EN GL I SH
CATALOGUE 2021
BAB TECHNOLOGIE GmbH Hörder Burgstraße 44263 Dortmund Germany Phone: +49 231 476425–30 Fax: +49 231 476425–59 Email: info@bab-tec.de Internet: www.bab-tec.de The information in this catalogue is provided without guarantee. We reserve the right to make technical and design changes without prior notice. All Smart Home Apps are independent products and are not legally associated with the third-party manufacturers mentioned herein. Neither BAB APP MARKET GmbH, BAB TECHNOLOGIE GmbH nor App developers are in possession of the mentioned trademarks. 6 I Content
CONTENT
Gateways EIBPORT V3 8
CUBEVISIONMODULE 18
APPMODULE 20
DUODMX GATEWAY 28
AUDIOMODULE 30
AUDIOAMP 37
FACILITYMASTER 38
LINKMODULE 40
DATALOGGER V2 42
KNXCONVERTER 44
INTERCOMMODULE 46
LOGIKMODULE 48
Integrated Visualisations CUBEVISION 2 52
CONTROL L 60
CUBEVISION 2 APP 66
DUO DMX APP 67
SMART SCREENS APP 68
Extra Programs CONTROL R 71
CONTROL W 72
DATAWAREHOUSE 2 73
CONTROL T 74
Touch Panels FLATTOUCH 76
SMARTSURFACE 78
HTS10 86
Accessory SDMODULE 90
Power Supply 91
Accumulator 93
Content I 7
GATEWAYS EIBPORT V3
New and available soon:
• Optional LTE modem
• LOGIKEDITOR Network integrated
• REST interface
• Secure remote access without
additional hardware
• Recovery function
EIBPORT
VISUALISATION. AUTOMATION. INTEGRATION.
The EIBPORT connects KNX or EnOcean building control with In addition to a simulation mode and search and documen-
the IP world. Create individual visualisations in the editor with tation functions, the LOGIKEDITOR also offers the option of
CONTROL L, almost automatically with CUBEVISION 2, or com- loading and exporting logic groups. Via the integrated web
bine both visualisation types for an even more comfortable platform logikeditor.de, you can load additional ready-made
control. The visualisations have been extended by a camera logic groups for many application areas free of charge.
archive, the long-term data recording for up to three years Via a secure connection you can also control and maintain
and the door communication. Whether simple or complex the EIBPORT remotely - thanks to the integrated VPN
- use over 50 integrated services for almost all automation Servers. On request, the EIBPORT also functions as an IP
tasks in building automation. router in the KNX installation and as a programming interface
Program your own control sequences with the graphical to the ETS.
LOGIKEDITOR or integrate third-party applications such as
Amazon® Alexa.
8 I Gateways
GATEWAYS EIBPORT V3
6 POSSIBLE COMBINATIONS
Extra modules
No extra module GSM EnOcean LTE
BASIS KNX
KNX KNX GSM KNX EnOcean KNX LTE
Art. no. 10104 Art. no. 10304 Art. no. 10504 Art. no. 10404
BASIS
BASIS EnOcean
EnOcean EnOcean GSM
Art. no. 13104 Art. no. 13304
Optional GSM®
With the GSM® module, your building automation system can also be reached where no Internet connection is
available. By sending and receiving SMS, basic functionalities are carried out autonomously.
1-Wire interface
The USB connection of the EIBPORT, in conjunction with the 1-Wire USB adapter, allows access to the inexpensi-
ve sensors of the 1-Wire range.
S0 Interface
The EIBPORT comes standard with four S0 inputs for recording consumption data. S0 counters (e. g. for electri-
city, gas or water) can be connected to the inputs.
Powernet KNX
On request, the EIBPORT is also available with Powernet KNX instead of KNX/TP interface. The device is equipped
with a power network coupler, which replaces the KNX/TP module.
New: LTE
Via the optionally available 4-band modem you connect to the EIBPORT independently of an existing network.
Use this flexible variant for complete parameterisation, analysis and ETS programming from any location. This
way, users can access their visualisation safely and conveniently.
Gateways I 9
GATEWAYS EIBPORT V3
6 POSSIBLE COMBINATIONS
EIBPORT KNX
• KNX TP connection via bus terminal
• Administration of all 65532 KNX group addresses
• Definable virtual group addresses
• Import of addresses from the ETS
• MDRC 8 MW
Art. no. 10104
EIBPORT EnOcean
• EnOcean via an external SMA • Numerous preset EnOcean profiles
antenna • Can be used as a repeater
• Range: 300 m open field/ 30 m • STM 300 transceiver module
in buildings (dependent on • External antenna: 2.50 m cable,
construction materials) magnetic base and SMA plug
• Input properties: any number • MDRC 8 MW
• Output properties: 128
Art. no. 13104
EIBPORT KNX EnOcean
• KNX TP connection via bus terminal • Input properties: any number
• Administration of all 65532 KNX • Output properties: 128
group addresses • Numerous preset EnOcean profiles
• Virtual group addresses • Can be used as a repeater
• Import of addresses from ETS • STM 300 transceiver module
• EnOcean via an external SMA • External antenna: 2.50 m cable,
antenna magnetic base and SMA plug
• Range: 300 m in open/ 30 m • MDRC 8 MW
in buildings (dependent on
construction materials)
Art. no. 10504
10 I Gateways
GATEWAYS EIBPORT V3
6 POSSIBLE COMBINATIONS
EIBPORT KNX + GSM™
• KNX TP connection via bus terminal • Send and receive text messages
• Administration of all 65532 KNX directly
group addresses • External antenna: 2.50 m cable,
• Virtual group addresses magnetic base and SMA plug
• Import of addresses from ETS • MDRC 8 MW
• 4-band modem
Art. no. 10304 to be discontinued
EIBPORT EnOcean + GSM™
• EnOcean via external SMA antenna • Latest STM 300 transceiver module
• Range: 300 m in open/ 30 m • 4-band modem
in building (dependent on • Send and receive text messages
construction materials) directly
• Input properties: any number • 2 external antennas: 2.50 m cable,
• Output properties: 128 magnetic base and SMA plug
• Numerous preset EnOcean profiles • KNXnet/IP server for access to KNX
• Can be used as a repeater
Art. no. 13304 to be discontinued
NEW: EIBPORT KNX LTE
• KNX/TP connection via Bus Terminal • WAN access via mobile radio
• Management of all 65532 KNX group • 2 x external antenna: 2.50 m cable,
addresses magnetic base and SMA plug
• Definable virtual address range • MDRC 8 MW
• Address transfer from the ETS
• 4-band modem
• Send and receive SMS directly
Art. no. 10404
Gateways I 11
GATEWAYS EIBPORT V3 VISUALISE YOUR BUILDING PERFECTLY STAGED Individual building visualisation with CONTROL L With CONTROL L the EIBPORT offers a most versatile, platform independent visualisation for tablets, touch panel PCs & Co. Use our provided templates or design your visualisation completely individual. The comfortable CONTROL L editor offers besides the unique live mode a multitude of ready-made visualiation elements like buttons, sliders, popup windows and RTR compo- nents. Create top visualisations at breathtaking speed with style sheets, master pages and integrated ESF data import. Read everything about CONTROL L starting on page 60. CUBEVISION 2 With CUBEVISION 2 the EIBPORT additionally provides a unique, 3D-animated visualisation, which is created automatically from the configuration data. With the "Smart Function Creator" you can create your own scenes directly in CUBEVISION 2, which automatically scales to the respective display, so that the same visualisation can be used from the Smartphone to the desktop system. In addition, CUBEVISION 2 can be integrated into CONTROL L on request to combine the advantages of both applications. Read all information about CUBEVISION 2 starting on page 52. 12 I Gateways
GATEWAYS EIBPORT V3
AUTOMATE & INTEGRATE
GRAPHICAL LOGIKEDITOR
With the graphical LOGIKEDITOR you can easily create even complex applications. With the search and documentation functi-
ons, you always have an overview. Thanks to the possibility of loading and exporting logic groups, you can reuse functions
once created in different projects, saving time and costs. The platform "logikeditor.de" provides many ready-made logic
groups for immediate use. Simulate complex scenarios before transferring them to the live system and use the intelligent log
to display and restore previous states. Of course we have developed the LOGIKEDITOR web-based - so you remain indepen-
dent of operating systems and end devices.
