INDEX
1
ABOUT DAIKIN

2      3
GLOBAL FOOTPRINT

4      5
THE DAIKIN DIFFERENCE

6      7
OUR TIMELINE

8      9
DAIKIN INDIA AT A GLANCE

                           10
                           APPLICATION OF THE PRODUCT

                           11       31
                           INVERTER SERIES

                           32       45
                           NON-INVERTER SERIES

                           46       52
                           OUTDOOR UNITS

53       56
CONTROLLERS

57       58
FUNCTION LINE-UP

59       68
SPECIFICATIONS
Solutions Maximum designs. | Minimum running cost - Daikin
Daikin, the world leader in air-conditioning
                                     brings a world full of love to India with its
                                     air-conditioning solutions. Known for superior
                                     Japanese technology, Daikin promises to spread
                                     joy in the air. With a wide range and features like
                                     never before, Daikin creates an environment of
                                     comfort through efficient air-conditioning. Daikin
                                     air-conditioners are manufactured keeping in
                                     mind different air-conditioning needs and also
                                     space requirements. Our wide range of air-
                                     conditioners are easy to install and are apt for
                                     residential and commercial usage.

ABOUT DAIKIN
Daikin® is a leading innovator and provider of advanced, high-quality
air-conditioning solutions for residential, commercial and industrial applications.
As World’s No. 1 Air-conditioning Company, Daikin is committed to delivering
air-conditioning solutions that enhance the quality of life all around the world. A
diverse multinational company, Daikin Industries Ltd. active in air-conditioning,
chemicals and oil hydraulics, was established in 1924. With headquarters at
Osaka, Japan, the Daikin family has more than 51,000 members, working across
60 production base units and 208 consolidated subsidiaries worldwide. As the
world’s sole manufacturer that develops a long line of products from refrigerants to
air-conditioners, Daikin advocates comfortable living on the strength of advanced
technologies.
Daikin is present in USA, Europe and Russia, Middle East, Africa, Asia, Oceania and
Middle-South America. We aim to serve our customers in each of these markets by
providing optimal airconditioning products.
Solutions Maximum designs. | Minimum running cost - Daikin
GLOBAL FOOTPRINT

                                                                                                NORTH
                                                                                               AMERICA

  2
Solutions 3600

                                                                                                                              MIDDLE-SOUTH
                                                                                                                                 AMERICA

                                                                                  North America/Central
                 Europe/Middle East/Africa                                        & South America

                      Daikin             Daikin                Daikin               Daikin America
                  Airconditioning   Airconditioning      Airconditioning
                  Central Europe          Spain                 Italy

                                                                                                       Daikin AC (Americas)

                                                                                  Daikin Holding USA

                   Daikin Europe          Daikin        Daikin Airconditioning
                        N.V.         Airconditioning          Germany
                                         France

                      Daikin             Daikin           Daikin Chemical
                  Airconditioning   IndustriesCzech          France
                        UK              Republic
Solutions Maximum designs. | Minimum running cost - Daikin
EUROPE

                                                                                                                     CHINA

                                                                                                                                  JAPAN
                                                           MIDDLE EAST

                                                                                                                                            3

                                                                                                                                          Solutions 3600
                                                                                   ASIA

                              AFRICA

                                                                                                                        OCEANIA
                                                 DAIKIN INDUSTRIES HEAD OFFICE
                                                 (INSIDE UMEDA CENTER BUILDING)

China                                                                Asia/Oceania

   Daikin (China)       Shanghai Daikin   Xi’an Daikin Qing’an         Daikin Industries      Daikin Compressor
    Investment          Airconditioning        Compressor                  Thailand                Industries

  Hui Zhou Daikin           Daikin           Daikin Fluoro           Daikin Airconditioning      Daikin Australia
Suns Airconditioning   Device(Suzhou)     Coating Shanghai              Singapore

       Daikin
  Fluorochemicals                                                   Daikin Airconditioning
       China                                                                 India
                                                                                               Daikin Industries Head
                                                                                               Office (Inside Umeda
                                                                                                 Center Building)
Solutions Maximum designs. | Minimum running cost - Daikin
THE DAIKIN                               THE LOGO
DIFFERENCE

As a world leader in technological
innovation, we’ve initiated and
funded a wide range of research
programmes in areas that directly
impact our air-conditioners
- ranging from mechanics
and electronics to chemicals             The triangle shape represents the
and fluorocarbons. With this             integration of three technological
knowledge, we build absolute             areas (mechanics, chemistry and
comfort into every product we            electronics), while the upper left
develop. Pioneering products             direction of the triangle symbolises
include the first packaged               Daikin’s innovative spirit that
air-conditioner in Japan 1951 and        aspires toward the future. The two
the world’s first Variable Refrigerant   blue colours (corporate colours)
Volume (VRV) system in 1982.             used in the corporate logo and
Daikin is committed to explore and       the triangle design element befit
adopt cutting-edge technology            Daikin’s emphasis on intellect
to continually offer value-added         and brightness. Black expresses
and solution-based products and          strength, a sense of positive
services to customers.                   presence and stability.
Solutions Maximum designs. | Minimum running cost - Daikin
ENVIRONMENTAL                              PICHONKUN
PHILOSOPHY

In February 2002, we created
an environmental symbol for the
Daikin Group. In environmental
protection activities, little efforts
that individuals make add up to big
things. The symbol, the Earth in the
shape of a green heart, represents
a determination on the part of each
and every employee of Daikin to
think green (think of the Earth and
take care of the environment).
As we continue developing our
business operations in various
fields, it is our mission to proactively
develop initiatives to respond to
environmental issues. Incorporating
environmental initiatives throughout       A mascot that represents Daikin’s
our management must be a priority          innovative thrust into the future is
for us. In all aspects of our business     called ‘PICHONKUN’. The new
operations, including product              mascot of Daikin is so named
development, manufacturing                 because of the sound it makes.
and sales, we need to formulate            Created in Japan, this dew droplet
initiatives that sustain and improve       represents the ‘fresh as morning
the environment. Meanwhile, we             nature’ of Daikin’s new range of
need to promote the development            air-conditioners and airpurifiers.
of new products and the innovation         PICHONKUN symbolises the best
of technologies that will lead to a        of nature-fresh, natural and
more environmentally healthy world.        eco-friendly.
Solutions Maximum designs. | Minimum running cost - Daikin
OUR TIMELINE
                 1924-2012

                         Akira Yamada
                         becomes the founder
                 1924    of the Osaka Kinzoku
                         Kogyosho Limited                                            The industry’s first compact room
                         Partnership.                                         1995   air-conditioner to use a swing compressor
                                                                                     to save energy is marketed.

                         Osaka Kinzoku Kogyo Co., Ltd. is established,
                         with the following corporate logo:
                         Trial manufacture of a methyl chloride type
                  1934
                         refrigerator succeeds. T he refrigerator is named
                         Mifujirator and production begins.                          Daikin Airconditioning France S.A. is established
                                                                              1993   in Paris as an air-conditioning system sales
                                                                                     company.

                         The Mifujirator refrigerator is delivered to
                  1936   Nankai Railways for trial use as Japan’s first
                         air-conditioner for trains.

                                                                                     Daikin Chemical Europe is established in
                                                                              1992   Düsseldorf, Germany.
  6
                  1951   Production of packaged air-conditioners begins.
Solutions 3600

                                                                                     Daikin America, Inc. and MDA Manufacturing,
                         A heat exchanging device is installed on the         1991   Inc. are established in the US.
                  1956   Soya, an Antarctic research vessel, as a cabin
                         heating system.

                         Residential-use air-conditioners equipped with
                         Japan’s first rotary compressor are marketed.               Daikin Industries (Thailand) Ltd. is established
                  1958   The heat-pump type packaged air-conditioner is       1990   in Thailand and begins production of
                         developed.                                                  air-conditioners.

                         Osaka Kinzoku Kogyo Co., Ltd. is renamed
                  1963   Daikin Kogyo Co., Ltd. (Renamed Daikin
                         Industries, Ltd. in 1982).
                                                                                     Daikin becomes first in the world to produce a
                                                                              1984   cumulative total of 1 million packaged
                                                                                     air-conditioners.
                         Cool air service by Daikin Aircon begins at
                  1964   J.N.R. Osaka Station. The air-conditioning
                         system is thereafter installed in major terminals.

                         A multiroom air-conditioning system with a
                         single outdoor unit is developed. A Freon heater            Japan’s first VRV system is developed.
                  1969   is employed in an air-conditioner, combining         1982   The industry’s first single-screw refrigerator is
                         heating and cooling functions.                              developed.
Solutions Maximum designs. | Minimum running cost - Daikin
All Daikin factories in Japan (Sakai,
       Yodogawa, Shiga, and Kashima) acquire
       ISO 14001 certification for environmental
1997   management.Presented 32nd Chairman’s
       award by the Japan Society for the
       promotion of the machine industry for Daikin
       Swing Compressor.

                                                             Acquisition of the major American
                                                             residential use air-conditioner company,
                                                             Goodman, to build a solid base for
       Japan’s first VRV system is developed.                positioning Daikin as the leading
1998   The industry’s first single-screw                     company in the global air-conditioner
       refrigerator is developed.                     2012
                                                             market. Launch of residential
                                                             air-conditioner featuring the world’s
                                                             first adoption of the next generation
                                                             refrigerant HFC32.

       Daikin Airconditioning Central Europe
                                                                                                          7
1999   GmbH is established in Austria as an
       air-conditioning system sales company.

                                                                                                        Solutions 3600
                                                             Acquired Japan’s leading air filter
                                                      2009   company Nippon Muki Co., Ltd.

