Good. Safe. Yellow. Price List 2021 Valid from February 2021
General information
The product groups at a glance
Rolls Belts Fibre discs
Klingspor rolls for hand sanding or use Klingspor abrasive belts are available Klingspor fibre discs are exceptionally
with handheld m achines are available in various sizes and grades to meet all suited for rough grinding work, rust
in a number of special grades designed grinding, sanding and finishing removal, deburring and working on
for a wide variety of materials – from requirements for a wide range of welded seams.
wood, to metal, to paint. materials and applications.
Abrasive strips, sheets and Abrasive mop wheels Abrasive mop discs
discs The abrasive mop wheel is p articularly The performance of the Klingspor
Klingspor strips, sheets and discs suitable for finishing where flexibility abrasive mop disc, with its fan-shaped
are available in various qualities and is a must. It matches the contours radial arrangement of the cloth
designs. of any workpiece perfectly. Klingspor grinding flaps, far exceeds that of
has the right abrasive mop wheel for other abrasive products.
virtually every application and for
nearly all t ypes of material.
Diamond tools Flexible abrasives
Klingspor's comprehensive range of di- Flexible abrasives which were
amond tools makes it easy for any user Kronenflex grinding discs and developed by Klingspor for precision
to work faster and with greater preci- cutting-off wheels finishing and polishing work on all
sion and endurance. As they are made Continuous innovation and the kinds of surfaces.
of carefully testedpremium grade development of specialised p roducts
materials, the products included in for all application a reas enables
each product line offer a wide range Klingspor to offer a range of grinding
of possible applications and meet the discs and cutting-off wheels to
highest safety standards. satisfy every need.
Carbide burrs
Klingspor carbide burrs are manufac-
tured according to the highest q uality
standards and with utmost precision.
The different cuts are adapted to meet
the specific requirements of various
materials and applications.
2
Rolls with paper backing
Coated abrasives
Abrasive paper
PS 30 D
Properties Applications
Bonding agent Resin Paint/Varnish/Filler J
Grain Aluminium oxide Wood J
Coating Semi-open Metals K
Backing D-paper
Advantages: Sharp grit and high aggressiveness for use on wood, varnish, fillers - Flexible and
tear resistant, easy folding - Product with good price-performance ratio
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Width x Length Packing Cat. List price
Grit
in mm unit/pcs. number Rs.
100 x 50000 60 1 252419 2,046.80
100 x 50000 80 1 252420 1,827.50
100 x 50000 100 1 252421 1,691.50
100 x 50000 120 1 252422 1,691.50
100 x 50000 150 1 252423 1,691.50
100 x 50000 180 1 252424 1,691.50
100 x 50000 220 1 331099 1,705.10
100 x 50000 320 1 252426 1,705.10
115 x 4500 40 10 174094 273.70
115 x 4500 60 10 174095 222.70
115 x 4500 80 10 174096 198.90
115 x 4500 100 10 174097 183.60
115 x 4500 120 10 174098 183.60
115 x 4500 150 10 174099 183.60
115 x 4500 180 10 174100 183.60
115 x 50000 40 1 174086 2,886.60
115 x 50000 60 1 174088 2,352.80
115 x 50000 80 1 174089 2,102.90
115 x 50000 100 1 174090 1,944.80
115 x 50000 120 1 174091 1,944.80
115 x 50000 150 1 174092 1,944.80
115 x 50000 180 1 174093 1,944.80
115 x 50000 240 1 182418 1,960.10
115 x 50000 320 1 182419 1,960.10
Prices per piece. Recommended prices. Other grits and sizes available on request.
Please observe: Minimum order quantities for manufactured items see page xx.
3Rolls with paper backing
Coated abrasives
Abrasive paper
PS 33 C
Properties Applications
Bonding agent Resin Paint/Varnish/Filler J
Grain Aluminium oxide Wood J
Coating Semi-open Plastic K
Backing C-paper
Advantages: Very high removal rate - Minimal clogging due to stearate coating - Longer service
life - Good tear resistance and flexibility
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Width x Length Packing Cat. List price
Grit
in mm unit/pcs. number Rs.
75 x 50000 40 1 359052 2,394.50
75 x 50000 60 1 356528 1,920.20
75 x 50000 80 1 359051 1,696.60
100 x 50000 60 1 322886 2,560.20
100 x 50000 80 1 248544 2,261.90
100 x 50000 100 1 201722 2,076.60
100 x 50000 120 1 300082 2,076.60
115 x 50000 40 1 158947 3,671.20
115 x 50000 60 1 155815 2,944.40
115 x 50000 80 1 147575 2,601.90
115 x 50000 100 1 147576 2,386.80
115 x 50000 120 1 153398 2,386.80
Prices per piece. Recommended prices. Other grits and sizes available on request.
Please observe: Minimum order quantities for manufactured items see page xx.
4Rolls with paper backing
Coated abrasives
Abrasive paper
PS 33 B
Properties Applications
Bonding agent Resin Paint/Varnish/Filler J
Grain Aluminium oxide Wood J
Coating Semi-open Plastic K
Backing B-paper
Advantages: Very high removal rate - Minimal clogging due to stearate coating - Longer service
life - Good tear resistance and flexibility
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Width x Length Packing Cat. List price
Grit
in mm unit/pcs. number Rs.
100 x 50000 150 1 195550 2,076.60
100 x 50000 180 1 212055 2,076.60
100 x 50000 220 1 332434 2,093.60
100 x 50000 320 1 332338 2,093.60
100 x 50000 400 1 336506 2,093.60
100 x 50000 600 1 334254 2,093.60
115 x 50000 150 1 153177 2,386.80
115 x 50000 180 1 149480 2,386.80
115 x 50000 220 1 149698 2,408.90
115 x 50000 320 1 148891 2,408.90
115 x 50000 400 1 145520 2,408.90
115 x 50000 600 1 176492 2,408.90
Prices per piece. Recommended prices. Other grits and sizes available on request.
Please observe: Minimum order quantities for manufactured items see page xx.
5Rolls with paper backing
Coated abrasives
Abrasive paper
PS 22 N
Properties Applications
Bonding agent Resin Wood J Steel K
Grain Aluminium oxide Metals K
Coating Semi-open Paint/Varnish/Filler K
Backing E-paper Plastic K
Advantages: Universal product for hand sanding and handheld machine sanding of virtually any
material - Large grit range allows use from rough sanding to finishing
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Width x Length Packing Cat. List price
Grit
in mm unit/pcs. number Rs.
75 x 50000 60 1 342718 3,147.60
75 x 50000 80 1 342719 2,759.10
75 x 50000 100 1 342720 2,516.90
75 x 50000 120 1 342721 2,516.90
100 x 50000 60 1 333817 4,197.30
100 x 50000 80 1 333818 3,679.70
100 x 50000 100 1 333819 3,355.00
100 x 50000 120 1 332433 3,355.00
100 x 50000 150 1 333821 3,355.00
100 x 50000 180 1 333822 3,355.00
100 x 50000 220 1 333820 3,388.10
100 x 50000 320 1 339021 3,388.10
Prices per piece. Recommended prices. Other grits and sizes available on request.
Please observe: Minimum order quantities for manufactured items see page xx.
6Rolls with cloth backing
Coated abrasives
Abrasive cloth
KL 385 JF
Properties Applications
Bonding agent Resin Metals J Wood K
Grain Aluminium oxide NF metals J
Coating Close Stainless steel K
Backing JF-cotton Plastic K
Advantages: Attractively priced universal product for profile grinding - Optimal adaptation to
workpiece contours - Tears off cleanly and easily from the roll
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Width x Length Packing Cat. List price
Grit
in mm unit/pcs. number Rs.