LOGIKEDITOR NETWORK INTEGRATION
LOGIKEDITOR NETWORK: the online collection with hundreds of sample logic groups is now directly available in EIBPORT V3.
Immediately after logging in, the latest logic groups are displayed in the dashboard and are available for immediate import
if desired. You can now learn more about a specific logic group with just one click. You can find the appropriate logic group
within seconds using the integrated search function.
Gateways I 13GATEWAYS EIBPORT V3 AUTOMATE & INTEGRATE GRAPHICAL LOGIKEDITOR These Logic Elements for automation are offered by graphical LOGIKEDITOR: • Alexa Device • Threshold Value • Alexa Scene • Statistics • Astrotimer • Scene • Binary Logic • Text Processor • Data Converter • Logic Gate • Email Sender • Transformator • Static Value / Initial Value • Staircase Timer • HTTP Request • Comparator • Calendar • Distributor • Camera Archive • Delayer • New: REST interface • Value Store • Lua Script • Value Read • Mathematics • Weekly Timer • Collective Signal • Cyclic Sender All Logic Elements can be graphically linked to each other. With the help of so-called "tools" these connections can be modulated at lightning speed: • Binary filter • Delayer • Inverter • Value Filter • Calculator • Translator • Toggle • Network cameras • Round values 14 I Gateways
GATEWAYS EIBPORT V3
AUTOMATE & INTEGRATE
JOB EDITOR CLASSIC
The EIBPORT provides a whole range of directly available automation functions that can be easily edited via the form-based
configuration mask.
These jobs for automation are offered by the Job Editor Classic:
• Astro Clock • Room temperature controller
• Date receiver & transmitter • Threshold value
• Time receiver & transmitter • SMS sender
• Text (EIS 15) Multiplexer • SMS receiver (for devices with GSM module)
• Email dispatch • Status indicator
• Hysteresis • Staircase automat
• Pulse counter (For KNX and S0) • Comparator
• Integrator • Delayer
• Week clock • Wake-on-LAN
• Year clock • Cyclic transmitter
• Light scene • Counter
• Logic (AND, OR, XOR, object, NAND,
NOR, NXOR, NObject)
• Mathematics
These jobs for integration are offered by the Job Editor Classic:
• 1-Wire (compatibility with many sensors) • KNX integration of AUDIOMODULEs
• 4 x S0 interface for direct meter connection • Integration of UDP-based applications with
• Optional integration of EnOcean UDP sender & receiver
• Option. GSM interface for control via SMS • Sonos Radio Control
• New: Option. LTE interface for using EIBPORT • MySQL database logging possible
via mobile data (additional software for evaluation via freeware
• System coupling to other devices such as DATAWAREHOUSE 2)
FACILITYMASTER or LINKMODULE • Integrated KNXnet/IP server for the coupling
• ekey integration of the Home & Multi product range and interface functionality
• Connection of infrared capable devices with the help • Amazon® Alexa
of IR-Trans • Network cameras
• HTTP request with response evaluation
Gateways I 15GATEWAYS EIBPORT V3
INTEGRATE
CONNECT SYSTEMS SEAMLESSLY
By using the EIBPORT, the KNX / EnOcean automation is extended many times over. The connection to the IP network enables
numerous other applications. Additionally, the available connection options for 1-Wire and S0 products allow the integration
of a variety of cost-effective components. Arbitrary operating units, such as smartphones, tablet PCs and even Amazon® Alexa,
can access and control the system participants across systems. Network cameras from various manufacturers provide insight
into what is happening on site. Multimedia systems can be flexibly integrated with the graphical LOGIKEDITOR or the JOB
EDITOR CLASSIC. With the help of BAB SECURELINK, buildings can be securely linked via the Intranet or Internet and integrated
into a central property management system. On request, an e-mail or SMS is sent in case of relevant events. New: The optio-
nally available LTE interface enables uncomplicated WAN access via the mobile network.
EIBPORT Functional Overview
Building automation
Actuator with
current value detection Weather Statio Sensor Blinds Sensor Heating Window contact
Further services KNX
1-Wire, S0-Bus
EnOcean GSM
1-Wire
S0
BAB SECURELINK Remote support 1-Wire
with FACILITYMASTER via ETS temperature sensor S0 counter
Multmedia
EIBPORT
LAN RS232
Moxa
BAB SECURELINK
with EIBPORT Email
IRTrans IR HIFI Projector TV
Internet
LAN
BAB SECURELINK
with LINKMODULE SMS via GSM WLAN-Router
AUDIOMODULE AUDIOSERVER SONOS
LAN
Voice Intercom Operating clients Netzwerkdienste
BABTECHNO
LOGIE
Energy data
Desktop PC / SMARTSURFACE / Desktop PC / recording
INTERCOMMODULE CONTROL L CUBEVISION CONTROL W APPMODULE SQL database IP camera
KNXnet/IP
Smartphone / Tablet /
Door opener App for iOS® or Android® App for iOS® or Android® Amazon® Echo
Facility coupling
via KNXnet/IP Commissioning
By means of virtual group addresses (a definable KNX address range, which is only processed within the EIBPORT), services can
be linked as desired.
