Western Cape: Informal
settlements status
research reports
research series published by the Housing Development Agency
WESTERN CAPE research report
The Housing Development Agency (HDA)
Block A, Riviera Office Park,
6 – 10 Riviera Road,
Killarney, Johannesburg
PO Box 3209, Houghton,
South Africa 2041
Tel: +27 11 544 1000
Fax: +27 11 544 1006/7
Acknowledgements
• Eighty 20
Disclaimer
Reasonable care has been taken in the preparation
of this report. The information contained herein
has been derived from sources believed to be
accurate and reliable. The Housing Development
Agency does not assume responsibility for any
error, omission or opinion contained herein,
including but not limited to any decisions made
based on the content of this report.
© The Housing Development Agency 2012
page 1
WESTERN CAPE research report
Contents
Part 1: Introduction 4
Part 2: Data sources 5
2.1 Survey and Census data 5
2.2 Other Data from Stats SA 9
2.3 National Department of Human Settlements (NDHS) and LaPsis 9
2.4 Eskom’s Spot Building Count (also known as the Eskom Dwelling Layer) 9
2.5 Community Organisation Resource Centre (CORC) 10
2.6 Provincial data: Western Cape 11
2.7 Municipal data: City of Cape Town 11
Part 3: The number and size of informal settlements in
the Western Cape 14
3.1 Estimating the number of households who live in informal settlements 14
3.2 Estimating the number of informal settlements 17
Part 4: Profiling informal settlements in the Western Cape 19
4.1 Basic living conditions and access to services 19
4.2 Profile of households and families 21
4.3 Income, expenditure and other indicators of wellbeing 22
4.3.1 Income 22
4.3.2 Expenditure 23
4.4 Age of settlements and permanence 23
4.5 Housing waiting lists and subsidy housing 26
4.6 Health and vulnerability 26
4.7 Education 28page 2
WESTERN CAPE research report
Contents
Part 5: Profiling informal settlements in the City of Cape Town 29
5.1 Basic living conditions and access to services 29
5.2 Profile of households and families 31
5.3 Employment 31
5.4 Age of settlements and permanence 32
5.5 Education 32
Part 6: Conclusions 33
Part 7: Contacts and references 34
Part 8: Appendix: Statistics South Africa surveys 35
8.1 Community Survey 2007 35
8.2 General Household Survey 35
8.3 Income and Expenditure Survey 2005/6 36
8.4 Census 2001 36
8.5 Enumerator Areas 36page 3
WESTERN CAPE research report
List of abbreviations
CORC Community Organisation Resource Centre
EA Enumeration Area
GHS General Household Survey
GIS Geographical Information Systems
GTI GeoTerraImage
HDA Housing Development Agency
HH Households
IES Income and Expenditure Survey
LaPsis Land and Property Spatial Information System
NDHS National Department of Human Settlements
PSU Primary Sampling Unit
Stats SA Statistics South Africapage 4
WESTERN CAPE research report
part 1
Introduction
In terms of the HDA Act No. 23, 20081, the Housing Development Agency (HDA), is mandated
to assist organs of State with the upgrading of informal settlements. The HDA therefore
commissioned this study to investigate the availability of data and to analyse this data relating to
the profile, status and trends in informal settlements in South Africa, nationally and provincially
as well as for some of the larger municipalities. This report summarises available data for the
Western Cape province.
1
The HDA Act No.23, 2008, Section 7 (1) k.page 5
WESTERN CAPE research report
part 2
Data sources
A number of data sources have been used for this study. These include household level data from
the 2001 Census and a range of nationally representative household surveys. Settlement level
data was also reviewed, including data from the City of Cape Town, various national data sources
including the National Department of Human Settlements, the Housing Development Agency
and Eskom as well as provisional data based on a recent study commissioned by the province.
There is no single standard definition of an informal settlement across data sources, nor is there
alignment across data sources with regard to the demarcation of settlement areas. It is therefore
expected that estimates generated by various data sources will differ.
It is critical when using data to be aware of its derivation and any potential biases or weaknesses
within the data. Each data source is therefore discussed briefly and any issues pertaining to the
data are highlighted. A more detailed discussion on data sources is provided in the national report
on informal settlements prepared for the HDA.
2.1 Survey and Census data
Household-level data for this report was drawn from various nationally representative surveys
conducted by Statistics South Africa including 2007 Community Survey (CS)2, the General
Household Survey (GHS) from 2002 to 2009 and the 2005/6 Income and Expenditure Survey
(IES)3. In addition, the study reviewed data from the 2001 Census4.
The census defines an informal settlement as ‘An unplanned settlement on land which has not
been surveyed or proclaimed as residential, consisting mainly of informal dwellings (shacks)’.
In turn, the census defines an ‘informal dwelling’ as: ‘A makeshift structure not erected according
to approved architectural plans’. In the 2001 Census all residential Enumeration Areas (EAs)5
are categorised as one of Informal Settlements, Urban Settlements, Tribal Settlements or Farms.
