THORN CONTRACTOR GUIDE
The easy way to buy
Zumtobel Group is an international lighting group
and a leading supplier of innovative lighting solutions,
lighting components and associated services
Thorn Lighting has been operating in New THORNeco was launched in New Zealand in
Zealand since 1936 and was purchased by 2018 and is proving to be a very successful
Zumtobel Group in 2000. new brand. This modern and efficient
product family is the economical answer for
In 2016 we moved to new, purpose-built
the wholesale market and OTC business.
premises comprised of warehouse, factory
THORNeco is perfectly positioned to meet the
and office space measuring over 2733 sqm.
current and future needs of electricians and
In 2019 almost 100% of our lighting turnover
installers.
is LED.
All luminaires in the THORNeco family offer
Thorn brand stands for high-performing,
exceptional light quality, energy efficiency and
efficient and reliable lighting solutions that
a long life-span. THORNeco is available via our
are easy to use. Our products can be found
wholesale partners.
in many different applications such as: sport,
road, tunnel, cityscape, office, education or
industry.
Thorn is a globally trusted supplier of quality
outdoor and indoor lighting with integrated
controls. Its products are used in over 100
countries.
5 YEAR WARRANTY
Thorn Lighting is a leading global
luminaire manufacturer and provides
a five year warranty for its complete
5 YEA R product range.
GUARANTEE
4 CONTENTS
DOWNLIGHTS WALL OR CEILING MOUNT
CETUS 6 CHALICE 8 KATONA 10
ESCORT 12 JEWEL 2 14 LUNA 16
SURFACE AND SUSPENDED BATTENS
COLLEGE 18 IQ WAVE 20 POPPACK LED 22
SURFACE AND SUSPENDED INDUSTRIAL
ROYAL 24 HIPAK LED 26 FORCE LED 28
FLOODLIGHTING
AQUAFORCE PRO 30 LEDFIT 32
URBAN
FLEXITY 34 CHARTOR 36 D-CO LED 38
SURFACE AND SUSPENDED
EMERGENCY
VOLUPTO 40 PIAZZA 42 VOYAGER SOLID 44
VOYAGER SURFACE 45 VOYAGER BLADE 2 46 VOYAGER IP65 47
VOYAGER JUMBO 48 VOYAGER WALL 49 VOYAGER WIDE 50
VOYAGER RECESSED 51 VOYAGER TS2 52
6 DOWNLIGHTS
CETUS
CETUS LED downlight incorporating thermally optimised, low height, aluminium body
FEATURES MATERIALS/FINISH
High efficacy up to 111lm/W for low energy Housing/body: aluminium, powder coated white
consumption. RAL 9016
Useful life L80 at 25⁰C. Reflector: powder coated white RAL 9016
Direct replacement for traditional 1x26W or 2x26W
compact fluorescent downlights with up to 65% INSTALLATION/MOUNTING
energy saving. Tool free installation direct out of box.
Only 88mm overall height to allow installation into Suitable for a wide range of ceiling types and
low and restricted ceiling voids. depths from 1-40mm thickness.
Sealed to IP44, suitable for use in bathrooms without Overall height of 88mm allows installation into
the need for separate attachments.
low and restricted ceiling voids.
Cut out diameter = 190mm.
Remote driver makes installation and maintenance
quick and easy.
DESCRIPTION CIRCUIT POWER (W) LUMEN OUTPUT WEIGHT (KG) PART NO
CETUS LED 1000 HF 830 9.4 1000 0.70 96242095
CETUS LED 1000 HF 840 9.4 1000 0.70 96242096
CETUS LED 2000 HF 830 19.5 2000 1.75 96242097
CETUS LED 2000 HF 840 19.5 2000 1.75 96242098
NOTE: Emergency options available
CETUS LED 1000LM CETUS LED 2000LM
8 DOWNLIGHTS
CHALICE
LED Downlight range in two sizes offering a direct replacement for CFL solutions
FEATURES MATERIALS/FINISH
High efficacy of up to 110lm/W for low energy Housing/body material: Aluminium painted white
consumption.
Bezel finish: RAL9016
Less than 100mm overall height making it ideal
for low ceiling void depth. Reflector finish: Satin
IP54 (IP20 from above) as standard for use in INSTALLATION/MOUNTING
bathrooms/washrooms. Chalice can be installed directly from the box into
CFL replacement with low maintenance lifetime a wide range of ceiling types including thicknesses
of L70 50,000 hours. from 1mm-40mm.
Remote driver for quick and easy installation.
DESCRIPTION CIRCUIT POWER (W) LUMEN OUTPUT WEIGHT (KG) PART NO
CHAL 150 LED1400-830 HF RSB 12.3 1400 0.49 96629023
CHAL 150 LED1400-840 HF RSB 12.3 1400 0.49 96629024
CHAL 150 LED2000-830 HF RSB 17.3 2000 0.49 96629025
CHAL 150 LED2000-840 HF RSB 17.3 2000 0.49 96629026
CHAL 150 LED3000-830 HF RSB 27.5 3000 0.49 96629027
CHAL 150 LED3000-840 HF RSB 27.5 3000 0.49 96629028
CHAL 200 LED1400-830 HF RSB 13.2 1400 0.91 96629019
CHAL 200 LED1400-840 HF RSB 13.2 1400 0.91 96629020
CHAL 200 LED2000-830 HF RSB 17.8 2000 0.91 96642304
CHAL 200 LED2000-840 HF RSB 17.8 2000 0.91 96642305
CHAL 200 LED3000-830 HF RSB 27.5 3000 0.91 96629021
CHAL 200 LED3000-840 HF RSB 27.5 3000 0.91 96629022
150 VERSION 200 VERSION
10 WALL OR CEILING MOUNT
KATONA
The problem solver for almost any lighting task
FEATURES Clean, smooth aesthetic design reduces dust and
Very slim, functional and well protected luminaire for dirt accumulation, ensures easy cleaning and lowers
installation on walls and ceilings, indoors and outdoors. maintenance requirements.
Available in two designs, round and square in a MATERIALS/FINISH
white finish with two lumen packages, 1000lm Body and Bezel: white polycarbonate
and 2000lm.
Diffuser: white polycarbonate
Offered in warm white (3000K) or cool white
(4000K), both CRI 80. Screws: steel, zinc plated
Katona is IP65 with protection against dust and INSTALLATION/MOUNTING
water, making it an ideal fitting for indoor and Suitable for installation directly to walls or ceilings,
outdoor applications. indoors or outdoors. Loop-in, loop-out is possible for
IK10 rating resists impacts up to 20 joules ensuring cables up to 2.5mm². BESA compatible.
a high level of protection for public circulation areas.