       Established a company for the
       manufacture and sale of swing
2001   compressors in Bangkok, Thailand,                     Recipient of ‘Eco Products Awards’
       called Daikin Compressor Industries Ltd.              Japan’s Ministry ofthe Environment’s
                                                      2008   Minister’s Prize for ‘Sho-ene Toban’, a
                                                             building air-conditioner remote energy-
                                                             savingcontrol service.

       Received the 11th Annual Grand Prize
2002   for the Global Environment presented by
       the NikkanKogyou Shimbun.

                                                             Acquisition of major global
                                                             air-conditioning manufacturer OYL
                                                             Industries (Malaysia)with the aim of
                                                             becoming the No.1 air-conditioning
                                                      2006   manufacturer. Establishment of
                                                             Environmental Response Department at
                                                             Daikin Europe N.V. to take the lead in
       Daikin is ranked 1st in market share of               environmental response in the European
2003   residential use air-conditioners in Japan             region.
       throughout the fiscal year of 2003.
Solutions Maximum designs. | Minimum running cost - Daikin
DAIKIN
                                                                                                 INDIA
                                                                                                 AT A
                                                                                                 GLANCE

                 Daikin Airconditioning India Pvt. Ltd., a subsidiary of Daikin Industries
  8              Ltd., Japan is one of the leading global manufacturers of both residential
                 and commercial air-conditioning systems. Backed by the superior
Solutions 3600

                 technology, the organisation offers a wide range of energy efficient
                 air-conditioning solutions to customers.

                 After introducing our superior air-conditioning solutions in India in
                 the year 2000, we gained the trust of our valuable customers with our
                 innovative range of products and dedication towards quality.
                 An ISO 14001 certified company, we remain committed to keep
                 customers at the core of everything we do. Imbued with a ‘Quality First’
                 global philosophy, we at Daikin, walk on to realise our dream for a
                 better world.

                 ‘Quality First’ is clearly reflected in the value delivered such as low noise
                 level, low power consumption, cooling efficiency, ease of installation,
                 high reliability – all targeted to improve the quality of life.

                 Daikin India’s manufacturing plant at Neemrana, Rajasthan aims at
                 creating products that will make people’s lives more comfortable.

                 It is supported by a network of production bases worldwide and
                 showcases the application of advanced technology and equipment. Our
                 comprehensive quality control system features centrally computerised
                 management of quality and production data to facilitate timely
                 production that bears the stamp of excellent quality.

                 Daikin Neemrana facility incorporates Daikin’s global Environmental
                 Management System (EMS) that has been implemented in the factory
                 to promote adapting procedures for refrigerant handling, resource
                 conservation and waste management.
2004                             2002                         2000

Daikin India becomes a           Daikin introduces VRV        Daikin enters the Indian
wholly owned subsidiary of       technology in India.         market in a JV with Usha
Daikin Industries Ltd., Japan.                                Shriram Group at 80:20
                                                              stakes respectively as Daikin
                                                              Shriram Airconditioning.

 2007                             2008                         2009

Daikin India relocates           Groundbreaking               Production commences
HQ to Gurgaon and                ceremony of Daikin India’s   at manufacturing plant in
commences business of            manufacturing base at        Neemrana, Rajasthan.
McQuay chillers in India.        Neemrana, Rajasthan.

                                                                                                9

                                                                                              Solutions 3600
 2013                             2012                         2010

Fresh round of ` 330             Production of High Wall      Fresh round of ` 250
crore investment                 Split air-conditioners       crore investment. Thus
                                 with R-32 refrigerant        taking it to a total of
                                 commences.                   ` 743 crore.

 2015

MoU signed with Rajasthan
government for ` 600 crore
investment

` 60 crore investment for
Research & Development
Centre to be opened next year
APPLICATION
                 OF THE PRODUCT

                 RETAIL                                                        OFFICES / BANKS
                 Versatility and control are the keys to create a              The challenge for an office or bank is the ability to
                 comfortable condition within trading areas and changing       effectively heat or cool open plan areas as well as
                 rooms that will keep customers shopping. It’s important       meeting rooms. Cooling a meeting room when it is
                 to select a system that offers excellent performance, while   empty will mean running costs mount up unnecessarily.
                 minimising operating costs and energy consumption.            Conditions within open-plan areas are important for staff
                                                                               comfort levels.

10
Solutions 3600

                 IT & SERVER ROOMS                                             RESTAURANTS
                 Computer systems run round the clock and require a            Guests expect a perfect atmosphere, including
                 controlled temperature environment to operate effectively.    comfortable conditions. Heat generated from lighting,
                 Equipment in these rooms can generate a lot of heat and       the kitchen area and the dining area can all contribute
                 not removing the heat effectively can cause computer          to make restaurants uncomfortable with inadequate
                 servers to malfunction. Downtime from inoperable servers      air-conditioning. Air-conditioning needs to be discreet
                 can mean lost business and productivity.                      and flexible to meet the demands of your restaurant and
                                                                               customers.
INVERTER
SERIES
CEILING
SUSPENDED
TYPE
FHQ SERIES
COOLING ONLY & HEAT PUMP
FHQ SERIES
                 COOLING ONLY & HEAT PUMP

                 UPGRADE TO A QUIET AND COMPACT SYSTEM

                                                                                                         D
                                                                                                                  H
                                           100   0

                                  WIDE AIR DISCHARGE           EASY CLEAN,          OIL RESISTANT     UNIFORM HEIGHT              QUIET                 PROGRAMME
                                  OPENINGS PRODUCE            FLAT SURFACES             GRILLE          AND DEPTH               OPERATION                  ‘DRY’
                                      A SPREADING
                                  100 DEGREE AIRFLOW

                      FHQ50BV~125BV                  (COOLING ONLY)                         5.0 KW ~ 12.5 KW                                            COOLING

                                                                                            5.0 KW ~ 11.2 KW                                            COOLING
                        FHQ50BV~125BV (HEAT PUMP)
                                                                                            6.0 KW ~ 13.5 KW                                             HEATING
14

                                                                  ACCESSORY REQUIRED FOR INDOOR UNIT
Solutions 3600

                  IRED LCD REMOTE CONTROLLER
                 W                                                                                     WIRED LCDREMOTE CONTROLLER
                 WITH WEEKLY SCHEDULE TIMER
                                                                                           Standard                                                                                    Option

                 BRC1D61                                                                               BRC1C61

                 Note: S
                        tandard for both Cooling Only a
                                                        nd Heat Pump models. Remote controller        Note: Remote controller cable not included. Cables must be procured locally.
                       cable not included. Cables must be procured locally.

                 WIRELESS LCD REMOTE CONTROLLER                                                        NAVIGATION REMOTE CONTROLLER

                                                                                            Option                                                                                     Option
                 A signal receiver must be added to the indoor unit.

                 BRC7EA66                   BRC7EA63W                   SIGNAL                         BRC1E62
                 (Cooling Only)             (Heat Pump)                 RECEIVER UNIT                  (Wired Remote Controller)
                                                                        (Installed type)
                 Wireless remote controller and signal receiver unit are sold as a set.                Note: Remote controller cable not included. Cables must be procured locally.

                 1 TR (TONS OF REFRIGERATION) = 3.517 KW
FEATURES                                IDE AIR DISCHARGE OPENINGSPRODUCE A
                                                                      W
                                                                      SPREADING 100º AIRFLOW

                                                  Cooling    Heat
                 FHQ-BVV1B
                                                   Only      Pump
                 Auto swing                             •     •
                 Draft prevention function              -     •
                 Switchable fan speed(2 step)          •     •
                 Programme ‘Dry’                        •     •
                 High ceiling application               *1    *1
                                                                                                         100°
                 Two selectable
Comfort                                                 *2    *2
                 temperature-sensors
                 Hot start (after defrost)              -     •
                 Year-round                                           AIR IS BLOWN UP TO 50º IN THE DOWNWARD DIRECTION
                 coolingapplicable                     -     •

                 Night quiet operation                  *3    *3
                 Timer selector                         •     •
                 Weekly schedule timer                  *4    *4
Cleanliness      Anti-bacterial air filter              •     •
                 Drain pump mechanism                   *5    *5                                                                       50°
                 Pre charged for up to 30 m             *3    *3
                 Long-life filter                       •     •
Work &
                 Filter sign                            •     •     • INSTALLABLE ON CEILINGS 3.5 M HIGH
Servicing
                 Low gas pressure detection             *3    *3
                 Emergency operation                    •     •
                 Self-diagnosis function                •     •                                                                                      15
                 Auto-restart                           •     •

                                                                                                                                                     Solutions 3600
                 Auto-cooling/
                 heating change-over                   -     •

                 Control by 2 remote                    •     •
                 controllers
Control
features         Group control by 1 remote             •     •
                 controller
                 External command control               •     •
                                                                    • TWO SELECTABLE TEMPERATURE-SENSORS
                 Central remote control                 •     •     	Both indoor unit and wired remote controller (option
                 Interlock control                      •     •       (BRC1E62)) contain temperature-sensors. Temperature
                                                                      sensing can be set at the unit or, to further improve comfort
                 Anti corrosion treatedheat
Others                                                  *3    *3      level, closer to the target area at the wired remote control.
                 exchangers
                                                                      This feature requires initial setting by the installer.
 *1		 Installable on max. 3.5 m high ceiling
                                                                    	Temperature-sensor on indoor unit must be used when the air-conditioner
 *2		 Applicable when wired remote controller is used                 is controlled from another room. W
                                                                                                        ireless remote controller does not have a
 *3		 For outdoor units                                               temperature-sensor.