50 x 50000 40 1 218094 3,204.50
50 x 50000 60 1 218096 2,805.00
50 x 50000 80 1 218097 2,626.50
50 x 50000 100 1 218098 2,507.50
50 x 50000 120 1 218099 2,507.50
50 x 50000 150 1 218100 2,507.50
50 x 50000 180 1 218101 2,507.50
50 x 50000 220 1 218102 2,533.00
50 x 50000 240 1 218103 2,533.00
50 x 50000 320 1 218105 2,533.00
50 x 50000 400 1 218107 2,533.00
Prices per piece. Recommended prices. Other grits and sizes available on request.
Please observe: Minimum order quantities for manufactured items see page xx.
7Rolls with cloth backing
Coated abrasives
Abrasive cloth
KL 385 JF
Properties Applications
Bonding agent Resin Metals J Wood K
Grain Aluminium oxide NF metals J
Coating Close Stainless steel K
Backing JF-cotton Plastic K
Advantages: Attractively priced universal product for profile grinding - Optimal adaptation to
workpiece contours - Tears off cleanly and easily from the roll
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Width x Length Packing Cat. List price
Grit
in mm unit/pcs. number Rs.
100 x 45000 60 1 358264 5,174.80
100 x 45000 80 1 356686 4,822.10
100 x 45000 100 1 356730 4,601.90
100 x 45000 120 1 358265 4,601.90
100 x 45000 150 1 356731 4,601.90
100 x 45000 220 1 356685 4,647.00
100 x 45000 320 1 358266 4,647.00
Prices per piece. Recommended prices. Other grits and sizes available on request.
Please observe: Minimum order quantities for manufactured items see page xx.
8Rolls with cloth backing
Coated abrasives
Abrasive cloth
KL 385 JF
D.I.Y. Packs Properties
Bonding agent Resin
Applications
Metals Wood
J K
Grain Aluminium oxide NF metals J
Coating Close Stainless steel K
Backing JF-cotton Plastic K
Advantages: Universal product for profile sanding - Optimal adaptability to workpiece contours -
Clean and easy tearing off the roll
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Width x Length Packing Cat. List price
Grit
in mm unit/pcs. number Rs.
100 x 5000 60 1 358275 748.00
100 x 5000 80 1 358180 688.50
100 x 5000 100 1 358179 663.00
100 x 5000 120 1 358276 663.00
100 x 5000 150 1 358178 663.00
100 x 5000 220 1 358181 671.50
100 x 5000 320 1 358274 671.50
Prices per piece. Recommended prices. Other grits and sizes available on request.
Please observe: Minimum order quantities for manufactured items see page xx.
9Fibre discs
Coated abrasives
Abrasive fibre disc
FS 710
Properties Applications
Bonding agent Resin Wood J
Grain Aluminium oxide
Coating Close
Advantages: Universal fiber disc for woodworking
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Diameter x Hole Packing Cat. List price
Grit Hole pattern
in mm unit/pcs. number Rs.
125 x 22 36 R 10 25 340469 29.90
125 x 22 60 R 10 25 340470 28.60
125 x 22 80 R 10 25 340471 28.60
125 x 22 120 R 10 25 340472 28.60
Abrasive fibre disc
FS 720
Properties Applications
Bonding agent Resin Metals J
Grain Aluminium oxide
Coating Close
Advantages: Universal fiber disc for metalworking
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Diameter x Hole Packing Cat. List price
Grit Hole pattern
in mm unit/pcs. number Rs.
100 x 16 24 R 10 25 340670 30.30
100 x 16 36 R 10 25 340669 29.80
100 x 16 60 R 10 25 340668 29.10
100 x 16 80 R 10 25 340667 28.90
100 x 16 120 R 10 25 340666 28.90
125 x 22 24 R 10 25 340573 36.60
125 x 22 36 R 10 25 340473 36.10
Prices per piece. Recommended prices. Other grits and sizes available on request.
Please observe: Minimum order quantities for manufactured items see page xx.
10Fibre discs
Coated abrasives
Continuation of FS 720, Abrasive fibre disc
Diameter x Hole Packing Cat. List price
Grit Hole pattern
in mm unit/pcs. number Rs.
125 x 22 60 R 10 25 340580 35.70
125 x 22 80 R 10 25 340574 34.80
125 x 22 120 R 10 25 340581 34.80
180 x 22 24 R 10 25 340475 61.60
180 x 22 36 R 10 25 340474 60.90
180 x 22 60 R 10 25 340665 58.00
180 x 22 80 R 10 25 340664 56.80
180 x 22 120 R 10 25 340663 56.80
Abrasive fibre disc
FS 800
Properties Applications
Bonding agent Resin Metals J
Grain Zirconia alumina
Coating Close
Advantages: Aggressive fiber disc for metalworking
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Diameter x Hole Packing Cat. List price
Grit Hole pattern
in mm unit/pcs. number Rs.
100 x 16 24 R 10 25 340584 46.60
100 x 16 36 R 10 25 340582 42.80
100 x 16 60 R 10 25 340583 39.60
100 x 16 80 R 10 25 340579 38.30
100 x 16 120 R 10 25 340578 38.30
125 x 22 24 R 10 25 340577 64.40
125 x 22 36 R 10 25 340476 56.50
125 x 22 60 R 10 25 340576 50.30
125 x 22 80 R 10 25 340595 49.00
125 x 22 120 R 10 25 340596 49.00
180 x 22 24 R 10 25 340592 107.60
180 x 22 36 R 10 25 340477 104.40
180 x 22 60 R 10 25 340468 97.50
180 x 22 80 R 10 25 340593 92.80
180 x 22 120 R 10 25 340591 92.80
Prices per piece. Recommended prices. Other grits and sizes available on request.
Please observe: Minimum order quantities for manufactured items see page xx.
11Sheets with paper backing
Coated abrasives
Abrasive paper, waterproof
PS 8 C
Properties Applications
Bonding agent Resin Paint/Varnish/Filler J
Grain SiC Plastic J
Coating Close Glass/Stone K
Backing C-paper Metals K
Advantages: Ideal for hard and tough surfaces - Very flexible latex paper allows excellent adaptation -
Can be used wet and dry
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Width x Length Packing Cat. List price
Grit
in mm unit/pcs. number Rs.
230 x 280 80 50 269429 43.40
230 x 280 100 50 269435 38.30
230 x 280 120 50 269444 33.20
230 x 280 150 50 269448 31.50
Abrasive paper, waterproof
PS 8 A
Properties Applications
Bonding agent Resin Paint/Varnish/Filler J
Grain SiC Plastic J
Coating Close Glass/Stone K
Backing A-paper Metals K
Advantages: Ideal for hard and tough surfaces - Very flexible latex paper allows excellent adaptation -
Can be used wet and dry
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000 2500
Width x Length Packing Cat. List price
Grit
in mm unit/pcs. number Rs.
230 x 280 180 50 269269 29.80
230 x 280 220 50 269275 29.80
230 x 280 320 50 269289 29.80
230 x 280 400 50 269299 29.80
Prices per piece. Recommended prices. Other grits and sizes available on request.
Please observe: Minimum order quantities for manufactured items see page xx.
12Sheets with paper backing
Coated abrasives
Continuation of PS 8 A, Abrasive paper, waterproof
Width x Length Packing Cat. List price
Grit
in mm unit/pcs. number Rs.