DESCRIPTION CIRCUIT POWER (W) LUMEN OUTPUT WEIGHT (KG) PART NO
Round
KAT RD 1000-830 HF 8.3 1000 0.94 96631303
KAT RD 1000-840 HF 8.3 1000 0.94 96629365
KAT RD 2000-830 HF 16.3 2000 0.98 96631305
KAT RD 2000-840 HF 16.3 2000 0.98 96629367
Square
KAT SQ 1000-830 HF 8.3 1000 0.96 96631306
KAT SQ 1000-840 HF 8.3 1000 0.96 96629368
KAT SQ 2000-830 HF 16.3 2000 0.99 96631308
KAT SQ 2000-840 HF 16.3 2000 0.99 96629370
Side Entry
KAT RD SE 1800-840 HF 16.3 1800 1.5 96631537
NOTE: Emergency and Microwave Sensor options availableROUND VERSION SQUARE VERSION
12 WALL OR CEILING MOUNT
ESCORT
A robust and durable bulkhead for surface mounting, sealed to IP65
FEATURES MATERIALS/FINISH
Durable cast alloy construction for interior and Diffuser: opal polycarbonate with vandal
exterior usage. resistant screws
A self-contained IP65 weatherproof bulkhead Body: cast aluminium, finished white
luminaire. Control gear: switch start
Suitable for interior and exterior industrial or
public amenity usage. INSTALLATION/MOUNTING
Direct wall or ceiling mounting. Drill points on rear
Vandal resistant materials and fixings.
for ceiling/wall box/BESA mounting. Rear cable
Complete with 4000K LED. entry hole and mounting points pre-drilled and
sealed with rubber grommets. Ø20mm cable entry
at each end and 4 fixing points. 3-way terminal
block 2x2.5mm² capacity. Cable gland and blanking
grommets (2) supplied.
*All dimensions in mm
DESCRIPTION CIRCUIT POWER (W) LUMEN OUTPUT WEIGHT (KG) PART NO
ESCORT LED I-SLCT 800/1000-840 OP WH 8 800/1000 1.2 96630597
NOTE: Emergency options available14 WALL OR CEILING MOUNT JEWEL 2 A basic wall or ceiling mounted IP65 bulkhead suitable for indoor or outdoor use FEATURES MATERIALS/FINISH Compact size with smooth lines. Black or white polycarbonate base with opal Sealed to IP65. diffuser. 50,000 hour LED CRI>80. INSTALLATION/MOUNTING Suitable for indoor or outdoor use. Wall or ceiling mount, indoor or outdoor. DESCRIPTION CIRCUIT POWER (W) LUMEN OUTPUT WEIGHT (KG) PART NO JEWEL 2 LED BULKHEAD OP WHI 10 1000 0.4 96294620 JEWEL 2 LED BULKHEAD OP BLK 10 1000 0.4 96294621
16 WALL OR CEILING MOUNT
LUNA
An ultra slim high light output LED Bulkhead
FEATURES MATERIALS/FINISH
Very slim profile polycarbonate diffuser. White moulded body with opal polycarbonate
IP54 on all models for use in damp areas. diffuser.
High lumen packages with very even diffuser INSTALLATION/MOUNTING
luminance. Quick wall and ceiling mounting is easy with
supplied quick mounting bracket.
300
40
DESCRIPTION CIRCUIT POWER (W) LUMEN OUTPUT WEIGHT (KG) PART NO
LUNA 08-12W 1120-840 12 1120 0.45 96293743
LUNA 12-18W 1620-840 WH 18 1620 1.1 96293744
LUNA 12-25W 2490-840 WH 25 2490 1.4 96293745
Tri-colour
LUNA 12-18W 830\840\857 SELECT WH DIM 18 1800 1.1 9629414818 SURFACE AND SUSPENDED
COLLEGE
A curved profile range of linear LED luminaires for surface or suspended mounting
FEATURES INSTALLATION/MOUNTING
Clear prismatic diffuser in polycarbonate for specific Two cable entry holes (Ø21.5mm) in the centre
light control and impact resistance. of the back spine.
Rigidly fixed diffuser held in place by screwed on Optional cable entry through each end cap. Fitting
polycarbonate end caps for improved diffuser security supplied with sealing grommets and ‘quick-fix’
and vandal/impact resistance. horseshoe sliding washers for direct screw fixing
Sealed to IP44. to surface.
Easy installation and cleaning. Standard BESA fixings. 5 x 2 x 2.5mm2 + 3 x 2 x
2.5mm2 piano key terminal block for dimmable
MATERIALS/FINISH emergency versions.
Body and gear tray: white galvanised prepainted
steel
End caps: polycarbonate
Diffuser: precision extruded clear prismatic
polycarbonate
DESCRIPTION CIRCUIT POWER (W) LUMEN OUTPUT WEIGHT (KG) PART NO
COLLEGE LED4200-840 HF L1200 33 4200 3.63 96628932
COLLEGE LED2900-840 HF L1500 23 2900 4.44 96628922
COLLEGE LED4650-840 HF L1500 37 4650 4.44 96628918
COLLEGE LED6500-840 HF L1500 64 6500 4.44 96628877
NOTE: Emergency, dimming and control options available20 SURFACE AND SUSPENDED
IQ WAVE
Surface or suspended luminaire with modern, flowing lines
FEATURES MATERIALS/FINISH
A lightweight, modern surface or suspended Body, diffuser, frame and endcaps: polycarbonate
luminaire with indirect LED light source. (TPa) finished in white (close to RAL9016)
Innovative and Thorn patented MV tech optic offers Gear tray: pre-coated white steel. Complete with
excellent uniformity and glare control. 4000K LED
Direct/indirect light for illuminance on faces and INSTALLATION/MOUNTING
walls to encourage a comfortable, communicative
Suitable for suspension with included Y suspension
working environment.
kit and pre-assembled power cord.
Possibility to install as continuous run through wiring.
Suitable for direct surface or BESA mounting,
Easy, wireless solution allows retro fitting with central or end-cap cable entries.
no rewiring.
Standard products can be connected via optional
4000K colour temperature. continuous run kit.
Through wiring versions are available.
DESCRIPTION CIRCUIT POWER (W) LUMEN OUTPUT WEIGHT (KG) PART NO
Surface
IQ SURF S LED2600-840 HF WH 22 2600 4 96629267
IQ SURF S LED4250-840 HF WH 40 4250 4 96629269
IQ SURF L LED4250-840 HF WH 35 4250 4.9 96629271
IQ SURF L LED4900-840 HF WH 42 4900 4.9 96629273
IQ SURF L LED6700-840 HF WH 61 6700 4.9 96629275
Suspended
IQ SUSP S LED4250-840 HF ML3 WH 40 4250 4.3 96629279
IQ SUSP S LED6700-840 HF ML3 WH 61 6700 4.3 96629283
NOTE: Also available: integrated PIR and microwave sensors, controls, wireless, wiring and mounting options22 BATTENS
POPPACK LED
Batten with integrated LED technology for low energy consumption
FEATURES MATERIALS/FINISH
LED 1:1 replacement for single and twin Body: coated, formed steel, white (RAL9016)
fluorescent battens. End caps: injection moulded polycarbonate, white
Lumens range from 3000lm to 6000lm. Diffuser: textured opal acrylic
Up to 136lm/W.
INSTALLATION/MOUNTING
4000K and CRI 80.
Electrical connection via 3 x 2 2.5mm² terminal block.
Useful life: 50 000h L80.
Complete with 4000K LED.
Optional screws can be added to end caps to lock
the housing for increased security.
Additional savings can be achieved via DALI control
and an integral PIR sensor.
DESCRIPTION CIRCUIT POWER (W) LUMEN OUTPUT WEIGHT (KG) PART NO
POPPACK LED3000-840 HF L1200 23.5 3000 1.4 96630918
POPPACK LED4500-840 HF L1200 36.4 4500 1.4 96630922
POPPACK LED6000-840 HF L1500 52 6000 1.7 96630938
NOTE: Switchable, DALI ballast, sensor and emergency options available24 RECESSED
ROYAL
An efficient ultra slim recessed LED luminaire
FEATURES Panel part no. and driver part no. to be ordered
Recess LED modular luminaire with high concurrently.
performance design. Suitable for office, retail, hospital and schools.