 *4		 Applicable when BRC1D61 or BRC1E62 is used
 *5		 Option                                                        • SWITCHABLE FAN SPEED: HIGH/MIDDLE/LOW

                                                                    • PROGRAMME ‘DRY’
                               COMFORT
                                                                    	Dehumidification is micro-processor controlled to prevent
                                                                      abrupt and uncomfortable c hanges in air temperature.
•		AUTO-SWING (UP & DOWN) BRINGS COMFORT TO
    THE ROOM

• DISTRIBUTES AIR EVENLY THROUGHOUT THE ROOM
• EASY CLEAN, FLAT SURFACES
                                                                                                          FOR 71BV INDOOR UNIT
                   For all maintenance tasks, access is from bottom surface.

                 • OIL RESISTANT GRILLE
                 	Oil-resistant plastic is used for the air discharge grille.
                   This satisfies durability in restaurants and other similar                            30mm                                                                     30mm
                                                                                                         or more                            1,160mm                               or more
                   environments.

                   Note: Intended
                              for use in salons, dining rooms and ordinary sales floors. This
                         specification is not suitable for kitchens or other harsh environments.
                                                                                                        *WATER USED IN THE TEST-RUN CAN NOW BE DRAINED FROM THE AIR
                                                                                                        DISCHARGE OPENING RATHER THAN FROM THE SIDE AS WAS FORMERLY
                 • QUIET OPERATION                                                                      THE CASE.
                 	Sound operation has been reduced on the exposed ceiling
                   suspended type unit.                                                                 •		DRAIN PUMP KIT (OPTION) CAN BE EASILY
                                                                                                dB(A)       INCORPORATED
                    INDOOR UNIT                       HIGH                          LOW                     Drain pipe connection can be done inside the unit.
                                                                                                            Refrigerant and drain pipe outlets are at the same
                          50BV                           39                           35
                                                                                                            opening.
                          60BV                           39                           35

                          71BV                           39                           35

                          100BV                          42                           37
                                                                                                                                                                             600mm
                          125BV                          44                           39

                 Note: A
                        nechoic chamber conversion value, measured according to JIS parameters
                       and criteria. During operation these values are somewhat higher owing to
                       ambient conditions.

                                                                                                                                                            Drain pump kit
                   SES QUIET STREAM FAN AND OTHER QUIET
                  U
                  TECHNOLOGIES                                                                                                                              (built inside main unit)

16
                                                                                                        •		ALL WIRING AND INTERNAL SERVICING CAN BE
                                                                                                            DONE FROM UNDER THE UNIT
Solutions 3600

                                                                                                        • PIPES MORE EASILY RIGGED

                        Turbulent flow          Straightening           Quiet                           • LOW GAS PRESSURE DETECTION
                        is produced             vane                    stream fan
                                                                                                        	(Applicable to RZQ71KCV4A, RZQ100/125KCV4A,
                                                                                                          RZQ100/125HAY4A outdoor units)

                                                                                                        • LONG-LIFE FILTER LASTS UP TO 6 MONTHS*
                                        WORK & SERVICING                                                  * For dust concentration of 0.15 mg/m3
                                                                                                        	Two time settings (2500 hrs and 1250 hrs) are available to match the installation
                                                                                                           environment. M  aintenance time warning is displayed on the remote controller
                 •		FLEXIBLE INSTALLATION FLEXIBILITY FOR FREEDOM                                         (filter sign).
                     OF DESIGN
                                                                                                        • N
                                                                                                           ON-DEW FLAP BRISTLES MINIMISE CLINGING DIRT
                 • UNIFORM HEIGHT AND DEPTH                                                               AND SIMPLIFY CLEANING
                 	Compact design for small-capacity models to meet tighter                                Absence of bristles minimises clinging dirt and simplifies cleaning.
                   dimensional spaces.

                 • FLEXIBLE INSTALLATION
                   The unit fits more snugly into tight spaces.

                                                                                                          Non-dew flap
CEILING
MOUNTED
SLIM DUCT TYPE
FDXS SERIES
HEAT PUMP
FDXS SERIES
                 HEAT PUMP

                 SUITABLE FOR TIGHT CEILING SPACES

                                                                           SLIM PROFILE        QUIET
                                                                                             OPERATION

                                                                                 2.4 KW ~ 6.0 KW                                COOLING
                          FDXS25~60C (HEAT PUMP)
                                                                                 3.2 KW ~ 7.0 KW                                 HEATING

18
                                                             ACCESSORY REQUIRED FOR INDOOR UNIT
Solutions 3600

                 WIRED LCD REMOTE CONTROLLER

                                                                                                                                                Standard

                 BRC944B2

                 Note: 3
                        m (BRCW901A03) or 8 m (BRCW901A08) length wired
                       remote controller cord is necessary.

                 WIRELESS LCD REMOTE CONTROLLER

                                                                                                                                                 Option

                 ARC433B69                                                                Signal receiver unit
                                                                                          (Separate type)

                 A signal receiver must be added to the indoor unit.                     A signal receiver must be addedto the indoor unit.
FEATURES                                          COMFORT

                                                • QUIET OPERATION
                                         Heat
               FDXS-CVMA                        	Indoor unit quiet operation provides a low sound level of
                                         Pump
                                                  29 dB(A) and outdoor unit quiet operation provides a low
            Switchable fan speed         •
                                                  sound level of 44 dB(A) for FDXS25C.
Comfort     Programme ‘Dry’               •
                                                • DISTRIBUTES AIR EVENLY THROUGHOUT THE ROOM
            Hot start                     •
                                                     The only visible signs of these unobtrusive units are their
            Pre charged for up to 10 m    •          discharge grilles. They fit completely inside the ceiling to
Work &
Servicing                                            maintain the original décor of a room. Each unit comes with
            Self-diagnosis function       •
                                                     its own wireless remote controller.
            Auto-restart                  •
Control
features    Auto-cooling/                                         WORK & SERVICING
                                          •
            heating change-over
Others      PE fin                        •     • SLIM PROFILE
                                                	The new series adds a 2.5 kW model. All units share the
                                                  same low height of just 200 mm. This means it is now
                                                  possible to install a unit inside a shallow ceiling cavity with a
                                                  height of just 240 mm.

                                                                                                                      19

                                                                                                                      Solutions 3600
FLOOR
STANDING
TYPE
FVQ SERIES
COOLING ONLY & HEAT PUMP
FVQ SERIES
                 COOLING ONLY & HEAT PUMP

22
                 COMFORT THROUGH NEW AIRFLOW CONTROL
Solutions 3600

                                  NEW COMFORTABLE              LIGHTWEIGHT       EMPLOYS A SAFETY   SWITCHABLE FAN   PROGRAMME      QUIET
                                  AIRFLOW CONTROL            INDOOR UNIT     LOCK FUNCTION OF        SPEED           ‘DRY’      OPERATION
                                                                                  SUCTION GRILLE

                          FVQ71~140         (COOLING ONLY)                             7.1 KW ~ 13.5 KW                             COOLING

                                                                                       7.1 KW ~ 13.5 KW                             COOLING
                            FVQ71~140 (HEAT PUMP)
                                                                                       8.0 KW ~ 16.0 KW                             HEATING

                                                                   ACCESSORY REQUIRED FOR INDOOR UNIT

                 NAVIGATION REMOTE CONTROLLER

                                                                                                                                                Option

                 BRC1E62
                 (WIRED REMOTE CONTROLLER)
                 Note: R
                        emote controller cable not included. Cables must be
                       procured locally.
FEATURES                                                           COMFORT

                                                                   •		NEW COMFORTABLE AIRFLOW CONTROL
                                                 Cooling    Heat
                 FVQ-CVEB                                            1.		Left and Right Directions (By Remote Controller)
                                                  Only      Pump
                                                                          Auto swing direction is selectable from three patterns to suit the
               Auto swing                              •     •            layout of the room.
               Independent up-and-down                •     •
               airflow
               Switchable fan speed(3 step)           •     •      PATTERN 1
                                                                    WIDE SWING TOWARD THE FRONT
               High fan speed mode                     *1    *1
               Programme ‘Dry’                         •     •
               Two selectable
Comfort        temperature-sensors                     *2    *2

               Hot start (after defrost)               -     •
               Year-round cooling
               applicable                              -     •

               Night quiet operation                   *3    *3
                                                                    WHEN INSTALLED IN THE CENTER OF A WALL
               Timer selector                          •     •
               Weekly schedule timer                   *4    *4

Cleanliness    Anti-bacterial air filter               •     •
                                                                    PATTERN 2
               Pre charged for up to 30 m              *3    *3     SWING ON THE LEFT SIDE
               Long-life filter                        •     •
               Filter sign                             •     •
Work &
Servicing      Low gas pressure detection              *3    *3
               Emergency operation                     •     •                                                                                 23
               Self-diagnosis function                 •     •

                                                                                                                                               Solutions 3600
               Auto-restart                            •     •
               Auto-cooling/                                        WHEN INSTALLED IN THE CORNER OF A ROOM
               heating change-over                    -     •

               Control by 2 remote                     •     •
               controllers
Control
               Group control by 1 remote
features                                               •     •      PATTERN 3
               controller
                                                                    SWING ON THE RIGHT SIDE
               External command control                •     •
               Central remote control                  •     •
               Interlock control                       •     •
               Anti corrosion treatedheat
Others                                                 *3    *3
               exchangers

*1		 Applicable for FVQ71/100
*2		 Applicable when wired remote controller is used
*3		 For outdoor units
                                                                    WHEN INSTALLED IN THE CORNER OF A ROOM
*4		 Applicable when BRC1E62 is used
2.		Up and Down Directions (By Hand)                                 • COMFORTABLE FAN SPEED CONTROL
                       Independent up and down airflow directions facilitate even
                       room temperature and help save energy.                             • HIGH FAN SPEED MODE (ONLY FVQ71/100)
                                                                                            To carry airflow to the far side of the room, airflow rate
                                                                                             can be increased 5% or 10% depending on the installation
                            Freely select both up and down airflow direction
                               with 8-louver (horizontal blade) operation.                   condition or customer’s request (Field setting by remote
                                                                                             controller).
                                    New unit
                                               1       Upper louver (1)                   • SWITCHABLE FAN SPEED: HIGH/MIDDLE/LOW
                                                       Upper interlocking louver (4)
                                               2       Lower interlocking louver (2)
                                                       Lower louver (2)                   • PROGRAMME ‘DRY’
                                                       Each set of louvers 1 to           	Dehumidification is micro-processor controlled to prevent
                                                       4 can be independently
                                               3       adjusted.                            abrupt and uncomfortable c hanges in air temperature.
                                               4       (Manual adjustment)
                                                                                          • ENERGY-SAVING
                                                                                          	A DC fan motor improves efficiency.