230 x 280 600 50 269314 29.80
230 x 280 800 50 269323 31.50
230 x 280 1000 50 269328 31.50
230 x 280 1200 50 269334 31.50
230 x 280 1500 50 269340 31.50
230 x 280 2000 50 269344 31.50
230 x 280 2500 50 269352 31.50
Abrasive paper, waterproof
PS 11 C
Properties Applications
Bonding agent Resin Paint/Varnish/Filler J
Grain SiC Plastic J
Coating Close Glass/Stone K
Backing C-paper Metals K
Advantages: Special product for auto repair and painting - For hard and tough surfaces - Good
adaptation and high stability - Can be used wet and dry
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Width x Length Packing Cat. List price
Grit
in mm unit/pcs. number Rs.
230 x 280 80 50 2023 48.50
230 x 280 100 50 2117 42.50
230 x 280 120 50 2116 37.40
230 x 280 150 50 2011 35.70
230 x 280 180 50 2012 33.20
Prices per piece. Recommended prices. Other grits and sizes available on request.
Please observe: Minimum order quantities for manufactured items see page xx.
13Sheets with paper backing
Coated abrasives
Abrasive paper, waterproof
PS 11 A
Properties Applications
Bonding agent Resin Paint/Varnish/Filler J
Grain SiC Plastic J
Coating Close Glass/Stone K
Backing A-paper Metals K
Advantages: Special product for auto repair and painting - For hard and tough surfaces - Good
adaptation and high stability - Can be used wet and dry
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Width x Length Packing Cat. List price
Grit
in mm unit/pcs. number Rs.
230 x 280 220 50 2002 33.20
230 x 280 320 50 2005 33.20
230 x 280 400 50 2007 33.20
230 x 280 600 50 2009 33.20
230 x 280 800 50 2010 35.70
230 x 280 1000 50 11892 35.70
230 x 280 1200 50 6616 35.70
230 x 280 1500 50 186794 35.70
230 x 280 2000 50 186795 35.70
Prices per piece. Recommended prices. Other grits and sizes available on request.
Please observe: Minimum order quantities for manufactured items see page xx.
14Sheets with paper backing
Coated abrasives
Abrasive paper
PL 28 C
Properties Applications
Bonding agent Resin Wood J
Grain Aluminium oxide Paint/Varnish/Filler J
Coating Close
Backing C-paper
Advantages: Universal product suitable for hand sanding or power-tool grinding of wood and
other materials
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Width x Length Packing Cat. List price
Grit
in mm unit/pcs. number Rs.
230 x 280 60 50 269221 20.40
230 x 280 80 50 269224 17.90
230 x 280 100 50 269226 17.00
230 x 280 120 50 269230 17.00
230 x 280 150 50 269235 17.00
230 x 280 180 50 269237 17.00
230 x 280 220 50 269239 17.00
Finishing paper
PL 31 B
Properties Applications
Bonding agent Glue Paint/Varnish/Filler J
Grain Aluminium oxide Wood J
Coating Semi-open Metals K
Backing B-paper
Advantages: Product with optimal price-performance ratio - Optimised wear properties for hand
sanding - Very fine surface scratch pattern
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Width x Length Packing Cat. List price
Grit
in mm unit/pcs. number Rs.
230 x 280 60 50 353428 30.60
230 x 280 80 50 353464 27.20
230 x 280 100 50 353461 24.70
230 x 280 120 50 353465 24.70
Prices per piece. Recommended prices. Other grits and sizes available on request.
Please observe: Minimum order quantities for manufactured items see page xx.
15Sheets with paper backing
Coated abrasives
Continuation of PL 31 B, Finishing paper
Width x Length Packing Cat. List price
Grit
in mm unit/pcs. number Rs.
230 x 280 150 50 353466 24.70
230 x 280 180 50 353462 24.70
230 x 280 220 50 353463 25.50
230 x 280 320 50 358198 25.50
230 x 280 400 50 358199 25.50
Abrasive paper
PS 33 C
Properties Applications
Bonding agent Resin Paint/Varnish/Filler J
Grain Aluminium oxide Wood J
Coating Semi-open Plastic K
Backing C-paper
Advantages: High removal rate - For diverse applications - Reduced clogging due to stearate
coating
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Width x Length Packing Cat. List price
Grit
in mm unit/pcs. number Rs.
230 x 280 40 50 147849 48.50
230 x 280 60 50 147850 38.30
230 x 280 80 50 147851 33.20
230 x 280 100 50 149719 30.60
230 x 280 120 50 147852 30.60
Prices per piece. Recommended prices. Other grits and sizes available on request.
Please observe: Minimum order quantities for manufactured items see page xx.
16Sheets with paper backing
Coated abrasives
Abrasive paper
PS 33 B
Properties Applications
Bonding agent Resin Paint/Varnish/Filler J
Grain Aluminium oxide Wood J
Coating Semi-open Plastic K
Backing B-paper
Advantages: High removal rate - For diverse applications - Reduced clogging due to stearate
coating
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Width x Length Packing Cat. List price
Grit
in mm unit/pcs. number Rs.
230 x 280 150 50 149528 30.60
230 x 280 180 50 147853 30.60
230 x 280 220 50 149529 30.60
230 x 280 320 50 149530 30.60
230 x 280 400 50 148971 30.60
230 x 280 500 50 170667 30.60
230 x 280 600 50 170668 30.60
Abrasive paper, actively coated
PS 73 CW
Properties Applications
Bonding agent Resin Paint/Varnish/Filler J
Grain Aluminium oxide Plastic J
Coating Semi-open
Backing C-paper
Advantages: High quality product for use on varnish, paint and filler - High removal rate -
Substantially reduced clogging and significantly longer service life due to additional special coating
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Width x Length Packing Cat. List price
Grit
in mm unit/pcs. number Rs.
230 x 280 80 50 311108 42.50
Prices per piece. Recommended prices. Other grits and sizes available on request.
Please observe: Minimum order quantities for manufactured items see page xx.
17Sheets with paper backing
Coated abrasives
Abrasive paper, actively coated
PS 73 BW
Properties Applications
Bonding agent Resin Paint/Varnish/Filler J
Grain Aluminium oxide Plastic J
Coating Semi-open
Backing B-paper
Advantages: High quality product for use on varnish, paint and filler - High removal rate - Sub-
stantially reduced clogging and significantly longer service life due to additional special coating
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Width x Length Packing Cat. List price
Grit
in mm unit/pcs. number Rs.
230 x 280 150 50 301196 39.10
230 x 280 180 50 301197 39.10
230 x 280 220 50 301198 39.10
230 x 280 240 50 301199 39.10
230 x 280 280 50 301200 39.10
230 x 280 320 50 301201 39.10
230 x 280 400 50 301202 39.10
230 x 280 600 50 301204 39.10
230 x 280 800 50 308410 39.10
230 x 280 1000 50 308411 39.10
230 x 280 1200 50 311188 39.10
230 x 280 1500 50 308412 39.10
Prices per piece. Recommended prices. Other grits and sizes available on request.
Please observe: Minimum order quantities for manufactured items see page xx.
18Abrasive screen
Abrasive screen, self-fastening, waterproof
AN 400
Properties Applications
Bonding agent Resin Paint/Varnish/Filler J Composites J
Grain Aluminium oxide Gel coats J Wood J
Backing Polyester grid Plaster J Wood-based materials J
Plasterboard walls J
Advantages: Effective and full surface dust extraction thanks to open lattice structure - Dust-free
sanding extends the service life of the abrasive - Improved health and safety due to reduced dust
formation at the work station - Independent of existing extraction hole patterns - Waterproof
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Width x Length Packing Cat. List price
Grit
in mm unit/pcs. number Rs.
