What can we do?
…Discuss, Design & Manufacture
We’ve built a reputation as specialists in
the design and manufacture of high
quality corporate furniture for a diverse
Public and Private sector client list.
We offer a range of standard Our aim is to take away For each scheme we assign one
products as well as endless the headache of furniture of our project management
possibilities for bespoke items. procurement and provide team to ensure you are kept
As a design-led company our sensible, cost effective completely up to speed with
product portfolio is constantly solutions. developments. Samples and
developing and evolving. prototypes will be produced if
In all areas of the business necessary, to give a ‘hands on’
We pride ourselves on the we have skilled staff in their feel for style and quality.
exceptional service we offer chosen field. From initial
to our clients from initial enquiry contact with our sales and We can work from other
through to after sales care. design team you can be peoples’ designs and with
We offer as much or as little as assured we will supply ideas all other trades to ensure
you like from a simple standard and solutions to suit all the smoothest possible
solution, to appointing your interior projects, with client delivery and installation
own designer to work with visits followed by free of charge by our fit out team with the
a specialised client brief. presentations, visualisations minimum possible disruption
and space planning. to the client.
Fray_MASTER_ModularTab_AW 29/5/06 22:26 Page 3
Our Overview
Judges/courtroom benches Reception counters
The products
schemes
Reception
Formal furniture
Witness boxes, fitted furniture Secure payment counters
Docks, galleries, barriers and gates
Ministerial, judicial and jury suites
DDA compliant solutions
Enquiry desks
shown in this
Meeting tables
Reception and payment counters
Reception storage
Waiting/breakout areas
overview provide
Court crests and accessories
Seating
Display facilities/branding
Seating
only a taste of our
extensive portfolio.
Executive desks Flexible tabling systems Please use all information as a
& conference
Modular tabling
furniture
Executive office
Computer returns Modular tabling systems guide. If you do not see exactly
Meeting tables Meeting tables
Bookcases One piece tables
what you want, please ask.
Credenzas Presentation solutions
We have an endless library of
Specialist storage Audio visual furniture
Breakout furniture Storage & accessories
additional images set up ready
Seating Seating to email or post. Let us know
the code number at the top of
the page you are interested in
Non-handed workstations Bar areas and we can let you have further
principles
Desking
Hotel & leisure
Computer desking Bedroom furniture details on that particular product
Classroom furniture Foyer furniture and other similar schemes.
Call centre furniture Boardrooms
Branch furniture Conference facilities Bear in mind the specifications
Desktop/floor standing screens Brasserie & dining shown are not the only options.
Storage & accessories Meeting furniture Feel free to pick elements you
Seating Reception areas
like from different products and
we will provide designs to meet
your criteria.
Customised tables
furniture
Boardroom
Flexible tabling systems
Meeting tables
One piece tables
Presentation solutions
Audio visual furniture
Storage & accessories
Seating
Reflex® is a trademark of Fray Design Ltd.
Reflex2®, Kinnel® and Spyda® are also
trademarks of Fray Design Ltd. and have
European Patent.
All designs and images in this brochure are
© copyright Fray Design 2006.
Fray_MASTER_ModularTab_AW 29/5/06 22:26 Page 4
4
Sector Brief
Public – Council Irregular shaped chamber requires
multifunctional and flexible furniture solution,
within budget and time restraints.
MT_070
Irregular space, flexible solution
Table information Solution comprises Rectangular and
trapezoid tables with removable modesty
panels, front bench, fitted storage and seating.
Furniture details
25mm banded and inlaid tops with
1000
solid lippings and ports. Flexible folding
reflex frames.
Option Choice
Key features
Finish Crown/quarter cut oak veneer Many layout possibilities available. Room
Inlay Walnut can be cleared in minutes with all furniture
Spec Executive housed in storage units.
Shape Rectangle and trapezoid
Base Reflex
Fray_MASTER_ModularTab_AW 29/5/06 22:26 Page 5
Sector Brief
Private – Exhibition and Convention Centre Large hall requires tabling to suit dining and
conferencing requirement, maximum
5
numbers on a tight budget.
MT_001
One frame suits all
Solution comprises Square reflex Table information
folding frames with a full set of square
and circular tops.
Furniture details
Heat resistant melamine tops with folding
reflex frames, circular tops lock into frames
to aid stability.
Key features Option Choice
Square frames take both square and Finish Lugano oak melamine
circular tops resulting in large cost savings Inlay N/A
and minimal storage requirement when not Spec Multipurpose
in use.