                                                                                          • QUIET OPERATION
                 Example applications
                                                                                                                                                                    dB(A)

                                                                                             INDOOR UNIT                 HIGH             MIDDLE              LOW
                  When cooling
                                                                                                    71 C                    43               41                38
                  Turning louvers 1 and 2 upward and turning 3 and                4
                  horizontal will reduce uneven room temperature.                                  100 C                    50               47                44

                                                                                                   125 C                    51               48                46
                             1                                                                     140 C                    53               51                48

                             2                                                            Note: Anechoic chamber conversion value, measured according to JIS parameters
                                                                                                 and criteria. During operation these values are somewhat higher owing to
                                                                                                 ambient conditions.

                             3
                                                                                          • QUICK AND EASY INSTALLATION AND MAINTENANCE
24                           4
Solutions 3600

                                                                                                                WORK & SERVICING
                  When heating
                                                                                          •		LIGHTWEIGHT INDOOR UNIT
                  Leaving louvers 1 and 2 horizontal and turning 3 and                4
                                                                                             E
                                                                                              nables smooth transport and installation of the indoor unit.
                  downward will reduce uneven room temperature.
                                                                                                                                                                      (kg)

                                                                                             INDOOR UNIT                71C         100 C         125 C        140 C
                             1
                                                                                                 WEIGHT                  39           47            47           47
                             2
                                                                                          •	LONG-LIFE FILTER LASTS ABOUT 1 YEAR*,
                                                                                            MAINTENANCE NOT REQUIRED
                             3                                                              *For dust concentration of 0.15 Mg/ M
                             4

                                                                                          • EMPLOYS A SAFETY LOCK FUNCTION OF SUCTION GRILLE
                                                                                            The grille will not open even upon impact.

                                                                                          •	EASIER CONNECTION WITH THE CENTRALISED
                                                                                             CONTROL SYSTEM
DUCT CONNECTION
MIDDLE HIGH STATIC
PRESSURE TYPE
FBQ SERIES
COOLING ONLY & HEAT PUMP
FBQ SERIES
                 COOLING ONLY & HEAT PUMP

                 FLEXIBLE USE OF SPACE IS MADE POSSIBLE USING DUCTS TO
                 CREATE A ROOM FILLED WITH COMFORT.

                                                        USE REMOTE                   QUIET               TWO SELECTABLE                  EASY
                                                      CONTROLLER TO                                  TEMPERATURE-SENSORS           MAINTENANCE
                                                      ADJUST AIRFLOW

                         FBQ50~140D          (COOLING ONLY)                                 5.0 KW ~ 14.0 KW                                             COOLING

                                                                                            7.1 KW ~ 13.1 KW                                             COOLING
                           FBQ71~140D (HEAT PUMP)
                                                                                            8.0 KW ~ 16.0 KW                                              HEATING
26

                                                                 ACCESSORY REQUIRED FOR INDOOR UNIT
Solutions 3600

                 WIRED LCD REMOTE CONTROLLER                                                           IRED LCDREMOTE CONTROLLER
                                                                                                        W
                                                                                                        WITH WEEKLY SCHEDULE TIMER
                                                                                           Standard                                                                                     Option

                 BRC1C61                                                                                BRC1D61

                 Note: S
                        tandard for both Cooling Only a
                                                        nd Heat Pump models. Remote controller         Note: Remote controller cable not included. Cables must be procured locally.
                       cable not included. Cables must be procured locally.

                 WIRELESS LCD REMOTE CONTROLLER                                                         NAVIGATION REMOTE CONTROLLER

                                                                                            Option                                                                                      Option
                 A signal receiver must be added to the indoor unit.

                 BRC4C64                    BRC4C62                     SIGNAL                          BRC1E62
                 (Cooling Only)             (Heat Pump)                 RECEIVER UNIT                   (Wired Remote Controller)
                                                                        (Installed type)
                 Wireless remote controller and signal receiver unit are sold as a set.                 Note: Remote controller cable not included. Cables must be procured locally.

                 1 TR (TONS OF REFRIGERATION) = 3.517 KW
FEATURES                                                             COMFORT

                                                                   •		QUIET OPERATION
                                                 Cooling    Heat
                 FBQ-DV1                                                                                                                      dB(A)
                                                  Only      Pump
               Switchable fan speed (2 step)                        INDOOR UNIT                       HIGH                        LOW
                                                       •     •
                                                                            50 D                         37                         32
               Programme ‘Dry’                         •     •
                                                                            60 D                         37                         32
               Two selectabletemperature-             *1    *1
               sensors                                                      71 D                         37                         32
               Hot start (after defrost)               -     •
                                                                           100 D                         38                         33
Comfort
               Year-round cooling
               applicable                              -     •             125 D                         40                         36
               Night quiet operation                   *2    *2            140 D                         40                         36

               Timer selector                          •     •
                                                                   •	TWO SELECTABLE TEMPERATURE-SENSORS
               Weekly schedule timer                   *3    *3       Both indoor unit and wired remote controller (option)
               Anti-bacterial air filter               *4    *4       contain temperature-sensors. Temperature sensing can be
Cleanliness                                                           set at the unit or, to further improve comfort level, closer
               Silver ion anti-bacterial              •     •        to the target area at the wired remote control. This feature
               drain pan
                                                                      must be set during commissioning by the technicians.
               Drain pump mechanism                    •     •
                                                                      emperature-sensor on indoor unit must be used when the air-conditioner
                                                                     T
               Pre charged for up to 30 m              *2    *2      is controlled from another room. Wireless remote controller does not have a
                                                                     temperature-sensor.
               Long-life filter                        *4    *4
Work &         Filter sign                                         • I NCREASED FREEDOM OF DESIGN, THANKS TO
                                                       •     •
Servicing                                                            VARIABLE CONTROL OVER EXTERNAL STATIC
               Low gas pressure detection              *2    *2      PRESSURE
               Emergency operation                                   Comfort airflow achieved in accordance with conditions
                                                       •     •
                                                                     such as duct length. Using a DC fan motor, the external
               Self-diagnosis function                 •     •       static pressure can be controlled within a range of 50 Pa                        27
               Auto-restart                            •     •       to 200 Pa.

                                                                                                                                                      Solutions 3600
               Auto-cooling/                                                           Freely control external static pressure
               heating change-over                    -     •

               Control by 2 remote                     •     •                   50 Pa                                    200 Pa
               controllers
Control
               Group control by 1 remote
features                                               •     •         Set to low static                          Set to high static pressure for
               controller
                                                                       pressure when                              advanced needs such as when
               External command control                                ducts are short.                           using dampers and long ducts.
                                                       •     •
               Central remote control                  •     •
               Interlock control                       •     •
               High-efficiency filter
Options                                                •     •

               Anti corrosion treatedheat
Others                                                 *2    *2
               exchangers

*1		 Applicable when wired remote controller is used
*2		 For outdoor units
*3		 Applicable when BRC1D61 or BRC1E62 is used
*4		 Option
•		SIMULTANEOUS AIR-CONDITIONING OF TWO ROOMS
                     AND VENTILATION GRILLE(VENTILATION OPENING)                                                     WORK & SERVICING
                    When air-conditioning two rooms simultaneously, the air
                     discharged into each room must be circulated back to the                    •		THIN, LIGHTWEIGHT INDOOR UNIT MAKES DELIVERY
                     air-conditioner. To achieve this, a ventilation duct should be                  AND INSTALLATION EASY
                     installed for each room or one of the indicated ventilation                    W
                                                                                                     ith a height of only 300 mm, installation is possible even in
                     grilles should be installed on the partitioning wall or under the              buildings with narrow ceiling spaces.
                     door between the rooms.

                                                                                                        300 mm

                                                                                                   Indoor          Height            Width           Depth           Machine
                                                                                                     unit          (mm)              (mm)            (mm)            weight
                          Partitioning wall                       Ventilates air through                                                                              (kg)
                                                                  the partitioning wall.
                                                                  (See below)                        50 D

                                                                                                     60 D                            1,000                               36
                                                                                                     71 D
                                                                                                                      300                              700
                         Door-installed                          Wall-installed                     100 D
                         ventilation grille                      ventilation grille
                                                                                                    125 D                            1,400                               46
                                                                                                    140 D

                                                                                                    D
                                                                                                     rain pump is equipped as standard accessory with 700mm lift.

                        Ventilation grille                       Ventilation grille

                                                                                                                                                          700 mm
28
                                          Under-door cutout
Solutions 3600

                                                                                                 •	REDUCED INSTALLATION TIME
                                                                                                  USE REMOTE CONTROLLER TO ADJUST AIRFLOW
                                                                                                 	When testing standard integrated ceiling units that employ
                                                                                                   duct work, much time is required to adjust airflow to the
                                          Under-door cutout                                        right level. Thanks to the ability provided by Daikin to
                                                                                                   automatically perform this troublesome adjustment using a
                  Note: The under-door cutout method should be used only when there is a small     remote controller, this step is now quick and easy.
                  volume of airflow.
                                                                                                   (Adjust by H tap).

