We Keep
the World
in Motion.
Company presentation
www.elinmotoren.at
January 2019
... in Motion.
What you can expect from ELIN Motoren:
• high industrial standards based on decades of experience
• highest quality drive solutions at competitive prices
• application know-how in the defined market sectors
• the commitment of an innovative company
• personal customer service at all levels
• after sales services & life cycle support
Page 2 We Keep the World in Motion.
A Global Player for Electrical Drives…
TRASYS
Beteiligungs- und Management GmbH
• Generators for wind energy and decentralized energy systems • AC traction motors air and liquid cooled
• Motors for industrial plant applications, marine, oil & gas, • Traction drives (motor and gear)
power plants, plastics & tunneling • Traction generators, synchronous and asynchronous
ELIN Motors Bosnia d.o.o. Suzlon Generators Ltd. Medha Traction Equipment Ltd. Traktionssysteme Bosnia d.o.o.
(Živinice, BiH) (Pune, India) (Hyderabad, India) (Tuzla, BiH)
ELIN Metal Kft. Traction Systems Inc.
(Bátonyterenye, Ungarn) (Somerville, NJ / USA)
Page 3 We Keep the World in Motion.
Organisation Page 4 We Keep the World in Motion.
... in motion.
Profit from our experience in the following sectors:
Industrial Plant Applications
Asynchronous motors with squirrel cage and slip ring rotor, motors IP68 and motors for
operation with frequency converters for cement plants, opencast mining, steel plants,
chemical plants, water & environment, seawater desalination plants,
pulp & paper, test rig motors, applications for industrial plants
Decentralized Energy Systems
Synchronous generators for steam turbines (industrial turbines)
Hydro power (small and medium power), gas turbines, gas motors
Asynchronous generators for Hydro power (small power)
Power Plants
Three-phase short circuit motors for operation on mains as well as operation
on mechanically or electrically speed regulated drive systems for
all forms of large thermal power plants.
Page 5 We Keep the World in Motion.
... in motion.
Profit from our experience in the following sectors:
Plastics & Tunneling
Water jacket cooled low voltage motors for
tunnel boring, vertical and shaft drill units, underground mining, extruder and
compounder, mixer and kneader, injection moulding machines, roller mills,
metallurgy, pumps and presses
Marine, Oil & Gas
Asynchronous and slip ring motors for up-, mid- & downstream solutions, petrochemistry,
air separation, compressors and pumps as well as explosion proof applications (Ex n, e, p).
Certified solutions for marine applications requirements (ABS, Bureau Veritas, DNV, KR, LR,…)
Wind Energy
Asynchronous and synchronous generators
(conventional, DFIG‘s, PMG's),
On- und offshore
Page 6 We Keep the World in Motion.
Power Ranges
Three-Phase Squirrel Cage and
Wind Energy Slip Ring Generators
Plastics
Tunneling Three-Phase Squirrel Cage Motors
Mining
Compressor Drives
Industrial Plant Applications Three-Phase Squirrel Cage and Slip Ring Motors
Power Plants
Decentralized Energy Systems Synchronous & Asynchronous Generators
20,000
10,000
65,000
35,000
2,500
1,000
2,000
5,000
750
200
500
kW / kVA
Page 7 We Keep the World in Motion.
Service
• Inspection
• Diagnostics
• Documentation
• Technical Support
• After Sales Services
• Spare Parts
• Maintenance and Maintenance Agreements
• Repair and Reconditioning of ELIN or other
manufacturers‘ products
• Installation and Commissioning
Page 8 We Keep the World in Motion.
Service • Technical project management in Weiz • International service and local support by our certified service partners (see above) • Full support over the whole life cycle of the machines Page 9 We Keep the World in Motion.