Shape Square/circle
Base Reflex
Fray_MASTER_ModularTab_AW 29/5/06 22:26 Page 6
6
Sector Brief
Public – Tribunal Building Meeting table required for small office
space to accommodate six users and
for board meetings where eight places
are required.
MT_027
Extendable table
Table information Solution comprises Two semi-circular
extendable Kinnel tables with removable wall
panel that acts as table extension piece.
Furniture details
38mm thick Boardroom spec semi-circular
tops with subtle Mackintosh inlay design,
feature inlay to rectangular panel, all on a
Kinnel frame.
Option Choice
Finish Crown/quarter cut oak veneer Key features
Inlay Walnut Mackintosh Wall panel has built up edge to hide fixings
Spec Boardroom/inlaid and cut down on weight, frame slides open
on internal rails.
Shape Semi-circle (extendable)
Base Kinnel (extendable)
Fray_MASTER_ModularTab_AW 29/5/06 22:26 Page 7
Sector Brief
Public – Embassy building Large quantity of conference tables need
to be flown out to Embassy building, whilst
7
in transit furniture must take up as little
space as possible. When in use flexibility
is paramount.
MT_002
Furniture to be flown in
Solution comprises Reflex rectangular Table information
tables, quadrant links, presentation lecterns
and stacking chairs.
Furniture details
Boardroom spec inlayed tables for high
profile meeting areas and conference spec
for conference and lecture facilities. Folding
reflex frames finished in chrome and black.
Option Choice
Key features Finish Crown/quarter cut oak veneer
Tables can be adapted to suit rooms with Inlay Walnut
removable partitions from small meetings Spec Executive
to large presentations.
Shape Rectangular and quadrant links
Base Reflex
Fray_MASTER_ModularTab_AW 29/5/06 22:26 Page 8
8
Sector Brief
Public – Government Department Team meeting room with sliding partition
wall requires tabling solution that creates
both small and large group layouts either
in one room or two.
MT_029
Large or small!
Table information Solution comprises Four piece modular
barrel shaped table on Kinnel frame with
two tone cantilever chairs.
Furniture details
Executive spec tops with matching
veneered cylindrical legs, separate
inlay detail to each to add to flexibility.
option choice Key features
Finish Crown/quarter cut beech veneer Modules designed to be usable separately
Inlay Walnut or in groups to provide many layout
Spec Executive possibilities in one room or two.
Shape Sectioned barrel
Base Kinnel (veneered)
Fray_MASTER_ModularTab_AW 29/5/06 22:26 Page 9
Sector Brief
Public - Council Circular Council Chambers requires
furniture to match listed building details
9
and be laid out with no hierarchy for
monthly meetings. Can table be
reconfigured to suit changing needs?
MT_062
To suit period features and culture
Solution comprises Ten curved table Table information
segments that make large circle or stand
alone joined by twenty traditional style chairs.
Furniture details
Veneered inlaid tops with built up edge
details, ornate slab style base with solid
details and curved modesty panels.
Key features Option Choice
Traditional moulding details taken from Finish Crown/quarter cut cherry veneer
building and incorporated into table design. Inlay Walnut with corner detail
Spec Executive with built up edge
Shape Curved
Base Panelled and featured
Fray_MASTER_ModularTab_AW 29/5/06 22:26 Page 10
10
Sector Brief
Private – Property Letting Company New company requires meeting furniture
that can be taken to numerous exhibitions
and shows, must be simple to set-up
and fold down for transport but provide
a sense of high quality.
MT_013
Simple set-up, high quality
Table information Solution comprises Rectangular and
semi-circular fully demountable reflex
tables and stacking timber framed chairs.
Furniture details
25mm veneered tops with solid wood
lippings that lock folding reflex frame into
place when assembled.
Option Choice Key features
Finish Crown cut oak veneer Tabling can be set up in seconds,
Inlay N/A transported in a small van and stand
Spec Conference up to constant heavy use.
Shape Rectangle and semi-circle
Base ReflexFray_MASTER_ModularTab_AW 29/5/06 22:26 Page 11
Sector Brief
Public – Assessment Department Large building with numerous rooms
requires modern system of tabling that
11
can be interchanged and provide endless
set-ups from breakout to dining areas
and classrooms.
MT_052
Frame fits four shapes of top
Solution comprises One set of extendable Table information
folding frames with a set of square, circular
and rectangular tops.
Furniture details
Veneered tops stained to match existing
wall panelling all provided with locating
batterns underneath, locking them onto
the flexible Reflex 2 frame.