                                              CLEANLINESS                                          1. Adjust to approximately ±10% of the rated H tap airflow.
                                                                                                   2. O
                                                                                                       nce actual operation has begun, adjustment of the rated airflow is not
                                                                                                      possible.

                 •		BACTERICIDAL TREATMENT FOR DRAIN PAN
                    Anti bacterial treatment, that includes silver ions, is used                • EASY MAINTENANCE
                     which assists in preventing the growth o f microorganisms that             	Maintenance is easy because the drain pan can be
                     cause smells and clogging.                                                    removed.
WALL
MOUNTED
TYPE
FAQ SERIES
COOLING ONLY & HEAT PUMP
FAQ SERIES
                 COOLING ONLY & HEAT PUMP

                 TOP CLASS IN THE INDUSTRY FOR COMPACTNESS AND SILENCE.
                 WALL MOUNTED AIR-CONDITIONERS DEMAND THIS KIND OF PERFORMANCE.

                            IMPROVED                 COMFORT EVEN ON     SOPHISTICATED       DRASTIC SIZE        LOW GAS                   EASIER TO
                             AIRFLOW                  THE FAR SIDE OF   EXTENSION DESIGN      REDUCTION       PRESSURE DETECTION         INSTALLAND SERVICE
                                                        THE ROOM

                          FAQ71~100          (COOLING ONLY)                     7.1 KW ~ 10.0 KW                                COOLING

                                                                                7.1 KW ~ 10.0 KW                                COOLING
                             FAQ71~100 (HEAT PUMP)
                                                                                8.0 KW ~ 11.2 KW                                HEATING
30

                                                                ACCESSORY REQUIRED FOR INDOOR UNIT
Solutions 3600

                 WIRED LCD REMOTE CONTROLLER

                                                                                                                                                      Standard

                 BRC1C61

                 Note: Remote controller cable not include.
                 Cables must be procured locally.

                 WIRELESS LCD REMOTE CONTROLLER

                                                                                                                                                        Option

                 A signal receiver must be added to the indoor unit.

                                                                            BRC7EB519 (C/O)                           Signal receiver unit
                                                                            BRC7EB518 (H/P)                           (Installed type)
FEATURES                                     Auto swing

                                                                                                        10º

                                                  Cooling      Heat
                     FAQ
                                                   Only        Pump
                Auto swing                              •         •                                                70º

                Draft prevention function               -         •        Auto swing from 10º to 70º

                Switchable fan speed                   •         •
                                                    (3 step)   (3 step)
                Auto airflow rate                       •         •
                                                        *3       *3
                                                                           5-level blow direction setting
Comfort         Program ‘Dry’                           •         •
                                                                                                        10º
                Two selectable                          •         •
                temperature-sensors (*1)
                Hot start (after defrost)               -         •
                Year-round cooling
                applicable                              -         •                                                70º
                                                                            ettable to five different levels
                                                                           S
                Night quiet operation (*2)              •         •        between 10º to 70º

                Setpoint auto reset (*3)                •         •
                Setpoint range set (*3)                 •         •        Auto blow direction control
Remote
                Weekly schedule timer (*4)              •         •                                     10º
Controller
                Off timer (programmed) (*3)             •         •
                                                                           L ast blow direction is saved in memory and
                On/off timer (*3)                       •         •         automatically set the next time the unit is
                                                                            turned ON.
Cleanliness     Mould-proof air filter                  •         •         (Factory setting is 10° for cooling and 70°
                                                                             for heating).
                Drain pump mechanism                    •         •
                                                        *5       *5
                Pre-charged for up to                   •         •       • SWITCHABLE FAN SPEED: HIGH/LOW
                30 m (*2)
Work &          Filter sign                             •         •         PROGRAMME ‘DRY’
Servicing       Low gas pressure                                          	Dehumidification is computer controlled to prevent abrupt
                                                        •         •
                detection (*2)                                              and uncomfortable changes in air temperature.                                   31
                Emergency operation                     •         •

                                                                                                                                                            Solutions 3600
                Self-diagnosis function                 •         •       • TWO SELECTABLE THERMO-SENSORS
                                                                          	Both indoor unit and wired remote controller (option)
                Auto-restart                            •         •
                                                                            contain thermo-sensors. Temperature detection can be set
                Auto-cooling/heating
                change-over                             -         •         at the unit or, to further improve comfort level, closer to the
                Control by 2 remote                                         target area at the wired remote control.
                                                        •         •
                controllers
                Group control by 1 remote                                   Note: T
                                                                                   hermo-sensor on indoor unit must be when the air-conditioner is
Control                                                 •         •               controlled from another room. (Wireless remote controller does not have
                controller
Features                                                                          a thermo-sensor).
                External command control                •         •
                Central remote control                  •         •       • COMFORT EVEN ON THE FAR SIDE OF THE ROOM
                Interlock control                       •         •       	To carry air to the far side of long rooms, extra-high air blow
                DIII-NET communication                                      adds 10% more fan speed to the ‘high’ setting.Air blow
                                                        •         •
                standard                                                    strength is selected from the remote controller.
                Anti corrosion treated heat             •         •
Others          exchangers (*2)

 *1		 Applicable when wired remote controller is used
 *2		 For the outdoor units
 *3		 Applicable when BRC1E62 is used
 *4		 Applicable when BRC1D61 is used
 *5		 Option

                              COMFORT                                     • LOW GAS PRESSURE DETECTION
                                                                          	Insufficient gas charging is normally hard to detect. During
•		IMPROVED AIR BLOW MODES ENSURE COMFORTABLE AIR                          post-installation trials and regular inspection procedures,
    DISTRIBUTION ACROSS THE ENTIRE ROOM.                                    the refrigerant level is monitored by computer to ensure
                                                                            proper gas pressure.
NON
INVERTER
SERIES
WALL
MOUNTED
TYPE
FTN SERIES
COOLING ONLY
FTN SERIES
                 COOLING ONLY

                 TOP CLASS IN THE INDUSTRY FOR COMPACTNESS AND SILENCE.WALL
                 MOUNTED AIR-CONDITIONERS DEMAND THIS KIND OF PERFORMANCE.

                                RAPID COOLING     COMFORT EVEN ON EFFECTIVE COOLING     DRASTIC SIZE    DIFFERENT FAN SPEEDIS      EASIER TO
                               IGHEST FAN SPEED
                              H                    THE FAR SIDE OF     WITH LOWER       REDUCTION            AVAILABLE FOR      INSTALL AND SERVICE
                            FOR IMMEDIATE COMFORT    THE ROOM           NOISE LEVEL                        COMFORT SELECTION

                                  FTN80JXV16     (COOLING ONLY)                                                         8.2 KW

                   ACCESSORY REQUIRED FOR INDOOR UNIT                                                                FEATURES
36
Solutions 3600

                                                                                                           FTN80JXV16                            Cooling Only
                 WIRELESS LCD REMOTE CONTROLLER
                                                                                                         Quiet Mode                                    •
                                                                        Standard                         Dry Mode                                      •
                                                                                       Comfort           Auto Mode                                     -
                                                                                                         Sleep Mode                                    •
                                                                                                         Turbo Mode                                    •
                                                                                                         Selectable Fan Speed                          •
                 BRC52A62                                                                                Automatic Vertical Swing                      •

                                                                                       Airflow           Manual Horizontal Airflow                     •
                                                                                                         4-Way Air Discharge                           -
                                                                                                         8-Way Air Discharge                           -
                                                                                       Work &            Self Diagnosis                                -
                                                                                       Servicing         Built-in-High HeadDrain Pump                 -
                                                                                       IAQ               Washable Saranet Filter                       •
                                                                                                         Anti CorrosionHydrophilic
                                                                                       Fin type                                                        •
                                                                                                         Gold Fin
                                                                                                         With Wireless Remote Controller               •
                                                                                       Control
                                                                                       features
                                                                                                         With Wired Remote Controller                  -
                                                                                                         Auto Random Restart                           •
                                                                                       Power             Power from Outdoor
                                                                                                                                                       •
                                                                                       supply

                                                                                       *1		 Option
                                                                                        1 TR (Tons of Refrigeration) = 3.517 kW
•		SLEEP MODE
                         COMFORT                                    	Once activated, Sleep Mode ensures a comfortable
                                                                        environment for restful sleep. Depending on the mode, set
•		STYLISH FLAT-PANEL                                                  temperature is	 increased/decreased gradually according to
	Ideal blend of style and function. Regular cleaning is easier        normal sleeping temperature patterns.
    by just wiping the flat front panel. This ensures the air-
                                                                     COOLING MODE
    conditioner looks brand new at all time.                                    Cooling

• TURBO MODE
	Once it is activated the air-conditioner will run on full power                                                         +1°C
  with the indoor fan running at maximum speed for 20

                                                                                Temperature
                                                                                                             +0.5°C
  minutes. This enables the set temperature to be achieved
                                                                                                   +0.5°C
  faster. If Turbo and Sleep are activated at the same time,
  the Sleep mode timer will be reset, it will resume after Turbo
  function is cleared.
                                                                                                                                 Hours
                                                                                                  0 1/2 1             2
                                                                                              Sleep set on