In addition, dwellings are categorised as either formal dwellings6 or informal dwellings, including
shacks not in backyards, shacks in backyards and traditional dwellings. There are therefore two
potential indicators in the 2001 Census that can be used to identify households who live in
informal settlements, one based on enumeration area (Informal Settlement EA) and the other
based on the type of dwelling (shack not in backyard).
2
T he Community Survey is a nationally representative, large-scale household survey. It provides demographic and socio-economic information such as
the extent of poor households, access to facilities and services, levels of employment/unemployment at national, provincial and municipal level.
3
The Income and Expenditure Survey was conducted by Statistics South Africa (Stats SA) between September 2005 and August 2006 (IES
2005/2006). It is based on the diary method of capture and was the first of its kind to be conducted by Stats SA.
4
The Census data is available for all SA households; where more detail is required the 10% sample of this data set is used. Choice of data set is
highlighted where applicable.
5
An EA is the smallest piece of land into which the country is divided for enumeration, of a size suitable for one fieldworker in an allocated period
of time. EA type is then the classification of EAs according to specific criteria which profiles land use and human settlement in an area.
6
Formal dwellings include house or brick structure on a separate stand, flat in a block of flats, town/cluster/semi-detached house, house/flat/room
in backyard and a room/flatlet on a shared property.page 6
WESTERN CAPE research report
According to the 2001 Census, 143,000 households in the Western Cape (12% of households)
lived in an informal dwelling or shack not in a backyard in 2001 while 117,000 households (10%
of households) lived in enumeration areas that are characterised as Informal Settlements. Just
over 92,000 households lived in both.
cha rt 1
Cross-over of Type of Dwelling and Enumeration Area: western cape
Total households who live in an informal settlement
OR in a shack not in a backyard: 167 250
Main
dwelling:
EA: Informal 92 404 Informal
Settlement dwelling/
116 944 (8% of WC shack not in
households) backyard
(10% of WC 142 709
households)
(12% of WC
households)
79% of households who live in EAs classified as Informal
Settlements, live in shacks not in backyards
63% of households who live in shacks not in backyards,
live in EAs classified as Informal Settlement
Source: Census 2001.
Unlike census data, survey data does not provide an EA descriptor. However, surveys do provide
an indication of dwelling types, aligned with the main categories defined in the census. In the
absence of an EA descriptor for informal settlements, the analysis of survey data relies on a
proxy indicator based dwelling type, namely those who live in an ‘Informal dwelling/shack, not in
backyard e.g. in an informal/squatter settlement’.
Census data can provide an indication of the suitability of this proxy. According to the Census, of
those households in the Western Cape who live in EAs categorised as Informal Settlements, 79%
live in shacks not in backyards. A further 10% of households in these EAs live in formal dwellings,
6% live in shacks in backyards (it is not clear whether the primary dwelling on the property is itself
a shack) and 4% live in traditional dwellings.
Conversely the data indicates that 35% of all households in the Western Cape who live in shacks
not in a backyard do not, in fact, live in EAs categorised as Informal Settlements. 32% live in EAs
categorised as Urban Settlements and 1% live in Farm EAs.page 7
WESTERN CAPE research report
cha rt 2
Breakdowns of Type of Dwelling and Enumeration Area: western cape
Housing type breakdown for EA breakdown for shacks
Informal Settlement EAs not in backyards
(Western Cape) (Western Cape)
Shack not Informal
in backyard Formal settlement
79% dwelling 65% Urban
10% settlement
32%
Shack in backyard 6%
Traditional dwelling 4%
Other 2%
Other areas 2%
Farm 1%
Source: Census 2001.
Note: Formal dwelling includes flat in a block of flats, dwelling on a separate stand, backyard dwelling, room/flatlet,
and town/cluster/semi-detached house.
The analysis based on surveys using the dwelling type indicator ‘shack not in backyard’ to identify
households who live in informal settlements should therefore be regarded as indicative as there is
insufficient data in the surveys to determine whether these households do, in fact, live in informal
settlements as defined by the census, or by local or provincial authorities.
A further challenge with regard to survey data relates to the sampling frame. In cases where
survey sample EAs are selected at random from the Census 2001 frame, newly created or rapidly
growing settlements will be under-represented. Given the nature of settlement patterns, informal
settlements are arguably the most likely to be under-sampled, resulting in an under-count of
the number of households who live in an informal settlement. Further, if there is a relationship
between the socio-economic conditions of households who live in informal settlements and the
age of the settlement (as it seems plausible there will be) a reliance on survey data where there is
a natural bias towards older settlements will result in an inaccurate representation of the general
conditions of households who live in informal settlements. This limitation is particularly important
when exploring issues relating to length of stay, forms of tenure and access to services. A second
word of caution is therefore in order: survey data that is presented may under-count households
in informal settlements and is likely to have a bias towards older, more established settlements.