Micro prismatic diffuser reduces glare control.
MATERIALS/FINISH
Ready for use, supplied with all components
Body: white painted aluminium frame
including flex and plug.
Diffuser: micro-prismatic diffuser
Life: L80 70 000hrs at 25⁰ C (L70>60 000hrs
at 50⁰C. INSTALLATION/MOUNTING
Suitable for UGR19 requirements. Suitable for recessed mounting in T-bar.
Luminaire efficacy: 117lm/W. Pre-wired 1.5m flex and plug.
Fixed output Tridonic driver.
*Glare evaluation in accordance with AS/NZS 1680.1 for standard office
(X = 4 H, Y = 8 H, reflection factors 70/50/20
Panel Kit
DESCRIPTION CIRCUIT POWER (W) LUMEN OUTPUT WEIGHT (KG) PART NO
ROYAL PANEL LED3500-840 12X3 HF TRI FP 31 3500 4 kg 96648543
ROYAL PANEL LED4500-840 12X6 HF TRI FP 42 4500 7 kg 96648544
ROYAL PANEL LED2700-840 6X6 HF TRI FP 23 2700 4 kg 96648545Driver DESCRIPTION DRIVER CONTROL PART NO ROYAL-DRV TR-FIX 3500 800mA CON FP Fixed Output 96648560 ROYAL-DRV TR-FIX 4500 1050mA CON FP Fixed Output 96648562 ROYAL-DRV TR-FIX 2700 600mA CON FP Fixed Output 96648558
26 INDUSTRIAL
HIPAK LED
The third generation of this innovative luminaire offers stunning performance and value
FEATURES HIPAK is also suitable for applications such as
High bay luminaire with plug and play connection retail, where appearance and visual comfort are
for rapid installation. high priorities.
Two sizes and six lumen outputs ranging from MATERIALS/FINISH
10,000lm up to 35,000lm. Housing: Die cast aluminium
Wide (WD) light distributions and specially Lens/Diffuser: polycarbonate
designed reflectors.
DALI (HFI-X) enables greater energy savings INSTALLATION/MOUNTING
plus motion and daylight sensor integration. Supplied pre-wired with quick connect plug
and mounting hook.
Highly efficient one-for-one replacement for
conventional industrial luminaires. With a higher Stirrup mounting accessories to be ordered
efficacy than its predecessors, it promises a separately. Refer to website for other mounting
quicker payback. instructions.
DESCRIPTION CIRCUIT POWER (W) LUMEN OUTPUT WEIGHT (KG) PART NO
HIPAK LED10000-840 HFI-X WD GEN3 75.3 10000 3.15 96630803
HIPAK LED15000-840 HFI-X WD GEN3 103.5 15000 3.15 96630804
HIPAK LED20000-840 HFI-X WD GEN3 134.5 20000 3.15 96630805
HIPAK LED25000-840 HFI-X WD GEN3 176 25000 5.7 96630806
HIPAK LED30000-840 HFI-X WD GEN3 201.4 30000 5.7 96630807
HIPAK LED35000-840 HFI-X WD GEN3 233.7 35000 5.7 96630808
Sensor
SENSOR MWS HIPAK GEN3 96630823
Stirrup
HIPAK STIRRUP L MCE/MWA (1pc.) G3 96631860
HIPAK STIRRUP S MCE/MWA (1pc.) G3 96631534
NOTE: Emergency options available28 INDUSTRIAL
FORCE LED
Compact IP66 dust and moisture proof LED luminaire
FEATURES MATERIALS/FINISH
Dust and moisture proof luminaire with fully Canopy: fully recyclable aluminium painted white
recyclable aluminium body. Diffuser: polycarbonate with linear prisms
Lumen packages 4150lm and 6150lm. Toggles: stainless steel
Highly efficient LEDs (>120lm/W) reduce energy
consumption. Further savings from longer INSTALLATION/MOUNTING
maintenance lifecycle. For surface, BESA or suspended mounting
and outdoor wall mounting without canopy.
Unique prismatic diffuser and wireless
integrated controls. Quick fix brackets supplied for surface mounting.
Mounting kits for conduit, chain suspension and
catenary suspension are available as accessories.
Complete with 4000K LED.
DESCRIPTION CIRCUIT POWER (W) LUMEN OUTPUT WEIGHT (KG) PART NO
FORCELED 4000 HF L840 34 4000 2.61 96617235
FORCELED 6000 HF L840 53 6000 2.65 96242061
NOTE: Emergency option available30 INDUSTRIAL
AQUAFORCE PRO
AquaForce Pro sets a new standard for moisture and dust resistant LED lighting
FEATURES MATERIALS/FINISH
IP66 rating stands against dust and powerful Canopy: light grey polycarbonate
jets of water. Diffuser: high transmission opal polycarbonate
Unique Drip Edge Effect stops dirt and moisture with refraction prisms
from gathering on the luminaire.
INSTALLATION/MOUNTING
Cutting-edge light transmission technology with
Patented snap-on mechanism EasyClick for clipless
refraction prisms provides smooth light without
mounting of diffuser. For surface or suspended
sharp edges.
mounting.
EasyClick mechanism allows simple, snap-on
Quick-fix brackets supplied for surface mounting.
mounting and seven different wiring possibilities
Suitable for ceiling or wall (both vertically and
are available.
horizontally). Mounting kits for conduit, chain
4000K colour temperature CRI>80 with suspension and catenary suspension are available as
3 MacAdam ellipses. accessories. Suitable for through wiring with H05W
Luminaire efficacy: Up to 132lm/W. or NYM cable (rated 10A).
Medium-beam (MB) light distribution. NOTE: Please contact your consultant if you are planning to
use the luminaire in environments with chemical pollutants,
Complies with the requirements of international high or condensing humidity and major variations in
food industry standards. temperature.
DESCRIPTION CIRCUIT POWER (W) LUMEN OUTPUT WEIGHT (KG) PART NO
AQFPRO S LED 2900-840 PC WB HF 22 2900 1.7 92901967
AQFPRO S LED 4300-840 PC WB HF 34 4300 1.7 92901916
AQFPRO L LED 6400-840 PC WB HF 51.4 6400 2.1 92901898
AQFPRO L LED 8000-840 PC WB HF 64 8000 2.5 92901918
NOTE: Available in fixed output or DALI dimmable control gear and Quick connect and built-in through wiring. Also available in emergency options.32 FLOODLIGHTING
LEDFIT
An ultra lightweight, reliable and efficient alternative to general purpose HID floodlights
FEATURES MATERIALS/FINISH
Ultra lightweight, compact design for ease of Body: die cast aluminium light grey, 150 sanded,
installation and minimal aesthetic impact. textured RAL9006
True asymmetric optic provides light distribution Stirrup: galvanised steel
and excellent light control with no need to tilt. Visor: polycarbonate with external surface powder
Maintenance free for 50 000 hours lifetime. coated light grey, 150 sanded, textured RAL9006
Reduce energy consumption by approximately INSTALLATION/MOUNTING
80% compared with similar HIT solutions.
Pre wired with 60cm cable.
Complete with 4000K LED.
Stirrup can be fixed by one M10 and/or two
Luminaire efficacy: 100 lm/W. M8 fixation points.
Reversible allowing different mounting positions.
