THE MONITOR MANUFACTORY Product catalog 2020 Made in Germany since 1993
2 www.distec.de
POS-Line
Brilan 4K
Fire load optimized
monitors
High Bright monitors
VideoWall monitors
Xtra-Line
Customized
monitors
Table of contents
The company................................................................................................... 04
Manufactory products.................................................................................... 06
Manufactory portfolio..................................................................................... 12
POS-Line - monitors from 15“ up to 64.5“..................................................... 16
Brilan 4K – monitors from 42.5“ up to 74.5“................................................. 42
Fire load optimized monitors from 24“ up to 64.5“....................................... 50
High Bright monitors from 31.5“ up to 54.6“................................................. 64
VideoWall monitors 46“............................................................................... ...70
Xtra-Line monitors from 27“ up to 46“........................................................... 74
Customized monitors..................................................................................... 80
Contacts.......................................................................................................... 82
Brochure concept and design: Distec GmbH, Marketing, February 2020
Information, pictures, illustrations and content may not, in whole or in part, be copied, photocopied or reproduced from this brochure without the prior written consent of Distec GmbH.
All trademarks and product names in this brochure are the property of their respective owners.
All figures are typical values. The real values may vary. The optical characteristics are determined after the panel has been „ON“ for approximately 30 minutes at an ambient tempe-
rature of 25° C (77° F). Life time of the backlight is defined as the time to take until the brightness reduces to 50% of its original value.
Copyright Distec GmbH. Information in this document is subject to change without prior notice. Liability for errors, misprints, color deviations and omissions excluded.
www.distec.de 3
The
Company
Distec headquarters in Germering near Munich
Registered office Hörselberg-Hainich, Germany
4 www.distec.de
Distec GmbH is a subsidiary of the listed German FORTEC Elektronik AG which is a system supplier for device manufacturers of industrial high-tech products. The areas of expertise range from pure distribution, through development and production, to complete solu- tions. Distec GmbH was founded in Germering near Munich in 1993 and is one of the pioneers of flat panel technolo- gy with proprietary hardware controllers. From the very beginning, the focus has been on the industrial markets with their specific requirements for reliability in operation, longevity and long-term availability of the individual components. Today, Distec GmbH develops and produces, among other things, long-lasting monitor solutions, which are characterized by robust TFT displays. Even difficult environmental conditions and harsh operating conditions pose no problem for our monitors. Reliability, flexibility and resilience - that‘s what Distec monitors stand for. Our standard products are often the basis for the development of customized solutions. Customer focus: At our innovation and production sites in Hörselberg-Hainich near Eisenach and Germering near Munich we develop, design, produce and certify our products. Experience and state-of-the-art system technology: The engineers in our development centers draw on many years of experience with LCD panels and simultaneously focus on current and future technologies. System solutions from a single source: We are specialized in developing, manufacturing and delivering custom solutions in all areas such as mechanics, touch integration, electronic assemblies and software. This includes a variety of controls, from the simple video card to PCs of different power levels, monitors for all installation options including any required IP protection and integration into existing infrastructures. Quality and service: As an ISO9001: 2015 certified company, we develop, design and manufacture our monitor solutions according to industrial quality criteria. High-quality components, longevity - even under harsh opera- ting conditions - as well as long-term availability are standard. www.distec.de 5
Manufactory
products
6 www.distec.de
MONITORS FROM DISTEC
Made in Germany
Development, engineering and design, manufacturing and quality assuran-
ce – all processes take place in Germany and derive from one source –
Made in Germany.
Our monitors stand for reliabilty, quality and flexibility. We pursue these
characteristics as our defined goals from the early stage of development by selecting durable and rugged com-
ponents over supplier determination, interface configuration until the stage of design and implemention and
extensive quality control. Our product portfolio comprises the „POS-Line“ as our standard product line which
offers a wide ranges of options in terms of control, protection, touch and design, our High Bright series is adjus-
ted to challenging lighting conditions and fireload optimized monitors from our BLO-Line. The new BLO-Line
monitors of Distec match the strict fire safety regulations of DE EN 13501-1 in the highest class A1, s1-d0 and
can be optionally equipped with an extinguishing device.
Beyond that we passionately develop customised solutions in cooperation with our customers for any area of
application.
Distec manufactory
We oversee and supervise every step of development of our monitors. We realize products and solutions
according to your needs with utmost care. Each monitor is manufactured in our house – that´s why our name
stands for high quality.
Diligence and greatest flexibility at the same time, creativity and open-mindedness for new ideas – these tradi-
tions and virtues determine the outcome of our efforts in our medium-sized enterprise.
DEVELOPMENT DESIGN
MANUFACTURING
QUALITY ASSURANCE
www.distec.de 7
DISTEC CONTROLLER AND PCs
VideoPoster IV (VP IV)
Interfaces: 1 x LAN, 2 x USB, 1 x HDMI in, 1 x Line out,
1 x microSD Card Slot
VideoPoster is an industrial FHD Media Player based on
a Raspberry Pi® CM3/ CM3+ and a ArtistaMedia-III Base
Board.
It features functions like auto-play and auto-loop of a playlist after power on.
Full HD capable network player displays MPEG media files, such as videos and still images. The
content may be updated via USB connection. VideoPoster can be configured with any common
web browser by using our software Artista Device Finder for Windows® or by typing the IP-adress
of your device into the address bar of the web browser manually.
Our free ACC Control-Center-Software for Windows® allows for quick updating of playlists run by
all mediaplayers within a network via Ethernet or USB flash drive (push update) so that VideoPoster
contents can be created and allocated in an easy and convenient way.
IoT
Interfaces: 1 x LAN, 2 x USB, 1 x HDMI in, 1 x Line out,
1 x microSD Card Slot
Storage device: internal memory (starting from 4 GB),
microSD (up to 256 GB)
Artista IoT is a combination of Distec ArtistaMEDIA-III
Base Bord and an industrial ARM computing platform, based on Raspberry Pi® Compute Module
3 or 3+ (CM3 or CM3+). The controller board may be optionally equipped with different operating
systems, for instance with a pre-installed Raspbian.
PRISMA MEDIA ECO (VIDEO PME)
Interfaces: 1 x HDMI (DVI via HDMI), 1 x DisplayPort, 1 x
VGA, 1 x Audio Line out, 1 x USB Remote
The PrismaMEDIA-Eco is an economic, efficient, space
saving and powerful controller card. Its features include
a zoom function, OSD menu and an ambient light sen-
sor allows for automatic brightness adjustment.
8 www.distec.de
PRISMA III A (VIDEO PIIIA)
Interfaces: 1 x VGA, 1 x DVI (HDMI via DVI), 1 x S-Video,
1 x Composite Video, 1 x USB Remote
Prisma-III A controller card ensures high performance
for any monitor application.
Besides the zoom function, OSD menu and ambi-
ent light sensor for automatic brightness adjustment, its special features include an integrated
operation hours counter for power- and display-on, Powerful Picture-in-picture (PIP) and Pic-
ture-and-Picture (PAP) functionalities.
Multimedia Controller (VIDEO 4K)
Interfaces: 2 x HDMI 2.0 IN, 1 x HDMI 2.0 out (4K Daisy
Chain), 1 xDisplayPort 1.2 IN, 1 x RS232 IN, 1 x RS232
out, 1 x USB-A (upload)
The multimedia controller is a powerful and versatile
industrial UHD controller board, allowing for a display resolution up to 3840p x 2160p @ 60Hz.
It also features automatic brightness adjustment and power supply for a wide range of display
panels.
IQ Atom
Interfaces: 2 x LAN, 1 x USB 3.0, 1 x USB 2.0,
1 x HDMI, 1 x VGA, 1 x RS232/422/485, 1 x RS232 (opti-
onal)
Our monitors can be equipped with integrated PCs. The
IQ Atom is driven by an Intel® Atom® E3845 (1,9GHz)
microprocessor, contains an integrated graphics card,
a 4GB DDR3L main memory and a 128GB SSD with mSATA interface. IQ Atom is the economic
solution for simple applications.