80 x 133 80 50 337892 46.80
80 x 133 100 50 337891 43.40
80 x 133 120 50 337890 43.40
80 x 133 150 50 337894 43.40
80 x 133 180 50 337889 43.40
80 x 133 240 50 337893 43.40
80 x 133 320 50 337895 43.40
80 x 133 400 50 337896 43.40
Prices per piece. Recommended prices. Other grits and sizes available on request.
Please observe: Minimum order quantities for manufactured items see page xx.
19Abrasive block
Abrasive block, flexible, coated on 4 sides
SK 500
Properties Applications
Grain Aluminium oxide Paint/Varnish/Filler J
Coating Close Wood J
Plastic K
Metals K
Advantages: Can be used flat and upright (four usable sides) - For flat and profiled surfaces due to
flexible foam core - Robust, washable and reusable
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Width x Length x Height Packing Cat. List price
Grit Density Grit colour Foam colour
in mm unit/pcs. number
70 x 100 x 25 60 hard brown grey 100 125279 65.30
70 x 100 x 25 80 hard brown grey 100 225165 65.30
70 x 100 x 25 100 hard brown grey 100 125280 65.30
70 x 100 x 25 120 hard brown grey 100 225166 65.30
70 x 100 x 25 180 hard brown grey 100 225167 65.30
70 x 100 x 25 220 hard brown grey 100 225168 65.30
70 x 100 x 25 280 hard brown grey 100 225169 65.30
Abrasive block, flexible, coated on 4 sides
SK 700 A
Properties Applications
Grain Aluminium oxide Paint/Varnish/Filler J
Coating Close Wood J
Plastic K
Metals K
Advantages: Suitable for flat or upright use on all four sides - The angled edge (approx. 45°)
makes it an exceptional choice for narrow, tapering workpiece contours - Excellent contouring and
pressure distribution thanks to flexible foam core - Robust, washable and reusable
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Width x Length x Height Packing Cat. List price
Grit Density Grit colour Foam colour
in mm unit/pcs. number Rs.
89 x 125 x 25 60 hard brown grey 100 337846 105.40
89 x 125 x 25 80 hard brown grey 100 337847 105.40
89 x 125 x 25 100 hard brown grey 100 337848 105.40
89 x 125 x 25 120 hard brown grey 100 331019 105.40
Prices per piece. Recommended prices.
20Abrasive sponge
Abrasive sponge, flexible, coated on 2 sides
SW 501
Properties Applications
Grain Aluminium oxide Paint/Varnish/Filler J
Coating Close Wood J
Plastic K
Metals K
Advantages: Satin surface scratch pattern - For low and high profiled surfaces (two usable sides) -
Crease and break resistant - Washable and reusable
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Width x Length x Height Packing Cat. List price
Grit Density Grit colour Foam colour
in mm unit/pcs. number Rs.
96 x 123 x 12,5 120 soft brown yellow 100 125281 59.40
96 x 123 x 12,5 220 soft brown yellow 100 125282 59.40
Abrasive sponge, flexible, coated on 2 sides
SW 502
Properties Applications
Grain SiC Paint/Varnish/Filler J
Coating Close Plastic J
Wood K
Metal K
Advantages: For low and high profiled surfaces (two usable sides) - Crease and break resistant -
Washable and reusable
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Width x Length x Height Packing Cat. List price
Grit Density Grit colour Foam colour
in mm unit/pcs. number Rs.
96 x 123 x 12,5 120 soft black yellow 100 244377 60.60
96 x 123 x 12,5 220 soft black yellow 100 244379 60.60
Prices exclude VAT. Recommended prices. Other grits and sizes available on request.
Please observe: Please see Applications Guide on page xx.
21Discs with paper backing, self-fastening
Coated abrasives
Abrasive paper, self-fastening
PS 22 K
Properties Applications
Bonding agent Resin Wood J Plastic K
Grain Aluminium oxide Metals J
Coating Semi-open Stainless steel K
Backing E-paper Paint/Varnish/Filler K
Advantages: Universal abrasive disc for metalworking and woodworking - Uniform surface scratch
pattern - Available in many grit sizes and dimensions
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Diameter Hole Packing Cat. List price
Grit
in mm pattern unit/pcs. number Rs.
125 40 s GLS 19 50 332637 34.00
125 60 s GLS 19 50 305133 28.10
125 80 s GLS 19 50 254920 24.70
125 100 s GLS 19 50 294704 23.00
125 120 s GLS 19 50 314120 23.00
125 150 s GLS 19 50 265061 23.00
125 180 s GLS 19 50 265062 23.00
125 220 s GLS 19 50 300418 23.00
125 400 s GLS 19 50 321778 23.00
150 40 U GLS 3 50 89181 45.90
150 60 U GLS 3 50 86634 36.60
150 80 U GLS 3 50 86635 32.30
150 100 U GLS 3 50 97072 29.80
150 120 U GLS 3 50 86636 29.80
150 150 U GLS 3 50 86637 29.80
150 180 U GLS 3 50 87528 29.80
150 220 U GLS 3 50 100157 29.80
150 320 U GLS 3 50 97779 29.80
150 400 U GLS 3 50 128356 29.80
Prices per piece. Recommended prices. Other grits and sizes available on request.
Please observe: Minimum order quantities for manufactured items see page xx.
22Discs with paper backing, self-fastening
Coated abrasives
Abrasive paper, self-fastening
PS 33 CK
Properties Applications
Bonding agent Resin Paint/Varnish/Filler J
Grain Aluminium oxide Wood J
Coating Semi-open Plastic K
Backing C-paper
Advantages: High removal rate - For diverse applications - Reduced clogging due to stearate
coating
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Diameter Hole Packing Cat. List price
Grit
in mm pattern unit/pcs. number Rs.
125 40 s GLS 19 100 255154 28.90
125 60 s GLS 19 100 256636 23.80
125 80 s GLS 19 100 240593 21.30
125 100 s GLS 19 100 240594 19.60
125 120 s GLS 19 100 240597 19.60
150 40 U GLS 3 100 147647 38.30
150 60 U GLS 3 100 147124 31.50
150 80 U GLS 3 100 146946 28.10
150 100 U GLS 3 100 143694 25.50
150 120 U GLS 3 100 146947 25.50
Prices per piece. Recommended prices. Other grits and sizes available on request.
Please observe: Minimum order quantities for manufactured items see page xx.
23Discs with paper backing, self-fastening
Coated abrasives
Abrasive paper, self-fastening
PS 33 BK
Properties Applications
Bonding agent Resin Paint/Varnish/Filler J
Grain Aluminium oxide Wood J
Coating Semi-open Plastic K
Backing B-paper
Advantages: High removal rate - For diverse applications - Reduced clogging due to stearate
coating
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Diameter Hole Packing Cat. List price
Grit
in mm pattern unit/pcs. number Rs.
125 150 s GLS 19 100 262265 19.60
125 180 s GLS 19 100 298362 19.60
125 220 s GLS 19 100 262244 19.60
125 320 s GLS 19 100 264786 19.60
125 400 s GLS 19 100 264060 19.60
125 600 s GLS 19 100 285688 19.60
150 150 U GLS 3 100 149151 25.50
150 180 U GLS 3 100 146948 25.50
150 220 U GLS 3 100 149255 25.50
150 240 U GLS 3 100 146907 25.50
150 320 U GLS 3 100 147126 25.50
150 400 U GLS 3 100 147125 25.50
150 600 U GLS 3 100 172010 25.50
Prices per piece. Recommended prices. Other grits and sizes available on request.