Selected Certificates
• EN ISO 9001:2015
issued 2017, ISO 9001 original approval in 1996
• EN ISO 14001:2015
issued 2017, ISO 14001 original approval in 2016
• BS OHSAS 18001:2007
issued 2017, OHSAS 18001 original approval in 2011
• Underwriters Labs, issued 2001
• ATEX Compliance, issued 2003, renewed 2017
• ANZEx, issued 2006
• Certificate according to ISO 3834-2,
issued 2017, original approval in 2012
EN ISO 9001:2015
• Certificates for “Marine” (ABS, BV, DNV, KR, LR,…)
Page 10 We Keep the World in Motion.History • Foundation of F. Pichler Werke / Weiz 1892 • Renamed ELIN 1908 • ELIN becomes a 100 % subsidiary of the newly founded Austrian Industries AG (which is 100 % owned by ÖIAG) 1989 • ELIN Motoren becomes an independent company within VA Technologie AG, which itself was spun off from Austrian Industries AG 1993 • Going public of VA Technologie AG (Vienna Stock Exchange) 1994 • TRASYS buys 80,1% shares of ELIN Motoren GmbH 2002 • Joint Venture with Suzlon Generators Ltd., Pune / India 2004 • TRASYS becomes 100% owner of ELIN Motoren GmbH 2005 • New premises in Preding/Weiz 2009 • Foundation of the subsidiary ELIN Motors Bosnia d.o.o., Živinice/BiH 2015 • Acquisition of Nordmetal Kft., Bátonyterenye/H 2017 Renamed ELIN Metal Kft. (11/2018) Page 11 We Keep the World in Motion.
Preding/Weiz
• Research and
Production Centre:
built in 2008
• Plant area: 50,000 m²
• Production: 17,000 m²
• Offices: 5,000 m²
• Height of shop floor:
up to 12 m
• Length: 240 m
• Width: 70 m
• Crane capacity:
up to 80 to, 8.25 m
• Connected load: 5 MW
Page 12 We Keep the World in Motion.Lamination Shop
• Lamination Shop:
built in 2001
• Plant area: 3,000 m²
• Production: 2,000 m²
• Warehouse: 1,000 m²
• Crane capacity:
up to 25 to, 8.5 m
Page 13 We Keep the World in Motion.Test Field
• Testing of synchronous,
asynchronous and direct
current machines
• Feed voltage:
AC: 400 V up to 15 kV
DC: up to 600 V
• Power:
up to 6 MW direct
coupling
• Alternative load testing
for asynchronous
machines up to 15 MW
• Alternative testing for
synchronous machines
up to 65 MVA
Page 14 We Keep the World in Motion.All our efforts revolve around our customers' success. Page 15 We Keep the World in Motion.
Project: Boxberg Power Plant Block R - BFP
Location: Germany
Year: 2009
• Type: HKM110D04
• Power: 13500 kW
• Voltage: 10 kV
• Frequency: 50 Hz
• Speed: 1478 rpm
• Cooling: Air / water cooled
• Quantity: 1 piece
• Application: Pump
• Highlight: Start-up at 75 % of the
nominal voltage
against full resisting
moment of the pump.
Best efficiency (>97
%) at 75 % of the
nominal power (usual
operation point of this
application)
Copyright: Vattenfall Europe
Page 16 We Keep the World in Motion.Project: Moorburg – ID-Fan
Location: Hamburg, Germany
Year: 2012
• Type: HKM111Z10
• Power: 11000 kW
• Voltage: 10 kV
• Frequency: 50 Hz
• Speed: 592 rpm
• Cooling: Air / water cooled
• Quantity: 2 pieces
• Application: Fan
• Highlight: Power plant design
standard: Start-up
after voltage drop
against open valve
and partial voltage
≥ 80 % with reduced
start-up current. Focus
on low noise level.
Page 17 We Keep the World in Motion.Project: White Nile Sugar
Location: Sudan
Year: 2006
• Type: HRH-063 P14
• Power: 960 kW
• Voltage: 3.3 kV
• Frequency: 50 Hz
• Speed: 421 rpm
• Cooling: Exhaust air
discharged by a
conduit
• Quantity: 20 pieces
• Application: Pipe cased shaft
pump
• Highlight: Vertical installation
on pipe cased shaft
pump with low
vibrations (between
0.12 and 0.48
mm/sec measured)
/ automatic brush
lifting device
Page 18 We Keep the World in Motion.Project: Sarooj Busher
Location: Iran
Year: 2006
• Type: HRR-010 Z06
(526096)
• Power: 4300 kW
• Voltage: 6300V
• Frequency: 50 Hz
• Speed: 992 rpm
• Cooling: Tube cooled
• Quantity: 1 pc
