM Fiber For Visible RGB 125μm diameter SM specialty fibers
Through To Near IR SM1500
(4.2/125) (6.4/125) (7.8/125) (9/125)
Operating Wavelength (nm) 1520 - 1650
450nm to 1750nm single-mode transmission Cut-Off Wavelength (nm) 1350 - 1520
Numerical Aperture 0.29 - 0.31 0.19 - 0.21 0.15 - 0.17 0.13 - 0.15
• 125/245μm fiber for SM transmission from 450nm - 1750nm Mode Field Diameter (μm) 4.0 - 4.5 6.0 - 6.8 7.4 - 8.6 8.5 - 9.9
• 80/170μm fiber for high reliability, small form-factor telecom components @1550nm @1550nm @1550nm @1550nm
• Ultra-low & low profile, bend-insensitive fiber for de-polarized FOGs, acoustic sensors Attenuation (dB/km) @1550nm ≤1.5 ≤0.5 ≤0.4 ≤0.35
& small form-factor sensor components Proof Test (%) 1, 2 or 3 (100, 200 or 300 kpsi)
• High NAs for enhanced bend-insensitivity Cladding Diameter (μm) 125 ± 1
• High Ge content offering intrinsic photosensitivity for FBG inscription without hydrogenation Core Cladding Concentricity (μm) ≤0.50 ≤0.75
Coating Diameter (μm) 245 ± 7
Typical applications: Coating Type Dual Acrylate
• Hydrophones/Geophones • DTS/DAS/DSS Operating Temperature (oC) -55 to +85
• Telemetry • Laser diode pigtails
• Down-link fibers • Biomedical probes
• FBGs • Couplers Silicon photonic fiber
Specifications SM1500ES(3/125)
125μm diameter SM specialty fibers Operating Wavelength (nm) 1510 - 1650
Cut-Off Wavelength (nm) 1400 - 1500
SM450 SM600 SM750 SM800 SM980 SM980 SM980 Numerical Aperture 0.38 - 0.42
(5.6/125) (3.7/125) (4.5/125) (5.8/125) Mode Field Diameter (μm) 4.0 - 4.5 @1550nm
Operating Wavelength (nm) 488 - 633 - 780 - 830 - 980 980 - 1550 Attenuation (dB/km) ≤30 @1550nm
633 780 830 980 Proof Test (%) 1 (100 kpsi)
Cut-Off Wavelength (nm) 350 - 500 - 610 - 660 - 870 - 970 Cladding Diameter (μm) 125 ± 1
450 600 750 800 Core Cladding Concentricity (μm) ≤0.3
Numerical Aperture 0.10 - 0.14 0.21 - 0.17 - 0.13 - Coating Diameter (μm) 245 ± 15
0.23 0.19 0.15 Coating Type Acrylate
Mode Field Diameter (μm) 2.8 - 4.1 3.6 - 5.3 4.5 - 6.5 4.7 - 6.9 3.4 - 4.0 4.2 - 4.9 5.3 - 6.4 Operating Temperature (°C) -55 to +85
@488nm @633nm @780nm @830nm @980nm @980nm @980nm
Attenuation (dB/km) ≤50 ≤15 ≤5.0 ≤5.0 ≤2.0 @980nm
@488nm @633nm @780nm @830nm
Proof Test (%) 1, 2 or 3 (100, 200 or 300 kpsi)
Cladding Diameter (μm) 125 ± 1
Core Cladding Concentricity (μm) ≤0.75 ≤1.0 ≤0.50
Coating Diameter (μm) 245 ± 7
Coating Type Dual Acrylate
28 WWW.FIBERCORE.COM WWW.FIBERCORE.COM 29SECTION 3 - SM FIBER SECTION 3 - SM FIBER
Specifications continued
High Temperature Acrylate
Reduced diameter SM specialty fibers
Coated SM Fiber
SM800(4.2/80) SM980(4.5/80) SM1250(5.4/80) SM1250(9/80)
Operating Wavelength (nm) 830 - 980 980 - 1550 1310 - 1550
Cut-Off Wavelength (nm) 660 - 800 870 - 970 1150 - 1250