16 I GatewaysEXAMPLES EIBPORT V3 GUARANTEE SAFETY MEASURES AT A GLANCE The EIBPORT offers a maximum of security. Current encryption technologies, secure access and recovery functions for the de- vice are integrated as standard. An extensive user administration offers selective access for authorized users only. • HTTPS access • BAB Secure Link • Encrypted user authentication • New: Secure remote access • Integrated VPN server • New: Recovery function TECHNICAL SPECIFICATIONS • Power supply: 12–30 V DC Interfaces (depending on variant): • Power consumption:
GATEWAYS CUBEVISIONMODULE
New and available soon:
• Web Editor
• Security Chip
• Quick Access Menu
• Import of KNX projects
• New Smart Functions
• ETS Inside Server
CUBEVISIONMODULE
OUR BEST SMARTHOME VISUALISATION
The CUBEVISIONMODULE offers a unique building visualisa- With the "Smart Function Creator" you create your own
tion and is very easy to set up and operate. The well thought- scenes and smart home functions by drag 'n' drop within the
out user interface scales automatically on almost all display user interface. The CUBEVISIONMODULE is available with
devices. Thus Smartphone, Tablet and Co. become the direct KNX connection or as EnOcean variant.
control centre for your intelligent home in no time.
CUBEVISION 2 can be easily configured in your web browser: Read all information about CUBEVISION 2 starting
Import a KNX project, select background images and define on page 52.
functions. Now, the complete visualisation will be created
automatically.
18 I GatewaysGATEWAYS CUBEVISIONMODULE
Included
KNX IP router
functionality
Also available as
RF version
TECHNICAL SPECIFICATIONS
EnOcean specifications:
• Operating voltage: 12–32 V DC • Operating frequency: 868.3 Mhz
• Typical power consumption 300 mA at 12 V DC • Range: 300 m outdoors / 30m indoors
• Power consumption:GATEWAYS APPMODULE
NEW in APPMODULE:
• Smart Screens
• KNX project import
• Support of Panasonic®,
Bluesound®, Rutenbeck,
Home Connect, IFTTT and more
• ETS Inside Server
APPMODULE
THE IoT+ GATEWAY.
Come Together. With the APPMODULE you can easily connect offers smart home apps for integrating IoT devices and
the whole world of IoT with KNX and EnOcean. services as well as functional extensions such as intelligent
Whether Amazon® Alexa, SONOS®, Philips® hue, Netatmo®, presence simulation. With the new "Smart Screens" you can
IFTTT, or DoorBird®: Install the appropriate Smart Home App even control any IoT, KNX and EnOcean device with your
on the APPMODULE and get started. Easy and simple. Once smartphone in just one interface. The direct KNX connection,
integrated, you control IoT devices with any KNX or EnOcean the integrated KNX router functionality and the convenient
components - and vice versa, of course. For example, start KNX project import complete the scope of the APPMODULE.
your favourite songs with a wall switch or control your KNX
lighting with Amazon® Alexa.
The constantly growing portfolio in the BAB APP MARKET
20 I GatewaysGATEWAYS APPMODULE
Also available as
RF version
Included
KNX IP router
functionality
TECHNICAL SPECIFICATIONS
• Operating voltage: 12–32 V DC Special features:
• Typical power consumption 300 mA at 12 V DC • Many different Smart Home Apps can be
• Power consumption:GATEWAYS APPMODULE
COME TOGETHER: UNDER ONE UMBRELLA
Whether TV, multi-room system or LED lights - more and The APPMODULE brings them all under one roof, linking them
more everyday items are becoming "smart". However, these with KNX, EnOcean and each other.
systems are often self-contained.
APPMODULE
Modbus
22 I GatewaysGATEWAYS APPMODULE
DISCOVER SURPRISING POSSIBILITIES: SMART HOME APPS
Home Connect
Link Home Connect devices from Bosch, Siemens and Neff to the KNX and EnOcean world!
Washing machine, refrigerator and stove become fully integrated participants of your smart
home system in no time.
iRoom KNX Connect
iRoom offers Apple® certified smart docking stations. With "iRoom KNX Connect", you can
now easily link iRoom's stylish products with KNX and other IoT components.
R-Connect
The IP switch actuators IP8 and IP4 from Rutenbeck can now be controlled with «R-Connect»
using the attractive portfolio of KNX push-button sensors. This app including the APPMODULE
is now also available directly from Rutenbeck.
free@home Control
Busch-free@home® is the smart, radio-based home control system from Busch-Jaeger and is
ideal for both new construction and renovation and refurbishment projects.
With the APPMODULE you can now also connect free@home with KNX.
AGFEO Connect
The AGFEO IP-Video TFE 1 IP door phone has a digital bell label in which you can insert com-
pany logos, texts or pictures. Control the contents now with KNX.
Energy Manager
This app uses artificial intelligence to optimise the use of PV energy. The Energy Manager dis-
tributes generated energy to storage and consumers. Thus, this app minimises both the feed-in
and the purchase of energy from the public grid.
Harmony Connect
The Logitech® Harmony Hub is compatible with more than 270,000 entertainment and smart
home devices. You can now control the convenient «Harmony Actions» with KNX or EnOcean.
Russound Connect
Russound® multi-room audio amplifiers are among the best the market has to offer. With the
APPMODULE and this app you can now integrate products based on the RIO protocol into KNX
systems.
AMTRON Connect
The innovative Amtron wallboxes ensure e-mobility through intelligent charging management.
Together with «Amtron Connect» and the APPMODULE, the e-car now becomes an integral
part of your intelligent home.
Gateways I 23GATEWAYS APPMODULE
DISCOVER SURPRISING POSSIBILITIES: SMART HOME APPS
BAB Alexa
With this app you can integrate the Alexa voice control system from Amazon into your Smart
Home based on KNX, EnOcean and IP.
Bluesound Connect
The «Bluesound Connect» App allows Bluesound music systems to easily be connected to the
KNX system. This allows the control system to not only be fully integrated into the visualisation,
but also allows easy combination with other services or simple control via KNX push-buttons.
Panasonic Connect
Integrate Panasonic TVs into your smart home based on KNX, EnOcean and IP. Seamless
connection with «Panasonic Connect» enables control with all Smart Home components and
building visualisations.
HUE:CONTROL
This App connects your Philips® hue Bridge with KNX so that you have access to all connected
Philips hue lights through the building automation. The simple authorisation process makes
connection particularly easy.
FritzControl Complete
Control your Fritz!BOX® router conveniently via available KNX or EnOcean clients and com-
bine router commands with any scenarios. It is simple, for example, to active the Guest WIFI
using a push button and monitor the call monitor in the visualisation.
HEOS Connect
Connect your Denon® HEOS devices to the KNX or EnOcean world! You can enjoy the top-
quality sound of Denon® in all rooms via WLAN and control the convenient functions via your
existing visualisation system or any number of push-button sensors.