An additional consideration relates to sample sizes. While the surveys have relatively large sample
sizes, the analysis is by and large restricted to households who live in shacks not in backyards,
reducing the applicable sample size significantly. Analysis of the data by province or other
demographic indicator further reduces the sample size. In some cases the resulting sample can be
too small for analysis. In most cases this is not true for the Western Cape.page 8
WESTERN CAPE research report
tab le 1
Sample sizes in the different surveys
Census 2001 Community Income and General
Survey 2007 Expenditure Household
Survey 2005/6 Survey 2009
Total Total Households Total Sample Total Sample Total Sample
number of number of living in survey size for survey size for survey size for
households households informal sample households sample households sample households
living in settlement size living in size living in size living in
shacks EAs shacks shacks shacks
not in a not in a not in a not in a
backyard backyard backyard backyard
Western 1 211 485 142 709 116 944 26 425 2 106 2 404 186 2 530 243
Cape
City of Cape 778 696 110 148 89 126 14 318 1 484
Town
Source: Census 2001 (10% sample), Community Survey 2007, IES 2005/6, GHS 2009; Household databases.
A final consideration relates to the underlying unit of analysis. Survey and census data sources
characterise individuals or households rather than individual settlements. These data sources
provide estimates of the population who live in informal settlements as well as indications of
their living conditions. The data as it is released cannot provide an overview of the size, growth
or conditions at a settlement level7 although it is possible to explore household-level data at
provincial and municipal level depending on the data source and sample size.
The definition of a household is critical in understanding household level data. By and large
household surveys define a household as a group of people who share a dwelling and financial
resources. According to Statistics SA ‘A household consists of a single person or a group of people
who live together for at least four nights a week, who eat from the same pot and who share
resources’. Using this definition, it is clear that a household count may not necessarily correspond
to a dwelling count; there may be more than one household living in a dwelling. Likewise a
household may occupy more than one dwelling structure.
From the perspective of household members themselves the dwelling-based household unit may
be incomplete. Household members who share financial resources and who regard the dwelling
unit as ‘home’ may reside elsewhere. In addition, those who live in a dwelling and share resources
may not do so out of choice. Household formation is shaped by many factors, including housing
availability. If alternative housing options were available the household might reconstitute itself
into more than one household. Thus, while the survey definition of a household may accurately
describe the interactions between people who share a dwelling and share financial resources for
some or even most households, in other cases it may not. The surveys themselves do not enable
an interrogation of this directly.
7
It may be possible for Statistics South Africa to match EA level data from the 2001 Census to settlements to provide an overview of specific
settlements. Given that the Census data is ten years old, and that conditions in informal settlements are likely to have changed significantly since
then, the feasibility of this analysis was not established.page 9
WESTERN CAPE research report
2.2 Other data from Stats SA
A dwelling frame count was provided by Stats SA for the upcoming 2011 Census. The Dwelling
Frame is a register of the spatial location (physical address, geographic coordinates, and place
name) of dwelling units and other structures in the country8. It has been collated since 2005
and is approximately 70% complete. The Dwelling Frame is used to demarcate EAs for the 2011
Census9.
There are 153 sub-places in the Western Cape with at least one EA classified as ‘Informal
Residential’10, totalling 729 EAs (covering a total area of 26.56 square kilometres). There are
Dwelling Frame estimates for 122 (80%) of these ‘Informal Residential’ EAs, totalling 50,660
Dwelling Frames. Since the Dwelling Frame is only approximately 70% complete, and not all units
are counted within certain dwelling types, the count should not be seen as the official count of
dwellings or households within the EA Type.
2.3 National Department of Human Settlements
(NDHS) and LaPsis
The 2009/2010 Informal Settlement Atlas compiled by the NDHS indicates there are 201 informal
settlement polygons in the Western Cape. No household estimates are provided.
LaPsis (Land and Property spatial information system), an online system developed by the
HDA, builds on the data gathered by the NDHS and overlays onto it land and property data
including cadastre, ownership, title documents and deeds (from the Deeds Office), administrative
boundaries (from the Demarcation Board) and points of interest from service providers such as
AfriGIS11. The data indicates there are 189 informal settlements in the Western Cape; 51 of these
have a households and shack count.
2.4 Eskom’s Spot Building Count (also known as
the Eskom Dwelling Layer)
Eskom has mapped and classified structures in South Africa using image interpretation and manual
digitisation of high resolution satellite imagery. Where settlements are too dense to determine
the number of structures these areas are categorised as dense informal settlements. Identifiable
dwellings and building structures are mapped by points while dense informal settlements are
mapped by polygons.
Shape files provided by Eskom revealed 234 polygons categorised as Dense Informal Settlements
in the Western Cape, covering a total area of 17 square kilometres. The dataset does not
characterise the areas, nor does it match areas to known settlements. Latest available data is
based on 2008 imagery. Eskom is currently in the process of mapping 2009 imagery and plans to
have mapped 2010 imagery by the end of the year.
8
Bhekani Khumalo (2009), ‘The Dwelling Frame project as a tool of achieving socially-friendly Enumeration Areas‘ boundaries for Census 2011,
South Africa’, Statistics South Africa.
9
A
n EA is the smallest piece of land into which the country is divided for enumeration, of a size suitable for one fieldworker in an allocated period
of time. EA type is then the classification of EAs according to specific criteria which profiles land use and human settlement in an area.