Numerical Aperture 0.14 - 0.18 0.17 - 0.19 0.19 - 0.21 0.11 - 0.13 • High temperature acrylate coatings to withstand temperatures up to 150°C continuous
Mode Field Diameter (μm) 3.8 - 4.9 4.2 - 4.9 5.0 - 5.7 8.2 - 9.9 • Low profile, bend insensitive fibers for downhole seismic sensors, high temperature distributed
@830nm @980nm @1310nm @1310nm pressure sensors, temperature sensors, down-links and telemetry
Attenuation (dB/km) ≤3.0 @830nm ≤2.0 @980nm ≤1.0 @1310nm ≤2.0 @1310nm • Enhanced photosensitivity
Proof Test (%) 1, 2 or 3 (100, 200 or 300 kpsi)
Cladding Diameter (μm) 80 ± 1 Typical applications:
Core Cladding Concentricity (μm) ≤0.50 • Geophones • Fiber Bragg Gratings (FBGs)
Coating Diameter (μm) 170 ± 5 • DTS, DAS, DSS and DPS • Temperature sensors
Coating Type Dual Acrylate • Embedded sensors
Operating Temperature (oC) -55 to +85
Specifications
SM1500 SM1500 SM1500 SM1500 SM1500 SM1500
(4.2/50) (4.2/80) (5.3/80) (6.4/80) (7.8/80) (5.3/80)HT (6.4/80)HT (6.4/125)HT (7.8/125)HT (9/125)HT
Operating Wavelength (nm) 1520 - 1650 Operating Wavelength (nm) 1520 - 1650
Cut-Off Wavelength (nm) 1350 - 1520 Cut-Off Wavelength (nm) 1350 - 1520
Numerical Aperture 0.29 - 0.31 0.23 - 0.25 0.19 - 0.21 0.15 - 0.17 Numerical Aperture 0.23 - 0.24 0.19 - 0.21 0.15 - 0.17 0.13 - 0.15
Mode Field Diameter (μm) 4.0 - 4.5 5.0 - 5.6 6.0 - 6.8 7.4 - 8.6 Mode Field Diameter (μm) 5.0 - 5.6 6.0 - 6.8 7.3 - 8.3 8.5 - 9.9
@1550nm @1550nm @1550nm @1550nm @1550nm @1550nm @1550nm @1550nm
Attenuation (dB/km) @1550nm ≤2.0 ≤1.5 ≤0.8 ≤0.5 ≤0.35 Attenuation (dB/km) @1550nm ≤0.8 ≤0.5 ≤0.4 ≤0.35
Proof Test (%) 1, 2 or 3 (100, 200 or 300 kpsi)
Proof Test (%) 1, 2 or 3 (100, 200 or 300 kpsi) Cladding Diameter (μm) 80 ± 1 125 ± 1
Cladding Diameter (μm) 50 ± 1 80 ± 1 Core Cladding Concentricity (μm) ≤0.5 ≤0.75 ≤0.4
Core Cladding Concentricity (μm) ≤0.50 Coating Diameter (μm) 170 ± 5 245 ± 7
Coating Diameter (μm) 110 ± 6 170 ± 5 Coating Type High Temperature Acrylate
Coating Type Single Dual Acrylate Operating Temperature (℃) -55 to +150
Acrylate
Operating Temperature (oC) -55 to +85
30 WWW.FIBERCORE.COM WWW.FIBERCORE.COM 31SECTION 3 - SM FIBER SECTION 3 - SM FIBER
0.11NA 0.20NA
0.14NA 0.30NA
10000 Specifications continued
Polyimide 1000
Bend Induced Loss (dB/km)
100 SM1500 SM1500 SM1500 SM1500 SM1500
Coated SM Fiber 10 (4.2/50)P (4.2/80)P (5.3/80)P * (6.4/80)P * (7.8/80)P
1 Operating Wavelength (nm) 1520 - 1650
0.1 Cut-Off Wavelength (nm) 1350 - 1520
For embedded and high 0.01 Numerical Aperture 0.29 - 0.31 0.23 - 0.25 0.19 - 0.21 0.15 - 0.17
temperature applications 0.001 Mode Field Diameter (μm) 4.0 - 4.5 5.1 - 5.6 6.0 - 6.8 7.4 - 8.6
0.0001 @1550nm @1550nm @1550nm @1550nm
• Polyimide coated enabling survival 0 5 10 15 20 25 30 35 40 45 50 Attenuation (dB/km) @1550nm ≤3.0 ≤2.5 ≤1.5 ≤0.75 ≤0.7
at temperatures up to 300°C Coil Diameter (mm) Proof Test (%) 1 or 2 (100 or 200 kpsi)