IQ Core-i
Interfaces: 2 x DisplayPort, 2x LAN, 4x USB 3.0, 1 x Audio,
1 x MIC in
IQ Core-i5 monitors are connected to a different powerful
integrated PC, driven by an Intel® Core™-i5-7300 (2,6GHz)
microprocessor, contain an integrated graphics card, an 8GB DDR4 main memory and a 120GB
M.2 Sata SSD. IQ Core-i allows to run ambitious applications.
www.distec.de 9
DISTEC EXTENDED MONITOR OPTIONS
Touch screen
Resistive touch screen, POS-Line 15“, 17“, 19“
PCAP touch screen, POS-Line 15.6“, 17.3“, 21.5“ and 24“
Resistive touch screen panels may be used with bare or gloved fingers or other input objects, such
as a stylus. They comprise two electrically resistive layers that sense each other and become
connected when pressure is applied. With the resulting change of voltage, the position of pressure
can be detected by the touchscreen´s controller. Resistive touch screen panels can sense only a
limited number of touch points at once. In contrast, PCAP touch sensors respond to the registra-
tion of change in capacitance which is caused by touching the surface of the screen. The touch
can be sensed with fingers or any other conductive item as suitable method of input. Compared to
resistive touch screens, PCAP touch sensors are able to register up to 80 touch points at once.
TrueFlat-Touch screen
PCAP touch screen with tempered safety glass (TSG), thickness:
3-5mm. depending on the size, with black passepartout, printed
glass, RAL 9005, for POS-Line sizes from 15” up to 54.6” and
Brilan 4k
PCAP touch (description above) with TrueFlat glass: a combination of PCAP touch sensor and
tempered glass. In addition, it also gives the monitor a appealing high quality optical design.
Tempered safety glass
Tempered safety glass (TSG), thickness: 3-5mm, depending on
the size, for all POS-Line monitors
To ensure display protection we use tempered glass which is
flush mounted with the display panel at the front of the monitor. Tempered glass has undergone a
special thermal treatment which makes it more resistant to shock and surface damage.
TrueFlat glass
Tempered safety glass (TSG), thickness: 3-5mm, depending on
the size,with black passepartout, printed glass, RAL 9005, for
POS-Line and Brilan 4k
TrueFlat glass is tempered glass with a black passepartout
installed at the display front. It protects the panel and contributes
to an enhanced appearance of the monitor.
10 www.distec.deTrueFlat bezel with touch screen
PCAP touch screen with TSG, thickness: 3-5mm. depending on
the size, with black passepartout, printed glass, RAL 9005, coa-
ted steel bezel in RAL 9006, for POS-Line size from 31.5“, XT-
RA-Line 27
Touch screen and bezel are both front mounted in one unit. The
additional frame is an upgrade for the appearance of the monitor
and also protects the display at the side.
TrueFlat bezel with glass
TSG, thickness: 3-5mm, depending on the size, with black passe-
partout, printed glass, RAL 9005, coated steel bezel in RAL 9006,
for POS-Line from size 31.5“, XTRA-Line 27
Tempered glass and bezel are both front mounted in one unit.
The additional frame is an upgrade for the appearance of the
monitor and also protects the display at the side.
Front bezel
Steel, powder coated in RAL 9005, available for POS-Line, Brilan
4K and our High Bright monitor line
The front bezel functions as edge protection and is also a front
design feature at the same time.
Aluminium bezel
Aluminium, brushed, for POS-Line sizes from 31.5“ up to 54.6“
The front bezel functions as edge protection and is also a front
design feature at the same time.
Front plate
Steel, powder coated in RAL 9005, for POS-Line 15“, 17“ and 19“
Aluminium, powder coated in RAL 9005, for POS-Line 15.6“,
17.3“, 21.5“ and 24“
The front plate is especially suitable for flush mounted monitor
installation into wall spaces and niches.
www.distec.de 11Manufactory Portfolio 12 www.distec.de
MONITORS UP TO 24“
Display size 15.0 17.0 19.0 15.6 17.3 21.5 24.0
Resolution 1024 x 768 1280 x 1024 1920 x 1080 FHD
Function available
Touch Page 18 Pae 22 Page 26 Page 20 Page 24 Page 28 Page 30
PME Page 18 Page 22 Page 26 Page 20 Page 24 Page 28 Page 30
IQ ATOM Page 18 Page 22 Page26 Page 20 Page 24 Page 28 Page 30
VideoPoster Page 18 Page 22 Page 26 Page 20 Page 24 Page 28 Page 30
IoT Page 18 Page 22 Page 26 Page 20 Page 24 Page 28 Page 30
BLO-Line PME Page 58
BLO-Line IQ Page 58
BLO-Line IoT Page 58
MONITORS FROM 27“
Display Size 27.0 31.5 42.0 42.5 46.0 54.6 64.5 54.6 74.5
Resolution 1920 x 1080 FHD 3840 x 1920 x 1080 FHD 3840 x 2160 4K
2160 4K
Function available
Touch Page 74 Page 32 Page 34 Page 44 Page 36 Page 38 Page 46
PME Page 32 Page 34 Page 36 Page 38 Page 40
PrismaIIIA Page 74 Page 32 Page 34 Page 36 Page 38 Page 40
MM card 4K Page 44 Page 46 Page 48
IQ ATOM Page 32 Page 34 Page 36 Page 38 Page 40
IQ Core-i Page 32 Page 34 Page 36 Page 38 Page 40 Page 46 Page 48
VideoPoster Page 32 Page 34 Page 36 Page 38 Page 40
IoT Page 32 Page 34 Page 36 Page 38 Page 40
BLO PME Page 54 Page 55 Page 56 Page 57
BLO IQ Page 54 Page 55 Page 56 Page 57
BLO-LIne PME Page 59 Page 60 Page 61 Page 62 Page 63
BLO-Line IQ Page 59 Page 60 Page 61 Page 62 Page 63
BLO-Line IoT Page 59 Page 60 Page 61 Page 62 Page 63
www.distec.de 13TOUCH SCREEN MONITORS UP TO 24“
Display Size 15.0 17.0 19.0 15.6 17.3 21.5 24.0
Resolution 1024 x 768 1280 x 1024 1920 x 1080 FHD
Function available
Touch Page 18 Page 22 Page 26 Page 20 Page 24 Page 28 Page 30
PME Page 18 Page 22 Page 26 Page 20 Page 24 Page 28 Page 30
IQ ATOM Page 18 Page 22 Page 26 Page 20 Page 24 Page 28 Page 30
IoT Page 18 Page 22 Page 26 Page 20 Page 24 Page 28 Page 30
TOUCH SCREEN MONITORS FROM 27“
Display Size 27.0 31.5 42.0 42.5 46.0 54.6 54.6
Resolution 1920 x 1080 FHD 3840 x 1920 x 1080 FHD 3840 x 2160
2160 4K 4K
Function available
Touch Page 74 Page 32 Page 34 Page 44 Page 36 Page 38 Page 46
PME Page 32 Page 34 Page 36 Page 38
PrismaIIIA Page 74 Page 32 Page 34 Page 36 Page 38
MM card 4K Page 44 Page 46
IQ ATOM Page 32 Page 34 Page 36 Page 38
IQ Core-i Page 32 Page 34 Page 36 Page 38
IoT Page 32 Page 34 Page 36 Page 38
14 www.distec.deMONITORS HIGH BRIGHT
Display Size 31.5 54.6
Resolution 1920 x 1080 FHD
Function available
PrismaIIIA Page 66 Page 68
IQ ATOM Page 66 Page 68
IQ Core-i Page 66 Page 68
VideoPoster Page 66 Page 68
MONITORS VIDEO WALL
Display Size 46
Resolution 1920 x 1080 FHD
Function available
MM card 4K Page 72
SPECIAL DESIGNS
Display Size 27 37 46
Resolution 1920 x 1080 FHD 1920 x 540 FHD 1920 x 1080 FHD
Function available
PME Page 76 Page 77
IoT Page 78
www.distec.de 15POS-Line – monitors from 15“ up to 64.5“ Flexible and versatile by optional bezels and touch technologies – for integration, desktop, wall mounting 16 www.distec.de