10
The EA descriptor for informal settlements in the 2011 Census is ‘Informal Residential’; in 2001 the EA type was ‘Informal Settlement.’
AfriGIS was given informal settlements data by the provincial departments of housing to create the map layers.
11 page 10
WESTERN CAPE research report
2.5 Community Organisation Resource Centre
(CORC)
CORC is an NGO that operates in all provinces across the country, with the aim of providing
support to ‘networks of communities to mobilise themselves around their own resources and
capacities’12. In order to provide a fact base to enable communities to develop a strategy and
negotiate with the State with regard to service provision and upgrading, CORC profiles informal
settlements and undertakes household surveys. These surveys have been conducted in areas across
the country by community members in these settlements. Community members are trained by
CORC and are provided with a basic stipend to enable them to do their work. Improvements are
made to questionnaires using community consultation and professional verification. This ensures
that comprehensive and relevant data is collected. CORC also gathers other settlement level
data on service provision including the number and type of toilets and taps. A list of settlements
that have been enumerated recently in the Western Cape is summarised below, together with
household and population estimates.
tab l e 2
Enumeration of informal settlements by CORC in the Western Cape
Name of Region Date Number of Population
settlement households
Joe Slovo City of Cape Town May 2009 2 748 7 946
Doornbach City of Cape Town September 2009 1 855 4 555
Manenberg City of Cape Town December 2009 3 139 1 322
Sheffield Road City of Cape Town December 2009 149 504
TT Section City of Cape Town February 2010 272 995
Barcelona City of Cape Town March 2010 2 230 6 600
Europe City of Cape Town October 2010 1 832 5 125
Los Angeles City of Cape Town November 2010 325 876
Shukushukuma City of Cape Town February 2011 306 718
Garden City City of Cape Town February 2011 317 753
lungrug Stellenbosch February 2011 1 876 4 088
la Rochelle Stellenbosch February 2011 25 100
Schoopiehoegte Stellenbosch February 2011 19 79
Devon valley Stellenbosch February 2011 10 15
Gif Stellenbosch February 2011 17 41
Kylmore Stellenbosch February 2011 9 26
Meerlust Stellenbosch February 2011 10 25
12
See http://www.sasdialliance.org.za/about-corc/page 11
WESTERN CAPE research report
2.6 Provincial data: Western Cape
The Western Cape Department of Human Settlements has commissioned a study of informal
settlements in the province, excluding the City of Cape Town. While findings are provisional and
unpublished, that data indicates there are 51,224 shacks spread across 230 informal settlements as
summarised below.
tab le 3
Informal settlements in the Western Cape (excl. City of Cape Town)
Number of informal Number of informal dwellings
settlements in informal settlements
Cape Winelands 72 21 652
Central Karoo 1 17
Eden 107 14 035
Overberg 35 8 787
West Coast 15 6 733
Total (excl. City of Cape Town) 230 51 224
Source: Western Cape Department of Human Settlements.
2.7 Municipal data: City of Cape Town
The City recently published a report estimating the number of households living in informal
settlements in the City of Cape Town Metropolitan Municipality13. The report uses the 2001
Census count of 110,000 as a baseline14 and applies a growth rate of 6% per annum to arrive at
a current estimate of 174,000 households who live in informal settlements in 2009. Various data
sources were used to derive this growth rate including historic rates of growth as per the 1996
and 2001 censuses, growth rates from the General Household Survey (various years), as well as
estimates based on aerial photography and physical dwelling counts done by the Solid Waste
Department as part of its area cleaning program. Projected figures determined by PDG for 2010
to 2019 have also been used. The official estimate of the number of households living in informal
settlements is summarised on the following page:
13
ity of Cape Town (2010), Strategic Development Information and GIS Department, Estimated Number of Households Living in Informal
C
Settlements, Karen Small.
14
110,000 represents those households living in shacks not in backyards. Note that according to the Census there were 89 126 households living
in EAs classified as Informal Settlement EAs in the City of Cape Town.page 12
WESTERN CAPE research report
cha rt 3
Estimated number of households in informal settlements:
City of Cape Town
Estimated Estimated
number of annual
households growth
(000s) rate %
6.0%
300 – – 6%
260
251
242
250 – 233 – 5%
4.6% 206 224
4.5% 215
4.4% 4.3%
4.2% 4.1%
200 – 190 198 4.0% – 4%
181 3.9% 3.8%
174 3.7%
150 – – 3%
110
103
100 – – 2%
50 – – 1%
0– –0
1996 2001 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019
Estimated number of households (000s) Estimated annual growth rate %
Source: City of Cape Town (2010), Strategic Development Information and GIS Department, Estimated Number of Households
Living in Informal Settlements, Karen Small.
Note: Assumption that one informal dwelling is occupied by one household.
These figures are used across the City for planning purposes whenever the unit of analysis is the
household. However, in the case of provision of services (such as water and sanitation) household
counts or estimates are not used as these services are delivered to consumer units or delivery points
and not directly to households. For this reason an estimate of the number of informal dwellings or
shacks in the City is also important.