   T room
                                                                    • AUTO RANDOM RESTART WITH LAST-STATE-MEMORY
                                                                    	In the event of a sudden power failure during operation,
                                                                      unit restarts automatically in 64 different recovery timing
                                                                      patterns (within 180 seconds to 244 seconds) and the unit
     T set                                                            will operate based on the previous setting (operating mode,
         Start            20 min         30 min                       temperature setting and fan speed). This ensures that
                                                                      air-conditioners in the same building resume randomly
                                                                      instead of all units resuming at the same time, preventing
•		LOWER SOUND LEVEL                                                 power surge 	 after a blackout.
	With up to five selectable fan speeds, users are given more
   choices. By selecting Quiet mode,	the sound pressure level
                                                                                       Power                                      Power
   can be reduced to an unobtrusive 39 dBA.                                            Failure                                   Returns
                                                                                                                 Stop
                                                                                                                                                37

                                                                                                                                                Solutions 3600
                                                                             Operation                                                Restart

                             39    dBA

                                                                                                               E2PROM

                                                                                                Setting stored before power failure
• COMPACT AND EASY-TO-USE HANDSET
	1. Prominent 40 mm LCD display.
  2. Real time clock display.                                      HIGHER COOLING CAPACITY WALL MOUNTED UNIT
  3. Dedicated buttons for Quiet and Turbo functions.               WITH THE KEY FEATURES BELOW:
                                                                    •	Uniform Air Distribution
                                                                       Automated air swing ensures conditioned air is
                                                                       distributed evenly.
                                                                    • Quiet Operation
                                                                    	Random-pitched fan blade delivers high air flow at lower
                                                                       sound level.
                                                                    • Easy Maintenance
                                                                    	Air intake grille is easily detachable to be cleaned
                                                                       with water.
FLOOR
STANDING
TYPE
FVRN & FVQN SERIES
COOLING ONLY & HEAT PUMP
FVRN & FVQN SERIES
                 COOLING ONLY & HEAT PUMP

40               AN IDEAL WAY OF SAVING SPACE WITH STYLE AND FUNCTIONALLY, WITH
                 ITS EASE OF INSTALLATION. IT IS SUITED TO BE INSTALLED IN OFFICES,
                 COMMERCIAL SHOPS, RESTAURANTS AND SHOWROOMS.
Solutions 3600

                                      SELECTABLE          QUIET MODE     WITH WIRELESS          DRY MODE     WASHABLE
                                      FAN SPEED                           CONTROLLER*                        SARANET FILTER

                         FVRN71~140   (COOLING ONLY)                     8.2KW ~ 16.1 KW                             COOLING        1

                                                                         8.2KW ~ 16.1 KW                                 COOLING
                          FVQN71 ~ 140 (HEAT PUMP)
                                                                         8.1KW ~ 16.0 KW                                  HEATING
                 1   FVRN71 only

                                                         ACCESSORY REQUIRED FOR INDOOR UNIT

                 WIRELESS HANDSETS                                                     WIRED HANDSET

                                                                        Standard                                                        Option

                 BRC52A62                            BRC52A61                          BRC52A62
                                                                                       BRC51A62
                 (Cooling Only)                      (Heat Pump)                       (Cooling Only)
                                                                                       BRC51A61
                                                                                       (Heat Pump)
• TURBO MODE
                             FEATURES                                         	Once it is activated the air-conditioner will run on full power
                                                                                with the indoor fan running at maximum speed for 20 minutes.
                                                Cooling                Heat
               FVR/QN-AXV1                                                      This enables the set temperature to be achieved faster.
                                                 Only                  Pump
                Turbo Mode                          •                   •
                Quiet Mode                          •                   •
                                                                                  T room
 Comfort        Dry Mode                            •                   •
                Auto Mode                           -                   •
                Sleep Mode                          •                   •
                Selectable Fan Speed                •                   •           T set
 Airflow        Manual Vertical Swing               •                   •              Start                20 min        30 min
                Automatic Horizontal Airflow        •                   •

                Washable Saranet Filter             •                   •
 IAQ                                                                          • AUTO RANDOM RESTART WITH LAST-STATE-MEMORY
                Plasma (Optional)                   •                   •     	In the event of a sudden power failure during operation, the
                Anti CorrosionHydrophilic          •                    •      floor standing restarts automatically in 64 different recovery
 Fin type       Gold Fin                           *2                   *2      timing patterns (within 180 seconds to 244 seconds) and
                With Wireless Remote                                            it will operate based on the previous settings (operating
                                                    •                   •
                Controller                                                      mode, temperature setting and fan speed). This ensures
 Controller     With Wired Remote                                               that air-conditioners in the same building resume randomly
                                                   *1                   *1
                Controller
                                                                                instead of all units resuming at the same time, preventing
                Auto Random Restart                 •                   •
                                                                                power surge after a blackout.
 Power          Power from Outdoor
                                                    •                   •
 supply                                                                                        Power                              Power
                                                                                               Failure                           Returns                41
                Condensate Water Drain                                                                            Stop
 Option                                            *1                   *1
                Pump

                                                                                                                                                        Solutions 3600
                Large Buttons on Control
                Panel                               •                   •
                                                                                        Operation                                        Restart
                Key lock For Prevention of          •                   •
 Other          Setting Change
                Error Code Display on the                                                                      E2PROM
                Seven-Segment of the               •                   •
                Control Panel                                                                      Setting stored before power failure
 *1		 Option
 *2		 Outdoor units only
  1 TR (Tons of Refrigeration) = 3.517 kW                                                          WORK & SERVICING
                          COMFORT

•		FLOOR STANDING AIR FLOW                                                    L OCATION OF CONDENSATE W
                                                                                                         ATER DRAIN
	The floor standing is able to achieve air flow distance up to                PUMP
   25m*
                                                                               * Condensate water
                                                                               drain pump is
                                                                               optional, separately
                                                                               purchased and field
                                                          V_r (m/s)
                                                           Global
                                                                2.44
                                                                               installed.
                                                                1.22

                                                                0.00
                                                                                                                                     Condensate
                                                                                                                                     water drain pump

                                                                                                            Piping              Floor Standing Type
                                   25m

                                                 *Note: Based on size 140
CONTROLLERS
                   AFETY CACHE DURING REMOVAL OF FILTER
                  S
                  FOR PREVENTION OF ACCESS TO ELECTRICAL
                                                                                 The floor standing unit can be controlled by following methods:
                  AND MECHANICAL PARTS
                                                                                 a) Settings by pressing the control panel on the unit.
                                                                                 b)	Settings by using the wireless controller (wireless controller
                                                                                    comes as standard)
                                                                                 c) Settings by wired remote controller (optional)

                                                                                 •		FLOOR STANDING CONTROL PANEL
                                                                                 	A stylish black control panel with white LED light for crisp
                                                                                    clear display.

                                                                                                                                 On State

                  REMOVABLE WASHABLE SARANET FILTER
                                                                                      White display lights up
                                                                                      to indicate modes and
                                                                                      temperature setting when
                                                                                      switched on

                                                                                      KEY LOCK icon displayed
                                                                                      when activated

                                                                                      KEY LOCK Function:
                                                                                      Activation and deactivation
                                                                                      of keylock by pressing
                                                                                      ‘SWING’ and ‘TURBO’
                                                                                      together for five seconds
                                             AIR FLOW

                 • AUTO SWING
42               	Left and right auto swing to cool the corners o
                                                                  f the room.        The floor standing unit
                                                                                      is incorporated with IR
                                                                                      sensor for usage with
                                                                                      wireless controller(wireless
Solutions 3600

                                                                                      controller comes as
                                                                                      standard)

                                                                                      a) Prominent 40mm LCD display
                                                                                      b) ‘Glow in the dark’ ON/OFF
                                                                                          button
                                                                                      c) Real-time clock display
                                                                                      d) Dedicated button for Turbo
                  Auto horizontal swing                                                   function

                                                                                                               OTHERS

                                                                                 •		SPACE IN THE UNIT BELOW THE FAN ABLE TO
                                                                                     ACCOMMODATE DRAIN PUMP, DEPENDING
                                                                                     ON 	DRAIN PUMP SIZE (DRAIN PUMP IS OPTIONAL,
                                                                                     SEPARATELY PURCHASED AND FIELD INSTALLED)

                                                                                 •		LARGE BUTTONS ON CONTROL PANEL FOR EASE
                                                                                     OF USE

                  Manual setting of
                  vertical airflow louvers                                       •		ERROR CODE DISPLAY ON THE SEVEN-SEGMENT OF
                                                                                     THE CONTROL PANEL INDICATES BY BLINKING

                                                                                 •		KEY LOCK FOR PREVENTION OF SETTING CHANGE BY
                                                                                     UNAUTHORISED PERSONNEL
CEILING
CONCEALED
SERIES
FDMRN & FDB/MF SERIES
COOLING ONLY & HEAT PUMP
FDMRN/ FDMQN/
                 FDB/MF SERIES
                 COOLING ONLY & HEAT PUMP

                 ENHANCE THE DÉCOR OF YOUR ROOM WITH THE NEW
                 UNOBTRUSIVE CONCEALED SERIES

                                        SELECTABLE            QUIET MODE        WITH WIRELESS          DRY MODE              WASHABLE
                                        FAN SPEED                                CONTROLLER*                                 SARANET FILTER

                 FDBF12~FDMF54        (COOLING ONLY)                            3.5 KW ~ 15.8 KW                            COOLING

44               FDMRN25~140        (COOLING ONLY)                              2.4 KW ~ 16.1 KW                            COOLING

                                                                                2.8 KW ~ 16.1 KW                            COOLING
                 FDMQN25~140 (HEAT PUMP)
Solutions 3600

                                                                                2.8 KW ~ 16.1 KW                            HEATING

                                                            ACCESSORY REQUIRED FOR INDOOR UNIT

                 WIRED HANDSETS                                                               WIRELESS HANDSETS

                                                                              Standard                                                              Standard

                                                                                              BRC52A62
                 BRC52A62
                 BRC51A62                                                                     (Cooling Only)
                 (Cooling Only)
                 BRC51A61
                 (Heat Pump)
                                                                                                                    (Applicable for FDMR/QN only)
                                       (Applicable for FDMR/QN only)