• Application: Raw Mill
• Highlight: 2nd shaft end
Amb. Temp.: 50°C
Page 19 We Keep the World in Motion.Project: Test Bench Drives
Location: Germany
Year: 2012
• Type: HKF and MKH
• Power: 620 kW – 3200 kW
• Voltage: 690 V – 3.3 kV
• Frequency: 50 / 60 Hz
• Speed: 0 - 3000 rpm
• Cooling: Air/Water
& forced ventilation
and water jacked
• Quantity: 11 pieces
• Application: Test field
Page 20 We Keep the World in Motion.Project: 8 TBM – Crossrail
Location: Great Britain
Year: since 2011
• Type: MKH428W04
• Power: 160 kW
• Voltage: 400 V
• Cooling: water – cooled
• Quantity: Totally 82 Motors
• Appliance: Cutter Head Drive
Page 21 We Keep the World in Motion.Project: Mining and Tunneling
Location: Worldwide
Year: since 1975
• Type: dMCV, dPRW, dMKH
• Power: 100 – 400 kW
• Voltage: 400 – 1140 V
• Cooling: water – cooled
• Protectionclass: ATEX EN 60079
• Appliance: Cutter Head and
Hydraulic
Page 22 We Keep the World in Motion.Project: Extruder for thermoplastic
Location: Worldwide
Year: since 2000
• Type: various MKH-7/8
• Power: 30 – 1320 kW
• Voltage: 380 – 690 V
• Cooling: water - cooled
• Appliance: Extruder
© Leistritz
Page 23 We Keep the World in Motion.Project: Siemens / „POSCO Korea“
Location: Korea
Year: 2012
• Type: HRM-080 C04
• Power: 7,850 kW
• Voltage: 6,000 V
• Frequency: 60 Hz
• Cooling: Air/ Water
• Quantity: 3
• Application: Turbo compressor
Siemens
• Highlight: KOSHA Design
Exp IIC Zone2
design
Brush lifting device
Start via liquid starter
Page 24 We Keep the World in Motion.Project: GEA / „LUKOIL - Krasnodar“
Location: Russia
Year: 2010
• Type: HKM-171 E02
• Power: 5,300 kW
• Voltage: 6,000 V
• Cooling: Air/ Water
• Quantity: 3
• Application: Cameron Compressor
• Highlight: Exp IIB T3, Zone2
Balancing G0,8
Shaft vibration max.
25µm p-p
High level of
auxiliaries
Starting current
3,9xFLC via soft
starter
GOST+ RTN
Page 25 We Keep the World in Motion.Project: LMF / „Western GECO“
Location: all over the world
Year: 2012
• Type: MCZ-545 N04
• Power: 1,400 kW
• Voltage: 690 V
• Cooling: Water Jacket cooled
• Quantity: 3
• Application: Reciprocating
compressor
• Highlight: DNV Certified
Double shaft end
IM2202
Flange mounted
Operation on
exploration ships
Page 26 We Keep the World in Motion.Project: Windpark „Janneby“
Location: Germany
Year: 2013
• Type: MRM-063 Z06
• Power: 3,100 / 3,400 kW
• Voltage: 660 V
• Speed: 1,010 rpm
• Cooling: Air / water
• Application: Nordex N100 / N117 /
N131 turbines
Page 27 We Keep the World in Motion.Project: Windpark „Donghai bridge“ (Off-shore)
Location: China
Year: 2011
• Type: HRM-171 Z06
• Power: 5,300 kW
• Voltage: 6.3 kV
• Speed: 1,006 rpm
• Cooling: Air / water
• Application: Sinovel SL 5000
Page 28 We Keep the World in Motion.Project: Torsvik
Location: Torsvik, Schweden
Year: 2004
• Type: HTM-110 D04
• Power: 18,300 kVA
• Voltage: 10.5 kV
• Speed: 1,500 rpm
• Cooling: Air - Water
• Application: Steam turbine
(generator mounted
gearbox)
Page 29 We Keep the World in Motion.Project: Envesta Energie- & Dienstleistungs GmbH
Location: KW Johnsbach
Year: 1958
Service:
Stator winding,
new collector, 2011
• Type: Sy 4004 / E26
• Power: 700 kVA
• Voltage: 400 V
• Current: 1010 A
• Frequency: 50 Hz
• Speed: 1,500 rpm
• Make: ELIN
Page 30 We Keep the World in Motion.Project: KW Gaulwerk
Location: Imst
Year: 1982
Service:
Overhaul of synchronous
generator, 2011
• Type: S 20012
• Power: 1,000 kVA
• Voltage: 5,250 V
• Current: 318 A
• Frequency: 50 Hz
• Speed: 500 rpm
• Make: ELIN
Page 31 We Keep the World in Motion.Project: KW Offensee 1
Location: Ebensee
Year: 1908
Service:
Renewal of stator winding,
synchronous rotor
• Type: Wid 1020/500
• Power: 1,200 kVA
• Voltage: 3,000 V
• Current: 231 A
• Frequency: 50 Hz
• Speed: 500 rpm
• Make: SSW