A report entitled ‘Informal Dwelling Count for Cape Town15 (1993 – 2005)’ is currently being updated
based on shack counts from aerial photography. The City of Cape Town’s Corporate GIS branch
(within the Information and Knowledge Management Department) has been responsible for these
shack counts since 2002. The Department commissioned the aerial photography and was responsible
for ortho-rectification16. At present the GIS department has informal shack count data up to June
2008 (see chart below). These 2008 shack counts will be incorporated into the updated report, due
to be released at the end of June 2011. A new shack count is currently underway using November
2009 aerial photography, to be completed in 201117. The GIS department completed new aerial
photography in March 2011. It will take a few months to deliver the rectified imagery; once this is
complete they will then immediately start the shack counting process again based on the March 2011
imagery18.
15
ity of Cape Town (2006), Information and Knowledge Management Department, Strategic Information Branch, Informal Dwelling Count for
C
Cape Town (1993-2005), Elvira Rodriques, Janet Gie and Craig Haskins.
Ortho-rectification is the process of geometrically correcting an aerial photograph so that distances are uniform and the photograph can be
16
measured like a map.
17
As at the end of May, the GIS department was still in the process of comparing and reconciling their results with other departments.
18
The 2009 imagery was flown at a 15cm resolution and the 2011 imagery was flown at a 10-12cm resolution which will be very accurate.page 13
WESTERN CAPE research report
Shack counts are done using the Feature Analyst software, an automated process with around 80%
success rate, leaving a 20% count to be done manually (a point is captured on every shack)19. It is
noteworthy that the shack count estimates differ noticeably from the household count estimates
summarised above. Shack counts are generally an undercount due to the difficulty of determining
boundaries of every structure particularly when they are built right next to each other and are located
under vegetation.
cha rt 4
Shack counts based on aerial imagery: City of Cape Town
Number
of shacks
(000s)
140 – 134
120 – 116
109
104
97 95 98
100 –
84
80 –
60 –
40 –
20 –
0–
2002 Feb 2003 Jul 2004 Jan 2005 Dec 2006 Jun 2007 Jan 2007 Sep 2008 Jun
Year/month
Source: City of Cape Town.
The City of Cape Town is currently developing a GIS Informal Settlement project. The purpose of this
project is to collate the numerous sources of data relating to informal settlements available to the
City (including shack counts from aerial photography, physical dwelling counts, and survey household
estimates) and to develop more up-to-date, reliable household and dwelling figures.
Each department involved in the project will collect and capture their own data sets, before sending
the data to the Corporate GIS branch to ensure all the standards have been adhered to. All data sets
will have Meta Data attached and will include the following:
• Settlement name
• Settlement boundaries
• Number of settlements
• Number of shacks per settlement
• Number of doors per settlement needed for refuse collection
• All utility services such as stand pipes, number of toilets, water pipes
• Health data
• Number of households
There will also be reports of previous studies done in specific settlements. The project is expected to
be completed by December of this year (2011).
To determine whether an informal settlement is serviced or not, the GIS branch uses a cadastral overlay which incorporates property ownership,
19
road networks and so on. This information is then verified with the City‘s service departments.page 14
WESTERN CAPE research report
Part 3
The number and size of
informal settlements in
the Western Cape
3.1 Estimating the number of households who live
in informal settlements
According to the Census, 117,000 households in the Western Cape (10% of households in the
province) lived in EAs classified as Informal Settlements in 200120. 78% lived in enumeration
areas classified as Urban Settlements and a further 9% in EAs classified as Farms. Western Cape
accounts for 11% of all households in informal settlement EAs in the country (it accounts for
10% of all households overall).
Census data at a municipal level is summarised below for Western Cape.
tab le 3
4
Households living in Informal Settlement EAs in the Western Cape
Municipality Number of HH in Informal % of HH in municipality/
Settlement EAs province that live in Informal
Settlement EAs
Cape Winelands 10 889 6.8%
(formerly Boland)
Central Karoo 0 0%
City of Cape Town 89 126 11.4%
Eden 9 512 7.9%
Overberg 4 972 8.5%
West Coast 2 445 3.1%
Western Cape 116 944 9.7%
Source: Census 2001.
According to the 2007 Community Survey, 110,000 households (approximately 8% of households
in the Western Cape) live in shacks not in backyards, down from 143,000 households (12%
of households) in 2001 as reported by the Census. In terms of absolute numbers there was
a decrease of around 33,000 in the number of households living in shacks not in backyards
between 2001 and 2007.
20
With regards to settlement type, Informal Settlement is one of the ten EA descriptors used.page 15
WESTERN CAPE research report
According to the 2007 Community Survey 9% of households in shacks not in backyards live in
this province (11% of all households in the country live in this province).