                                                                                              BRC52A61
                                                                                              (Heat Pump)

                                                   LCD type
                                                                                                                    (Applicable for FDMR/QN only)
                                            (Aplicable for FDB/MF)

                 Note: For the availability of FDMF 30/36/42/48/54 please contact your nearest Daikin Channel partner
FEATURES                                     DOUBLE PROTECTION DRAINAGE SYSTEM

                                                                         he primary drain pan is designed with high thermal
                                                                        T
                                              Cooling            Heat
              FDMR(Q)N                                                  insulation material and moulded in gradient for better
                                               Only              Pump
                                                                        condensate water drainage. The extra secondary drain pan
               Auto Fan Speed                     •               •
                                                                        ‘built-in’ to the standard unit offers extra protection against
               Auto Mode                         -                •     possible water leaking problems.
Comfort        Auto Defrosting                   -                •
               Dry Function                       •               •
                                                                                FLEXIBILITY IN SYSTEM DESIGN
               Sleep Mode                         •               •
                                                                         he unit offers fan motor that can operate up to 4 speeds,
                                                                        T
IAQ            Washable Saranet Filter            •               •
                                                                        thus providing choices of external static pressure for
               Anti Corrosion                    •                •    designing ducting system.
Fin type       Hydrophilic
               Gold Fin                          *2               *2

               Wireless Controller               *1               *1
               Wired Controller                   •               •
Controller     24 Hour On/Off Timer               •               •                                              Primary Drain Pan
                                                                                                                 Polystyrene (Ps) With
               Delay Timer                        •               •                                              Height Impact
                                                                                                                 Polystyrene (Hips) Cover
               Self Diagnosis Display             •               •
               Auto Random Restart                •               •
Protection     Hydrophilic Gold Fin               •               •
               OutdoorHeat Exchanger                                                                            Secondary Drain Pan
                                                                                                                 With Insulation
Power          Power from Outdoor
                                                  •               •
supply
*1		 Option                                                                        SELF DIAGNOSIS FEATURES
*2		 Outdoor units only
 1 TR (Tons of Refrigeration) = 3.517 kW
                                                                         he microprocessor provides the possibility to detect and
                                                                        T
                                                                        to diagnose any faults that occurs in the system. Faults are        45
           EXCELLENT AIR DISTRIBUTION                                   displayed as error code in the wired controller. This will ease

                                                                                                                                            Solutions 3600
                                                                        the troubleshooting process.
 he conditioned air can be distributed evenly to every corner
T
of the room through ducting. This helps to create a pleasant
environment and maintain comfort. Furthermore, multiple
areas can be conditioned simultaneously by using just one
indoor unit.

           AUTO RANDOM RESTART WITH
              LAST-STATE-MEMORY

In the event of a sudden power failure during operation,
 unit restarts automatically in 64 different recovery timing
 patterns (within 180 seconds to 244 seconds) and the unit
 will operate based on the previous setting (operating mode,
 temperature setting and fan speed). This ensures that
 air-conditioners in the same building resume randomly
 instead of all units resuming at the same time, preventing
 power surge after a blackout.

             Power                              Power
             Failure                           Returns
                                 Stop

         Operation                                     Restart

                              E2PROM

                 Setting stored before power failure
OUTDOOR
UNITS
OUTDOOR UNITS
                 NEW COMPACT OUTDOOR UNIT - INVERTER

                                     RZR50LVVM                                                     RZR100LVVM                               RZR100LUY1
                                     RZR60LVVM                                                                                           RZR125LVVM/LUY1
                                     RZR71LVVM                                                                                           RZR140LVVM/LUY1

48
Solutions 3600

                                     RZQ71KCV4A                                                    RZQ100KCV4A                            RZQ100HAY4A
                                                                                                   RZQ125KCV4A                            RZQ125HAY4A
                                                                                                   RZQ140KCV4A                            RZQ140HAY4A

                                                                       EASY INSTALLATION AND MAINTENANCE

                 PRE CHARGED FOR UP TO 30 METRES                                                            • COMPACT AND LIGHTWEIGHT
                 If refrigerant piping length does not exceed 30 m, there is no                             	Reduced installation work thanks to light, compact
                 need for on-site gas charging.                                                               outdoor unit.
                                                                                                             Comparison of outdoor units
                 •		LONG PIPING LENGTH
                                                                                                                                   Conventional             New
                                                                                                                                   (RZR100KU)            (RZR100LV)
                 Allowed refrigerant piping length and level difference
                                                                                                                Height (mm)             1,170                990
                                                  RZR50-140LV               RZQ100-140KC
                                                    RZQ71KC                 RZQ100-140HA                         Weight (kg)             92                   78

                     Pre charged1                                      30 m

                                                     50 m                         75 m
                      Max length               (Equivalent length           (Equivalent length
                                                     70 m)                        90 m)
                      Max. level                                       30 m
                      difference
                   Note: 1Additional refrigerant charging is required if the refrigerant pipe is
                   longer than the length.
DURABILITY

                                                        Reduced by      s the bottom frame is subject to corrosion, corrosion-proof
                                                                       A
                                                        180 mm
                                                                       galvarium steel plate is adopted to enhance durability. Heat
                                                 990                   exchange fins are provided with anti-corrosion treatment.
                                                 mm
                                                        Reduced by
                                                        14 kg          CONSTRUCTIONNON-TREATED FIN PE FIN
                                                                                                                                                      Aluminium
     RZR100KU                   RZR100LV
                                                                                                                                                      Hydrophilic film
                                                                                                                                                      Aluminium
                                                                                                                                                      Corrosion resistant
•		4-DIRECTION PIPING OFFERS GREATER LAYOUT                                                                                                          acrylic resin
     FREEDOM
	 (Not applicable for RZR50-71)
    The outer panel for the piping connection part of the front,                                           DEMAND CONTROL FUNCTION
     right side and back can be removed and is easier for
     post-installation piping work.                                     he maximum capacity is maintained within a set level of
                                                                       T
                                                                       power consumption, which makes it possible to keep comfort
                                                                       and effective demand control.

                                                                                                                Limitation

                                                                                                  consumption
                                                                                                     Power

                                                                                                                  8.00             12.00         16.00                20.00
                                           Separation                                                           * Required for KRP58M51 (Option)                      Time
                                           available

• FACILITATES PUMP-DOWN                                                NIGHT TIME QUIET OPERATION FUNCTION                                                                              49
	 (Refrigerant recovery function)
   A pump-down switch is provided to make it easier to                 he Automatic Night Quiet Mode will initiate 8 hours after
                                                                       T

                                                                                                                                                                                        Solutions 3600
    collect refrigerant if the unit is to be moved or layout           the peak temperature is reached in the daytime, and normal
    modified. Pump-down function is available for pre-charged          operation will resume 10 hours after that. (By remote
    refrigerant amount.                                                controller at site)
                                                                     *Reducing noise will reduce capacity slightly.

• LOW GAS PRESSURE DETECTION FUNCTION                                                                                                                 Sound level1 (dB(A))
	 Effective gas monitoring reduces the labour required for             Cooling                                             Heat pump
                                                                          only                                                                        Rated
                                                                                                                                                                      Night quiet
    operation, maintenance and repairs.                                                                                                                                 mode
                                                                       RZR50/60LV                                                   -                   48                 44
                     ENERGY SAVING                                       RZR71LV                                               RZQ71KC                  48                 44

                                                                         RZR100LV                                          RZQ100KC/100HA               49                 45
 (RZR50-71 only)
                                                                         RZR125LV                                          RZQ125KC/125HA               50                 45
  hrough use of a V-cut propeller fan that imitates the
 T
 efficiency of the swan, a migratory bird, airflow becomes               RZR140LV                                          RZQ140KC/140HA               50                 46

 smooth and loss is reduced.                                         Note: 1 Anechoic chamber conversion value, measured according to JIS parameters
                                                                     and criteria. During operation these values are somewhat higher owing to ambient
                                                                     conditions. 2 Value when cooling. Value will differ when heating.

                                                                                                                       Peak in outdoor temperature
                                                                              Sound3 (dB(A)) Load (%) Capacity (%)

                                                                                                                     100

                                                                                                                                        8 hours    10 hours
                                                                                                                     50

     Φ550 V-cut propeller fan          Imitating theperformance                                                      0
                                                                                                                     49
                                       of the swan
                                                                                                                                                                      Note: 3In case
                                                                              Operation

                                                                                                                                                  Quiet mode
                                                                                                                     45                                               of RZR100

                                                                                                                      8.00 12.00 16.00 20.00 0.00       4.00   8.00
• SMOOTH AIR INLET BELL MOUTH AND AERO
                     TECHNOLOGY FORENERGY EFFICIENCY                                                                       SPIRAL FAN
                                                                                                                         	(not applicable for RZR50-71)
                  The high efficiency compressor to achieve a high COP.                                                 	 T
                                                                                                                             hese two features work to reduce noise. Guides are added
                                                                                                                            to the bell mouth intake to reduce turbulence in the airflow
                 • C  OMPRESSOR EQUIPPED WITH RELUCTANCE DC MOTOR                                                          generated by fan suction. The Aero Spiral Fan features
                 	 Daikin DC Inverter models are equipped with the                                                        blades with bent edges, further reducing turbulence.
                     Reluctance DC motor for compressor. The Reluctance DC
                     motor uses two different types of torque, neodymium                                                                                                 With the bent              Without the bent
                                                                                                                                                                          blade edge                   blade edge
                     magnet*1 and reluctance torque*2. This motor can save
                    energy because it generates more power with a smaller
                    electric power than an AC or conventional DC motor.

