Tasarsailing 2021
NEWSHEET
2021 Price
on new Tasar
Dinghies
starting at
£7,900 includes VAT
Summer 2021
Signal Locker have new Bethwaite
Ta s a r s f r o m t h e X S P f a c t o r y
available for sale this season.
Our starting point is a standard
'Measurement Boat'. This comprises
the basic hull and deck plus all the
fittings that are included when a
Tasar is weighed-in for a regatta.
This option allows current Tasar
owners to upgrade using their
existing fittings.
The standard specification of the
'Measurement Boat' does not include
the mast, spars, sails or foils.
However when you buy a new hull, you are also eligible for a 10% discount on all of those items, and in f act any eq uipment in Signal Locker's catalogue for six months following deliver y of your Measurement Boat. A complete ready-to-race Tasar is £12,300 incl 20% VAT. This includes everything, boat, rig, sails, foils, covers, trolley. ‘Measurement Boat’ Price • £7,900 Including 20% VAT ex works Lymington UK Complete Boat Price • £12,300 Including 20% VAT ex works Lymington UK • Approximate equipment weights are listed on the sheet below Payment Terms • £2,500 with order • Balance prior to delivery Order and Delivery • Order form to be completed • Acknowledgement and delivery date agreed • Delivery arrangements confirmed • After sales support European Orders Include • Invoice without 20% VAT • Export documents arranged S IG N A L LO C K E R The specialist Tasar store and European Agent. W www.tasarsailing.com E info@tasarsailing.com T +44 01590 678699
Outline Specification…
The specification for our factory order is for the hull, deck and thwart assembly,
plus fittings that are typically installed when the boats are in 'Measurement Trim’…
• Primary Hull Fittings – forestay U-bolt, mast pin, hatches, gudgeons, thwart
strut
• RCB Shroud Tracks – tracks, underbars, RCB cars, cleats, pull-back lines and
handles
• Toestraps – saddles, cleats, padded toestraps, adjuster lines and shock-cord
tensioner
• Jib Tracks – tracks, cars, cleats
• Traveller System – track, 3-pin channel top car, ratchet blocks, traveller line
& cleats
• Mainsheet Swivel and Block – swivel with mainsheet ratchet block only
Hull Specification
Hull and deck assemblies are built by XSP to the new specification, including the
new centreboard case / thwart arrangement, revised deck laminate exclusion of
plastic handholds.
Tasar weight
The new minimum weight of hulls built is now 61 kg. The minimum weight of boats
in measurement trim remains at 68kg, which allows for about 7 kg of fit-out weight.
New Boat Orders…
Orders are accepted on the following basis:-
Equipment included with new boats will be as per attached 2021 specification
unless agreed otherwise in writing
For a period of 6 months following delivery, additional fit-out equipment (eg.