Please observe: Minimum order quantities for manufactured items see page xx.
24Discs with film backing, self-fastening
Coated abrasives
Abrasive film, self-fastening
FP 77 K T-ACT
Properties Applications
Bonding agent Resin Paint/Varnish/Filler J Composites J
Grain Aluminium oxide Primer J Plastic K
Coating Semi-open Filler J
Backing Film Gel coats J
Advantages: New high performance disc with optimised clogging behaviour - Increased service
life due to the new coating, which prevents the adhesion of paint and dust particles - With a highly
flexible and perfectly flat film backing for high quality surface finishing
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Diameter Hole Packing Cat. List price Discount
Grit
in mm pattern unit/pcs. number Rs. group
150 240 U GLS 3 100 353146 45.90 Rs. 7
150 320 U GLS 3 100 353145 45.90 Rs. 7
150 400 U GLS 3 100 353144 45.90 Rs. 7
150 600 U GLS 3 100 353142 45.90 Rs. 7
150 800 b GLS 47 100 353134 45.90 Rs. 7
150 1000 b GLS 47 100 353133 45.90 Rs. 7
150 1200 b GLS 47 100 353132 45.90 Rs. 7
150 1500 b GLS 47 100 353131 45.90 Rs. 7
150 2000 b GLS 47 100 353130 45.90 Rs. 7
Prices per piece. Recommended prices. Other grits and sizes available on request.
Please observe: Minimum order quantities for manufactured items see page xx.
25Discs with paper backing, self-fastening / Abrasive screen
Coated abrasives
Abrasive paper, self-fastening
PS 77 CK T-ACT
Properties Applications
Bonding agent Resin Paint/Varnish/Filler J Composites J
Grain Aluminium oxide Primer J Plastic K
Coating Semi-open Filler J
Backing C-paper Gel coats J
Advantages: New high performance disc with optimised clogging behaviour - Increased service life
due to the new coating, which prevents the adhesion of paint and dust particles - For aggressive
sanding at high loads, a flexible and tear resistant C-latex paper is used in the grit range 60 - 220
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Diameter Hole Packing Cat. List price
Grit
in mm pattern unit/pcs. number Rs.
150 60 U GLS 3 100 353195 41.70
150 80 U GLS 3 100 353194 36.60
150 100 U GLS 3 100 353193 34.00
150 120 U GLS 3 100 353192 34.00
150 180 U GLS 3 100 353190 34.00
150 220 U GLS 3 100 353189 34.00
Abrasive screen, self-fastening, waterproof
AN 400
Properties Applications
Bonding agent Resin Paint/Varnish/Filler J Composites J
Grain Aluminium oxide Gel coats J Wood J
Backing Polyester grid Plaster J Wood-based materials J
Plasterboard walls J
Advantages: Effective and full-surface dust extraction thanks to open lattice structure - Dust-free
sanding extends the service life of the abrasive - Improved health and safety due to reduced dust
formation at the work station - Independent of existing extraction hole patterns - Waterproof
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Diameter Packing Cat. List price
Grit
in mm unit/pcs. number Rs.
125 80 50 337898 59.50
125 100 50 337899 53.60
125 120 50 337900 53.60
125 150 50 337901 53.60
125 180 50 337905 53.60
Prices per piece. Recommended prices. Other grits and sizes available on request.
Please observe: Minimum order quantities for manufactured items see page xx.
26Abrasive screen / Discs with foam backing, self-fastening
Coated abrasives
Continuation of AN 400, Abrasive screen, self-fastening, waterproof
Diameter Packing Cat. List price
Grit
in mm unit/pcs. number Rs.
125 240 50 337904 53.60
125 320 50 337903 53.60
125 400 50 337902 53.60
150 80 50 337886 81.60
150 100 50 337887 74.00
150 120 50 337885 74.00
150 150 50 337884 74.00
150 180 50 337883 74.00
150 240 50 337888 74.00
150 280 50 341655 74.00
150 320 50 337876 74.00
150 400 50 337877 74.00
150 500 50 341622 74.00
150 600 50 340193 74.00
150 800 50 340195 74.00
Sanding disc with foam material,
self-fastening
FD 500 Properties Applications
Bonding agent Resin Paint/Varnish/Filler J
Aluminium
Grain
oxide/SiC
Foam material/
Backing
velours
Advantages: Uniform pressure distribution thanks to elastic foam coating - Extremely fine scratch
pattern - Superior flexibility and adaptability on contours and profiles - Exceptionally well suited for
finishing - Suitable for wet and dry use -Available in grit 1000, 1500 (Aluminium oxide) and 2000,
3000 (SiC)
Available grits:
16 24 30 36 40 50 60 80 100 120 150 180 220 240 280 320 360 400 500 600 800 1000 1200 1500 2000
Diameter Hole Packing Cat. List price
Grit
in mm pattern unit/pcs. number Rs.
75 1000 Q0 10 351406 47.60
75 3000 Q0 10 351407 47.60
125 1000 Q0 10 342291 113.90
125 1500 Q0 10 342290 113.90
125 2000 Q0 10 342289 113.90
125 3000 Q0 10 342288 113.90
150 1000 Q0 10 342294 158.10
150 1500 Q0 10 342293 158.10
150 2000 Q0 10 342295 158.10
150 3000 Q0 10 342292 158.10
Prices per piece. Recommended prices. Other grits and sizes available on request.
Please observe: Minimum order quantities for manufactured items see page xx.
27Discs with foam backing, self-fastening / Sander
Continuation of FD 500, Sanding disc with foam material, self-fastening
Diameter Hole Packing Cat. List price
Grit
in mm pattern unit/pcs. number Rs.
225 1000 Q0 10 351726 339.20
225 1500 Q0 10 351725 339.20
225 2000 Q0 10 351727 339.20
225 3000 Q0 10 351728 339.20
Air grinder
Dynabrade
Advantages: Includes low profile sanding plate with balanced weight, made of premium quality
urethane - Removable motor to reduce costs for downtime associated with routine maintenance -
Manual speed control - Ideal for vertical and high pressure sanding applications
Diameter Max. Packing Cat. List price
Thread/Shaft Specification
in mm RPM unit/pcs. number Rs.
125 1/4 inch EXTREME 12000 rpm 1 356610 30,620.00
125 1/4 inch SPIRIT 12000 rpm 1 356608 23,360.30
150 1/4 inch EXTREME 12000 rpm 1 356611 30,620.00
150 1/4 inch SPIRIT 12000 rpm 1 356607 23,360.30
Orbital Sander
SPARTAN
Advantages: Adjustable for nearly all sanding jobs - Sanding of wood, metals, and polymer surfaces -
The ergonomic design allows for a comfortable use
Diameter Packing Cat. List price
Thread/Shaft Specification
in mm unit/pcs. number Rs.
125 thread M8 KLING-ON 1 355719 16,361.00
125 thread M8 PSA 1 355710 17,631.50
150 thread M8 KLING-ON 1 355717 17,910.80
150 thread M8 PSA 1 355709 17,910.80
Prices per piece. Recommended prices.
28Backing pads
Backing pad
HST 100
Advantages: Polyurethane backing pads for Spartan PSA
Diameter Suitable Packing Cat. List price
Adaptor Thread/Shaft Density
in mm for unit/pcs. number Rs.
