Studer Innotec communication solutions
In today's digitalised world, monitoring and control is becoming increasingly important. In the
 process, always larger volumes of data should be transmitted at highest possible speed. As a
                    result, the transmission technologies are rapidly evolving.

Studer offers a wide range of transmission tools so that you are constantly connected to your
system. Whether a simple system overview for the user, security and warning messages or as
          support tool for the technician, there is the right solution for every need.

    The solutions range from 3G technology to satellite transmission, SNMP / Modbus and
                              professional SCADA integration.

 Studer Web Portal

     4G                                                                   3G

                       2G

                                                                                     Solar Monitor
System Monitoring & Control - G3 - Studer Innotec
3G                  Internet based access

Interface for a remote interacon with the installaon including real me                                                  Key Points
informaon, access to all se ngs and to the last 30 days of log files.
                                                                                                                           - Real me display
                Xtender
                                                                                                                           - Parameter se ng access
                             Studer BUS                       3G
               VarioTrack                         Xcom-GSM           ISP                                                   - Log files from last 30 days
               VarioString
                                                                                                                           - Use of local SIM card
                                                                                                                           - Noficaon by email or SMS
The intelligent plug & play soluon allows the configuraon of alarm                                                        - System sharing
messages to be sent to one or more persons by email or SMS.                                                                                   More info

                                                                   LAN based communication sets
 4G                   With the LAN-based soluon, a wide variety of transmission units can be used to establish the communicaon with our web
                      portal. In addion, the soluon offers the same benefits as the 3G applicaon shown above.

 5G                   Studer Power Electronics                             Transmission Device                       Studer Web Portal

                                   Xtender                                                       Internet
                                  VarioTrack                                        LAN
                                  VarioString
                                                                                    Modem

                                                                                                   3G

                                                                            3G      3G UMTS
                                                                                    Modem
                                     Studer BUS

                                                                            4G
                                                                                                   4G
                                                                                    4G LTE
                                                                                    Modem

                                                                            5G      5G
                                                                                    Modem
                                                                                                   5G

                                Xcom-LAN
                                                                                    Satellite
                                                             LAN                                 Satellite
                                                                                                                           ISP
                                                                                    Modem

                                                                                                                                               More info

                      Key Points                      Use 3G, 4G or 5G modems compable with your local network operator
Energy management system (EMS) and energy storage sets

    With the integraon of a SCADA unit, a completely individual working system can be realized, which works according to the
    specific requirements of the user. For this advanced applicaon with an external SCADA system we offer interfaces with
    comprehensive and open communicaon protocols. They allow to remotely read all informaon and also to modify the
    configuraon parameters of an Xtender / VarioTack / VarioString system.

    Many customers have developed complete storage systems with this open communicaon opon.

    The Xcom-232i with the RS232 interface, or the Xcom-CAN with the CAN interface is used for such applicaons.

                             SCADA / EMS                                                            Energy Storage
              Open SCADA                         Partner SCADA / EMS                                       Storage Systems

                Your
              Soluon

                                                                       Xcom-232i

                                            Studer Public
                                           Serial Protocol                                    Studer BUS        Xtender
                                                                          or                                   VarioTrack
                                            Studer Public                                                      VarioString
                                            CAN Protocol

                                                                       Xcom-CAN

  Full operaon control       The protocols are open,                                      Pre-programmed SCADA /               Complete storage
    over the Xtender,          accessible and for free        Uni- or mul cast, the
                                                                                           EMS systems in which the           systems with Studer
VarioTrack and VarioString                                       products can be
                                                                                              Xtender, VarioTrack,           components which can
     for an individual             - CAN protocol            controlled individually or
                                                                                               VarioString can be            be obtained as a ready-
        applicaon                - Serial protocol                 as a group
                                                                                          integrated for own systems             to-use soluon
Modbus
                                                                              TM                                                                      Sunspec
                                         Solar Monitor                             platform
                                                                                                                                                       SNMP

Turnkey soluon with the possibility to add external devices for a monitoring integraon of addional PV producon plants or different
sensor measurements, for local applicaons with Modbus or SNMP, or internet based applicaons for monitoring.

                                                                                                  Grid-e
                                                                                                  inverter

                                                             ...many others

                                                                                                         AC-Coupling
                                                Communicaon BUS

           Xcom-232i                                        Xtender
                                     Studer BUS                                                     AC-BUS

                                      Sensors
                                                                                                  VarioTrack
                                                                                                  VarioString

                                                                                                    DC-BUS

        Monitoring                              Modbus                                     SNMP                           External devices

                                                                                   The SNMP V.3 uses strong             Seamless integraon of all
                                                                                      encrypon to prevent               known grid-e inverter
                                                                                    fraud and is widely used                     brands
                                                                                        by local network
                                                                                     operators. Off the shelf            Common solar producon
        Smart gateway to                                                           compable with different                   monitoring
  support the client with a fast      Full Modbus (TCP) IEC                        network monitors such as
   and smart access to system          61131-3 library allow                         HP Open view, Nagios,
     informaon, real me             easy intergraon in any                      Paessler PRTG, Castlerock
  monitoring and data-logging          SCADA / PLC system                              SNMPc, The Dude                    Compable with many
                                                                                         (Mikrok), etc.               sensors (energy, irradiaon,
     Alarm noficaon by                 Sunspec compable                                                               temperature, digital input,
         SMS or Email                                                                                                         wind speed)

  Soluon in cooperaon with Solar Monitor
System Monitoring & control solutions