Survey-based estimates of the number of households who live in shacks not in backyards vary,
sometimes quite significantly. For instance, in 2007 the Community Survey estimates around
110,000 households living in shacks not in backyards in the Western Cape while the 2007 GHS
estimates around 143,000 such households. Estimates based on the GHS indicate an annual
growth of 2% between 2002 and 2009, while estimates based on the Census and Community
Survey indicate an annual growth of -4% between 2001 and 2007. A comparison of data from
the census and various surveys is summarised below.
chart 5
Households by dwelling type: western cape
Number of
households
(000s)
1 600 – – 1 600
1 478
1 428
1 369 1 379 – 1 400
1 400 – 1 286 1 333 3%
2% 1 272
1 209 1 244
1 166 1 204 – 1 200
1 200 –
300 – – 300
200 – – 200
100 – – 100
143 110 -4% 118 170 125 148 143 143 124 134 2% 148
12% 8% 10% 14% 10% 12% 11% 10% 9% 9% 12%
0– –0
Census CS GHS GHS GHS GHS GHS GHS GHS GHS IES
2001 2007 2002 2003 2004 2005 2006 2007 2008 2009 2005/6
2001: Number of households in Informal Settlement EAs: 116 944 (10%)
Total households
HH lives in shack not in backyard
Source: Census 2001 (full database), Community Survey 2007, IES 2005/6, GHS 2002-2009 (reweighted) .
Note: Dashed line indicates new sample designs for GHS (2002-2004, 2005-2007, 2008-2009).page 16
WESTERN CAPE research report
According to the 2007 Community Survey, at 84,000 the City of Cape Town has the highest
number of households living in shacks not in backyards in the Western Cape. The chart below
summarises municipal-level data for all shacks, including those not in backyards and those in
backyards.
chart 6
Households living in shacks (by municipality): western cape
Shack not in backyard Shack in backyard
% of HH living in shacks not in backyard % of HH living in shacks not in backyard
9% 9% 5% 5% 2% 1% 6% 9% 5% 5% 3% 1%
Number of Number of
households households
(000s) (000s)
90 – 60 –
84 56
80 –
50 –
70 –
60 – 40 –
50 –
30 –
40 –
30 – 20 –
13
20 –
12 10 – 9
10 – 9
3 3
3
1 0 0
0– 0–
City of Cape West City of Cape West
Cape Town Winelands Coast Cape Town Winelands Coast
Eden Overberg Central Eden Overberg Central
Karoo* Karoo*
Source: Community Survey 2007 HH.
* Sample size is less than 40.page 17
WESTERN CAPE research report
Data from the 2001 Census and the 2007 Community Survey can be used to explore growth rates
for households living in shacks at a municipal level. This data is summarised in the bubble chart
below. The size of the bubble indicates the size of the segment in 2007 while its location along
the x-axis indicates the annual rate of growth. Of course in some of these areas high growth has
occurred off a very low base. It is of interest that in most areas, growth rates for backyard shacks
far exceeds that of shacks not in backyards. While this may reflect increased official determination
to prevent the expansion of informal settlements it may also reflect sampling biases; new informal
settlements may not have been surveyed in 2007.
chart 7
Households living in shacks (by municipality) – CAGR: western cape
Compound annual growth (2001 -2007)
(Household lives in a shack not in a backyard, household lives in a shack in a backyard, Western Cape)
City of Cape Town
56 306
9%
City of Cape Town Eden
84 300 12 318 Overberg
-4% 1% 2 833
West 7%
Coast
1 293 Eden
Central
-9% Karoo* 12 919
107 24%
-1% Cape
Cape Winelands
Overberg West
Winelands 9 493
3 259 Central Coast
8 785 7%
-10% Karoo* 2 644
-6%
152 2%
-3%
-9% -6% -3% 0% 3% 6% 9% 24%
HH lives in shack not in backyard HH lives in backyard shack
Source: Census 2001 and Community Survey 2007.
Note: 2005 provincial borders have been used.
Note: CAGR = Compound Annual Growth Rate (between 2001 and 2007).
*Sample size is less than 40
3.2 Estimating the number of informal settlements
While survey and census data provide an estimate based on households, various data sources
provide estimates of the number of informal settlements. The LaPsis data estimates 189 informal
settlements across the province while the Atlas data set from the NDHS indicates 201 informal
settlement polygons. Provisional research from the Western Cape Department of Human
Settlements indicates 230 settlements, excluding the City of Cape Town.
Available data sources at a ‘settlement’ level are summarised below together with household
level data based on the 2001 Census and the 2007 Community Survey. Note that settlements are
identified and defined differently in these data sources.page 18
WESTERN CAPE research report
tabl e 5
Estimates and/or counts of informal settlements and households
Number of informal settlements Number of households in informal Number of shacks in
settlements informal settlements
LaPsis: Atlas: Stats SA: Eskom: Provincial Municipal Census Census Community Municipal Provincial Municipal
Informal Informal Sub places Polygons estimates estimates 2001: HH 2001: HH Survey 2007: estimates estimates estimates
settlements settlement with at least classified in informal in shacks HH in shacks
polygons one EA as ‘Dense settlement not in not in back-
classified as Informal’ EAs backyards yards
‘Informal
Residential’
Cape - 30 72 10 889 12 381 8 785 21 652
Winelands
Central - 1 0 113 107 17
Karoo
City of 139 139 298 89 126 110 148 84 300 173 600 134 055
Cape Town
Eden 16 25 107 9 512 11 850 12 318 14 035
Overberg 31 3 35 4 972 5 923 3 259 8 787
West Coast 3 4 15 2 445 2 294 1 293 6 733
Western 189 201 153 234 230 116 944 142 709 110 062 51 224
Cape
* Households in informal settlements to be upgraded between 2010/11 and 2013/14 (Outcome 821): 45,360 in Western Cape.