Option Choice
Key features Finish Crown cut honey oak veneer
One flexible, folding frame fits four shapes Inlay N/A
of top. Spec Seminar
Shape Rectangle and semi-circle
Base Reflex 2Fray_MASTER_ModularTab_AW 29/5/06 22:26 Page 12
12
Sector Brief
Public – Government Department Large meeting space requires multi-
functional ‘different’ tabling solutions
to suit various requirements. Tables
must fold away into store cupboard
leaving an empty room.
MT_038
Multi-functional ‘different’ tabling
Table information Solution comprises 15 part multi-shape
table, storage credenzas, and 24 cantilever
framed chairs.
Furniture details
Two tone executive spec outer tops
with contrasting conference inner tops.
All tables are on folding silver cantilever
frames with modesty panels.
Option Choice
Finish Maple, BE maple, cherry veneer Key features
Inlay Walnut Maximum flexibility with over 30 different
Spec Executive/conference configuration options, all tabling folds flat
and hangs in small store cupboard.
Shape Many possible options
Base Folding cantileverFray_MASTER_ModularTab_AW 29/5/06 22:26 Page 13
Sector Brief
Private – Services Motorway services function rooms require a
system of modular tabling that can be used
13
across several sites. Rooms may need to
be reconfigured up to five times a day.
MT_004
Reconfigured several times a day!
Solution comprises Demountable reflex Table information
tables, mobile projector units, folding lecterns,
refreshment credenzas and stacking chairs.
Furniture details
Heat and scratch resistant melamine tops
throughout with frames and presentation
furniture that folds flat to store.
Key features Option Choice
Multifunctional modular solution that can be Finish Lugano oak melamine
quickly reconfigured to suit all possibilities. Inlay N/A
Spec Multipurpose
Shape Rectangle and semi-circle
Base ReflexFray_MASTER_ModularTab_AW 29/5/06 22:26 Page 14
14
Sector Brief
Private – Food manufacturer Provide a fully flexible tabling solution for a
large video conferencing room. Tables must
be able to be quickly and easily changed to
suit different scenarios and group sizes.
MT_012
Versatile video conferencing
Table information Solution comprises Rectangular reflex
tabling with 90 degree hook in quadrant links,
integrated microphones and storage credenza.
Furniture details
Veneered table tops with banding
and inlay detail and solid wood lippings,
folding frames to match existing chairs.
Option Choice Key features
Finish Crown/quarter cut maple veneer Modular nature of tables with lift off
Inlay Ebony tops and fold flat frames provides
Spec Executive endless possibilities in seconds.
Shape Rectangular & quadrant links
Base ReflexFray_MASTER_ModularTab_AW 29/5/06 22:26 Page 15
Sector Brief
Public – Armed Forces Command centre with video conferencing
facility needs refurbishing, tabling set-up
15
must suit varying attendance and have an
opulent feel.
MT_031
Varying attendance, opulent feel
Solution comprises Five rectangular Table information
table modules on height adjustable bases
with traditional timber framed chairs.
Furniture details
38mm thick banded and inlaid veneered
tops with bull-nose edge detail supported
by matching arrowhead bases.
Key features Option Choice
Modules can be reconfigured to provide Finish Crown/quarter cut warm cherry
separate meeting tables or one grand Inlay Walnut
video conferencing solution. Spec Boardroom
Shape Rectangular
Base ArrowheadFray_MASTER_ModularTab_AW 29/5/06 22:26 Page 16
16
Sector Brief
Public – Fire and Rescue Fire and Rescue service are about to
undergo a refurbishment project for all
stations in the region, design a system
of furniture fit for educational workshops
for children.
MT_030
Educational workshops
Table information Solution comprises Modular meeting/
teaching tables, internet pods, modular screens,
storage, display and breakout furniture.
Furniture details
Melamine tops ensure maximum possible
life expectancy for heavy usage, inset silver
detail to match frames and fittings.
Option Choice Key features
Finish Japanese ash melamine Corporate identity created across all
Inlay Silver stations with bold colour schemes.
Spec Multipurpose/inlaid
Shape Rectangular
Base ReflexFray_MASTER_ModularTab_AW 29/5/06 22:26 Page 17
Sector Brief
Public – Specialist college Design a simple and durable table that
can be used across many classrooms,
17
must provide maximum flexibility from
room to room.
MT_065
Modular meetings
Solution comprises Hundreds of classroom Table information
desks, teachers desks, computer benches,
learning centre furniture, storage and seating.
Furniture details
Melamine tops with optional silver inlay,
robust fixed frame with adjustable feet,
various tops and panels added dependant
on function of desk.