DESCRIPTION CIRCUIT POWER (W) LUMEN OUTPUT WEIGHT (KG) PART NO
LEDFIT M 90W A/S CL1 L840 90 W 9000 3 96628333
LEDFIT S 45W A/S CL1 L840 45 W 4500 1.7 9662833234 URBAN
FLEXITY
Discreet and versatile LED lantern for city space lighting
FEATURES MATERIALS/FINISH
Modern, discreet and versatile post top LED lantern Canopy and base: die-cast aluminium (EN AC-46100)
which is easy to integrate into the cityscape and powder coated dark grey (close to RAL7043)
residential areas. Enclosure: clear polycarbonate. Complete with
100,000 hour maintenance free lifetime for 4000K LED
fast return on investment and low total cost
of ownership. INSTALLATION/MOUNTING
Recommended mounting height of 3m to 6m on
3600lm, 4000K.
post top spigot/columns Ø60mm or Ø76mm.
Luminaire efficacy: 79-90lm/W.
Post top mounting to Ø76mm column, maximum
LED light source, dedicated optics and integrated spigot length 75mm. Pre-wired with 5m cable.
Bi-power dimming for energy savings.
Connector version supplied with 1m wire and
Compatible with DALI, 1-10V, RF, Power Line, connector.
Minicell, Nema, Presence Detection.
Clear UV stabilised polycarbonate enclosure.
DESCRIPTION CIRCUIT POWER (W) LUMEN OUTPUT WEIGHT (KG) PART NO
FLEX 24L50-740 WSC-S CL2 W5 D76 ANT 40 3600 4.7 96270782
FLEX 24L105-740 WSC-S CL2 W5 D76 ANT 83 6550 4.7 9627111436 URBAN
CHARTOR
A timeless bollard offering modest visual guidance and comfortable white light with minimal glare
FEATURES MATERIALS/FINISH
Suitable for any application thanks to high specs and Head: die-cast aluminium, black
two mounting types: base plate (MPL) and ground Lens: clear polycarbonate
(MGR).
Internal optics: die-cast aluminium
Simply order one post and one head, for
a complete bollard. Post: galvanised aluminium painted powder
coat black
Semi-opal, anti-UV diffuser.
The LED head can be easily connected to all Chartor INSTALLATION/MOUNTING
Bollard types for refurbishment to a low power, low Base plate or buried mounting, latter option
maintenance luminaire. Simply connect the LED embeds 450mm into the ground.
driver directly to the mains. 250mm base plate version fixes via four Ø15mm
holes at 200mm centres.
Ø60mm central hole for wiring. Three way
terminal block for 2 x 4mm² cable.
DESCRIPTION CIRCUIT POWER (W) LUMEN OUTPUT WEIGHT (KG) PART NO
Head with Fresnel Lens
CHARTOR HEAD LF LED1500-840 SATIN BLACK 24.5 1500 2.3 96646244
CHARTOR HEAD LF LED800-840 LUC SATIN 800 2.3 96649333
Post
CHARTOR POST MGR BK - 10 9601895138 URBAN
D-CO LED
A timeless LED bollard offering comfortable visual guidance
AS/NZS
60598
FEATURES MATERIALS/FINISH
Comfortable white light with no glare provided Top and body: aluminium, powder coated grey 900
by a semi-opal anti-UV PC diffuser. Diffuser: semi-opal anti-UV polycarbonate
Suitable for any application thanks to high
specs and two heights. INSTALLATION/MOUNTING
Suitable for flange mounting.
50,000 hour lifetime (L80, 25⁰) ensures
low maintenance costs. Suitable for base plate mounting.
4000K LED, CRI>80.
Flange mounting.
DESCRIPTION CIRCUIT POWER (W) LUMEN OUTPUT WEIGHT (KG) PART NO
D-CO LED BOLLARD 700 30L50 840 CL1 14 700 4.15 96262146
D-CO LED BOLLARD 1000 30L50 840 CL1 14 1000 5.45 9626214540 URBAN
VOLUPTO
A smart, post top LED lantern with a radially symmetric distribution
FEATURES MATERIALS/FINISH
Volupto offers a new, decorative, modern approach Base and canopy: corrosion resistant die cast,
for city environments. powder coated aluminium finished texturised
Attractive lighting performances designed around anthracite grey (close to RAL7043). Additional
technology with a wide variety of light distribution colours on request.
options. Diffuser: UV stabilised polycarbonate (up to IK10)
With its high-tech mixing chamber, Volupto minimises Internal reflector: highly reflective white
glare and maximises efficiency for an unobtrusive
luminaire effect. INSTALLATION/MOUNTING
Post top mounting: Ø60mm. Low weight for ease
A truly intelligent luminaire with fully integrated
of manipulation. Pre-wired for ease of installation,
motion solution together with further connectivity
1 tool. 120⁰ fixing screws for perfect adjustment on
options.
the pole.
Maintenance with access from above, one tool.
DESCRIPTION CIRCUIT POWER (W) LUMEN OUTPUT WEIGHT (KG) PART NO
VO 18L50-740 RS CL1 W5 T60 ANT 28 3800 7.59 96631905
VO 18L70-740 RS CL1 W5 T60 ANT 40 5000 7.59 96631907
VO 18L105-740 RS CL1 W5 T60 ANT 60 7000 7.59 9663190942 URBAN
PIAZZA
A robust wall mounted outdoor luminaire suitable for building perimeter applications
FEATURES MATERIALS/FINISH
Unique photometrics with 3 metre forward light Back-plate: die cast aluminium painted anthracite
throw and 12 metre spacing. (RAL7016)
Very low upward light throw with less than Body: polycarbonate in anthracite colour (RAL 7016)
2.5% ULOR. Diffuser: textured clear polycarbonate
Excellent 116 lm/W efficiency.
INSTALLATION/MOUNTING
Easy installation, back mounted, BESA and
Wall mountable. Ø20mm cable entry via rear or side
surface mounted conduit compatible.
conduit entries. Recommended 3-4 metre mounting
Rated 60,000h L70 at 25⁰C. height. Complete with 4000K LED.
DESCRIPTION CIRCUIT POWER (W) LUMEN OUTPUT WEIGHT (KG) PART NO
PIAZZA II LED 1690-840 HF ANT 15.4 1690 2.8 96666256
PIAZZA II LED 2700-840 HF ANT 25 2700 2.8 96666261
Photocell
PIAZZA II LED 2700-840 HF P ANT 25 2700 2.8 9666626444 EMERGENCY
VOYAGER SOLID
LED bulkhead for easy emergency lighting
AS/NZS
2293
FEATURES MATERIALS/FINISH
The luminaire can be wall or ceiling mounted. Body: large size, white polycarbonate
Self test emergency lighting circuit. Cover: transparent polycarbonate
3 hour, electronic, fixed output control gear. INSTALLATION/MOUNTING
Flexible switch allows luminaire to be installed Easy installation with hinged electronics and big
maintained or non-maintained. wiring space.
Bulkhead emergency luminaire for use
without decals.
DESCRIPTION CIRCUIT POWER (W) WEIGHT (KG) PART NO
VOYAGER SOLID L MS E3T-S WH 2.3 0.9 96629765VOYAGER SURFACE
A high performance LED emergency light
AS/NZS
2293
FEATURES MATERIALS/FINISH
With energy efficient LED lamps and reliable lithium- White powder coated steel rim with white
ion battery, the Voyager Surface delivers superior light aluminium disc.
output allowing greater spacing.
INSTALLATION/MOUNTING
Low 0.5W standby power consumption.
Surface mount.
Retrofitting is easy with an adapter plate to suit older
applications included in the box.