PLAY
The «PLAY» App allows SONOS® music systems to easily be connected to the KNX system. As a
result, not only can the controls be fully integrated into the visualisation, but it is also possible
to combine it with other services or control it using simple KNX buttons.
DoorBird Control
With this app, you can easily integrate DoorBird door intercom systems into your KNX or EnO-
cean building automation system. DoorBird door stations are easy to install and can be used
with the existing infrastructure.
IFTTT Connect
With this app for the APPMODULE you connect over 600 IoT and web services with KNX or
EnOcean. For example, transfer KNX counter readings to Google Tables or link your current
geographical location to KNX scenes.
24 I GatewaysGATEWAYS APPMODULE
PJLink
You can use this App to control PJLink-supported devices – for example from Sony®, Sharp® or
Hitachi® via KNX. Alongside the usual control commands, the range of functions also includes
reporting regarding troubleshooting.
Speech
With «Speech» you create speech files in different languages and with different speaker
voices. The audio files are automatically stored in the APPMODULE and can be transferred to
other apps or streamed to the network.
PushIT
Stay up to date! «PushIT» brings the push notification service to building automation. With
the help of technology from PushBullet, it is thus possible to transmit images or text messages
almost instantaneously.
RE:BLINDS
This app enables the control and tracking of blinds that do not communicate their position
independently. For this purpose, the time for raising and lowering is determined and referen-
ced manually.
Sequencer
With «Sequencer» you can create individual Smart Home scenarios. Start your cinema am-
bience, including lighting and shading control, or switch off KNX and IoT components when
you leave the house by pressing a button. More comfort is not possible.
Homematic Control
Whether KNX or EnOcean: With «Homematic Control», you can connect HomeMatic® compo-
nents such as motion detectors, window contacts, smoke detectors or radiator thermostats
to your building automation in no time at all.
Soundtouch
Connect your Bose® SoundTouch™ devices to KNX and EnOcean! Via WLAN you can enjoy
the top sound of Bose® in all rooms and control the convenient functions via your existing
visualisation or any push-button.
TransRED
TransRED connects all infrared capable devices with the building system technology by means
of the IR-Trans LAN gateways. Thus you can integrate almost the entire range of current con-
sumer electronics into the building automation.
Weather
WEATHER connects your building control system in an intelligent way with data from Open-
WeatherMap (openweathermap.org). The data enables you to integrate the predicted weat-
her into various applications.
Gateways I 25GATEWAYS APPMODULE
DISCOVER SURPRISING POSSIBILITIES: SMART HOME APPS
NUKI Control
Connect your Nuki Smart Lock with the KNX and EnOcean world and control the comfortable
functions additionally with all KNX or EnOcean components or via your existing visualisation!
MODBUS TCP Connect
With this app you connect an existing Modbus gateway via TCP with the building automation.
Netweather
With this app you can connect Netatmo® devices to your building automation in no time at
all. Sensors and weather stations thus become a fully integrated part of your building auto-
mation.
DE:CONTROL
With DE:CONTROL you can easily integrate your DENON® receivers with network interface
into a KNX or EnOcean system. The entire range of control commands is available for opera-
tion e.g. from building visualisation or via push-button sensors.
ASCII Tool
This app enables bidirectional TCP/IP ASCII. Create a protocol of 50 freely definable com-
mands and responses each including a uniform EOL marker.
Busch-Radio iNet (by Busch-Jaeger®)
With this app you can integrate the «Busch-Radio iNet» into your KNX or EnOcean building
automation.
MAIL
With this Smart Home App, you can send e-mails from your KNX system to any recipient. For
example, send the meter reading of your KNX Smart Meter once a month or be informed as
soon as a presence detector reports a movement.
P-Charge
With the P-Charge App you get an extensive integration of the EV Charge Control Basic from
PHOENIX CONTACT (EM-CP-PP-ETH) functions into the building automation. In this way you
always have the charge status of your electric vehicle in view.
PRESENCE
«Presence» is an intelligent presence simulation. The app records the desired switching ope-
rations while you are at home. In your absence, the recorded data is played back - creating a
particularly realistic simulation.
26 I GatewaysEXAMPLES APPMODULE
APPMODULE Smart Home Apps
KNX ALEXA,
The functions of the FRITZ!Box® Smart Home App
Smart Home App Smart Home App
«Fritz Control» «Amazon® Alexa» «HEOS® Connect»
and the HEOS® players are trigge-
red either with a KNX button or by
HEOS® Player
voice command via Amazon® Echo.
Through bidirectional communica-
tion, functions of the FRITZ!Box® (e.g.
presence detection) can trigger KNX
LAN
telegrams. Conversely, the guest
Amazon® Alexa
WLAN can be switched on via KNX or APPMODULE
playlists can be started. KNX
FRITZ!box
KNX Sensor KNX Actuator
APPMODULE Smart Home Apps
IP ALEXA,
Smart Home App Smart Home App
Smart Home App
»Fritz Control« »BAB Alexa« »SoundTouch«
The APPMODULE IP works as a stand-
alone device with the Smart Screens
and triggers the linked functions of SoundTouch®
the respective Smart Home app.
Alternatively it can communicate
with the KNX bus via KNX/IP routing.
WLAN LAN
Linked KNX actuators can also be
Smart Screens APPMODULE IP Amazon® Alexa
controlled - for example by voice in-
put. In conjunction with a KNXnet/IP
router or e.g. EIBPORT, the
APPMODULE IP can transfer values LAN
to the KNX bus. In this way any KNX FRITZ!box
devices can be integrated.
Tastsensor
KNX
KNX IP Router
KNX Aktor
Gateways I 27GATEWAYS DUODMX GATEWAY
GATEWAY BETWEEN KNX AND DMX
The DUODMX GATEWAY is the bi-directional KNX or EnOcean «DMX-Configurator» makes it possible. Due to its compact
interface to the DMX world – easy to configure and flexible dimensions and different mounting options, the DUODMX
in use. Two configurable DMX interfaces, each with 512 GATEWAY is ideally suited for retrofitting in ceilings.
channels, allow independent control of two DMX worlds.
With the bi-directional SR versions you can control DMX with COMFORTABLE. QUICK. INTUITIVE.
Discover our latest free app for controlling
KNX and vice versa. Various device variants and the wireless
DUO DMX APP all of our DUODMX GATEWAY variants.
LAN option allow the use in almost every scenario. Easily link GET IT ON
channels and scenes to KNX addresses using Drag ’n’ Drop.
