THE DRIVING FORCE
TM
TECHNOLOGY Federal Signal is The Driving Force™
behind the technology that provides safe
and reliable emergency warning for
first responders. It is our commitment
EXCLUSIVE TO FEDERAL SIGNAL, THESE to engineer the most reliable and high-
performing products for your emergency
TECHNOLOGIES ARE IDENTIFIED BELOW. vehicle.
FS CONVERGENCE NETWORK products ROC (RELIABLE ONBOARD CIRCUITRY™)
utilize a serial communication cable to provide technology eliminates approximately 85% of the
“plug-and-play” installation of Federal Signal’s light connection failure points found in a typical light bar.
bars and other warning devices to Federal Signal’s Wires, connections, and assemblies are replaced
compatible siren amplifiers and controllers, such as by PCB assemblies, reducing labor repair time and
our Pathfinder product family.
®
increasing the road time for emergency vehicles.
FSLINK® is a built-in software technology that RUMBLER® is a low frequency siren that works
incorporates a shared set of flash patterns within simultaneously with primary siren tone that
Federal Signal’s LED perimeter lights, interior lights, penetrates solid materials allowing vehicle operators
and beacons. This shared flash pattern software and nearby pedestrians to feel the sound waves.
allows various products to be wired together, set in a The Rumbler is particularly effective for Police and
common pattern, and then synchronized together in Fire/EMS applications when used in dense urban
order to flash simultaneously or alternately. environments with heavy vehicle and pedestrian
traffic.
FSJOIN™ is a programming compatibility feature
of Federal Signal’s light bars and exterior/interior SLR (SOLARIS® LED ROTATOR) maximizes
warning lights that work in conjunction with the LED light source for full light coverage. The SLR
Pathfinder light/siren controllers. This feature
®
rotators in Navigator , Vision SLR, and SLR Beacon
® ®
enables the synchronization of functions, operation, provide rotating, oscillating, flashing and flood light
and flash patterns of individual light heads from functionality.
multiple warning devices to create a unified vehicle
solution. FSJoin further provides the capability
to synchronize warning lights on multiple “like- SOLARIS® LED Reflector Technology is engineered
programmed” vehicles to unify the visual and audible to increase off-axis warning and maximize the LED
warning of a multi-vehicle response. light source to eliminate dark spots and distribute
360-degrees of light coverage.
HOTFOOT® lighted mounting feet provide
additional light through powerful Solaris LED V-SHAPE® light bar is mechanically designed to
reflectors that are built into the mounting system of have a non-linear shape (“V-shape”) providing an
light bar. advantage in terms of off-axis warning performance
compared to light bars with a traditional linear
shape. All other variables being equal, the physical
SPECTRALUX multicolor LED technology “V-shape” enables the light bar to deliver more
®
provides the ability for a LED light head to change optical warning to critical 45- and 90-degree
color while in operation. LEDs can change between intersection angles than a linear light bar.
Red, Blue, Amber or White through user-selected
flash patterns.
Q-SIREN® The sound of the Q-siren is a registered
trademark of Federal Signal Corporation, and it
provides distinctive, recognizable long-distance Ask your local Federal Signal
warning. Representative how you can experience
the latest in lighting and siren systems.
www.fedsig.com | 800.264.3578