125 SPARTAN thread M8 Spartan PSA medium 1 355987 1,270.40
150 SPARTAN thread M8 Spartan PSA medium 1 355988 1,549.70
Backing pad
HST 200
Advantages: Polyurethane backing pads for Spartan Kling-on
Diameter Suitable Packing Cat. List price
Adaptor Thread/Shaft Density
in mm for unit/pcs. number Rs.
125 SPARTAN thread M8 Spartan Kling-on medium 1 355989 1,270.40
125 SPARTAN thread M8 Spartan Kling-on medium 1 355994 1,587.50
150 SPARTAN thread M8 Spartan Kling-on medium 1 355990 1,549.70
Prices per piece. Recommended prices.
29Kronenflex® cutting-off wheels
Application guides
1. EAN code (EAN 13) 8. Information about the
manufacturer
2. Safety pictograms
9. Operating restrictions
3. Max. operating speed
10. S
afety standard
4. Klingspor cat. number
(oSa / EN 12413)
5. S
pecification of design, grade
11. Max. RPM
and bond according to EN 12413
12. Safety pictograms
6. Dimensions in mm and inches
13. Product group / type
7. A
pplications (see colour coding
system)
14. Klingspor brand Kronenflex®
Performance classes
Kronenflex® cutting-off wheels and grinding discs come in three performance classes with six colour codes for a quick overview of the
most important material applications.
Products for universal application, offering Optimised products for different High performance products for special
a particularly attractive price-performance applications. Excellent service life and applications. Highest service life and
ratio. cutting performance. cutting performance in the respective
material application area.
30Kronenflex® cutting-off wheels
for handheld machines
Cutting-off wheel
A 960 TZ
SPECIAL Class
Bond
SPECIAL Applications
Stainless steel
EEEEEEE J
Aggression EEEEEED Steel J
Service life EEEEEEE
Advantages: Free of iron, sulphur and chlorine - Short cutting times and long service life - Low
thermal load - Low burr formation - Optimised bonding for considerably longer service life - For
diverse applications - 25 pieces delivered in the Kronenflex® tub for long lasting high performance
and moisture protection
Diameter x Width Max. operating Max. Packing Cat. List price
Form
x Bore in mm speed RPM unit/pcs. number Rs.
105 x 1 x 16 H 80 m/s 14500 rpm 25 326432 166.70
115 x 1 x 22,23 H 80 m/s 13300 rpm 25 322180 141.10
125 x 1 x 22,23 H 80 m/s 12200 rpm 25 322181 160.70
Cutting-off wheel
A 24
EXTRA Class
Bond
EXTRA Applications
Metals
EEEEDDD J
Aggression EEEEDDD
Service life EEEEDDD
Advantages: Proven a million times over - Standard wheel with outstanding price-performance
ratio - For universal use in metalworking - Fast cutting off of solid material
Diameter x Width Max. operating Max. Packing Cat. List price
Form
x Bore in mm speed RPM unit/pcs. number Rs.
100 x 2,5 x 16 G 80 m/s 15300 rpm 25 188998 100.10
125 x 2,5 x 22,23 G 80 m/s 12200 rpm 25 188463 115.40
125 x 3,2 x 22,23 G 80 m/s 12200 rpm 25 209016 139.20
180 x 2 x 22,23 H 80 m/s 8500 rpm 25 286455 152.50
180 x 3 x 22,23 H 80 m/s 8500 rpm 25 13490 152.50
230 x 3 x 22,23 H 80 m/s 6600 rpm 25 13492 219.20
Prices per piece. Recommended prices.
31Kronenflex® cutting-off wheels
for handheld machines / for portable chop saws
Cutting-off wheel
A 24 R
SUPRA Class
Bond
SUPRA Applications
Steel
EEEEEDD J
Aggression EEEEDDD Stainless steel K
Service life EEEEEDD Castings K
Advantages: Optimised combination for use on steel - Can be used on stainless steel - Good
cutting properties
Diameter x Width Max. operating Max. Packing Cat. List price
Form
x Bore in mm speed RPM unit/pcs. number Rs.
100 x 2,5 x 16 G 80 m/s 15300 rpm 25 13754 102.40
125 x 2,5 x 22,23 H 80 m/s 12200 rpm 25 13295 120.20
180 x 3 x 22,23 H 80 m/s 8500 rpm 25 13456 182.10
Cutting-off wheel
A 330
EXTRA Class
Bond
EXTRA Applications
Steel
EEEEEDD J
Aggression EEEEEDD Stainless steel K
Service life EEEEEDD Aluminium K
Castings K
Advantages: More stability during cutting due to two glass fibre reinforcement mesh - Good
cutting speed with a long service life - Recommended for various materials and different profiles -
Usable on chop saws in craft and industry
Diameter x Width Max. operating Max. Packing Cat. List price
Form
x Bore in mm speed RPM unit/pcs. number Rs.
350 x 2,5 x 25,4 H 80 m/s 4400 rpm 10 339069 809.30
Prices per piece. Recommended prices.
32Kronenflex® large cutting-off wheels for stationary cutting
for portable chop saws
Cutting-off wheel
A 630 N
SUPRA Class
Bond
SUPRA Applications
Steel
EEEEEDD J
Aggression EEEEEED Stainless steel K
Service life EEEEEED Aluminium K
Castings K
Advantages: Aggressive performance with an outstanding service life - An exceptional choice for
the cutting of solid material - Bond optimised for universal use - Low thermal load - Minimal burr
formation
Diameter x Width Max. operating Max. Packing Cat. List price
Form
x Bore in mm speed RPM unit/pcs. number Rs.
350 x 2,5 x 25,4 H 80 m/s 4400 rpm 10 339070 971.50
Prices per piece. Recommended prices.
33Product overview - Other products available
Backing pads
Backing pad
ST 358
Advantages: Medium-hard backing pad allows good adaptation to the workpiece - For universal
use, especially for surface and finish grinding (grit 50 and finer) - High temperature resistance
Sizes, minimum purchasing quantities and prices available on request
Backing pad
ST 358 A
Advantages: For rough grinding - Cool grinding - Increased aggressiveness due to hard, ribbed
abrasive surface - High temperature resistance and stability
Sizes, minimum purchasing quantities and prices available on request
Backing pad for self-fastening discs
HST 359
Advantages: Good adhesion for all velour-coated abrasive discs - For medium-duty rough grinding
and polishing
Sizes, minimum purchasing quantities and prices available on request
34Product overview - Other products available
Quick Change Discs
About the product Applications
Klingspor Quick Change Discs are de- ‣‣Tool design and construction
signed for use on p neumatic and electric ‣‣Aviation industry
die grinders. The Quick Change Discs ‣‣Engine construction
allow a fast and safe tool change. ‣‣Turbine blade construction
‣‣Mould construction
‣‣Container and apparatus construction
‣‣Model building / model making
The system QMC (Quick Metal Connect)
The Quick Change Discs with metal locking are fixed on the backing pad by means of an internal thread.
The system QRC (Quick Roll Connect)
Fix the Quick Change Disc to the backing plate using the plastic threaded bushing and secure by turning 180° c lockwise.
Backing pad
QMC 555
Advantages: For secure mounting of QMC discs - Optimized abrasive properties (aggressiveness,
surface quality) due to three hardnesses
Sizes, minimum purchasing quantities and prices available on request
Backing pad
QRC 555
Advantages: For secure mounting of QRC discs - Optimized abrasive properties (aggressiveness,
surface quality) due to two hardnesses
Sizes, minimum purchasing quantities and prices available on request
35Product overview - Other products available
Abrasive mop wheels
About the product
Developed by Klingspor over 40 years ago the abrasive mop wheel has found many practical and economical uses in surface finishing work.