                                                       Reluctance DC Motor
                                             90                                                                                                                           Escaping eddies are sucked in by
                                                                                                                                                                           the bent blade edges, reducing
                                                                                                                                                                                 overall turbulence.
                      Motor efficiency (%)

                                             80
                                                                             Conventional
                                                                             DC motor                                    • DC FAN MOTOR
                                             70         More than 20%
                                                                                                                         	 E
                                                                                                                             fficiency improved in all areas compared to conventional
                                                              AC motor
                                                                                                                            AC motors, especially at low speeds.
                                             60
                                                                                                      Small load
                                                                                                      Low capacity
                                             50                                                       Large load           DC FAN MOTOR STRUCTURE
                                                  03   06       09       0         120
                                                       Rotational speed (rps)                         High capacity

                    Reluctance
                    DC motor
                                                                                Note: Data is based on studies
                                                                                conducted under controlled
                                                                                conditions at a Daikin
                                                                                laboratory.
50                                                                              *1. A neodymium magnet is                                                      DC MOTOR EFFICIENCY
                                                                                approximately 10 times stronger                                       (comparison with a conventional AC motor)
                                                                                than a standard ferrite magnet.
                                                                                                                                                    100
Solutions 3600

                                                                                *2. The torque created by the
                                                                                change in power between the
                                                                                iron and magnet parts.
                                                                                                                                                    80
                                                                                                                                                                 DC motor
                                                                                                                                   Efficiency (%)

                                                                                                                                                    60                            Approx.
                 • SMOOTH SINE WAVE DC INVERTER                                                                                                                                     20%
                                                                                                                                                                                  increase
                 	 Use of an optimised sine wave smoothes motor rotation,                                                                         40 Approx.
                     further improving operating efficiency.                                                                                             40%
                                                                                                                                                    20 increase
                                                               Sine wave DC inverter                                                                                                         AC motor
                                                                                                                                                     0
                                                                                                                                                     200 300 400 500 600 700 800 900 1000
                                                                                                                                                                       Motor speed (rpm)
                                                                                                                                                      Note: Data is based on studies conducted under controlled
                                                                                                                                                      conditions at a Daikin laboratory.
                   RZR50/60/71/100LVVM                                                          Swing bushing
                                                                                                Refrigerant gas
                   RZQ50/60KB, RZQ71KC
                                                                                                                                                                 33

                   >> Swing compressor
                   Energy savings are realised,                                                                                                             22
                   eliminating the friction and                                  Piston by incorporated
                   the leakage of refrigerant gas.                               blade and roller.

                   RZR125/140LVVM, RZR100/125/140LUY1                                                        Suction                                                         11
                   RZQ100/125/140KC, RZQ100/125/140HA
                                                                                          Discharge

                                                                                                        Scroll section
                   >> The structural scroll
                   Sucked gas is compressed in the scrolling                                               Motor
                   part before the heated motor, so that the                                              section
                   machine compresses the non-expanded gas,
                   resulting in high efficiency compression.
• S
   UPER AERO GRILLE                                                                   • WHAT IS COP
	 R
    efined ventilation mechanism enables further reduction in                            (Coefficient of Performance)
      required fan power.                                                                  OP is equal to capacity (kW) divided by power
                                                                                          C
                                                                                          consumption (kW), and the larger the COP value, the
• COMFORTABLE
                                                                                          higher the energy efficiency, enabling cooling and heating
       ENHANCED COMFORT WITH INVERTER
                                                                                          with less electricity and increasing the energy saving
      Inverter performs variable control of frequency, which
                                                                                          performance.
      determines air-conditioner’s power performance. At
      startup, full power is used to achieve the set temperature
      quickly. Then, the capacity is adjusted according to the
      outdoor temperature changes and subtle indoor load
      changes to achieve fine capacity control resulting in a more
      stable room temperature.
	 N
    on-inverter type air-conditioners must be switched on and off repeatedly,
      causing large fluctuations of the room temperature.

  COOLING OPERATION                                                                            RZR100LVVM

 Temp
 Set temp

                                                                                                                              Sound level1 (dB(A))

                                                                                                                           Rated2               Night quiet mode

                                                                                       RZR50/60LVVM                          48                          44
            Close a room                  Small temp.                       Time
            in less time                  difference                                   RZR71LVVM                             48                          44
                                                   Inverter power control
                                                                                       RZR100LVVM/LUY1                       49                          45
                                                   Non-inverter type air-conditioner

                                                                                       RZR125LVVM/LUY1                       50                          45

                                                                                       RZR140LVVM/LUY1                       50                          46               51
                                                                                       Note: 1 Anechoic chamber conversion value, measured according to JIS parameters

                                                                                                                                                                          Solutions 3600
                                                                                       and criteria. During operation these values are somewhat higher owing to ambient
   oft starter is unnecessary, making electrical installation
  S                                                                                    conditions. 2 Value when cooling. Value will differ when heating.
  work much simpler.
                              NON-INVERTER
                  Current

                                                            Starting
                                     Running                current
                                     current

                                                        Time
                                 INVERTER
                  Current

                                                            Running
                                                            current

                                                        Time

   t startup, inverter raises frequency smoothly, eliminating
  A
  the starting current spike.
OUTDOOR UNITS
                 NON INVERTER

                                     R(Y)N25/35CG                                                       R(Y)N50/60CG

                                         RR(Q)71C                                                  RR(Q)90/100/125/140D

                                  COMPACT & QUIET                                                              DURABILITY
52
                 • EQUIPPED WITH SCROLL COMPRESSOR FOR QUIETER                • I NSTALLATION AND MAINTENANCE
Solutions 3600

                    OPERATION                                                    (Smoother and easier)
                    Smooth running, minimal vibration, low operating noise.
                   (Applicable for RR(Q)90/100/125/140D)                       • P  RE-CHARGED FOR UP TO 7.5 METRES
                                                                               	If refrigerant piping length does not exceed
                                                                       dB(A)      7.5 m, there is no need for on-site gas charging.
                      Cooling Only/Heat Pump            Sound Level
                            Outdoor unit
                                                                               Allowed refrigerant pipe length and height difference
                            R(Y)N25CG                        46
                                                                                                         Pre-charged            Max. length               Max.
                            R(Y)N35CG                        49                                               *1                                        Elevation

                                                                                   R(Y)N25CG                  7.5 m               15 (12) m              10 (5) m
                            R(Y)N50CG                        52
                                                                                   R(Y)N35CG                  7.5 m               15 (12) m              10 (5) m
                            R(Y)N60CG                        52
                                                                                   R(Y)N50CG                  7.5 m               15 (12) m               8 (8) m
                            RR(Q)71CG                        58
                                                                                   R(Y)N60CG                  7.5 m               15 (12) m               8 (8) m
                            RR(Q)90DG                        58
                                                                                   RR(Q)71CG                  7.5 m               15 (15) m               8 (8) m
                            RR(Q)100DG                       58
                                                                                  RR(Q)90DG                   7.5 m               45 (45) m             25 (25) m
                            RR(Q)125DG                       60
                                                                                 RR(Q)100DG                   7.5 m               45 (45) m             25 (25) m
                            RR(Q)140DG                       65
                                                                                 RR(Q)125DG                   7.5 m               45 (45) m             25 (25) m

                                                                                 RR(Q)140DG                   7.5 m               35 (35) m             15 (15) m

                                                                                Note: *1Additional refrigerant charging is required if the refrigerant pipe is longer
                                                                                than the indicated length. For more information, see the engineering data.
CONTROLLERS
EASY-TO-READ LCD REMOTE CONTROLLER ALLOWS
VARIOUS SYSTEM CONTROL CONFIGURATIONS
AND CAN CONTROL MULTIPLE INDOOR UNITS.
(REMOTE CONTROLLER OPTIONS ARE SHOWN ON
THE PAGE INTRODUCING EACH INDOOR UNIT
MODEL).

                                                                                                 •		SIMPLE OPERATION
         NAVIGATION REMOTE CONTROLLER                                                                Large buttons and arrow keys
                            Wired Remote Controller BRC1E62
                                                                                                 	Large buttons and arrows keys for easy operation. Basic
•		CLEAR DISPLAY, SIMPLE OPERATION, ‘NAVIGATION                                                     settings such as fan speed and temperature can be
    REMOTE CONTROLLER’                                                                               intuitively operated. For other settings just select the
	This simple, modern design remote controller with fresh                                          function from the menu list.
   white colour matches your interior design. Operation is
   much easier and smoother.Just follow the indications on
   the navigation remote controller.

                                                                                                                                                                    53

                                                                                                                                                                    Solutions 3600
                                                                                                                                      GUIDE ON DISPLAY
                                                                                                                                      The display gives an
•		AUTO OPERATION MODE
                                                                                                                                      explanation of each setting
                                                                                                                                      for easy operation.

      2 SET POINTS
     Display set temperatures at both                                                            •		OTHER FEATURES
     cooling and heating operations.
                                                                                                     Multilingual display
                                                                                                 	Display is available in 11 languages (English, German,
                                                                                                     French, Spanish, Italian, Portuguese, Greek, Dutch,
                                                         Cool 26°C                                   Russian, Turkish and Polish).
                                                         Heat 20°C

      BACKLIGHT DISPLAY                        WEEKLY SCHEDULE TIMER
     Equipped backlight helps                 The schedule timer for each day
     operating in dark rooms.                  of the week can be set up easily
                                               (3 patterns).

For feature list refer feature table of individual series. Not all features are available with
all models.
You can also read
Next slide ... Cancel