Option Choice
Key features Finish Japanese ash melamine
One frame can be used for varying shapes Inlay N/A
and sizes of table to seat from two to six Spec Multipurpose
users, modular design provides endless
Shape Rectangular
layout possibilities.
Base Fixed frameFray_MASTER_ModularTab_AW 29/5/06 22:26 Page 18
18
Sector Brief
Public – Nursing college New presentation furniture required
for conference hall, needs to have
flexible staging with disabled access,
a demountable front bench and a
clever lectern to incorporate all gadgets
and controls.
MT_063
Flexible presentation set-up
Table information Solution comprises Folding dais system with
rectangular/curved sections, access ramp, bow
fronted folding desk, intelligent lectern and seats.
Furniture details
Staging has hidden folding frames and high
impact carpeted tops, desk and lectern
have horizontal contrasting beech veneered
band and blue marmoleum inset into tops.
Option Choice
Finish Sapele/beech veneer Key features
Inlay Blue marmoleum Entire set-up can be reconfigured to suit
Spec 30mm inlaid type of presentation, lectern specially
designed to house all equipment.
Shape Bow fronted
Base Panelled foldingFray_MASTER_ModularTab_AW 29/5/06 22:26 Page 19
What are the choices?
…Specification, Shape & Extras
Our product options are endless,
however there are several preferred
specifications, shapes, sizes and
styles used on a very regular basis.
Specifications Preferred options shown, many more available
as well as hybrids of those detailed below.
Multipurpose Seminar Conference
18mm melamine with radiused 18mm crown cut veneer tops 25mm crown cut veneer
and polished edges. and panels with radiused and tops and panels with solid
polished edges. lipped edges.
Executive Boardroom Inlaid
25mm crown cut veneer to 38mm crown cut veneer to Our laser machinery means that
centre of tops and panels centre of tops and panels whatever can be drawn can be
walnut or ebony inlay line and walnut or ebony inlay line recreated into tops and panels
quarter cut banding with solid and quarter cut banding to suit your scheme.
lipped edges. with solid lipped edges.
Bespoke
Why not think of your own Other materials are available from glass
designs or let our team put
forward proposals to
to laminates, metal to corian. Please ask!
personalise your scheme. Call the sales team on 01756 704040Fray_MASTER_ModularTab_AW 29/5/06 22:26 Page 20
20
Contact us
If you require any assistance please,
Call the sales team on 01756 704040
Table shapes
The plan views displayed show the most popular table shapes and sizes.
Nothing is set in stone. Shapes and dimensions can be tailored to suit.
1 2 3
4 5 6
1 Rectangular 2 Square 3 Semi-Circular
Width x Depth mm Width x Depth mm Width x Depth mm
S 1370 x 685 M 1500 x 750 L 1800 x 900 S 685 x 685 M 750 x 750 L 900 x 900 S 1370 x 685 M 1500 x 750 L 1800 x 900
4 60 degree trap 5 90 Degree quadrant link 6 Quadrant table
Width x Depth mm Width x Depth mm Width x Depth mm
1 2400 x 1200 3 3050 x 1850 5 6100 x 1850 S 685 x 685 M 750 x 750 L 900 x 900 S 1370 x 685 M 1500 x 750 L 1800 x 900
Also bespoke for any requirement
Any size and shape, we enjoy
Tops and frames can be purchased
a challenge! separately, circles also available.Fray_MASTER_ModularTab_AW 29/5/06 22:26 Page 21
Contact us
Or if you want us to call you
Simply, email sales@fraydesign.co.uk
21
Table bases
The visuals displayed show the most popular base designs and finishes.
Nothing is set in stone. Styles and finishes can be tailored to suit.
1 2 3
4 5 6
1 Reflex (fully demountable) 2 Reflex 2 (fully demountable) 3 Kinnel (removable legs)
Lift off tops fold flat frames, box leg Lift off tops fold flat frames, various Legs unbolt with tools to store tables
section. Square frames accept square leg sections. Frame accepts tops flat Veneered legs are very popular.
and circular tops. Hook on modesty of any shape.
panels and links available.
4 Fixed Frame 5 Beam Frame 6 Cantilever Frame
Available with various leg profiles. Available with floating top option. Can fold down if required. Cable
Split leg style with part veneered and Modesty panels available. management available to legs.
part steel is an option.
Also bespoke for any requirement
Any size and shape, we enjoy
a challenge!Fray_MASTER_ModularTab_AW 29/5/06 22:26 Page 22
22
Contact us
If you require any assistance please,
Call the sales team on 01756 704040
Configurations
The visuals displayed below show the most popular table layouts.