mast, spars, sails, foils etc.) can be purchased for the boat at a discount of
10% from Signal Locker published prices
Deposit:- £2,500 with order
Hull price:- £7,900 incl 20% VAT, delivery ex works Lymington
Complete boat price:- £12,300 incl 20% VAT, delivery ex works Lymington
Terms of Business:- BMF standard marine contract terms (Issue 15)
Individual specification sheet, offer and order form will be supplied prior to
delivery
Orders confirmed on receipt of deposit to be paid by bank transfer
Please contact us to discuss further by phone or email:
+44 (0) 7970 132110 info@tasarsailing.com
E&OE
2021 Tasar Weight File
Signal Locker Line item
Description Number Supplier Item weight g
Reference weight kg
100-100 Tasar hull, deck & thwart (white hull, grey deck) 1 XSP 61,500 61.5
Primary hull fittings
100-210 Thwart Strut (fixed length S/S) 1 Signal Locker 210 0.21
100-215 Thwart Lashing (3mm Dyneema) 1 Signal Locker 35 0.035
100-225 Thwart bushes (for traveller line fairlead) 2 Signal Locker 12 0.024
100-405 Self Bailer 1 Riley 367 0.367
100-520 Hatch - Grey 145mm Allen Hatch Assembly 3 Allen-AL537 145 0.435
100-605 Gudgeon - S/S Upper 1 Perf Sailcraft 138 0.138
100-610 Gudgeon - S/S Lower (with spring) 1 Perf Sailcraft 150 0.15
100-625 Forestay U Bolt 1 Wichard 6512 35 0.035
130-112 Mast Step Pin Plate (8mm) 1 Signal Locker 60 0.06
Toestraps & fittings
100-305 Toestrap Eyelet/Saddle/Fairlead (& fasteners) 8 Ronstan-RF134 14 0.112
100-310 Toestrap Clamcleat (hard anodised) 4 CL704AN 34 0.136
100-315 Toestrap - Padded (Set of 4) 1 Signal Locker 435 0.435
100-320 Toestrap Adjuster Line (5mm poly pre-stretch) 1 Signal Locker 95 0.095
100-325 Toestrap Shockcord 1 Signal Locker 110 0.11
Shroud tracks & cars
160-205 Shroud RCB-Track 19mm (and Fasteners) 2 Ronstan-1190 138 0.276
160-210 Shroud RCB-Track Backing Rod 2 Signal Locker 252 0.504
160-215 Shroud RCB-Track Car 2 Ronstan-RC11902 85 0.17
160-220 Shroud RCB-Track End Stop (pair) 2 Ronstan-11980 11 0.022
160-245 Shroud RCB - Pull-Back Lines & Handles (pair) 2 Signal Locker 30 0.06
160-250 Shroud RCB - Pull-Back Cleats & shackles (pair) 2 Signal Locker 16 0.032
Jib tracks, cars & fairleads
170-205 Jib Fairlead Track 451mm (silver) (& fasteners) 2 Allen-AL4274 175 0.35
170-210 Jib Fairlead Track End Stop 4 Allen-AL736 4 0.016
170-215 Jib Fairlead PTFE Slider (pair) 2 Allen-SAL4274
170-220 Jib Cleat Flat Mounting Plate 2 Signal Locker
170-225 Jib Fairlead 2 Allen-SAL4374 225 0.45
170-230 Jib Fairlead Plunger + Spring 2 Allen-SAL4574
170-235 Jib Cleat Slider 2 Allen-SAL4674
170-240 Jib Sheet Cam-matic Cleat 2 Harken-150 71 0.142
Kicker
190-400 Kicker Clamcleat with roller 2 CL236AN
190-405 Clamcleat Keeper 2 CL814 53 0.106
190-410 Kicker Tapered Pad for CL236AN 2 CL818
Mainsheet
210-110 Mainsheet Swivel Base (& fasteners) 1 Harken-144 417 0.417
210-120 Mainsheet Ratchet Block 1 Harken-2135 85 0.085
Traveller
220-105 Traveller Track (& fasteners) 1 Signal Locker 497 0.497
220-110 Traveller Eye Becket (& fasteners) 2 Ronstan-RF1050 18 0.036
220-135 Traveller Beam Car 3-pin Channel Top 1 Ronstan-RC61914 140 0.14
220-150 Traveller 40mm Carbo Ratchet block 2 Harken-2608 49 0.098
220-155 Traveller stand-up spring 2 Harken-097 4 0.008
220-165 Traveller stand-up boot 2 RWO R1814 10 0.02
220-185 Traveller control line 1 Signal Locker 130 0.13
220-190 Traveller 8mm Ronstan Low Friction Ring 2 RF-8090-08 10 0.02
220-200 Traveller Cam Cleat 2 Harken-150 71 0.142
Typical weight of Measurement Tasar excluding corrector weights 67.563
Signal Locker Limited 9 Stanley Road Lymington SO41 3SJ W tasarsailing.com T +44 1590 678699 E info@tasarsailing.com Company Registration 05298480 VAT 876060511