The Klingspor abrasive mop wheel comprises of high quality grinding flaps coated with aluminium oxide. The fan-shaped radial arrangement
is firmly anchored by a resign core at the centre of the abrasive mop wheel. The structure of the abrasive mop wheel
provides for very soft, comfortable grinding behaviour and adapts optimally to the contours of the workpiece. Klingspor abrasive mop
wheels are especially suited for achieving a very smooth surface finish.
Klingspor has the perfect abrasive mop wheel to suit every surface, ranging from even to profiled surfaces, and is suited for nearly every
material.
Abrasive mop wheel SM 611 H
The abrasive mop wheel with a wooden core is preferred for work
on floor stand grinders with cone shaped mounting spindles. It can
be mounted directly on the machine spindle without the use of a
mounting plate. Abrasive mop wheel SM 611 H is equipped with a
Ø 13 mm bore hole. Making bore hole adjustments to fit the respective
shaft diameter easy and quick - by simply drilling the appropriate bore
hole diameter.
Abrasive mop wheel
SM 611 W
This abrasive mop wheel is
equipped with a Ø 25.4 mm
mounting bore hole and can be
mounted to a machine without
the use of a mounting plate.
WSM 617
WSM 617 is a second generation
abrasive mop wheel with
integrated M14 and 5/8“ internal
threads. This wheel can be
mounted and demounted to an
angle grinder without the use of
any additional tools.
Abrasive flap drum SM 611 S,
Abrasive mop drum NCW / NFW 600 S
These drums are equipped with mounting bore holes starting from
19 mm for all standard satin finishing machines with the corresponding
machine spindles.
36Product overview - Other products available
Small abrasive mop
About the product
The small abrasive mop comprises of grinding flaps coated with aluminium oxide. The fan-shaped abrasive flaps are securely fixed to a central
mounting spindle. The grinding flaps‘ fan-shaped radial arrangement adapts perfectly to the contours of the workpiece. The wide range of grits
(40 – 320) and top size coat additives (with and without multibonds) make the Klingspor small abrasive mop perfect for a wide range of applica-
tions. The small abrasive mop is equipped with the following standard f eatures: a 6 mm or 3 mm fixing spindle and a shaft length of 40 mm.
Small abrasive mop
KM 613
Properties Applications:
Bonding agent Resin Stainless steel J
Grain Aluminium oxide Metals J
Wood K
Plastic K
Advantages: Universal product for steel and stainless steel materials - Even removal rate - Suitable
for use in hard-to-reach areas
Grits, sizes, minimum purchasing quantities and prices available on request
Small abrasive mop, cup-shaped
KMT 614
Properties Applications:
Bonding agent Resin Metals J
Grain Aluminium oxide Wood K
Plastic K
Advantages: Can be used in radial and front position
Grits, sizes, minimum purchasing quantities and prices available on request
Small finishing mop
NCS 600
Properties Applications:
Bonding agent Resin Stainless steel J
Grain Aluminium oxide Metals J
Plastic K
Advantages: High removal rate and fine surface scratch pattern due to combination of non-woven
and abrasive cloth flaps - Long service life
Grits, sizes, minimum purchasing quantities and prices available on request
Small finishing mop
NFS 600
Properties Applications:
Bonding agent Resin Metals J
Grain Aluminium oxide Stainless steel J
Advantages: Even finish throughout the entire service life - Optimal tool with high quality
non-woven flaps for creating a matt or satin finish
Grits, sizes, minimum purchasing quantities and prices available on request
37Product overview - Other products available
Flexible abrasives
About the product
R-Flex abrasives Mottling points
Used for finishing and polishing all kinds of surfaces. Despite their Create special surface effects with a uniform, extra fine finish.
elastic construction, R-Flex abrasives boast a long service life with R-Flex mottling points are used with great success for surface
high dimensional stability throughout their use. treatment a pplications in tank and container construction
(breweries, wine and champaign producers) and in plant
Mounted points construction for commercial kitchens. They are available with
Available in numerous sizes and grains. They are used for apparatus bonding agents E (specially designed for aluminium and NF metals)
and container construction, in the aviation and automobile indus- and the softer, more elastic bonding agents W and T (for stainless
tries, as well as in the food and chemical sectors. steel) – with the T bonding agent creating a glossier finish on
stainless steel surfaces and offering suitability for universal use.
The Sandflex hand block
Cleans, polishes and matt finishes a large variety of materials From stock, Klingspor mottling points ship with a 6 mm shaft and a
including metal, wood, paints, plastics, rubber and paper. In milled plane surface, making it possible to fix the tools securely
addition to its commercial applications, the Sandflex hand block is in place inside the machine adapter with a screw. If requested or
also excellent for car care and jobs around the house like cleaning made necessary by the respective machine, the mottling points can
iron soleplates, ski edges etc. Sandflex performs even better when also be supplied as made-to-order items without a flat portion and
used with water, soap, paraffin oil or pastes. With four different a full length round shaft.
grain sizes to choose from, you will find the right product for all
types of materials and jobs.
R-Flex wheels
Available with silicon carbide or corundum grit in different binding
hardnesses and dimensions. Typical applications are d eburring plastic
parts, giving surgical instruments their final finish, sharpening
knives, etc. R-Flex wheels are, due to their elastic attachment, easy
to shape and adjust to the contours of the tool during grinding.
R-Flex mounted points
RFS 651
Properties Applications:
Bonding agent Plastic Aluminium J
Grain SiC Stainless steel J
NF metals J
Advantages: Versatile mounted points for cleaning and finishing - Soft abrasion due to elastic
structure - Can be used until completely worn down
Grits, sizes, minimum purchasing quantities and prices available on request
R-Flex mottling points
RFM 652
Properties Applications:
Bonding agent Plastic Aluminium J
Grain SiC NF metals J
Advantages: Produces a satin surface scratch pattern - Soft abrasion due to elastic structure - Can
be used until completely worn down - Available in two executions: with flattened shaft for simple
and secure clamping (standard execution, stock items) and with full length round shaft (made to
order items)
38 Grits, sizes, minimum purchasing quantities and prices available on requestProduct overview - Other products available
Flexible abrasives
Sandflex mottling points
SFM 656
Properties Applications:
Bonding agent Plastic Stainless steel J
Grain SiC
Advantages: Produces a glossy finish on stainless steel surfaces - Soft abrasion due to elastic
structure - Can be used until completely worn down - Available in two executions: with flattened
shaft for simple and secure clamping (standard execution, stock items) and with full length round
shaft (made to order items)
Grits, sizes, minimum purchasing quantities and prices available on request
Hand block
SFK 655
Properties Applications:
Bonding agent Plastic Paint / Varnish J Leather J
Grain SiC Glass/Stone J Metals J
Wood J
Plastic J
Advantages: Universal hand block for cleaning and finishing - Can be used on many materials -
Cleaning performance is significantly increased by use of additives - Soft abrasion due to elastic
structure - Can be used until completely worn down
Grits, sizes, minimum purchasing quantities and prices available on request
R-flex wheel
RFR 654
Properties Applications:
Bonding agent Plastic Stainless steel J Plastic J
Aluminium Steel J Glass I
Grain
oxide / SiC NF metals J
Aluminium J
Advantages: Versatile abrasive wheel - Deburring, matt finishing and finishing with one tool -
Good adaptation to workpiece contour - Soft abrasion due to elastic structure - Can be used until
completely worn down - Available in Aluminium oxide (bonding Z) and SiC (bonding E and W)
Grits, sizes, minimum purchasing quantities and prices available on request
39Product overview - Other products available
Diamond tools
About the product
Remain in full control of all processes: staying true to this motto, Klingspor managed to rise to be one of the world’s first manufacturers of grinding
and cutting tools. The company is now applying their extensive experience in research and d evelopment and manufacturing, their global network
of distributors and their highly efficient service and logistics structure to their diamond tools. With its comprehensive and transparent diamond
product line, Klingspor offers the right tool for all standard machine types and applications.