Nothing shown is set in stone. Styles and finishes can be tailored to suit.
1 2 3
4 5 6
1 Conference 2 Horse shoe 3 Racetrack
4 Formal 5 Classroom 6 Banqueting
Also bespoke for any requirement Please see ‘What are the options?’ page for
popular specifications.
Any size and shape, we enjoy We have hundreds of pre-drawn tabling
layouts for many room shapes and sizes,
a challenge! these are set up ready to e-mail on request.
.Fray_MASTER_ModularTab_AW 29/5/06 22:26 Page 23
Contact us
Or if you want us to call you
Simply, email sales@fraydesign.co.uk
23
Credenzas
The visuals displayed below show the most popular credenza designs.
Nothing is set in stone, styles and finishes can be tailored to suit.
1 2 3
4 5 6
1 Standard Credenza 2 Bow Fronted Credenza 3 Sandwich detail sides Credenza
Adjustable internal shelves. Adjustable internal shelves. Option 1-2, 4 - 6 are all available with
sandwich detail.
4 Audio Visual Credenza 5 Tall Credenza 6 Credenza with drawers
Fully ventilated and cable managed. Adjustable internal shelves Option 1- 5 simply replace doors
designed to store box files. with drawers.
Also bespoke for any requirement
Why not add a glass top or inlay to Standard credenza dimensions
2 Door: 725mm H x 1000mm W x 550mm D
3 Door: 725mm H x 1500mm W x 550mm D
your credenza. 4 Door: 725mm H x 2000mm W x 550mm DFray_MASTER_ModularTab_AW 29/5/06 22:26 Page 24
24
Contact us
If you require any assistance please,
Call the sales team on 01756 704040
Presentation/audio visual units
The visuals show the most popular presentation/audio visual units.
Nothing is set in stone, styles and finishes can be tailored to suit.
1 2 3
4 5 6
1 Freestanding Presentation/AV Wall 2 Fitted Presentation/AV Wall 3 Wall mounted Screen/Smart
Board Housing
4 Mobile AV ‘C’ Unit 5 Large AV Lectern 6 Lectern
Mobile and folding lecterns also available
Also bespoke for any requirement
Any size and shape, we enjoy a challenge!Fray_MASTER_ModularTab_AW 29/5/06 22:26 Page 25
Contact us
Or if you want us to call you
Simply, email sales@fraydesign.co.uk
25
Additional Items
The visuals displayed show the most popular additional items.
1 2 3
4 5 6
1 Table and Frame Storage Unit 2 Table Storage Trolley 3 Demountable Dais System
Often fitted into alcoves or dead space Holds up to ten tables and fits through a Available in many sizes. Optional
standard doorway carpeted top and veneered facia panels
4 Fold Down Buffet Table 5 Storage Cupboard 6 Tambour Storage
Fitted to wall when available space Optional hinged doors Optional internals
is tight
Also bespoke for any requirement
Why not add solid timber moulding
All additional furniture can be designed to
details and ornate fittings. match your tabling.Fray_MASTER_ModularTab_AW 29/5/06 22:26 Page 26
26
Contact us
If you require any assistance please,
Call the sales team on 01756 704040
Seating
1a 2a 3a
1b 2b 3b
1a CONVOY-6X 2a FUNCTION-6A-2 3a 169701
1b CONVOY-6A 2b FUNCTION-8A 3b 169601
Many more styles available
All chair ranges are available with several
Why not add leather, wood or castors. base options, with or without arms.Fray_MASTER_ModularTab_AW 29/5/06 22:26 Page 27
Contact us
Or if you want us to call you
Simply, email sales@fraydesign.co.uk
27
Seating
4a 5a 6a
4b 5b 6b
4a LC710 5a MAN101P 6a 6536
4b LC704N 5b MAN100P 6b 6534
Many more styles available
All chair ranges are available with several
Why not add leather, wood or castors. base options, with or without arms.Fray_MASTER_ModularTab_AW 29/5/06 22:26 Page 28
Design Studio ON
What can you do?
…Call, Chat & Consider
Any question, any requirement,
please contact us, the Sales &
Design team will be happy to help.
Fray Design Ltd, Ghyll Way Call: 01756 704040
Airedale Business Centre Fax: 01756 704041
Keighley Road, Skipton sales@fraydesign.co.uk
North Yorks, BD23 2TZ www.fraydesign.co.ukYou can also read