The professional DMX-configuration software
28 I GatewaysGATEWAYS DUODMX GATEWAY
Also available as
RF version
TECHNICAL SPECIFICATIONS
• Operating voltage: 12-32 V DC • WLAN: 802.11 b (compatible with b/g/n) (Available for
• Power consumption:GATEWAYS DUODMX GATEWAY
TECHNICAL SPECIFICATIONS REG
• Operating voltage: 12-30 V DC Interfaces:
• Power consumption:EXAMPLES DUODMX GATEWAY
DUODMX GATEWAY KNX – TYPE 12021
DMX512 z. B. DMX-Dimmer
DUODMX GATEWAY
KNX/TP-Installation KNX/TP »KNX«
DMX512 z. B. DMX-Dimmer
The DUODMX GATEWAY 12021 is connected to the KNX bus via twisted pair. It thus receives its control commands directly via
the KNX bus and forwards DMX packages to the DMX dimmers.
DUODMX GATEWAY KNX SR – TYPE 12521
1 The DUODMX GATEWAY 12521 REG KNX SR is connected to the KNX bus and receives its control commands via the KNX bus.
2 The DMX packages for the DMX dimmers are then triggered.
3 The DMX mixing console (DMX master) is connected to the DUODMX GATEWAY (DMX slave).
4 The DMX packages are converted into KNX telegrams and sent to the KNX participants.
Art. no. 12521 DUODMX GATEWAY REG KNX SR
Art. no. 12011 DUODMX GATEWAY IP
Art. no. 12011w DUODMX GATEWAY IP WLAN
Art. no. 12021 DUODMX GATEWAY KNX
Art. no. 12031 DUODMX GATEWAY EnOcean
Art. no. 12041 DUODMX GATEWAY Standalone
Art. no. 12041w DUODMX GATEWAY Standalone WLAN
Art. no. 12111 DUODMX GATEWAY IP SR
Art. no. 12111w DUODMX GATEWAY IP SR WLAN
Art. no. 12121 DUODMX GATEWAY KNX SR
Art. no. 12090 Rail Mounting Adaptor
Gateways I 3132 I Gateways
GATEWAYS AUDIOMODULE
Included
KNX IP router
functionality
AUDIOMODULE
KNX MULTIROOM WITHOUT DETOURS
The AUDIOMODULE is a high-quality streaming client with a zone In addition to the possibility of playing music from local
digital sound processor (DSP), which is available with either servers or Internet radio stations, the integrated Logitech™
line-out or speaker-out. Whether as audio client or server: media server offers a variety of different functions through
Use the AUDIOMODULE in a very flexible way. The direct KNX the 3rd party plug-in offer. Easily connect external audio
connection allows you to connect it to KNX systems without sources such as CD players or TVs via the analogue input
any detours. Multi-room audio control with on-site operation with automatic source switching. Completed by the web-ba-
via KNX sensors or via a central building visualisation system is sed configuration, selectable DSP profiles and four available
child’s play with this module, which is only four units in size. device variants, the AUDIOMODULE becomes our best KNX
Theft- and tamper-proof installed in the installation distribu- multiroom solution in REG format.
tor, it is perfectly suited for use in commercial properties such
as hotels, as well as in areas accessible to the public. With or
without KNX integration: the AUDIOMODULE is also suitable
as a stand-alone solution for objects with only one music
Gateways I 33EXAMPLES AUDIOMODULE
AUDIOMODULE
AS A SERVER
The AUDIOMODULEs do each work as a client LAN
and connect to the central AUDIOMODULE
(room 1), which also functions as a server. This
transfers the music – for example from a USB USB storage
NAS drive (LAN, USB) AUDIOMODULE Analog audio source
stick or a NAS drive – over the network to the
AUDIOMODULE AUDIOMODULE AUDIOMODULE
remaining AUDIOMODULEs. The AUDIOMO-
KNX KNX KNX KNX
DULE is controlled either via KNX sensors, KNX
touch displays or a central building visualisation.
In addition, users can easily connect their own
audio sources (room 14) via the local audio
input, with a 3.5 mm jack. This structure offers Sensor Sensor Sensor Sensor
an individual musical experience in every single Room1 Room12 Room13 Room14
room.
AUDIOMODULE
STAND ALONE
The AUDIOMODULEs are each supplied with
AUDIOMODULE
music from their internal Logitech® Media Ser-
Kitchen
ver (LMS) and work independently. Audio data
is transferred from a locally attached storage WLAN Router
medium or NAS drive to the network. Any smart- LAN
UPnP
phone or tablet with UPnP application controls AUDIOMODULE
UPnP compatible
device
the music playback. Even music content stored
Livingroom
on smartphones or tablets can be transferred
NAS drive
directly to the AUDIOMODULE via WLAN.
AUDIOMODULE
Patio
34 I GatewaysGATEWAYS AUDIOMODULE TECHNICAL SPECIFICATIONS AUDIOMODULE Speaker AUDIOMODULE Line • Power supply: 24 V DC / 3 A • Operating voltage: 12-32 V DC • Power consumption: max. 72 W • Typical power consumption 350 mA at 12 V DC • Connection: screw plug-in terminal • Power consumption:
36 I Gateways
GATEWAYS AUDIOAMP
AUDIOAMP
POWER UP
The AUDIOAMP is an efficient audio amplifier with 2 x 50 range. With a 3.5 mm jack socket, the AUDIOAMP offers a fle-
Watt output power. As a rail-mounted device (MDRC), this xible and easy to handle input. For even more power, simply
Class D amplifier with an additionally integrated digital sound connect additional amplifiers via the line-out.