• Ultra-low and low profile, bend insensitive Cladding Diameter (μm) 50 ± 2 80 ± 2
fiber for downhole seismic geophone Core Cladding Concentricity (μm) ≤1.0 ≤0.5 ≤0.5 ≤0.75
sensors and high temperature distributed Typical applications: Coating Diameter (μm) 71 ± 5 102 ± 5
pressure and temperature sensors • Downhole sensors Coating Type Polyimide
• Enhanced photosensitivity • Geophones Operating Temperature (°C) -55 to +300
• Maintains composite material strength • DTS, DAS, DSS and DPS * Special easier to strip polyimide coating available for window stripping, for applications such as FBGs.
when embedded • Embedded sensors
• FBGs
• Biomedical in vivo sensors
• High temperature sensors
Specifications
SM1250 SM1500 SM1500 SM1500 SM1500
(10.4/125)P * (4.2/125)P (6.4/125)P (7.8/125)P (9/125)P
Operating Wavelength (nm) 1260 - 1650 1520 - 1650
Cut-Off Wavelength (nm) 1190 - 1330 1350 - 1520
Numerical Aperture 0.11 - 0.14 0.29 - 0.31 0.19 - 0.21 0.15 - 0.17 0.13 - 0.15
Mode Field Diameter (μm) 9.6 - 11.2 4.0 - 4.5 6.0 - 6.8 7.4 - 8.6 8.5 - 9.9
@1550 @1550nm @1550nm @1550nm @1550nm
Attenuation (dB/km) ≤0.7 @1310nm ≤2.5 ≤0.75 ≤0.7 ≤0.6
≤0.6 @1550nm @1550nm @1550nm @1550nm @1550
Proof Test (%) 1 or 2 (100 or 200 kpsi)
Cladding Diameter (μm) 125 ± 1
Core Cladding Concentricity (μm) ≤0.75 ≤0.5 ≤0.75
Coating Diameter (μm) 155 ± 5
Coating Type Polyimide
Operating Temperature (°C) -55 to +300
32 WWW.FIBERCORE.COM WWW.FIBERCORE.COM 33SECTION 3 - SM FIBER
Dual Band Bend Insensitive
Fiber
Dual Band Carbon Coated Telecoms style bend insensitive fibers with specialty coatings
SM Fiber • Low splice loss to standard telecoms fibers
• Hermetic coating • Dual band 1310nm and 1550nm transmission
• High operating temperature, up to 150°C and 300°C • High temperature coatings for use up to 150oC and 300oC
• Low attenuation • Low attenuation
• Excellent core cladding concentricity
• Hydrogen resistant Typical applications:
• Downhole distributed sensing (DTS, DAS, DSS)
Typical applications: • High temperature Fiber Bragg grating (FBG) sensors
• Distributed temperature sensors (DTS) • In vivo biomedical probes
• Distributed acoustic sensors (DAS)
• Distributed strain sensors (DSS)
Specifications
Specifications SM1250BI(9.8/125)CHT SM1250BI(9.8/125)P *
Operating Wavelength (nm) 1310 - 1650
SM1250(10.4/125)CHT SM1250(10.4/125)CP Cut-Off Wavelength (nm) ≤1300
Operating Wavelength (nm) 1260 - 1650 Numerical Aperture 0.11 - 0.13
Cut-Off Wavelength (nm) 1190 - 1330 Mode Field Diameter (μm) 9.0 - 10.6
Numerical Aperture 0.11 - 0.14 Attenuation (dB/km) ≤0.4 @1550nm
Mode Field Diameter (μm) 9.6 - 11.2 Proof Test (%) 1 (100 kpsi)
Attenuation (dB/km)SECTION 3 - SM FIBER SECTION 3 - SM FIBER
Silica Core Specifications
fluorinated cladding