POS-Line 64.5“ monitor with front bezel and glass applied as info terminal at the airport POS-Line 24“ IoT for organization of processes This product range is the result of more than 15 years of experience in the manufacturing of industrial display ap- plications. The monitors in the POS-Line series have been produced to industrial quality standards and are par- ticularly suitable for process monitoring and machine control, interactive kiosk applications and digital signage. Versatility in terms of installation and usage in various fields of application and settings is the defined principle of design. As a consequence, this series can be installed both as open-frame monitors for integration or, equipped with a frame, as desktop or wall mounted screens. Furthermore, we provide additional frame options including TrueFlat glass, or a front plate suitable for easy front-side integration. The POS-Line monitors can be driven by various video signals like HDMI, DVI, DisplayPort, VGA or a mediaplayer as well from the input of PCs, which are completely integrated into the monitors. Depending on their application our monitors can be equipped with touch systems, e.g. resistive or projected capacitive touch (PCAP). Similar to our smaller display units, our larger models with display sizes starting from 31.5” are extensively confi- gurable, and there are a variety of controller card types to choose from. Monitors with integrated Atom or Core-i PC are equipped with a detachable PC box. Hence, the PC is exchangeable for service purposes and the monitor does not have to be removed from the wall. POS-Line monitor open-frame in industrial use POS-Line monitor 42“ at train station POS-Line monitor 65“ at airport www.distec.de 17
PRODUCTS POS-Line 38.1 cm/ 15.0“
RESOLUTION 1024 x 768 px (XGA)
LUMINANCE 400 cd/m²
VIEWING ANGLE 160°h/ 140° v
CONTRAST 700:1
PANEL
BACKLIGHT LED
RESPONSE TIME 16 ms
COLOURS 16.7 millions
Order number Function Features and interfaces
1 x VGA, 1 x HDMI, 1 x DP, 1 x Audio line out,
DS-91-766 Prisma Media Eco
1 x USB remote, 1 x OSD button (4)
PC: Intel® Atom® E3845 (1.9 GHz), RAM: 4 GB
DDR3L, SSD 120 GB mSATA
DS-91-765 IQ Atom
Interfaces: 2 x Gigabit LAN, 1 x USB 3.0,
1 x USB 2.0, 1 x HDMI, 1 x VGA,
1 x RS232/422/485, 1 x RS232 (optional)
1 x LAN, 2 x USB, 1 x HDMI in, 1 x Line out,
1 x microSD Card slot
DS-91-767 VideoPoster
FUNCTIONS
Media player: MPEG-4 (H.264), FVL, AVI, jpeg,
tiff, png, pdf, bmp
XML play list, content update via content server
(HTTP protocol), FTP server or USB connection
Raspberry® PI CM3 ind. ARM-PC with Raspbian
OS; 1 x LAN, 1 x Audio line out, 1 x micro
DS-91-816 Raspberry® IoT SD-slot, 2x USB2.0 , 1x HDMI-in
Storage medium: internal storage (4GB),
microSD card (up to 256GB)
18 www.distec.deORDER NUMBER DS-91-345
TOUCH
TOUCH TECHNOLOGY 5-wire resistive, 1 touch point
CAN BE USED WITH PME, IQ Atom, IoT
CAN BE COMBINED WITH Front bezel, front plate
MATERIAL Powder coated aluminium, black RAL 9005
HOUSING
VESA MIS-D 200 x 100 (M4)
WEIGHT 2.2 - 2.3 kg without options
DIMENSIONS 333.4 x 265.4 x 51.0 mm without options
SPECIAL FEATURES no
Order number Description Can be combined with
DS-91-323 Front bezel Touch screen or safety glass
DS-91-748 Front plate Touch screen or safety glass
DS-91-789 Rack mount Touch screen or safety glass
DS-90-194 Safety glass Front bezel or front plate
DS-91-753 TrueFlat glass can not be combined with any other option
OPTIONS
DS-91-356 Brackets Set, one set additional to standard possible
NT-01-062 Power supply not included by default
DB-07-225 Power cable not included by default
Various data cables as well as operating systems, extensions SSD and main memory
are availabe.
www.distec.de 19PRODUCTS POS-Line 39.6 cm/ 15.6“
RESOLUTION 1920 x 1080 px (FHD)
LUMINANCE 400 cd/m²
VIEWING ANGLE 176°h/ 176° v
CONTRAST 1000:1
PANEL
BACKLIGHT LED
RESPONSE TIME 25 ms
COLOURS 16.7 Millionen
Order number Function Features and interfaces
1 x VGA, 1 x HDMI, 1 x DP, 1 x Audio line out,
DS-91-803 Prisma Media Eco
1 x USB remote, 1 x OSD button (4)
PC: Intel® Atom® E3845 (1.9 GHz), RAM: 4 GB
DDR3L, SSD 120 GB mSATA
DS-91-802 IQ Atom
Interfaces: 2 x Gigabit LAN, 1 x USB 3.0,
1 x USB 2.0, 1 x HDMI, 1 x VGA,
1 x RS232/422/485, 1 x RS232 (optional)
1 x LAN, 2 x USB, 1 x HDMI in, 1 x Line out,
1 x microSD Card slot
DS-91-804 VideoPoster Media player: MPEG-4 (H.264), FVL, AVI, jpeg,
FUNCTIONS
tiff, png, pdf, bmp
XML play list, content update via content server
(HTTP protocol), FTP server or USB connection
Raspberry® PI CM3 ind. ARM-PC with Raspbian
OS; 1 x LAN, 1 x Audio line out, 1 x micro
DS-91-817 Raspberry® IoT SD-slot, 2x USB2.0 , 1x HDMI-in
Storage medium: internal storage (4GB),
microSD card (up to 256GB)
20 www.distec.deORDER NUMBER DS-91-808 DS-91-807
TOUCH TECHNOLOGY PCAP, 2 mm TSG, PCAP, 3 mm TSG with
10 touch points passepartout RAL 9005,
TOUCH
10 touch points
CAN BE USED WITH PME, IQ Atom, IoT PME, IQ Atom, IoT
CAN BE COMBINED WITH Front bezel, front plate can not be combined with
any other option
MATERIAL Powder coated aluminium, black RAL 9005
HOUSING
VESA MIS-D 200 x 100 (M4)
WEIGHT 1.8 kg without options
DIMENSIONS 382.0 x 238.0 x 48.0 mm without options
SPECIAL FEATURES no
Order number Description Can be combined with
DS-91-809 Front bezel Touch screen or safety glass
DS-91-805 Front plate Touch screen or safety glass
DS-90-810 Safety glass Front bezel or front plate
DS-91-806 TrueFlat glass can not be combined with any other option
OPTIONS
DS-91-356 Brackets Set, one set additional to standard possible
NT-01-062 Power supply not included by default
DB-07-225 Power cable not included by default
Various data cables as well as operating systems, extensions SSD and main memory
are availabe.
www.distec.de 21PRODUCTS POS-Line 43.2 cm/ 17.0“
RESOLUTION 1280 x 1024 px (SXGA)
LUMINANCE 350 cd/m²
VIEWING ANGLE 160°h/ 140° v
CONTRAST 800:1
PANEL
BACKLIGHT LED
RESPONSE TIME 30 ms
COLOURS 16.7 millions
Order number Function Features and interfaces
1 x VGA, 1 x HDMI, 1 x DP, 1 x Audio line out,
DS-91-771 Prisma Media Eco
1 x USB remote, 1 x OSD button (4)
PC: Intel® Atom® E3845 (1.9 GHz), RAM: 4 GB
DDR3L, SSD 120 GB mSATA
DS-91-770 IQ Atom
Interfaces: 2 x Gigabit LAN, 1 x USB 3.0,
1 x USB 2.0, 1 x HDMI, 1 x VGA,
1 x RS232/422/485, 1 x RS232 (optional)
1 x LAN, 2 x USB, 1 x HDMI in, 1 x Line out,
1 x microSD Card slot
DS-91-772 VideoPoster Media player: MPEG-4 (H.264), FVL, AVI, jpeg,
tiff, png, pdf, bmp
FUNCTION
XML play list, content update via content server
(HTTP protocol), FTP server or USB connection
Raspberry® PI CM3 ind. ARM-PC with Raspbian
OS; 1 x LAN, 1 x Audio line out, 1 x micro
DS-91-818 Raspberry® IoT SD-slot, 2x USB2.0 , 1x HDMI-in
Storage medium: internal storage (4GB),
microSD card (up to 256GB)
22 www.distec.deORDER NUMBER DS-91-346
TOUCH
TOUCH TECHNOLOGY 5-wire resistive, 1 touch point
CAN BE USED WITH PME, IQ Atom, IoT
CAN BE COMBINED WITH Front bezel, front plate
MATERIAL Powder coated aluminium, black RAL 9005
HOUSING
VESA MIS-D 200 x 100 (M4)
WEIGHT 2.6 - 2.7 kg without options
DIMENSIONS 365.0 x 308.0 x 58.8 mm without options
SPECIAL FEATURES no
Order number Description Can be combined with
DS-91-758 Front bezel Touch screen or safety glass
DS-91-749 Front plate Touch screen or safety glass
DS-91-790 Rack Mount Touch screen or safety glass
DS-90-195 Safety glass Front bezel or front plate
DS-91-754 TrueFlat glass can not be combined with any other option
OPTIONS
DS-91-356 Brackets Set, one set additional to standard possible
NT-01-062 Power supply not included by default
DB-07-225 Power cable not included by default
Various data cables as well as operating systems, extensions SSD and main memory
are availabe.