Note: Provincial estimates from the Western Cape exclude the City of Cape Town.
While both LaPsis and Atlas databases rely on provincial data and should therefore be aligned with
provincial estimates, there are often differences. For instance, the City of Cape Town estimates 298
informal settlements while both LaPsis and Atlas reflect 139 in this municipality. The City of Cape
Town estimates 174,000 households living in informal settlements while the 2007 Community
Survey indicates 84,000 households living in shacks not in backyards and the 2001 Census reflects
89,000 households living in enumeration areas classified as informal settlements.
These differences most probably arise as a result of different data currency; provincial or municipal
estimates may have been collated more recently than national estimates. Variances may also
reflect a lack of alignment regarding the definition of an informal settlement as well as different
data collection methodologies.
Outcome 8 relates to Sustainable Human Settlements and Improved Quality of Life. National government has agreed on twelve outcomes as a
21
key focus of work between 2010/11 and 2013/14.page 19
WESTERN CAPE research report
Part 4
Profiling informal
settlements in the
Western Cape
The analysis of survey data investigates the characteristics of the dwellings and the profile of
households and individuals living in shacks not in backyards. As noted this variable is a proxy
for households who live in informal settlements. Where available, Census 2001 data relating
to households who live in Informal Settlement EAs has been summarised in the introductory
comments at the start of each sub-chapter.
4.1 Basic living conditions and access to services
In 2001, 16% of Western Cape households living in informal settlement EAs had piped water
in their dwelling or on their yard. A further 39% could obtain piped water within 200 metres
of their dwellings. 38% had access to piped water in excess of 200 metres from their dwellings
(there is no indication of how far away the water source is) while 6% had no access at all. 23% of
households in informal settlement EAs had flush toilets, 6% used pit latrines, 26% used bucket
latrines and 1% had chemical toilets; the remaining 44% had no access to toilet facilities. 31%
of households in informal settlement EAs used electricity for lighting and 75% had their refuse
removed by the local authority.page 20
WESTERN CAPE research report
Key trends relating to access to services for households living in shacks not in backyards are
summarised in the chart below.
cha rt 8
Access to services: Household lives in shack not in
backyard in western cape
Toilet facility Source of drinking water
% %
100 – 100 –
4%
9%
6% 1%
28%
80 – 38% 80 – 19%
24%
5%
4%
60 – 1%
4% 60 –
21%
20%
40 – 40 –
66% 71%
20 – 36% 42%
20 –
0– 0–
Census Community Census Community
2001 Survey 2007 2001 Survey 2007
Flush Piped water in dwelling
Bucket latrine Other**
Pit latrine Piped water in yard
Other* Piped water on community stand
None
Energy used for lighting Refuse collection
% %
100 – 1% 1% 100 – 4% 4%
12% 8% 5% 9%
8%
7%
80 – 80 – 8%
8%
42%
56%
60 – 60 –
40 – 40 – 75%
73%
20 – 45% 20 –
35%
0– 0–
Census Community Census Community
2001 Survey 2007 2001 Survey 2007
Paraffin Removed by local authority less often
Electricity Communal refuse dump
Candles No rubbish disposal
Other*** Own refuse dump
Removed by local authority at least
once a week
Source: Census 2001 and Community Survey 2007 HH.
* Other toilet facilities includes Chemical toilet and Dry toilet facility.
** Other water source incudes Borehole, Flowing water, Stagnant water, Well, Spring and Other.
*** Other energy sources includes Gas, Solar and Other.
Note: In the 2007 CS, refuse removed by local authority also includes refuse removed by private company.page 21
WESTERN CAPE research report
Access to services appears to have improved between 2001 and 2007; the proportion of
households who live in shacks not in backyards who say they have no toilet facilities declined from
38% in 2001 to 28% in 2007. Drinking water access improved slightly while use of electricity for
lighting increased from 42% to 56% between 2001 and 2007.
As has been highlighted, a word of caution is required in interpreting this data given potential
biases in the sample design towards more established settlements where service provision is
better.
4.2 Profile of households and families
In 2001, 26% of Western Cape households living in informal settlement EAs were single person
households. The average household size was 3.0. 19% of households were living in over-crowded
conditions. The majority of households were headed by males (64%).
According to the 2007 Community Survey, 18% of households living in shacks not in backyards
comprise a single individual. While significant, it is lower than the national average for households
living in shacks not in backyards where 23% comprise a single individual. According to the
Community Survey 41% of Western Cape households living in shacks not in backyards comprise
four or more persons. The average household size of households living in shacks not in backyards
in 2007 is 3.4 (in 2001 this was 3.2), compared to 3.8 in 2007 for those living in formal dwellings
(up from 3.7 in 2001). 23% of households living in shacks not in backyards live in over-crowded
conditions22.