processor (DSP) is the ideal complement to our audio product
TECHNICAL SPECIFICATIONS
• Power supply: 24 V DC • Speaker connection: 2 x 50 W RMS at 4Ω
• Power consumption: 120 W / 5 A • Screw-type plug-in terminal up to 3.6 mm2
(recommended power supply) • Potential-free inputs for volume / mute control
• Connection: screw-type plug-in terminal
• Climate resistant: EN 50090-2-2 Special features:
• Ambient temperature: 0 to +35 °C • High quality 28/56 bit DSP
• Relative humidity (non-condensing): 5% to 80% • 192 kHz Sample Rate
• 24 Bit AD / DA converter
Mechanical data: • DSP profiles replaceable
• Mounting: MDRC 4 MW • Class-D amplifier
• Dimensions (W x H x D) in mm: 72 x 90 x 63 • input limiter
• Housing: Plastic • Protection against overtemperature
• Protection class: IP20 (according to EN 60529) • Overload protection
• Status LEDs
Interfaces: • Volume preset via buttons on front of the housing
• Input via 3.5 mm stereo jack (1 Veff at 10 kΩ) • Automatic standby switchover
• Output via 3.5 mm stereo jack (1 Veff at 10 kΩ) • No software requirements
Art. no. 10540 AUDIOAMP
Gateways I 37GATEWAYS FACILITYMASTER FACILITYMASTER NEW DIMENSIONS. The FACILITYMASTER combines EIBPORT V3, DATALOGGER V2, encrypted system coupling across network domains. This way, APPMODULE, KNXCONVERTER and AUDIOSERVER in one the individual properties are easily connected via the Internet device. This guarantees a unique scope of services, ideal for or Intranet. With the help of the integrated DATALOGGER, the extensive requirements of larger projects. In addition, the the FACILITYMASTER offers professional data recording. It re- professional server hardware offers outstanding performance. cords up to 36 million data records in an internal SQL data- The combination of EIBPORT and APPMODULE enables a ver- base and, if desired, regularly sends a CSV file by e-mail. To satile integration of third-party applications. round off the portfolio, KNXCONVERTER and AUDIOSERVER While the EIBPORT provides visualisation and automation are also integrated. With the help of the KNXCONVERTER, for functions, the APPMODULE contributes the extensive applica- example, non-KNX-capable installations can be integrated via tion library from the BAB APP MARKET (www.bab-appmarket. a simple ASCII protocol, while the AUDIOSERVER is used for de). For a property connection and management with small multi-room installations with the AUDIOMODULE. configuration effort, the FACILITYMASTER is provided with the BAB SECURELINK protocol and (on request) the ADVANCED CENTRAL VIEW. BAB SECURELINK is also imple- mented in EIBPORT and LINKMODULE and thus enables an TECHNICAL SPECIFICATIONS • Operating voltage: 230 V AC Special features: • Processor: Intel® Core™ i3-8100 Processor (8 Gen.) • BAB SECURELINK • Memory: 8 GB 2400 MHz DDR4 • CONTROL R integrated • HDD: 2 x 500 GB SATA3, RAID 1 • CONTROL W included in delivery Mechanical data: Operating system: • Mounting: 19 inch rack 2 HE • Linux® OS • Front panel: 3 mm anodised aluminium • Chassis: hot-dip galvanised sheet steel, RAL 9006 white aluminium Interfaces: • KNX via KNXnet/IP • LAN: 2 x Gigabit Ethernet • Serial: COM 1 38 I Gateways
EXAMPLES FACILITYMASTER
FACILITYMASTER
FACILITY MANAGEMENT
The FACILITYMASTER is installed as a central manager in the company headquarters. The various properties located on the
Internet or intranet are connected to each other via BAB SECURELINK. It does not matter whether it is a location with
LINKMODULE without its own intelligence or a location with its own visualisation on an EIBPORT. Since LINKMODULE and
EIBPORT are also available with an EnOcean interface, it is possible to connect system components with EnOcean radio. The
information are combined in the central FACILITYMASTER and, thanks to ADVANCED CENTRAL VIEW (available on request),
can also be combined into a central control system in just a few steps.
Local KNX Bus
LINKMODULE
... up to 2000
control logics
FACILITYMASTER ACV Visualisation
INTRANET / INTERNET
BAB SECURELINK
Property A with Property B with Property C with
LINKMODULE LINKMODULE EIBPORT
KNX KNX KNX
Art. no. 10310 FACILITYMASTER
Gateways I 39GATEWAYS LINKMODULE
Also available as
RF version
Included
KNX IP router
functionality
LINKMODULE
SECURELY WELL CONNECTED.
With the LINKMODULE you connect remote KNX or EnOcean and FACILITYMASTER. The integrated address mapping provi-
systems via a network or the Internet. Simple and safe. des a simple remedy in case of address overlaps.
BAB SECURELINK (a special VPN connection) is used for trans- The LINKMODULE is available with KNX/TP interface or
mission between the communication partners and serves as EnOcean radio antenna. In conjunction with the integrated
the basis for system coupling. A SECURELINK connection can KNXnet/IP server, the device also serves as a KNXnet/IP rou-
be established in a few steps. The complex configuration of ter, an interface for the KNX commissioning software ETS, or
VPN parameters is a thing of the past. Via BAB SECURELINK gateway between EnOcean and KNXnet/IP.
you not only connect other LINKMODULEs, but also EIBPORT
TECHNICAL SPECIFICATIONS
• Operating voltage: 12–32 V DC • KNX: Twisted Pair via screw plug terminal block
• Typical power consumption 300 mA at 12 V DC • EnOcean: SMA plug (incl. 2,5 m
• Power consumption:GATEWAYS LINKMODULE
LINKMODULE
FACILITY COUPLING
WITH FACILITYMASTER Warehouse Central Visualisation Central warehouse
KNX/TP KNX/TP
The FACILITYMASTER with a central visualisation is installed in
the administration centre. The properties that do not require Headquarters
their own intelligence are simply linked to the headquarters
via the Internet with the help of the LINKMODULE and BAB LINKMODULE LINKMODULE
SECURELINK. Thanks to encryption, the data can be transmit- Internet
ted over a public network without hesitation.
FACILITYMASTER
BAB SECURELINK
LINKMODULE LINKMODULE
KNX
EnOcean®
LINKMODULE
FACILITY COUPLING
A remote system with a potential address overlap (e.g. both systems have the group address 1/0/1) has to be con-
nected to a larger system via the Internet: Thanks to the integrated address mapping function, the plant is connected
without any overlaps using simple rules.
Central visualisation
Internet
BAB SECURELINK
KNX Facility coupling KNX
Facility A LINKMODULE LINKMODULE Facility B
KNX installation KNX installation
Address mapping avoids overlaps
16/0/1 1/0/1
16/0/1 1/0/1
Art. no. 10551 LINKMODULE KNX
Art. no. 13551 LINKMODULE EnOcean
Gateways I 41GATEWAYS DATALOGGER V2
Included
KNX IP router
functionality
DATALOGGER V2
ANALYSE. CONTROL. OPTIMISE.
The DATALOGGER V2 is a powerful DIN rail device for in case of larger data volumes, in an external MySQL data-
recording KNX telegram data based on MySQL in real time. base. The ETS5 project information is used to structure the
It receives the data either via KNX/TP or KNXnet/IP. Configu- database automatically. The individually adaptable export
ration is done via a user-friendly web interface. Thanks to its takes place in a definable cycle automatically via e-mail, to
integrated KNXnet/IP server, the DATALOGGER V2 fulfils three the connected SDMODULE or manually via the network. By
functions at once: It offers IP router functionality for KNX, exporting as CSV or XLS files, the data can be used directly
records telegram traffic and, if desired, monitors IP and KNX and in various ways.
devices. The DATALOGGER records all data in an internal, or
TECHNICAL SPECIFICATIONS
• Operating voltage: 12-32V DC Interfaces:
• Typical power consumption 300 mA at 12 V DC • KNX via screw plug terminal (twisted pair)
• Power consumption:EXAMPLES DATALOGGER V2
DATALOGGER V2
AS AN IP-ROUTER
Equipped with a KNXnet/IP server, the
DATALOGGER V2 also offers IP router functio-
nality. It collects data via KNXnet/IP routing ETS 4/5
and from its own KNX line. The desired data is
LAN
automatically exported in XLS or CSV format
once a day, week or month by e-mail. Thanks
to KNXnet/IP tunneling, the DATALOGGER V2 is Export Email
also the programming interface for the ETS.