www.distec.de 23PRODUCTS POS-Line 43.8 cm/ 17.3“
RESOLUTION 1920 x 1080 px (FHD)
LUMINANCE 400 cd/m²
VIEWING ANGLE 160°h/ 140° v
CONTRAST 700:1
PANEL
BACKLIGHT LED
RESPONSE TIME 40 ms
COLOURS 16.7 millions
Order number Function Features and interfaces
1 x VGA, 1 x HDMI, 1 x DP, 1 x Audio line out,
DS-91-7676 Prisma Media Eco
1 x USB remote, 1 x OSD button (4)
PC: Intel® Atom® E3845 (1.9 GHz), RAM: 4 GB
DDR3L, SSD 120 GB mSATA
DS-91-775 IQ Atom
Interfaces: 2 x Gigabit LAN, 1 x USB 3.0,
1 x USB 2.0, 1 x HDMI, 1 x VGA,
1 x RS232/422/485, 1 x RS232 (optional)
1 x LAN, 2 x USB, 1 x HDMI in, 1 x Line out,
1 x microSD Card slot
DS-91-777 VideoPoster Media player: MPEG-4 (H.264), FVL, AVI, jpeg,
tiff, png, pdf, bmp
FUNCTION
XML play list, content update via content server
(HTTP protocol), FTP server or USB connection
Raspberry® PI CM3 ind. ARM-PC with Raspbian
OS; 1 x LAN, 1 x Audio line out, 1 x micro
DS-91-819 Raspberry® IoT SD-slot, 2x USB2.0 , 1x HDMI-in
Storage medium: internal storage (4GB),
microSD card (up to 256GB)
24 www.distec.deORDER NUMBER DS-91-760 DS-91-759
TOUCH TECHNOLOGY PCAP, 3 mm TSG, PCAP, 3 mm TSG with
TOUCH
10 touch points passepartout RAL 9005,
10 touch points
CAN BE USED WITH PME, IQ Atom, IoT PME, IQ Atom, IoT
CAN BE COMBINED WITH Front bezel, front plate can not be combined with
any other option
MATERIAL Powder coated aluminium, black RAL 9005
HOUSING
VESA MIS-D 200 x 100 (M4)
WEIGHT 2.4 - 2.5 kg without options
DIMENSIONS 416.6 x 259.2 x 52.5 mm without options
SPECIAL FEATURES no
Order number Description Can be combined with
DS-91-793 Front bezel Touch screen or safety glass
DS-91-750 Front plate Touch screen or safety glass
DS-91-791 Rack Mount Touch screen or safety glass
DS-91-596 Safety glass Front bezel or front plate
DS-91-755 TrueFlat glass can not be combined with any other option
OPTIONS
DS-91-356 Brackets Set, one set additional to standard possible
NT-01-062 Power supply not included by default
DB-07-225 Power cable not included by default
Various data cables as well as operating systems, extensions SSD and main memory
are availabe.
www.distec.de 25PRODUCTS POS-Line 48.3 cm/ 19.0“
RESOLUTION 1280 x 1024 px (SXGA)
LUMINANCE 300 cd/m²
VIEWING ANGLE 178°h/ 178° v
CONTRAST 2000:1
PANEL
BACKLIGHT LED
RESPONSE TIME 20 ms
COLOURS 16.7 millions
Order number Function Features and interfaces
1 x VGA, 1 x HDMI, 1 x DP, 1 x Audio line out,
DS-91-781 Prisma Media Eco
1 x USB remote, 1 x OSD button (4)
PC: Intel® Atom® E3845 (1.9 GHz), RAM: 4 GB
DDR3L, SSD 120 GB mSATA
DS-91-780 IQ Atom
Interfaces: 2 x Gigabit LAN, 1 x USB 3.0,
1 x USB 2.0, 1 x HDMI, 1 x VGA,
1 x RS232/422/485, 1 x RS232 (optional)
1 x LAN, 2 x USB, 1 x HDMI in, 1 x Line out,
1 x microSD Card slot
DS-91-782 VideoPoster Media player: MPEG-4 (H.264), FVL, AVI, jpeg,
tiff, png, pdf, bmp
FUNCTION
XML play list, content update via content server
(HTTP protocol), FTP server or USB connection
Raspberry® PI CM3 ind. ARM-PC with Raspbian
OS; 1 x LAN, 1 x Audio line out, 1 x micro
DS-91-820 Raspberry® IoT SD-slot, 2x USB2.0 , 1x HDMI-in
Storage medium: internal storage (4GB),
microSD card (up to 256GB)
26 www.distec.deORDER NUMBER DS-91-795
TOUCH
TOUCH TECHNOLOGY 5-wire resistive, 1 touch point
CAN BE USED WITH PME, IQ Atom, IoT
CAN BE COMBINED WITH Front bezel, front plate
MATERIAL Powder coated aluminium, black RAL 9005
HOUSING
VESA MIS-D 200 x 100 (M4)
WEIGHT 3.2 - 3.3 kg without options
DIMENSIONS 412.0 x 340.0 x 55.5 mm without options
SPECIAL FEATURES no
Order number Description Can be combined with
DS-91-325 Front bezel Touch screen or safety glass
DS-91-751 Front plate Touch screen or safety glass
DS-91-792 Rack Mount Touch screen or safety glass
DS-90-196 Safety glass Front bezel or front plate
DS-91-756 TrueFlat glass can not be combined with any other option
OPTIONS
DS-91-356 Brackets Set, one set additional to standard possible
NT-01-062 Power supply not included by default
DB-07-225 Power cable not included by default
Various data cables as well as operating systems, extensions SSD and main memory
are availabe.
www.distec.de 27PRODUCTS POS-Line 54.7 cm/ 21.5“
RESOLUTION 1920 x 1080 px (FHD)
LUMINANCE 300 cd/m²
VIEWING ANGLE 178°h/ 178° v
CONTRAST 5000:1
PANEL
BACKLIGHT LED
RESPONSE TIME 25 ms
COLOURS 16.7 millions
Order number Function Features and interfaces
1 x VGA, 1 x HDMI, 1 x DP, 1 x Audio line out,
DS-91-786 Prisma Media Eco
1 x USB remote, 1 x OSD button (4)
PC: Intel® Atom® E3845 (1.9 GHz), RAM: 4 GB
DDR3L, SSD 120 GB mSATA
DS-91-785 IQ Atom
Interfaces: 2 x Gigabit LAN, 1 x USB 3.0,
1 x USB 2.0, 1 x HDMI, 1 x VGA,
1 x RS232/422/485, 1 x RS232 (optional)
1 x LAN, 2 x USB, 1 x HDMI in, 1 x Line out,
1 x microSD Card slot
DS-91-787 VideoPoster Media player: MPEG-4 (H.264), FVL, AVI, jpeg,
tiff, png, pdf, bmp
FUNCTION
XML play list, content update via content server
(HTTP protocol), FTP server or USB connection
Raspberry® PI CM3 ind. ARM-PC with Raspbian
OS; 1 x LAN, 1 x Audio line out, 1 x micro
DS-91-821 Raspberry® IoT SD-slot, 2x USB2.0 , 1x HDMI-in
Storage medium: internal storage (4GB),
microSD card (up to 256GB)
28 www.distec.deORDER NUMBER DS-91-761 DS-91-762
TOUCH TECHNOLOGY PCAP, 3 mm TSG, PCAP, 3 mm TSG with
10 touch points passepartout RAL 9005,
TOUCH
10 touch points
CAN BE USED WITH PME, IQ Atom, IoT PME, IQ Atom, IoT
CAN BE COMBINED WITH Front bezel, front plate can not be combined with
any other option
MATERIAL Powder coated aluminium, black RAL 9005
HOUSING
VESA MIS-D 200 x 100 (M4)
WEIGHT 3.2 - 3.4 kg without options
DIMENSIONS 514.0 x 319.0 x 54.0 mm without options
SPECIAL FEATURES no
Order number Description Can be combined with
DS-91-689 Front bezel Touch screen or safety glass
DS-91-752 Front plate Touch screen or safety glass
DS-91-796 Safety glass Front bezel or front plate
DS-91-757 TrueFlat glass can not be combined with any other option
OPTIONS
DS-91-356 Brackets Set, one set additional to standard possible
NT-01-062 Power supply not included by default
DB-07-225 Power cable not included by default
Various data cables as well as operating systems, extensions SSD and main memory
are availabe.