Tamper resistant with no dome required.
Suitable for most emergency lighting applications.
50,000 hour LED.
Non-maintained manual test switch.
Lithium-ion battery (3 year warranty).
DESCRIPTION CIRCUIT POWER (W) WEIGHT (KG) PART NO
VOYAGER SURFACE DISK D40 E2 0.5 0.5 9629457846 EMERGENCY
VOYAGER BLADE 2
LED Slimline Exit Light
AS/NZS
2293
FEATURES MATERIALS/FINISH
Energy efficient low 3W standby power consumption. Polycarbonate body with polycarbonate diffuser.
One box solution: comes with both and single and INSTALLATION/MOUNTING
double-sided decals in running man pictograph
Terminal block and cable entry.
and the exit decal.
Wall, ceiling single-sided and ceiling double-sided
Maintained manual test switch.
mounting.
24m viewing distance.
50, 000 hour LED.
Lithium-ion battery (3 year warranty).
DESCRIPTION CIRCUIT POWER (W) WEIGHT (KG) PART NO
VOYAGER BLADE 2 SURFACE 24M E2 3 1.15Kg 96294579VOYAGER IP65
LED weatherproof exit light
AS/NZS
2293
FEATURES MATERIALS/FINISH
Low 3W standby power consumption. Polycarbonate body with polycarbonate diffuser
One box solution: Single Running Man pictograph INSTALLATION/MOUNTING
and EXIT decals included.
Terminal block and cable entry.
Maintained manual test switch.
Wall or ceiling mount.
24m viewing distance.
50,000 hour LED.
Lithium-ion battery (3 year warranty).
DESCRIPTION CIRCUIT POWER (W) WEIGHT (KG) PART NO
VOYAGER IP65 EXIT 24M E2 3 1.53 9629458448 EMERGENCY
VOYAGER JUMBO
Highly visible LED exit light
AS/NZS
2293
FEATURES MATERIALS/FINISH
40m viewing distance. Powder coated metal frame with polycarbonate
diffuser.
One box solution: comes with both single and double
sided decals in running man pictograph and exit decal. INSTALLATION/MOUNTING
Easy installation. Terminal block and cable entry.
Energy efficient long life 50,000 hour LED. Wall, ceiling single-sided and ceiling double-sided.
Maintained, manual test switch.
Lithium-ion battery (3 year warranty).
630mm 100
320
DESCRIPTION CIRCUIT POWER (W) WEIGHT (KG) PART NO
VOYAGER JUMBO EXIT 40M E2 5.3 4.3 96294583VOYAGER WALL
LED wall mount exit light
AS/NZS
2293
FEATURES MATERIALS/FINISH
Low 3W standby power consumption. Powder coated metal frame with polycarbonate
One Box solution: Single Running Man pictograph diffuser.
and EXIT decal included. INSTALLATION/MOUNTING
Energy efficient long life 50,000 hour LED. Terminal block and cable entry.
Maintained, manual test switch. Wall, ceiling single-sided and ceiling double-sided.
24m viewing distance.
Lithium-ion battery (3 year warranty).
DESCRIPTION CIRCUIT POWER (W) WEIGHT (KG) PART NO
VOYAGER WALL EXIT 24M E2 3 1.1 99629458150 EMERGENCY
VOYAGER WIDE
Wide body LED emergency exit light
AS/NZS
2293
FEATURES MATERIALS/FINISH
Low 3W standby power consumption. Polycarbonate body with polycarbonate diffuser.
One box solution: includes both single and double- INSTALLATION/MOUNTING
sided decals in running man pictograph and the
Terminal block and cable entry.
exit decal.
Wall, ceiling single-sided and ceiling double-sided.
Easy installation.
Energy efficient long life 50,000 hour LED.
Maintained, manual test switch.
24m viewing distance.
Lithium-ion battery (3 year warranty).
GWNE1609
160mm
378mm
202mm
DESCRIPTION CIRCUIT POWER (W) WEIGHT (KG) PART NO
VOYAGER WIDE EXIT 24M E2 3W 1.35 96294580VOYAGER RECESSED
LED recessed exit light
AS/NZS
2293
FEATURES MATERIALS/FINISH
Low 3W standby power consumption. Polycarbonate body with polycarbonate diffuser.
One box solution: comes with both single and double-
INSTALLATION/MOUNTING
sided decals in running man pictograph and the
exit decal. Terminal block and entry cable.
Energy efficient long life 50,000 hour LED. Recessed.
Easy installation.
Maintained, manual test switch.
24m viewing distance.
Lithium-ion battery (3 year warranty).
195
DESCRIPTION CIRCUIT POWER (W) WEIGHT (KG) PART NO
VOYAGER BLADE RECESSED 24M E2 3W 1.3 9629458252 EMERGENCY
VOYAGER TS2
Double spot LED emergency luminaire
AS/NZS
2293
FEATURES Replaces 2x20W and 2x35W traditional
2 x 3W energy efficient LED. halogen flood units.
Low 1.0W standby power consumption. Non maintained, manual test switch.
Light weight for easy wall mounting. 50,000 hour LED.
Supplied with flex and plug with adjustable heads. Lithium-ion battery (3 year warranty).
Long life LED in non-maintained mode. MATERIALS/FINISH
Useful in areas where it is difficult to mount Polycarbonate body.
conventional emergency luminaires.
INSTALLATION/MOUNTING
Can be used outside in loading docks, carparks Flex and plug supplied.
and evacuation assembly points.
Wall mount.
68
290
148
273
DESCRIPTION CIRCUIT POWER (W) WEIGHT (KG) PART NO
VOYAGER TS E2 1W 0.85 9629458554 SAFETY AND QUALITY
STANDARDS
REGULATORY COMPLIANCE MARK (RCM) ELECTRICAL SAFETY
All luminaires and lighting equipment which are AS/NZS 60598.1:2017 Luminaires – General
to be sold in Australia and New Zealand must requirements and tests (IEC 60598–1, Ed. 8.0 2014).
be permanently marked with the Regulatory AS/NZS 60598.2.2:2016 Recessed luminaires
Compliance Mark (RCM). The RCM tick indicates (IEC 60598–2–2, Ed. 3.0 2011 ).
compliance to:
AS/NZS 60598.2.3:2015 Luminaires for road and
• Electrical Safety street lighting (IEC 60598–2–3, Ed. 3.1 2011 ).
– Electrical Regulatory Authorities Council (ERAC)
– Australian and New Zealand State Regulators AS/NZS 60598.2.5:2002 Luminaires – Particular
e.g. NSW Fair Trading requirements – Floodlights (IEC 60598.2.5:1998).
– Australian and New Zealand Standards AS/NZS 60598.2.22:2005 Luminaires for emergency
• Electromagnetic Compatibility and Radio lighting (IEC 60598–2–22, Ed. 3.1 2002).
Frequency Operation AS 2293.3–2005 Emergency escape luminaires
- Australian Communications and Media Authority and exit signs (Australia Specific with 2 Hour
(ACMA) requirement).
– Australian and New Zealand Standard
Most Australian and New Zealand Standards (AS/ ELECTROMAGNETIC COMPATIBILITY
NZS) used for RCM compliance are based on similar AS CISPR 15:2017 Limits and methods of
EN or IEC Standards with similar numbering. The measurement of radio disturbance characteristics
AS/NZS requirements are similar to the equivalent of electrical lighting and similar equipment
EN or IEC standard although some additional
(CISPR 15:2013+AMD1 :2015 ED.8.1 ).
requirements are also prescribed.