Pure Silica Core SM300-SC SM400-SC SM1250SC SM1500SC SM1500SC
(10/125)* (7/80) (7/125)
SM Fiber
Operating Wavelength 320 - 430 405 - 532 1260 - 1650 1520 - 1650
(nm)
Conventional Fiber - Cut-Off Wavelength (nm)
• Excellent hydrogen resistance Ge-doped core, Dual Layer Acrylate ≤310 ≤400 1190 - 1330 1350 - 1520
• Reduced radiation induced attenuation silica cladding Polyimide (P) - - - 1350 - 1520
• Various NAs for bend insensitivity Numerical Aperture 0.12 - 0.14 0.11 - 0.14 0.17 - 0.19
• Coatings for temperature use up to 150°C Mode Field Diameter 2.0 - 2.4 2.5 - 3.4 9.2 - 10.8 6.7 - 7.6
and 300°C (μm) @350nm @480nm @1550nm @1550nm
• Carbon option for hermetic sealing Attenuation (dB/km)
• Hydrogen test data available Dual Layer Acrylate ≤70 @350nm ≤50 @430nm ≤0.8 @1310nm ≤0.8 @1550nm ≤0.8@1550nm
≤30 @532nm ≤0.8 @1550nm
Typical applications: Polyimide (P) - - ≤0.8 @1310nm ≤0.8 @1550nm ≤0.7 @1550nm
• DTS/DAS/DSS • Coiled acoustic ≤0.8 @1550nm
• Sensing in radiation environments • Biomedical probes Carbon High - - ≤0.8 @1310nm - -
• Microscopy • Sensing in hydrogen environments Temperature (CHT) ≤0.8 @1550nm
• Sensing using UV light Carbon - - ≤0.8 @1310nm - -
Polyimide (CP) ≤0.8 @1550nm
Proof Test (%) 1 or 2 (100 or 200 kpsi)
Cladding Diameter (μm) 125 ± 1 125 ± 2 80 ± 1 125 ± 2
See specification details on page 37. Core Cladding ≤0.75SECTION 4 - PHOTOSENSITIVE FIBER
High photosensitivity fibers for rapid
Photosensitive Fiber manufacture of FBGs
Fibercore’s photosensitive (PS) series of fibers have a high germania
For Temperature, Strain and and boron co-doped core composition, enabling high reflectivity gratings
to be written without the need to hydrogen-load. The mode field diameters
Biomedical Sensors and FBGs of the boron co-doped fibers are engineered so gratings may be spliced
into standard telecommunications, or pigtailing fiber with minimal
excess loss.
Fibercore offers a series of high germania SM1500 single-mode fibers
for distributed sensors and splice free sensor arrays. The cores of these
fibers contain more than 5X the germania content of standard
telecommunications fibers. This enables gratings to be written with
or without hydrogen loading, whilst maintaining low attenuation around
1550nm. The addition of polyimide coated versions of these fibers extends
the range, to cover high temperature harsh environment applications.
Typical applications:
• Temperature sensors • 3D shape sensing
• Strain sensors • Pressure sensors
• Biomedical sensors
There are two ranges in this section:
Boron Doped Photosensitive Fiber: Highly Germanium Doped Fiber:
Intrinsically photosensitive fibers High NA single-mode fibers in three different
for Bragg grating fabrication fiber diameters for writing FBGs with or without
hydrogenation
WWW.FIBERCORE.COM 39You can also read