www.distec.de 29PRODUCTS POS-Line 61.0 cm/ 24.0“
RESOLUTION 1920 x 1080 px (FHD)
LUMINANCE 300 cd/m²
VIEWING ANGLE 178°h/ 178° v
CONTRAST 5000:1
PANEL
BACKLIGHT LED
RESPONSE TIME 25 ms
COLOURS 16.7 millions
Order number Function Features and interfaces
1 x VGA, 1 x HDMI, 1 x DP, 1 x Audio line out,
DS-91-740 Prisma Media Eco
1 x USB remote, 1 x OSD button (4)
PC: Intel® Atom® E3845 (1.9 GHz), RAM: 4 GB
DDR3L, SSD 120 GB mSATA
DS-91-739 IQ Atom
Interfaces: 2 x Gigabit LAN, 1 x USB 3.0,
1 x USB 2.0, 1 x HDMI, 1 x VGA,
1 x RS232/422/485, 1 x RS232 (optional)
1 x LAN, 2 x USB, 1 x HDMI in, 1 x Line out,
1 x microSD Card slot
DS-91-741 VideoPoster Media player: MPEG-4 (H.264), FVL, AVI, jpeg,
tiff, png, pdf, bmp
FUNCTION
XML play list, content update via content server
(HTTP protocol), FTP server or USB connection
Raspberry® PI CM3 ind. ARM-PC with Raspbian
OS; 1 x LAN, 1 x Audio line out, 1 x micro
DS-91-822 Raspberry® IoT SD-slot, 2x USB2.0 , 1x HDMI-in
Storage medium: internal storage (4GB),
microSD card (up to 256GB)
30 www.distec.deORDER NUMBER DS-91-744 DS-91-745
TOUCH TECHNOLOGY PCAP, 3 mm TSG, PCAP, 3 mm TSG with
TOUCH
10 touch points passepartout RAL 9005,
10 touch points
CAN BE USED WITH PME, IQ Atom, IoT PME, IQ Atom, IoT
CAN BE COMBINED WITH Front bezel, front plate can not be combined with
any other option
MATERIAL Powder coated aluminium, black RAL 9005
HOUSING
VESA MIS-D 200 x 100 (M4)
WEIGHT 4.1 - 4.3 kg without options
DIMENSIONS 578.0 x 347.2 x 53.0 mm without options
SPECIAL FEATURES no
Order number Description Can be combined with
DS-91-747 Front Bezel Touch screen or safety glass
DS-91-746 Front Plate Touch screen or safety glass
DS-90-742 Safety glass Front bezel or front plate
DS-91-743 TrueFlat glass can not be combined with any other option
DS-91-356 Brackets Set, two sets additional to standard possible
OPTIONS
NT-01-062 Power supply not included by default
DB-07-225 Power cable not included by default
Various data cables as well as operating systems, extensions SSD and main memory
are availabe.
www.distec.de 31PRODUCTS POS-Line 80.0 cm/ 31.5“
RESOLUTION 1920 x 1080 px (FHD)
LUMINANCE 500 cd/m²
VIEWING ANGLE 178°h/ 178° v
CONTRAST 3000:1
PANEL
BACKLIGHT LED
RESPONSE TIME 8 ms
COLOURS 16.7 millions
Order number Function Features and interfaces
1 x VGA, 1 x HDMI, 1 x DP, 1 x Audio line out,
DS-91-411 Prisma Media Eco
1 x USB remote, OSD button (4)
1 x VGA, 1 x DVI (HDMI via DVI), 1 x S-Video, 1 x
DS-91-412 Prisma IIIA Composite Video, 1 x USB remote, OSD button
(4)
PC: Intel® Atom® E3845 (1.9 GHz), RAM: 4 GB
DDR3L, SSD 120 GB mSATA
DS-91-931 IQ Atom Interfaces: 2 x Gigabit LAN, 1 x USB 3.0, 1 x USB
2.0, 1 x HDMI, 1 x VGA, 1 x RS232/422/485, 1 x
RS232 (optional)
PC: Intel® Core™-i5-7300 U (2.6 GHz), Intel® HD
Graphics GT Serie, RAM: 8GB DDR 4
DS-92-022 IQ Core®-i5 SSD 120 GB M.2Sata
Interfaces: 2 x DP, 2x LAN, 4x USB 3.0,
1 x Audio, 1 x MIC in
1 x LAN, 2 x USB, 1 x HDMI in, 1 x Line out,
FUNCTION
1 x microSD Card slot
Media player: MPEG-4 (H.264), FVL, AVI, jpeg,
DS-91-414 VideoPoster
tiff, png, pdf, bmp
XML play list, content update via content server
(HTTP protocol), FTP server or USB connection
Raspberry® PI CM3 ind. ARM-PC with Raspbian
OS; 1 x LAN, 1 x Audio line out, 1 x micro
DS-91-981 Raspberry® IoT SD-slot, 2x USB2.0 , 1x HDMI-in
Storage medium: internal storage (4GB),
microSD card (up to 256GB)
32 www.distec.deORDER NUMBER DS-91-424 TrueFlat bezel with touch screen
DS-91-916 TrueFlat touch screen
DS-92-029 Touch screen without passepartout
TOUCH
TOUCH TECHNOLOGY PCAP, 4 mm safety glass with passepartout RAL
9005, 10 touch points
CAN BE USED WITH PME, IQ Atom, IoT
CAN BE COMBINED WITH can not be combined with any other option,
only DS-92-029 can be combined with bezel
HOUSING
MATERIAL Powder coated sheet steel, black RAL 9005
VESA MIS-F 400 x 400 (M6)
WEIGHT 12.5 - 16.5 kg without options
DIMENSIONS 759 x 454 x 79 - 101 mm without options
SPECIAL FEATURES no
Order number Description Can be combined with
DS-91-470 Front bezel Touch DS-92-029 or safety glass
DS-91-612 Alu design bezel Touch DS-92-029 or safety glass
DS-91-420 Safety glass Front bezel
DS-91-476 TrueFlat glass can not be combined with any other option
TrueFlat bezel with
DS-91-421 can not be combined with any other option
glass
OPTIONS
DS-91-930 PC Box Atom ext. PME, Prisma IIIA, VideoPoster
DS-92-033 PC Box Core-i5 ext. PME, Prisma IIIA, VideoPoster
Various data cables as well as operating systems, extensions SSD and main memory
are availabe.
www.distec.de 33PRODUCTS POS-Line 106.7 cm/ 42“
RESOLUTION 1920 x 1080 px (FHD)
LUMINANCE 700 cd/m²
VIEWING ANGLE 178°h/ 178° v
CONTRAST 4000:1
PANEL
BACKLIGHT LED
RESPONSE TIME 8 ms
COLOURS 16.7 millions
Order number Function Features and interfaces
1 x VGA, 1 x HDMI, 1 x DP, 1 x Audio line out,
DS-91-478 Prisma Media Eco
1 x USB remote, OSD button (4)
1 x VGA, 1 x DVI (HDMI via DVI), 1 x S-Video, 1 x
DS-91-479 Prisma IIIA Composite Video, 1 x USB remote, OSD button
(4)
PC: Intel® Atom® E3845 (1.9 GHz), RAM: 4 GB
DDR3L, SSD 120 GB mSATA
DS-91-932 IQ Atom Interfaces: 2 x Gigabit LAN, 1 x USB 3.0, 1 x USB
2.0, 1 x HDMI, 1 x VGA, 1 x RS232/422/485, 1 x
RS232 (optional)
PC: Intel® Core™-i5-7300 U (2.6 GHz), Intel® HD
Graphics GT Serie, RAM: 8GB DDR 4
DS-92-023 IQ Core®-i5 SSD 120 GB M.2Sata
Interfaces: 2 x DP, 2x LAN, 4x USB 3.0,
1 x Audio, 1 x MIC in
1 x LAN, 2 x USB, 1 x HDMI in, 1 x Line out,
FUNCTION
1 x microSD Card slot
Media player: MPEG-4 (H.264), FVL, AVI, jpeg,
DS-91-481 VideoPoster
tiff, png, pdf, bmp
XML play list, content update via content server
(HTTP protocol), FTP server or USB connection
Raspberry® PI CM3 ind. ARM-PC with Raspbian
OS; 1 x LAN, 1 x Audio line out, 1 x micro
DS-91-982 Raspberry® IoT SD-slot, 2x USB2.0 , 1x HDMI-in
Storage medium: internal storage (4GB),
microSD card (up to 256GB)
34 www.distec.deORDER NUMBER DS-91-917 TrueFlat bezel with touch screen
DS-91-918 TrueFlat touch screen
TOUCH
TOUCH TECHNOLOGY PCAP, 4 mm safety glass with passepartout RAL
9005, 10 touch points
CAN BE USED WITH PME, IQ Atom, IoT
CAN BE COMBINED WITH can not be combined with any other option
MATERIAL Powder coated sheet steel, black RAL 9005
HOUSING
VESA MIS-F 400 x 400 (M6)
WEIGHT 20.0 - 22.5 kg without options
DIMENSIONS 991 x 583 x 79 - 101 mm without options
SPECIAL FEATURES no
Order number Description Can be combined with
DS-91-494 Front bezel Safety glass
DS-91-613 Alu design bezel Safety glass
DS-91-502 Safety glass Front bezel
DS-91-499 TrueFlat glass can not be combined with any other option
TrueFlat bezel with
DS-91-561 can not be combined with any other option
glass
OPTIONS
DS-91-930 PC Box Atom ext. PME, Prisma IIIA, VideoPoster
DS-92-033 PC Box Core-i5 ext. PME, Prisma IIIA, VideoPoster
Various data cables as well as operating systems, extensions SSD and main memory
are availabe.