AS/NZS 4268:2017 Radio equipment and systems
– Short range devices – Limits and methods of
measurement.LED QUALITY CRITERIA
There is LED and there is LED
Various LED types are available on the market, COLOUR TEMPERATURE
performing different tasks with respect to service Whether the LED and/or the luminaire has warm
life, lighting quality and thermal management, or fairly cool light can be derived from the colour
depending on the application involved. So far temperature indicated. The higher the colour
there are only few standards enabling objective temperature, the cooler the lighting effect. A colour
comparison. temperature of 3000 K is generally called warm.
4000 – 4200 K is perceived as intermediate and
TEMPERATURES >5500 K as cool white.
In the data sheets provided by LED manufacturers,
the temperature at the semiconductor (Tj = T SERVICE LIFE
junction) is generally determined to be 25°. The Tc Usually, details regarding the service life of LEDs
temperature, however, is indicated for a measuring at specific temperatures are indicated by LED
point on the LED board. If the temperature defined manufacturers in/on the LED chip (see diagram).
by the board manufacturer is observed, the service To achieve these, reliable thermal management
life stated in the data sheet and/or the luminous flux must absolutely be ensured in the luminaires. For
of the module will be achieved. this purpose, Zumtobel Group uses various methods
As this information in part substantially differs from explained in greater detail under
the temperature levels given directly on the chip, this “Thermal management”. The service lives of the LED
may easily cause some confusion with respect to chips/boards are indicated in the ZG catalogues
reference values. and specifications. Product specific features, such
as more favourable thermal conditions, e.g. lower
LUMINOUS FLUX LEVELS AND EFFICIENCY temperatures than required by the manufacturer,
The light emanating from the LED chip or the LED have already been taken account of.
board is call ed luminous flux. In LED lighting we Another important question is which luminous
talk about the luminous flux of the luminaire instead flux level may be expected at the end of service
of the lamp lumen factor. The luminous flux of the life. A level of 70 % is normally assumed. Some
luminaire designates the light actually emanating manufacturers, however, indicate a luminous flux
from the luminaire. Efficiency is indicated in lumens of 50 %. These specific features should be observed
per watt (lm/W). It designates the ratio of luminous when selecting and comparing products.
flux to power supplied.
The luminous flux of an
LED depreciates faster at
higher temperatures.
Efficient thermal
management extends the
Relative luminous flux
life of LEDs.
Please consider the
definition of life as stated
by the LED manufacturer.
Operating Hours
55°C 80°C 100°C 125°C56 SAFETY AND QUALITY
LUMINOUS FLUX LEVELS OF LUMINAIRES THERMAL MANAGEMENT
One critical aspect in comparing LED luminaires of Efficient thermal management is indispensable in
different suppliers is the comparison of luminous order to achieve a long service life and to operate
flux levels, as mentioned above. In the catalogues of LEDs as efficiently as possible.
many manufacturers, you will find details regarding Not only will higher temperatures in the LED chip
the luminous flux and efficacy of individual LEDs reduce service life; the efficiency of the LED chip, too,
at ambient temperature of 25 °C, details regarding will decrease as temperature increases.
the luminous flux levels of the LED board used at a
specific Tc temperature, but also details regarding For reliable products with top efficiency levels – an
the luminous flux levels of luminaires and luminaire absolute must for providing a 5-year guarantee
efficacy levels, including the power loss of drivers and – Zumtobel Group uses both highly efficient
any potential loss of efficacy through lighting optics, passive surface cooling, e.g. with PANOS INFINITY,
such as lenses, reflectors or mixing chambers. and active systems with ventilator and SynJet™
membrane cooling. Yet reliable and efficient thermal
The indication of the luminous flux of the luminaire management starts at an earlier point: during
and of the system efficacy in catalogue data and the development process, that is – which includes
specifications certainly is the most meaningful as comprehensive tests and simulations in Zumtobel’s
it indicates the actually available luminous flux own laboratories.
emanating from the luminaire. These levels are
indicated in Zumtobel Groups’s catalogues and A large heat sink alone cannot generally be
specifications. considered a sufficient quality criterion for optimal
thermal management. A thermal connection
The diagram shows an example of possible efficacy between board and heat sink must also be ensured.
losses within a luminaire. The levels may vary For this purpose, Zumtobel uses thermal pads or
depending on changing materials and thermal compounds as required.
conditions. In case PANOS
of doubt, we recommend
INFINITY 200
comparing the photometric data by means of Within the scope of quality processes, thermal
infrared heat image connection of the LED chips to the boards is checked
lighting design software.
as well and compared with the LED manufacturer’s
specifications.
This know-how available within the Zumtobel Group
PANOS INFINITY 200 and at the individual plants, has enabled the Group
to develop the 5-year guarantee. It emphasises the
infrared heat image
consistent principle of quality observed throughout
the entire development and production processes of
products.
The LDT files reveal the truth!
Luminous flux of individual LEDs
WRONG (specifications from LED data sheet)
The data sheet specifications relate to
135 – 165 % of 25 °C Tj (Tj = junction temperature) in
luminaire luminous flux the LED chip – between the junctions in
the LED. However, the data sheets also
include permissible Tj temperatures of
150 °C in some cases. During operation,
high-performance LEDs get very hot.
WRONG
Heat however has a negative effect on
135 – 165 % of both luminous flux and the service life of
WRONG luminous flux
luminaire the LED.
Luminous flux of the LED module
110 – 140 % of
(without optic etc.)
luminaire luminous flux
In this case, the LED module is assumed
to be similar to a lamp. The LED module
thus has 100 % luminous flux. This value,
however, has yet to be reduced by the loss
WRONG in light output ratio.
110 – 140 % of Luminaire luminous flux (incl. light output
CORRECT
luminaire luminous flux ratio losses) This information refers to
the actual luminous flux of the luminaire,
100 % luminaire including any losses, for instance in the
luminous flux reflector etc.
CORRECTZUMTOBEL “STABLE WHITE” COLOUR RENDERING
“Stable White” is a Zumtobel quality label for mixing Today LED lighting solutions achieve high colour
chamber systems. In the LED sphere it comprises e.g. rendering in excess of Ra 90, and hence are more
a maximum admissible colour drift of 5 MacAdams sophisticated than many solutions using fluorescent
in the course of the service life of the LED. This lamps. Even the colour rendering levels of discharge
makes the criteria somewhat more stringent than lamps are achieved, as are other technical lighting
for fluorescent lamps, for instance, where even properties.
5 MacAdams and more are possible when using For its high-quality products, Zumtobel Group
different batches. collaborates closely, sometimes exclusively, with
“Stable White” also stands for fixed colour other manufacturers of LEDs and LED modules,
temperatures of warm (e.g. 3000 K) and which guarantees integration of the latest
intermediate (e.g. 4000 K). technologies at an early stage of any new product
development.
As regards the colour rendering of LEDs, the
following indications are of key importance:
normative colour rendering in the warmer colour
2700 3000 3400 4000 4900 6500
temperature range is usually higher with single-
chip-LEDs with a blue dye and yellow phosphor.
Colours should be rendered as naturally as possible
by choosing the corresponding phosphor mixes. For
a cooler colour temperature, the phosphor mix is
changed. LEDs
Ra > 90
with cooler light
Ra 90
colours are normally
ZUMTOBEL “TUNABLE WHITE” more efficient, but their colour rendering index is also
lower.