Klingspor
Expertise in diamonds
+45%
2012 2013 2014 2015
1. 2.
Continuous performance increase Reliable segments
Research, development and continuous testing have As we make them ourselves in-house, we can align the cores and
resulted in a steady performance increase of up to 45% edges of our diamond tools until they match each other perfectly.
in diamond tools made by Klingspor. This way, we can guarantee maximum performance regardless of
the application for which the user plans on using our tools.
3. 4.
Wide range of applications Three product lines
Designed for construction above and below ground, road building, Klingspor offers three finely attuned product lines. Every user will
roofers and stone cutters, Klingspor diamond products are suitable find the diamond tool that is suited perfectly for the specific task
for all mineral materials and can be mounted on handheld machinery, needed to be accomplished.
table saws, electric joint cutters and joint cutters with a capacity
of up to 20 kW.
5.
Toughest safety standards
Just as all other products made by Klingspor, our new diamond
tools comply with the strict oSa guidelines and are guaranteed
to comply with the European safety standard EN 13236.
40Product overview - Other products available
Diamond tools
The three product lines
The right tool for every application: Klingspor diamond tools are available in three product lines that are colour-coded to provide
the user with a quick overview of the most important materials for which the tools are suitable.
Product line 900 – High performance tools offering outstanding cutting
performance and service life. For users who need their tools to perform at peak
output and reliability even if subjected to the most punishing applications.
Product line 600 – Professional tools with an exceptional price-performance
ratio. For users who require diamond tools that deliver reliable and powerful
performance every day.
Product line 300 – Brand name quality at an affordable price. For users
who expect their tools to meet professional standards, but do not need to use
them continuously.
41Product overview - Other products available
Carbide burrs
About the product
Powerful milling and leveling of s urfaces and forms
Klingspor carbide burrs are used wherever outstanding stock necessary to find the solution that matches each application best.
removal and service life are pivotal to the proper processing of Thanks to the abundance of available toothing options, you can
hard-to-reach places. The burrs are manufactured according to be sure to achieve the desired outcome on any material and with
the highest quality standards and with utmost precision. Our unparalleled speed.
comprehensive product selection offers all shapes and dimensions
Type Form Type Form
HF 100 A (ZYA) Cylindrical HF 100 G (SPG) Arch shape
HF 100 B (ZYAS) Cylindrical with end cut HF 100 H Flame shape
HF 100 C (WRC) Cylindrical with spherical head HF 100 J (KSJ) Conical shape, pointed nose (60°)
HF 100 D (KUD) Spherical shape HF 100 K (KSK) Conical shape, pointed nose (90°)
HF 100 E (TRE) Oval shape HF 100 L (KEL) Conical shape, round nose
HF 100 F (RBF) Conical shape HF 100 M (SKM) Conical shape, pointed nose
Additional cuts available on request! HF 100 N (WKN) Dovetail
The cuts at a glance
2 Cuts
Standard cut / plain cut with good finishing properties for universal a pplications
3 Cuts aluminium
High stock removal rate and reduced clogging of teeth for working on
long-chipping and soft materials like NF metals and plastics
6 Cuts mega seller
Double cut for universal applications, improved handling and low vibration.
Creates a small chip.
New high performance tooth geometries for steel and INOX processing
10 Cuts high performance tooth geometry - steel
Toothing optimised for steel processing; significantly higher stock removal rate
compared to a standard cross-cut tooth geometry
11 Cuts high performance tooth geometry - INOX
Toothing optimised for the processing of austenitic as well as corrosion and
acid-resistant grades of stainless steel; strikingly improved stock removal
performance by contrast with standard cross-cut tooth geometries
42Product overview - Other products available
Abrasive mop discs
The three product lines
Klingspor offers three integrated product groups. For each user and application we offer the right abrasive mop disc. All abrasive
mop discs are manufactured according to the applicable standards and guarantee the highest degree of safety.
High performance products for special industrial and trade applications.
High performance and service life even when used intensively.
Professional products with excellent service life and high stock removal
rate. Aggressive grinding and long service life.
Ideal price-performance ratio for universal implementation. Excellent
grinding results on different steel materials.
43Minimum order quantities for manufactured items
Rolls
Type Grit range Type Grit range Minimum order Minimum order
PS 22 F ACT 40–150 CS 321 X 80–400 Width quantities Width quantities
PS 28 F 60–150 CS 333 X 60, 80, 120, 150 10 mm 29 pieces 80 mm 3 pieces
PS 29 F ACT 60–150 CS 341 X 50–320 15 mm 19 pieces 95 mm 3 pieces
CS 308 Y 40–80, 120 KL 361 JF 40–600 20 mm 14 pieces 100 mm 3 pieces
LS 309 X 40–360 KL 385 JF 40–600 25 mm 12 pieces 120 mm 2 pieces
LS 309 J 60–320 CS 410 X 60–120 28 mm 10 pieces 125 mm 2 pieces
LS 309 JF 60–400 CS 411 X 24–120 30 mm 10 pieces 140 mm 2 pieces
CS 310 X 24–400 CS 411 Y 36–80 35 mm 8 pieces 150 mm 2 pieces
CS 310 XF 40–280 40 mm 7 pieces 250 mm 1 pieces
LS 312 JF 60–320, 400 50 mm 6 pieces 300 mm 1 pieces
60 mm 5 pieces
Belts
Width Minimum order quantities Minimum order quantities NBF 800
3–50 mm 30 pieces Width Minimum order quantities
51–60 mm 25 pieces 6 – 13 mm 20 pieces
61–75 mm 20 pieces 14 – 30 mm 10 pieces
76–100 mm 15 pieces
Minimum order quantities NBS 800
101–150 mm 10 pieces
151–300 mm 10 pieces Width Minimum order quantities
301–400 mm 30 pieces 31 – 75 mm 5 pieces
401 mm and wider 10 pieces 76 – 320 mm 2 pieces
The minimum length for non-woven belts is 295 mm. We reserve the right to
over-deliver or under-deliver production items.
Fibre discs
Disc diameter Min. order quantities
up to 235 mm 1,000 pieces
Strips/Sheets
Minimum order Minimum order
Product Dimensions Product Dimensions
quantities quantities
Sheets 230 × 280 mm 250 pieces 70 × 125 mm 1,000 pieces
70 × 450 mm 500 pieces 80 × 133 mm 1,000 pieces
115 × 140 mm 1,000 pieces Self-fastening products 93 × 230 mm 500 pieces
Strips
93 × 230 mm 500 pieces 100 × 115 mm 1,000 pieces
115 × 280 mm 500 pieces 115 × 280 mm 500 pieces
Sheets exceeding
Minimum quantities on request
230 x 280 mm
Other sizes available on request.
Large sheets 1400 × 1540 mm 10 pieces
⚠ We reserve the right to over-deliver or
under-deliver made to order items.
44You can also read