www.distec.de 35PRODUCTS POS-Line 116.8 cm/ 46“
RESOLUTION 1920 x 1080 px (FHD)
LUMINANCE 700 cd/m²
VIEWING ANGLE 178°h/ 178° v
CONTRAST 4000:1
PANEL
BACKLIGHT LED
RESPONSE TIME 6.5 ms
COLOURS 16.7 millions
Order number Function Features and interfaces
1 x VGA, 1 x HDMI, 1 x DP, 1 x Audio line out,
DS-91-485 Prisma Media Eco
1 x USB remote, OSD button (4)
1 x VGA, 1 x DVI (HDMI via DVI), 1 x S-Video, 1 x
DS-91-487 Prisma IIIA Composite Video, 1 x USB remote, OSD button
(4)
PC: Intel® Atom® E3845 (1.9 GHz), RAM: 4 GB
DDR3L, SSD 120 GB mSATA
DS-91-933 IQ Atom Interfaaces: 2 x Gigabit LAN, 1 x USB 3.0, 1 x
USB 2.0, 1 x HDMI, 1 x VGA, 1 x RS232/422/485,
1 x RS232 (optional)
PC: Intel® Core™-i5-7300 U (2.6 GHz), Intel® HD
Graphics GT Serie, RAM: 8GB DDR 4
DS-92-024 IQ Core®-i5 SSD 120 GB M.2Sata
Interfaces: 2 x DP, 2x LAN, 4x USB 3.0,
1 x Audio, 1 x MIC in
1 x LAN, 2 x USB, 1 x HDMI in, 1 x Line out,
1 x microSD Card slot
FNCTION
Media player: MPEG-4 (H.264), FVL, AVI, jpeg,
DS-91-491 VideoPoster
tiff, png, pdf, bmp
XML play list, content update via content server
(HTTP protocol), FTP server or USB connection
Raspberry® PI CM3 ind. ARM-PC with Raspbian
OS; 1 x LAN, 1 x Audio line out, 1 x micro
DS-91-983 Raspberry® IoT SD-slot, 2x USB2.0 , 1x HDMI-in
Storage medium: internal storage (4GB),
microSD card (up to 256GB)
36 www.distec.deORDER NUMBER DS-91-924 TrueFlat bezel with touch screen
DS-91-925 TrueFlat touch screen
TOUCH
TOUCH TECHNOLOGY PCAP, 4 mm safety glass with passepartout RAL
9005, 10 touch points
CAN BE USED WITH PME, IQ Atom, IoT
CAN BE COMBINED WITH can not be combined with any other option
MATERIAL Powder coated sheet steel, black RAL 9005
HOUSING
VESA MIS-F 400 x 400 (M6)
WEIGHT 24.5 - 29.0 kg without options
DIMENSIONS 1078 x 633 x 80 - 102 mm without options
SPECIAL FEATURES no
Order number Description Can be combined with
DS-91-496 Front bezel Safety glass
DS-91-614 Alu design bezel Safety glass
DS-90-633 Safety glass Front bezel
DS-91-500 TrueFlat glass can not be combined with any other option
TrueFlat bezel with
DS-91-703 can not be combined with any other option
glass
OPTIONS
DS-91-930 PC Box Atom ext. PME, Prisma IIIA, VideoPoster
DS-92-033 PC Box Core-i5 ext. PME, Prisma IIIA, VideoPoster
Various data cables as well as operating systems, extensions SSD and main memory
are availabe.
www.distec.de 37PRODUCTS POS-Line 138.7 cm/ 54.6“
RESOLUTION 1920 x 1080 px (FHD)
LUMINANCE 700 cd/m²
VIEWING ANGLE 178°h/ 178° v
CONTRAST 4000:1
PANEL
BACKLIGHT LED
RESPONSE TIME 6.5 ms
COLOURS 16.7 millions
Order number Function Features and interfaces
1 x VGA, 1 x HDMI, 1 x DP, 1 x Audio line out,
DS-91-486 Prisma Media Eco
1 x USB remote, OSD button (4)
1 x VGA, 1 x DVI (HDMI via DVI), 1 x S-Video, 1 x
DS-91-488 Prisma IIIA Composite Video, 1 x USB Remote, OSD button
(4)
PC: Intel® Atom® E3845 (1.9 GHz), RAM: 4 GB
DDR3L, SSD 120 GB mSATA
DS-91-934 IQ Atom Interfaces: 2 x Gigabit LAN, 1 x USB 3.0, 1 x USB
2.0, 1 x HDMI, 1 x VGA, 1 x RS232/422/485, 1 x
RS232 (optional)
PC: Intel® Core™-i5-7300 U (2.6 GHz), Intel® HD
Graphics GT Serie, RAM: 8GB DDR 4
DS-92-025 IQ Core®-i5 SSD 120 GB M.2Sata
Interfaces: 2 x DP, 2x LAN, 4x USB 3.0,
1 x Audio, 1 x MIC in
FUNCTIONS
1 x LAN, 2 x USB, 1 x HDMI in, 1 x Line out,
1 x microSD Card slot
Media player: MPEG-4 (H.264), FVL, AVI, jpeg,
DS-91-492 VideoPoster
tiff, png, pdf, bmp
XML play list, content update via content server
(HTTP protocol), FTP server or USB connection
Raspberry® PI CM3 ind. ARM-PC with Raspbian
OS; 1 x LAN, 1 x Audio line out, 1 x micro
DS-91-984 Raspberry® IoT SD-slot, 2x USB2.0 , 1x HDMI-in
Storage medium: internal storage (4GB),
microSD card (up to 256GB)
38 www.distec.deORDER NUMBER DS-91-926 TrueFlat bezel with touch screen
DS-91-927 TrueFlat touch screen
TOUCH
TOUCH TECHNOLOGY PCAP, 4 mm safety glass with passepartout RAL
9005, 10 touch points
CAN BE USED WITH PME, IQ Atom, IoT
CAN BE COMBINED WITH can not be combined with any other option
MATERIAL Powder coated sheet steel, black RAL 9005
HOUSING
VESA MIS-F 400 x 400 (M6)
WEIGHT 34.5 - 37.0 kg without options
DIMENSIONS 1270 x 741x 80 - 102 mm without options
SPECIAL FEATURES no
Order number Description Can be combined with
DS-91-498 Front bezel Safety glass
DS-91-615 Alu design bezel Safety glass
DS-91-671 Safety glass Front bezel
DS-91-501 TrueFlat glass can not be combined with any other option
TrueFlat bezel with
DS-91-562 can not be combined with any other option
glass
OPTIONS
DS-91-930 PC Box Atom ext. PME, Prisma IIIA, VideoPoster
DS-92-033 PC Box Core-i5 ext. PME, Prisma IIIA, VideoPoster
Various data cables as well as operating systems, extensions SSD and main memory
are availabe.