“Tunable White” describes
2700 the option
3000 3400 to dynamically
4000 4900 6500
change
2700 the light of
3000 the LED
3400 4000in the4900
white light
6500 range, By mixing white light through LEDs of different light
colour temperatures of e.g. 2700 K to 6500 K can be colours, excellent colour rendering can be achieved at
variably adjusted. In the process, the LED luminaires simultaneously high efficiency.
LED board LED board
achieve a high colour rendering index of at least Ra Stable White Tunable White
80 to Ra > 90.
Ra > 90 Ra 90
Ra > 90 Ra 90
2700 3000 3400 4000 4900 6500
2700 3000 3400 4000 4900 6500
LED board LED board
Stable White Tunable White
LED board LED board
Stable White Tunable White58 SAFETY AND QUALITY
QUALITY
Thorn Lighting is committed to providing its customers with products and
services that are of the highest quality. All Thorn Lighting products are
Quality
designed and manufactured to ensure safety, reliability and performance. ISO 9001
Our expertise in meeting these goals is recognised EUROPEAN MADE PRODUCTS
internationally. Thorn Lighting is an active participant For European made luminaires and lighting
in developing International product (IEC), European components, European harmonisation of national
(EN) and lighting (CIE, ISO) Standards, as well as approval marks has been achieved through
local AS/NZ Standards. introduction of the ENEC mark.
The ENEC mark can be awarded by any of the
QUALITY ASSURANCE (AS/NZS ISO 9001)
recognised European approval authorities, such as BSI,
All activities associated with providing a quality VDE, SEMKO, in the same way as a national approval
product - design, development, testing, production, mark. ENEC is important because it indicates that the
despatch, customer service - are covered by each Thorn product is suitable for use throughout Europe and that
operation achieving compliance to an internationally all of the most onerous special national conditions of
recognised Quality System, ie AS/NZS ISO 9001, BSEN test standards have been complied with.
ISO 9000, EN ISO 9000 or ISO 9000.
In the case of lighting components such as ballasts,
All Thorn products from European design and transformers, emergency lighting units etc. the ENEC
production sites (in Austria, France, Germany, Sweden mark indicates that both safety and performance
and UK) are manufactured to the highest standard. standards have been complied with.
Each site is registered and operated under the quality
management system EN ISO 9001 standard. Thorn Lighting supported the introduction of
the ENEC mark as a major advance in product
THIRD PARTY PRODUCT APPROVALS certification and was the first UK Company to secure
approvals under this demanding scheme.
Third party approval requires independent
endorsement that product design is in accordance The CE mark signifies that a product conforms to
with published standards, and that controls to the requirements of relevant EEC directives. The
maintain quality in manufacture are applied. prime purpose of the mark is to assist customs and
market inspectors in facilitating the free trading and
Thorn Lighting holds many third party approvals,
movement of products within the EEC. At this time the
such as the BSI Kitemark for luminaires and
directives appropriate to general lighting products are
components. Many of our products carry other
the Low Voltage Directive (LVD), the Electromagnetic
European Test House approvals. NATA test reports
Compatibility (EMC) Directive and the Energy
are internationally recognised and are considered as
Efficiency (Ballasts for Fluorescent Lighting) Directive.
independent - third party test certification.
CE marking is compulsory declaration of conformity to
Thorn UK, under the BSI “Supervised Manufacturer’s indicate that the products meet all relevant directives
Testing Laboratory” system contract number BSI and requirements, eg. LVD, EMC and Ballast Efficiency.
001, carries out compliance testing to BSEN ISO/
The ENEC and CE mark has no legal standing within New
IEC 17025 - “Operation of testing laboratories”.
Zealand other than as “an assurance of safety”. Thorn
Furthermore Thorn UK photometric laboratory is
Lighting’s comprehensive compliance with all relevant
a listed registered member of the BSI Registered
standards, and implementation of systems to meet
Photometric Laboratory Scheme (No 003) and this
them, means its products comply with these European
ensures high quality of photometry measurement and
directives and the standards on which they are based.
production of data for all products.
Thorn Lighting selects and uses independent and/or ASSURANCE OF SAFETY
in-house test facilities to provide the necessary level New Zealand has various “Electrical Safety Acts”
of compliance coverage for all aspects of lighting and Australian Standard AS/NZS 3280
product performance and safety.
“Essential safety requirements for low voltage
equipment” makes it unlawful to make, hold, or
offer for sale any electrical appliance that is unsafe.WORKING TO PREVENT LIGHT POLLUTION Thorn uses efficient light sources and computer-
Glare; the uncomfortable brightness of a light source optimised optics in its products in order to maximise
and light trespass, the spilling of light beyond the the light output and enable precise control of the
boundary of a property, are other forms which can direction of the light. Thorn Lighting will continue to
also cause physiological and ecological problems. contribute to all learned bodies, ie. IES, The Lighting
Society, CIE, working in favour of better lighting
Thorn Lighting is committed to the application of
and to advise all its clients of the contribution that
better quality lighting. Properly designed luminaires
reducing glare and spill light makes towards better
and lighting schemes can substantially improve the
quality lighting and improving the lit environment.
quality of life.
EXPLANATION OF CLASSIFICATIONS
EMERGENCY LIGHTING IPX4. Splash proof (spray from any angle)
Emergency lighting is provided when the supply to IPX5. Water jet
the mains lighting fails. It helps people avoid panic, IPX6. Strong water jet
restores their confidence and guides them quickly IPx7. Temporary immersion up to 1m
and safely out of the building. Thorn Lighting offers IPX8. Long-term immersion to declared depth
a wide range of emergency lighting luminaires. These
may be integrated standard luminaires or separate IMPACT RESISTANCE
dedicated emergency units. The use of Joules (Newton metres - Nm) has been
The requirements and operation of emergency common for many years. More recently an IK rating
lighting is governed by legislation, the Building normally used for electrical enclosures and cabinets
code of New Zealand and Australian/New Zealand ( EN 50102:1995) has emerged as manufacturers
Standard AS/NZS2293. Operational performance apply it to their luminaires. The following chart
to the standard is achieved by the thermal and compares both ratings.
photometric test to Appendix C & D. All “standard
emergency products” Impact Resistance Rating Comparison
IK rating Joules of Energy IK rating Joules of Energy
INGRESS PROTECTION IK01 0.15j IK06 1j
The ingress protection (IP) code denotes the IK02 0.23j IK07 2j
protection against dust, solid objects and moisture IK03 0.35j IK08 5j
provided by the luminaire enclosure. If no code is
IK04 0.5j IK09 10j
marked the luminaire is deemed to be IP20.
IK05 0.7j IK10 20j
INGRESS PROTECTION (IP) CODE
(i) First digit of code denotes protection against SAFETY CLASSIFICATIONS
dust and solid objects Class I
IP2X. No entry of standard test finger to live parts Luminaires in this class are electrically insulated and
IP3X. No entry of >2.5mm Ø probe to live parts provided with a connection to earth. Exposed metal
IP4X. No entry of >1mm Ø probe to live parts parts that could become live in the event of basic
IP5X. Dust proof. (No dust deposit around live parts) insulation failure are protected by earthing.