KNXnet/IP-Router KNXnet/IP-Router DATALOGGER V2
KNX KNX KNX
1.1 1.2 1.3
DATALOGGER V2
AS A KNX/TP DEVICE
Connected to the twisted pair bus, the
DATALOGGER V2 records all desired KNX tele-
grams and stores them in its internal MySQL
database. The data is exported to the
ETS 4/5
SDMODULE in CSV or XLS format. No access to
the web interface is necessary for the export. e. g.
USB storage
The data export takes place automatically in Export
the preset cycle. The written data carrier can be via USB
or
removed for evaluation and replaced by a new SDMODULE DATALOGGER V2 Sensor Actuator Weather station
one.
KNX
Gateways I 43GATEWAYS KNXCONVERTER
Included
KNX IP router
functionality
KNXCONVERTER
PARLEZ VOUS ASCII?
The KNXCONVERTER converts KNX telegrams into ASCII code group addresses are stored in an address status table, which
and vice versa. With its help you can integrate third-party ap- can be read out by third-party applications. Different KNX
plications very easily. The device sends the data via TCP, UDP worlds with the same group addresses can be distinguished
(unicast or multicast) as well as HTTP. Thanks to the simple by a system ID. The upload of ETS5 project data simplifies the
structure of the KNXCONVERTER protocol (ASCII commands), creation of ASCII commands thanks to the use of identifiers
integration is as simple as possible. A KNX/TP connection and and data types. In addition, KNXCONVERTER can also be used
the integrated KNXnet/IP server provide the connection to as a programming interface for the ETS. You configure this
KNX. The number of data points is unlimited. The values of all device platform-independently via a web interface.
TECHNICAL SPECIFICATIONS
• Operating voltage: 12–32 V DC Interfaces:
• Typical power consumption 300 mA at 12 V DC • KNX via screw terminal (Twisted Pair)
• Power consumption:EXAMPLES KNXCONVERTER
KNXCONVERTER
AS A KNX/TP DEVICE
KNXCONVERTER is connected to the Twisted
Pair Bus as an additional KNX device. After the
LAN
implementation of the KNXCONVERTER proto-
KNXCONVERTER
col, the third party application communicates protocol
(TCP/UDP/HTTTP)
bi-directionally with the KNXCONVERTER via 3rd party device KNXCONVERTER
the network (TCP or UDP), giving the third party
application full access to the KNX system and
vice versa.
Heating Actuator Weather station
KNXCONVERTER
AS A KNXNET/IP DEVICE
In larger installations, the KNXCONVERTER
replaces an IP router with its integrated KNXnet/
IP server. With the help of the KNXCONVERTER
protocol, third-party applications are connected
bidirectionally to the complete system. In this Third-party manufacturer
way, the advantages of both worlds are ideally
KNXCONVERTER protocol
combined with almost no effort. (TCP/UDP/HTTP)
LAN
IP-Router IP-Router KNXCONVERTER
KNX KNX KNX
1.1 1.2 1.3
Gateways I 45GATEWAYS INTERCOMMODULE
NEW PRODUCT
INTERCOMMODULE
HELLO. AND WELCOME.
The INTERCOMMODULE establishes the connection between phone system. With freely configurable KNX triggers, you can
an IP-capable video door intercom system and the building implement many more convenience functions. For example,
automation. connect your sound system to the doorbell or receive a push
Together with the EIBPORT or the CUBEVISIONMODULE notification.
with CUBEVISION APP it is possible to display sound and The optionally available CONTROL T 2 software is available for
picture of a video door phone system within the visualisa- use without building automation. It turns your Windows PC or
tion. Integrated functions for opening the door or switching Mac into an indoor call station for your door communication
on the lighting offer the usual comfort of a modern IP door system.
Full integration control
Both SIP client and SIP server video door phones are supported by the INTERCOMMODULE.
The INTERCOMMODULE can therefore be operated in both "Client Mode" and "Server Mode".
Currently supported video door Currently supported video door
systems with »Client Mode«: systems with »Server Mode«:
DoorBird, 2N, AGFEO, Mobotix ABB/Busch-Jaeger Welcome with
INTERCOM IP Gateway 83342
46 I GatewaysEXAMPLES INTERCOMMODULE
INTERCOMMODULE
THE INTERCOMMODULE IN APPLICATION
The INTERCOMMODULE is connected to the IP gateway 83342 via LAN. It prepares the video and audio data for use with a
web browser. This allows a touch panel PC (e.g: SMARTSURFACE with CONTROL T 2) to be used as an indoor call station. In the
same way, the functions provided by the INTERCOMMODULE can be used as a visualisation using CONTROL L or CUBEVISION 2
(in preparation). Door communication thus becomes an integrated part of the building visualisation.
Busch-Welcome®
LAN
BABTECHN
OLOGIE
IP-Gateway
Busch-Welcome® 83342 INTERCOMMODULE Router SMARTSURFACE
or:
WLAN
Smartphone
LAN
EIBPORT /
DoorBird INTERCOMMODULE Router CUBEVISIONMODULE HTS 10
TECHNICAL SPECIFICATIONS
• Operating voltage: 12-32V DC Mechanical data
• Typical power consumption: 300 mA at 12 V DC • Mounting: REG housing 4 TE
• Power consumption:GATEWAYS LOGIKMODULE
NEW PRODUCT
LOGIKMODULE
PLATFORM FOR IDEAS.
The implementation of a graphical editor based exclusively search and documentation functions, the LOGIKEDITOR also
on state-of-the-art browser technologies opens up completely offers the possibility of loading and exporting logic groups.
new possibilities for users and system integrators. Program Via our new web platform logikeditor.de, you can load
your own control sequences (logic groups) with the graphical additional ready-made logic groups that execute application-
LOGIKEDITOR or integrate third-party applications via the oriented services.
universal REST interface. In addition to a simulation mode and
TECHNICAL SPECIFICATIONS
• Operating voltage: 12–32 V DC Interfaces (depending on variant):
• Typical power consumption 300 mA at 12 V DC • Ethernet: RJ45 socket
• Power consumption:GATEWAYS LOGIKMODULE
AUTOMATISE & INTEGRATE
GRAPHICAL LOGIKEDITOR
These logic elements are provided by the graphical LOGIKEDITOR:
• Astro clock • Scene
• Binary logic • Text Processor
• Data converter • Gate object
• E-mail sender • Transformer
• Fixed value / initialization • Staircase automat
• HTTP request • Comparator
• Calendar • Distributor
• Camera Archive • Delayer
• Mathematics • Value memory
• New: REST interface • Value Read
• Collective message • week clock
• Threshold value • Timer
• Statistics • Cyclic transmitter
All logic elements can be graphically linked to each other.