www.distec.de 39PRODUCTS POS-Line 163.9 cm/ 64.5“
RESOLUTION 1920 x 1080 px (FHD)
LUMINANCE 700 cd/m²
VIEWING ANGLE 178°h/ 178° v
CONTRAST 4000:1
PANEL
BACKLIGHT LED
RESPONSE TIME 8 ms
COLOURS 16.7 millions
Order number Function Features and interfaces
1 x VGA, 1 x HDMI, 1 x DP, 1 x Audio line out,
DS-91-954 Prisma Media Eco
1 x USB remote, OSD button (4)
1 x VGA, 1 x DVI (HDMI via DVI), 1 x S-Video, 1 x
DS-91-955 Prisma IIIA Composite Video, 1 x USB remote, OSD button
(4)
PC: Intel® Atom® E3845 (1.9 GHz), RAM: 4 GB
DDR3L, SSD 120 GB mSATA
DS-91-959 IQ Atom Interfaces: 2 x Gigabit LAN, 1 x USB 3.0, 1 x USB
2.0, 1 x HDMI, 1 x VGA, 1 x RS232/422/485, 1 x
RS232 (optional)
PC: Intel® Core™-i5-7300 U (2.6 GHz), Intel® HD
Graphics GT Serie, RAM: 8GB DDR 4
DS-92-026 IQ Core®-i5 SSD 120 GB M.2Sata
Interfaces: 2 x DP, 2x LAN, 4x USB 3.0,
1 x Audio, 1 x MIC in
1 x LAN, 2 x USB, 1 x HDMI in, 1 x Line out,
FUNCTION
1 x microSD Card slot
Media player: MPEG-4 (H.264), FVL, AVI, jpeg,
DS-91-956 VideoPoster
tiff, png, pdf, bmp
XML play list, content update via content server
(HTTP protocol), FTP server or USB connection
Raspberry® PI CM3 ind. ARM-PC with Raspbian
OS; 1 x LAN, 1 x Audio line out, 1 x micro
DS-91-985 Raspberry® IoT SD-slot, 2x USB2.0 , 1x HDMI-in
Storage medium: internal storage (4GB),
microSD card (up to 256GB)
40 www.distec.deMATERIAL Powder coated sheet steel, black RAL 9005
HOUSING
VESA MIS-F 800 x 400 (M6)
WEIGHT 44.0 - 46.0 kg without options
DIMENSIONS 1480 x 855 x 122 mm without options
SPECIAL FEATURES no
Order number Description Can be combined with
DS-91-951 Front bezel Safety glass
DS-91-950 Safety glass Front bezel
DS-91-952 TrueFlat glass can not be combined with any other option
OPTIONS
DS-91-930 PC Box Atom ext. PME, Prisma IIIA, VideoPoster
DS-92-033 PC Box Core-i5 ext. PME, Prisma IIIA, VideoPoster
Various data cables as well as operating systems, extensions SSD and main memory
are availabe.
www.distec.de 41Brilan 4K – monitors from 42.5“ up to 74.5“ Messages in high brilliance 42 www.distec.de
Brilan 4K 74.5“ monitor with front bezel Our Brilan 4K stands for a brilliant and detailed visualisation of images and high-quality, rugged design. This product perfectly matches your needs if you appreciate razor-sharp and vivid images in high resolution. With the largest screen dimension currently available (190,5 cm /74.5“ diagonal) we provide the ideal product for your application. For driving the Brilan 4K monitor we use controller cards with various interfaces, such as HDMI or DisplayPort 1.2a. There are further interfaces in order to run firmware updates and additional func- tions, including an infrared sensor. Moreover it supports scalability. In addition to controller cards, that are connected to external sources, the new Brilan 4k is also available with a separate PC box attached to the monitor, allowing it to be operated independently. UWith a resolution of 3840 x2160 pixels, Ultra High Definition (UHD/4k) TFT displays provide four times the resolution of standard Full HD monitors. The high density of pixels allows to display not only razor-sharp images but also delicate lines and structu- res. Four Full HD images can be displayed simultaneously without downscaling. Even scaled content, such as letters and fonts, are displayed much sharper which ensures fatigue-free reading. For example, finest hairline cracks can be visualized in medical technology and industry. www.distec.de 43
PRODUCTS BRILAN 4K 108 cm/ 42.5“
RESOLUTION 3840 x 2160 px (4K)
LUMINANCE 700 cd/m²
VIEWING ANGLE 178°h/ 178° v
CONTRAST 3000:1
PANEL
BACKLIGHT LED
RESPONSE TIME 8 ms
COLOURS 16.7 millions
Order number Function Features and interfaces
DS-92-063 Multi media 2x HDMI 2.0 in, 1x HDMI out (4K daisy chain),
open frame controller 4K 1x DisplayPort 1.2a in, 1 x RS232 in, 1 x RS232
out, 1 x USB-A (upload), 1 x Infrared sensor;
DS-92-082 with 1 x 7 button OSD
TrueFlat glass
Integrated full range speaker, 2 x 10 W
DS-92-083 with Edge fade-out, tiling, daisy chain wiring
touch screen 3M
P-series Daisy chain:
4k 60 Hz 4k 30 Hz FullHD 60 Hz
9 units 16 units 25 units
DS-92-088 internal Single 1 x LAN, 2 x USB2.0, 2 x USB 3.0, no opterating
board PC based on system
ARM Storage medium: internal storage (32 GB SD)
FUNCTION
44 www.distec.deORDER NUMBER DS-92-083 TrueFlat touch screen (monitor incl. touch
screen)
TOUCH
TOUCH TECHNOLOGY PCAP, 4.4 mm safety glass with passepartout RAL
9005, 80 touch points
CAN BE USED WITH Video 4K
CAN BE COMBINED WITH Glass protection frame
MATERIAL Powder coated sheet steel, black RAL 9005
HOUSING
VESA MIS-F 400 x 400 (M6)
WEIGHT 11.1 kg without options
DIMENSIONS 967 x 554.5 x 71 mm without options
SPECIAL FEATURES TrueFlat glass and TrueFlat touch screen are not single
options, the basic unit must be ordered according to
the desired equipment.
Order number Description Can be combined with
DS-92-098 Front bezel Open frame monitor
Glass protection
DS-92-084 TrueFlat glass or TrueFlat touch screen
frame
Safety glass with
DS-92-097 Open frame monitor
bezel
OPTIONS
LAN for remote
DS-92-087 with all versions
control
Rock Pi4 -
DS-92-088 with all versions
Mini-PC, intern
Various data cables are availabe.
www.distec.de 45PRODUCTS BRILAN 4K 138.7 cm/ 54.6“
RESOLUTION 3840 x 2160 px (4K)
LUMINANCE 700 cd/m²
VIEWING ANGLE 178°h/ 178° v
CONTRAST 4000:1
PANEL
BACKLIGHT LED
RESPONSE TIME 8.5 ms
COLOURS 16.7 millions
Order number Function Features and interfaces
DS-92-085 Multi media 2x HDMI 2.0 in, 1x HDMI out (4K daisy chain),
open frame controller 4K 1x DisplayPort 1.2a in, 1 x RS232 in, 1 x RS232
out, 1 x USB-A (upload), 1 x Infrared sensor;
DS-92-086 with 1 x 7 button OSD
TrueFlat glass
Integrated full range speaker, 2 x 10 W
DS-92-093 with Edge fade-out, tiling, daisy chain wiring
touch screen 3M
P-series Daisy chain:
4k 60 Hz 4k 30 Hz FullHD 60 Hz
9 units 16 units 25 units
DS-92-088 internal Single 1 x LAN, 2 x USB2.0, 2 x USB 3.0, no opterating
board PC based on system
ARM Storage medium: internal storage (32 GB SD)
FUNCTION
46 www.distec.deORDER NUMBER DS-92-093 TrueFlat touch screen (monitor incl. touch
screen)
TOUCH
TOUCH TECHNOLOGY PCAP, 5 mm safety glass with passepartout RAL
9005, 80 touch points
CAN BE USED WITH Video 4K
CAN BE COMBINED WITH Glass protection frame
MATERIAL Powder coated sheet steel, black RAL 9005
VESA MIS-F 400 x 400 (M6)
HOUSING
WEIGHT 32.0 kg without options
DIMENSIONS 1235 x 705 x 73 mm without options
SPECIAL FEATURES TrueFlat glass and TrueFlat touch screen are not single
options, the basic unit must be ordered according to
the desired equipment.