IP6X. Dust tight (no dust entry)
(ii) Second digit of code denotes protect against Class II
moisture These luminaires are designed and constructed
IPX0. No special protection so that protection against electric shock does not
IPX1. Protection against drops of condensed water rely on basic insulation only. This can be achieved
IPX2. Drip-proof (vertical falling drops of liquid) by means of reinforced or double insulation. No
IPX3. Rain-proof (rain up to angles of 60°) provision for earthing is provided.60 SAFETY AND QUALITY
OUR WARRANTY
ZG Lighting five year product warranty against defects
(New Zealand only) 5 YEA R
GUARANTEE
We warrant that, if used in accordance with their of faulty or replaced product, mileage, travel time,
intended purpose, the products marketed under the callouts, third party supervisors and security personnel;
trademarks “Zumtobel“, “Thorn” and “Thorneco” are free such costs shall be borne by the customer
from manufacturing defects and/or defective material • Parts subject to wear, such as, for instance, all
for the warranty period of five (5) years from the invoice standard lamps, batteries and starters for luminaires
date (or date of manufacture if invoice date is not with magnetic ballasts and hard drives; computers
known or available). This guarantee shall apply only to and servers containing either hard discs or mechanical
products delivered on or after October 1, 2015. parts subject to wear
The warranty applies to all products sold by ZG Lighting • Likewise, software defects, bugs or viruses
(NZ) Ltd. • Third party components or products which ZG Lighting
The warranty covers the products detailed above, (NZ) sells separately (for instance, OEM lamps,
provided that: ballasts or other componentry that are not fixed to
• The product is properly installed, and installation is or installed in the luminaire)
consistent with the manufacturer’s instructions, and • Settings and/or parameterisations on facilities that
is installed by a suitably trained and qualified installer vary on account of wear, fatigue, or dirt
• The product is not subjected to any unauthorised • Logistics claims where damages are reported more
modifications than 3 months after despatch date from ZG Lighting
• The product is only used for the purpose of (NZ) warehouses
illumination, in line with its designated purpose or the • Products that have been shipped to and installed
designated purpose of a luminaire of its general type in a country other than Australia or New Zealand
• There is evidence that the agreed maintenance In the event of the goods being replaced during the
and operating conditions have been met as per warranty period, the warranty on the replacement
manufacturer’s instructions and specifications goods will expire on the same date as the warranty
• Any faults or defects attributable to the misuse, abuse, period of the original goods they are replacing.
accident or non-observance of the manufacturer’s All claims or enquiries made under this warranty shall
instructions on the part of the user are specifically be processed as follows:
excluded
1. Within 14 working days of becoming aware of an
If a claim is made under this warranty and this warranty alleged fault, the customer must contact the company
applies then we may, at our own discretion repair the as detailed below.
product, replace the product with identical or equivalent 2. The customer must provide a proof of purchase from
product or refund the original purchase price of the the Supplier as well as photographic evidence of the
product. reported fault.
The warranty also covers reasonable labour cost and 3. If accepted as a valid warranty claim within the terms
equipment hire incurred with removing, repairing and described in this document, ZG Lighting (NZ) Ltd will
replacing defected products or components. The cover make suitable repairs, provide equivalent replacement
of labour will be only during normal business hours product or refund the original purchase price of the
7am - 4pm. The company will cover costs of necessary product.
equipment that may be required such as scaffolding 4. ZG Lighting (NZ) Ltd may request the customer
or lifts. The electrical contractor will be chosen by to have goods returned for repair or further
ZG Lighting (NZ) Ltd. In exceptional cases electrical investigation.
contractors may be chosen by the customer in which
5. In such cases (as item 4 above), the customer
case labour cost and equipment hire will only be covered
will be provided with a Goods Return Authority
by ZG Lighting (NZ) Ltd after a quote has been received
(GRA) number and ZG Lighting (NZ) Ltd will make
and approved in writing.
arrangements for collecting the goods from the
The warranty does not apply to: customer at a pre-determined date/time.
• Any other ancillary costs incurred in connection with
remedying the defects (such as, for instance, disposal6. If, after review of claim or further inspection of goods, You are entitled to a replacement or refund for a major
the claim is rejected, the customer will be provided failure and for compensation for any other reasonably
with a full explanation, and if requested, the goods foreseeable loss or damage. You are also entitled to
will be returned. have the goods repaired or replaced if the goods fail
Our goods come with guarantees that cannot be to be of acceptable quality and the failure does not
excluded under the New Zealand Consumer Law. amount to a major failure.
ENSURING LEGAL COMPLIANCE
When you purchase Thorn Lighting Products you can Combined with Zumtobel Group’s 5 year warranty on
rest assured that every effort has been made to ensure all Thorn Lighting products, you can be assured that
that the quality product complies with all current New your lighting will be safe, compliant and provide quality
Zealand legislation. lighting for years to come.
CREDIT RETURN POLICY
Customer Services Line 0800 800 834
ERROR WITH YOUR INVOICE ERROR WITH YOUR DELIVERY
1. Should you find an error with your invoice, call our 1. Call our Customer Services line within 7 days of
Customer Services line within 24 hours of receipt receipt of goods.
of the invoice. 2. Explain the discrepancy in your delivery, quoting
2. Explain the error, detailing the invoice number the packing slip and Thorn order number.
and Thorn order number. 3. We will arrange to recover any incorrectly supplied
3. We will arrange a credit/debit adjustment to your product and supply the correct item.
invoice immediately.
STOCK RETURNS
DAMAGED GOODS Our conditions of sale are:
1. Phone our Customer Services line within 7 days 1. Goods specially made to order or indented for your
of receipt of goods. purposes ARE NOT returnable. (See the relevant
2. We will: statement on your invoice/packing slip).
a) have the goods inspected 2. Where it is agreed that goods may be returned for
b) authorise the return for repair or replacement credit, these may be subject to a restocking fee of
3. We will prepare the goods return documentation up to 20%.
and send to you within 24 hours. 3. You must obtain a Goods Return Authorisation
4. If the goods are to be returned, please make sure the (GRA) from Customer Services before any goods
original Thorn Lighting packaging is still intact, with can be returned. No credit will be issued without
the correct documentation and our address. a GRA number.
4. Your returned goods must be accompanied by
the GRA and will be credited after they have been
received back into a Thorn branch and are confirmed
to still be in a saleable condition.THORN LIGHTING CONTRACTOR APP
Download our free app which has the latest contractor product ranges, ‘how to’ application
design guides and details of where you can buy Thorn products. After one quick sync, you can
view the app on the move without the need for internet connectivity.
Suitable for mobile and tablet.
Auckland - Headquarters Wellington - Sales Office
ZG Lighting (NZ) Limited ZG Lighting (NZ) Limited
27 Jomac Place Level 2
Avondale 1026 Thorndon Quay
T 0800 800 834 Wellington 6011
E Info.nz@zumtobelgroup.com T 0800 800 834
W thornlighting.co.nz W thornlighting.co.nz
Christchurch - Sales Office
Unit 7A
303 Blenheim Road
Upper Riccarton
Christchurch 8041
T 0800 800 834
W thornlighting.co.nz
For all Sales Enquiries/Orders/Returns please use the following email address:
thnz.reception@zumtobelgroup.com
5 YEA R
GUARANTEE
Thorn Lighting is constantly developing and improving its products. All descriptions, illustrations, drawings and specifications in this publication present only general
particulars and shall not form part of any contract. The right is reserved to change specifications without prior notification or public announcement. All goods supplied
by the company are supplied subject to the company’s General Conditions of Sale, a copy of which is available on request. All measurements are in millimetres and
weights in kilograms unless otherwise stated.
Publication No: CG_NZ Publication Date: 02/20You can also read