With the help of so-called «Tools», these connections can be modulated at lightning speed:
• Binary filter • Round values
• Inverter • Delayer
• Calculator • Value filter
• Changeover switch • Translators
Art. no. 10571 LOGIKMODULE IP
Art. no. 10575 LOGIKMODULE KNX
Art. no. 13571 LOGIKMODULE EnOcean
Gateways I 4950 I Gateways
Gateways I 51
Visualisations CUBEVISION 2
CUBEVISION 2 + Component of EIBPORT
+ Component of FACILITYMASTER
+ Component of CUBEVISIONMODULE
One of a kind. Self-explanatory. Creative. Be fascinated by the in only three steps: Import KNX project, select background
revolutionary CUBEVISION operating concept. The sophistica- images and define functions. The complete visualisation will
ted user interface scales automatically on almost all display be created automatically afterwards. With the "Smart Func-
devices. his way, smartphone, tablet and co. become the tion Creator" you create your own scenes and smart home
control center for your intelligent home in no time. functions by drag 'n' drop within the user interface.
CUBEVISION 2 can be easily configured in your web browser CUBEVISION 2 is Smart Home as it should be.
Desktop Computer with Touch Panel PC Hybrid Touch Sensor
Windows or MAC OS
® ®
52 I VisualisationsVisualisations CUBEVISION 2
HTS10 Apple® iPad® Apple® iPhone® Android®
Smartphone
Visualisations I 53BECOME A SMART HOME DIRECTOR With the «Smart Function Creator» you create scenes directly in CUBEVISION 2: Start the «Smart Function Creator», navigate in the visualisation as usual and simply move the desired visualisation elements for the scene into the «Drop Zone». All selected elements are considered in the scene with their current values, such as dimming value, color, temperature or mode. Now new: Use additional camera positions or your favorite playlists. Your finished scene then starts either time-controlled (with optional astro function), manually from the visualisation or by events in your Smart Home, such as reaching a certain temperature, the signal of a window contact or the triggering of a motion sensor. 54 I Visualisations
Visualisations I 55
Visualisations CUBEVISION 2
ALL ELEMENTS OF THE SCENE AT A GLANCE.
After you have moved all desired elements to the «Drop elements can also be set here retrospectively. Just assign a
Zone», you will be directed to the overview of your scene. suitable name to the scene and select an icon.
Here you can find all elements of the scene. Values, sequen-
ce, activity, as well as the delays between the individual
ICONS
Since the number of scenes you create is not limited, we have
equipped CUBEVISION 2 with more than 450 icons. So you
can find scenes within the visualisation even faster.
CUBEVISION 2 live and as video on
www.cubevision.info
56 I VisualisationsVisualisations CUBEVISION 2
ADD CONDITIONS.
With the «Smart Function Creator» you do not only create types «Time and Date», «Event», «Manual» and «Alexa» are
scenes, but also define exactly how they are to be triggered. available. If several triggers are configured in a scene, con-
From the control element in the visualisation, to a simple nect them to further conditions (AND/OR). Whether simple or
clock, to the combination of different conditions. The trigger complex, you can easily create your smart home functions.
TRIGGER TYPES
The type «Time and date» provides you with a weekly
clock with astronomical function. The «Event» type offers
Time and date Event you the possibility of, for example, exceeding a tempera-
ture or current consumption or, quite simply, operating a
* push-button as a trigger.
With the type «Manual» you place the trigger at the
desired position in CUBEVISION. With the brand new
«Alexa» trigger, you can now also trigger Smart Functions
Manual Alexa
conveniently by voice command.*
* Currently only available for the EIBPORT
Visualisations I 5758 I Visualisations
Visualisations I 59
VISUALISATIONS CONTROL L
THE GREAT FREEDOM + Component of EIBPORT
+ Component of FACILITYMASTER
WITH CONTROL L
With the platform-independent visualisation of the EIBPORT With style sheets, master pages and the integrated ESF data
for PCs and tablets you can create completely individual import you create top visualisations in breathtaking speed.
visualisations. Many ready-made control elements such as With the unique Live Mode, you can check your results at any
buttons, sliders, pop-up windows or room temperature cont- time without interrupting your work.
rollers help you to do so.
60 I VisualisationsVISUALISATIONS CONTROL L
EXAMPLES FOR VISUALISATIONS WITH CONTROL L
Whether pragmatic, project oriented or design oriented:
With CONTROL L you can design your visualisation with all the freedom you need. Down to the last pixel. With ease.
FLOOR PLAN VISUALISATION
In the commercial sector, it is particularly important to present
information about large buildings clearly and to make it easy to
operate. With CONTROL L you can easily import building floor
plans and effortlessly place operating and display elements in
place. The visualization templates available free of charge make
getting started child’s play.
Project: Konzerthaus Bremen / Michael Körbs
CORPORATE VISUALISATION
Branding guidelines and specifications by architects can be
implemented in detail with CONTROL L. From the background to
the individual control element, you can design everything accor-
ding to your customer's specifications with the tools of EIBPORT.
Down to the last detail.
Project: abráx arquitetos, Brazil / Elétrica Nova Lda.
AAL VISUALISATION
Ambient Assisted Living. The term is familiar – technologies and
services will be made easily accessible to people with disabilities
to make everyday life more comfortable and safer. We believe
that this will not work with rigid operating concepts.
With CONTROL L you can create user interfaces that are perfect-
ly adapted to users and their special needs.
Project: AALINA ® / REAL SMART HOME GmbH
Visualisations I 61VISUALISATIONS CONTROL L
THE CONTROL L EDITOR –
CONVENIENT AND TARGET-ORIENTED WORKFLOW
The CONTROL L Editor offers a whole range of tools that help you implement customer requirements on time and
within budget:
WYSIWYG editor with live mode
More than 45 standard and special control elements such as web container, energy display or a Dali
monitor are available to you as prefabricated elements. By Drag & Drop you can drag the desired
elements into the work area and position them with pixel accuracy using the adjustable grid. With
the unique live preview you can test your previous work at the push of a button.
Master pages and style sheets
If visualisation pages need to share common elements, you create and modify them in a central
location: the master pages. Changes will be applied to all pages that are linked to a master page.
In this way, you can adjust even extensive visualisations at lightning speed. With the style sheets
in CONTROL L you define colour filters, typography and graphic effects centrally for all desired
elements. In this way, you create visualisations in no time and even react to spontaneous change
requests with ease.
Modern browser technologies
PC, tablet or smartphone. You can create visualisations for different operating devices as required.
With slide elements, dialog boxes and freely configurable events, you can adapt your visualisa-
tion to any end device. For example, you can open dialogs or external web pages, or trigger HTTP
requests.
Unlimited data points and extensive user administration
We believe that limitations are passé. Therefore, with CONTROL L you enjoy the freedom to define
an unlimited number of data points. With the extensive user administration, you provide users with
the access rights they need.
62 I VisualisationsYou can also read