Order number Description Can be combined with
DS-92-091 Front bezel Open frame monitor
Glass protection
DS-92-089 TrueFlat glass or TrueFlat touch screen
frame
Safety glass with
DS-92-104 Open frame monitor
bezel
LAN for remote
DS-92-087 with all versions
OPTIONS
control
Rock Pi4 -
DS-92-088 with all versions
Mini-PC, intern
DS-92-033 PC Box Core-i5 ext. with all versions
Various data cables as well as operating systems, extensions SSD and main memory
are availabe.
www.distec.de 47PRODUCTS BRILAN 4K 190.5 cm/ 74.5“
RESOLUTION 3840 x 2160 px (4K)
LUMINANCE 700 cd/m²
VIEWING ANGLE 178°h/ 178° v
CONTRAST 4000:1
PANEL
BACKLIGHT LED
RESPONSE TIME 6.5 ms
COLOURS 16.7 millions
Order number Function Features and interfaces
DS-92-021 Multi media 2x HDMI 2.0 in, 1x HDMI out (4K daisy chain),
controller 4K 1x DisplayPort 1.2a in, 1 x RS232 in, 1 x RS232
out, 1 x USB-A (upload), 1 x Infrared sensor;
1 x 7 button OSD
Integrated full range speaker, 2 x 10 W
Edge fade-out, tiling, daisy chain wiring
FUNCTION
Daisy chain:
4k 60 Hz 4k 30 Hz FullHD 60 Hz
9 units 16 units 25 units
DS-92-088 internal Single 1 x LAN, 2 x USB2.0, 2 x USB 3.0, no opterating
board PC based on system
ARM Storage medium: internal storage (32 GB SD)
48 www.distec.deMATERIAL Powder coated sheet steel, black RAL 9005
HOUSING
VESA MIS-F 800 x 400 (M8) Monitor
MIS-F 75 x 75/ 100 x 100 (M4) for PC-Box
WEIGHT 52.0 kg without options
DIMENSIONS 1676 x 954 x 92 mm without options
SPECIAL FEATURES no
Order number Description Can be combined with
DS-92-032 Front bezel can not be combined with any other option
Glass protection
DS-92-036 TrueFlat glass
frame
DS-92-037 TrueFlat glass Glass protection frame
LAN for remote
DS-92-087 with all versions
control
OPTIONS
Rock Pi4 -
DS_92-088 with all versions
Mini-PC, intern
DS-92-033 PC Box Core-i5 ext. with all versions
Various data cables as well as operating systems, extensions SSD and main memory
are availabe.
www.distec.de 49BLO-Line – monitors
from 24“ up to 64.5“
High quality fire protection
50 www.distec.deMonitor BLO-Line (A1) 31.5“ with stainless steel housing, lock and Monitor BLO-Line (A1) 54.6“, BLO 54.6“ monitor B-s1,d0, RAL 9005
glass installed as info terminal at the airport portrait mode, RAL 9005
Protection against fire hazard and assessment of fire behaviour of building materials is a basic presumption
when planning and constructing buildings. Public areas, which are also marked emergency exit routes within
buildings must be accessible in case of fire. Flammable materials with high risk of smoke gas development
must not be used or installed in those areas.
Requirements for fire prevention often conflict the demand the demand of using monitors in public areas of
builings as visitor guiding systems, guest or employee information systems and for advertising purposes.
Usually the places of installation are also part of sign-posted emergency exit routes. Fire safety regulations
avoid the installation of devices which are supposed to increase fire load and to promote development of smo-
ke gas. Distec designed and developed a monitor series optimized in the contribution to fire and smoke gas
emission for usage in public areas and buildings. Monitors from our BLO-Line are available with two different
reaction to fire classification levels.
Higher security in case of fire in public spaces
www.distec.de 51Safety first
The European Standard EN13501-1 enables the classification of building materials and components in terms
of fire behavior and fire resistance. Additional criteria take a product’s tendency to produce smoke and flaming
droplets or particles into consideration. Since there is no such classification procedure for electronic devices,
monitors are tested in compliance with the SBI method according to EN 13823:2015-02 standard, which spe-
cifies a method of test in order to determine the reaction to fire performance of construction products when
exposed to thermal attack by a single burning item (SBI).
The required fire test was conducted in accordance with the above mentioned standards on the premises of
the Leipzig Institute for Materials Research and Testing, a recognised, notified and accredited testing, inspec-
tion and certification body in Germany. The results have been verified and certified by an independent expert
assessor. The results of the fire tests allow Distec to offer fire load optimized monitors in accordance with both
the classifications B (combustible materials with limited contribution to a fire) -s1 (little or no smoke gas emis-
sion), d0 (no production of flaming droplets) and even A1-s1, d0 (non-combustible materials - no contribution
to fire).
The new BLO line is A1 classified and certified. Consequently, it meets the respective fire safety regulations.
BLO-line monitors may be also equipped with an optional extinguishing device or even engineered for a higher
IP rating. Thus, our BLO monitors are most suitable for installation as information systems in public buildings,
such as hospitals, universities, schools, airports and other public areas in buildings. They are available as
common monitors or as an independent system with integrated PC. Hence, there is no need for additional fire
resistant housings which are both heavy in weight and more expensive. Therefore, our BLO-line monitors are
cost-effective and allow for an easy installation and handling.
No fire hazards with Distec BLO monitors
Monitors with A1-s1 d0 classification (according to DIN EN 13501-1 standard) are non-flammable, cause only
little or no smoke gas emission and do not produce flaming droplets or particles. For successful certification
based on the fire test, an expert report is issued by an authorized expert for preventive fire protection officially
appointed and sworn by the Federal Chamber of Engineers and an authorized expert for defensive fire protecti-
on.
During the mentioned fire test the monitor is exposed to open fire for the duration of 30 minutes so that mea-
surements of smoke gas emissions, heat release and dripping can be taken. A certificate for A1-s1, d0 classifi-
cation is enclosed with each monitor delivered.
Fire load certificate B-s1,d0
Fire load certificate A1-s1,d0
52 www.distec.deSet up in landscape and portrait mode Information screen with highest reaction to fire classification
German Standard and European Reaction to Fire Classification System
Basically, there is no classification system for electrical devices, including our monitors, according to DIN EN
13501-1 standard for building materials. Since there is no such a standard for electronic devices the fire test
has been carried out on the basis of DIN EN 13501-1 in order to make our monitors comparable to building
materials.
German classification Additional classification Building material Building material
class DIN EN class DIN 4102-1
no smoke no flaming
production droplets/ particles
13501-1 (Germany)
non combustible (without burning elements) X X A1 A1
non combustible (with parts of burning elements) X X A2-s1 d0 A2
X X B,C - s1 d0
X A2, B, C - s2 d0
X A2, B, C - s3 d0
flame resistant B1
X A2, B, C - s1 d1
X A2, B, C - s1 d2
A2, B, C - s3 d2
X X D - s1 d0
X D - s2 d0
X D - s3 d0
X D - s1 d2
normally flammable B2
D - s2 d2
D - s3 d2
X E
E - d2
easily flammable F B3
www.distec.de 53PRODUCTS BLO (B-s1,d0) 80.0 cm/ 31.5“
RESOLUTION 1920 x 1080 px (FHD)
LUMINANCE 500 cd/m²
VIEWING ANGLE 165°h/ 165° v
CONTRAST 3000:1
PANEL
BACKLIGHT LED
RESPONSE TIME 8 ms
COLOURS 16.7 millions
Oder number Function Features and interfaces
1 x VGA, 1 x HDMI, 1 x DP, 1 x Audio line out,
DS-91-727 Prisma Media Eco
1 x USB remote, OSD button (4)
PC: Intel® Atom® E3845 (1.9 GHz), RAM: 4 GB
FUNCTION
DDR3L, SSD 120 GB mSATA
DS-91-965 IQ Atom Interfaces: 2 x Gigabit LAN, 1 x USB
3.0, 1 x USB 2.0, 1 x HDMI, 1 x VGA, 1 x
RS232/422/485, 1 x RS232 (optional)
MATERIAL Powder coated sheet steel, black RAL 9005
HOUSING
VESA MIS-F 400 x 400 (M6)
WEIGHT 20.3 - 20.6 kg
DIMENSIONS 762 x 456 x 117.5 mm
SPECIAL FEATURES Fire protection glass and front bezel
certified according to B-s1,d0
54 www.distec.deYou can also read