Household heads in the Western Cape in shacks not in backyards are also noticeably younger
than those in formal dwellings; 48% are under the age of 35 compared to 18% in households
who live in formal dwellings.
132,000 children under the age of 18 live in shacks not in backyards corresponding to 36% of
the total Western Cape population who live in such dwellings. According to the Community
Survey 57% of households in shacks not in backyards have one or more children.
Data from the GHS can be used to explore the relationships between household members in more
detail. While the Community Survey finds that 18% of households are single person households
as noted above, the 2009 GHS indicates that roughly 29% of households living in shacks not
in backyards comprise single persons. That survey indicates that 22% of households living in
shacks not in backyards are nuclear families comprising a household head, his or her spouse and
children only. Single parent households, at 5% of households in shacks not in backyards, are not
particularly noticeable. 37% of households who live in shacks not in backyards contain extended
family members or unrelated individuals23. According to the GHS, the average household size for
shacks not in backyards has steadily decreased from 3.5 in 2005 to 3.0 in 2009.
22
household is considered over-crowded if there are more than two people per room. It is possible that this estimate is understated in the case
A
where more than one household inhabits the same dwelling.
23
Compared to Western Cape households who live in formal housing, the household composition of households in shacks not in backyards differs
most noticeably with respect to single person households and households that contain nuclear families. 30% of Western Cape households
in formal dwellings comprise a nuclear family while 18% comprise a single individual. 30% comprise extended family members or unrelated
individuals and 9% single parents – statistics which are not very different from those relating to households living in shacks not in backyards.page 22
WESTERN CAPE research report
4.3 Income, expenditure and other indicators of
wellbeing
4.3.1 Income
While both the 2001 Census and the 2007 Community Survey gather some data on income, the
quality of this data is relatively poor. A far more reliable source of this data is the 2005/6 Income
and Expenditure Survey (IES). That data source indicates that 84% of Western Cape households
who live in shacks not in backyards have a household income of less than R3,500 per month
measured in 2006 Rand terms. Inflating incomes to 2010 Rands (and assuming no real shift in
income) 72% of households living in shacks not in backyards earn less than R3,500 per month
in 2010 Rand terms.
As expected, the survey indicates that the proportion of households living in shacks not in
backyards declines as incomes increase. Around one in five of all households earning less than
R3,500 (in 2006 Rands) live in shacks not in backyards.
ch a rt 9
Proportion of shacks not in backyards
by income: western cape
% of
households
25 –
22%
20%
20 –
15 –
10 –
5– 4%
0–page 23
WESTERN CAPE research report
4.3.2 Expenditure
According to the IES, the proportion of households living in shacks not in backyards that transfer
maintenance or remittances26 at 47% is well above the average for Western Cape households as
a whole (24%)27.
4.4 Age of settlements and permanence
In 2001, the majority of households living in informal settlement EAs in the Western Cape (65%)
were living there five years previously. In 2001, 29% of households living in informal settlement
EAs claimed to own their dwelling; 9% rented and 61% occupied the dwelling rent-free. 12% of
households in informal settlement EAs had another dwelling aside from their main dwelling.
Analysis of data from the 2007 Community Survey indicates that the majority of people living in
a shack not in a backyard in 2007 had been living there for an extended period of time. Across
the province, 67% said they had not moved since 2001. Of those who said they had moved
since 2001, 59% moved from within the province and 36% moved from the Eastern Cape.
Cross province migration into the Western Cape is far more noticeable than in other provinces.
For instance, in the Eastern Cape, only 4% of those living in shacks not in backyards that had
moved since 2001 were from other provinces.
cha rt 1 0
Year and province moved from: western cape
Year person moved into this dwelling Province lived in before moving
(Lives in an informal dwelling/shack not in backyard, to this dwelling*
Western Cape) (Lives in an informal dwelling/shack not in
backyard, moved in after 2001, Western Cape)
LP
Outside RSA
2% 0%
1%
5% GA MP
NW
2% 0%
67% 4% 0%
3% FS
0% KZN
6% NC
1%
0%
13%
EC
36%
WC
2007 2001-2003 59%
2006 Born after October 2001
2005 Have not moved since October 2001
2004 Source: Community Survey 2007 Persons.
Note*: Sample sizes for some provinces less than 40.
According to the 2009 GHS, 96% of Western Cape households living in shacks not in backyards
indicate that they were living in a shack not in backyard five years previously28. The survey does
not indicate whether the dwelling or the broad location of the dwelling is the same.
There may be some basis for a degree of scepticism when looking at this data. As noted in the
overview of data sources, there may well be a sampling bias towards older, more established
settlements. In addition, if households in informal settlements believe there is a link between the
duration of their stay in that settlement and their rights either to remain in the settlement or to
26
Both cash and in kind payments.
27
For single person households living in shacks not in backyards in the Western Cape, this proportion is 70%.
28
For all South African households in shacks not in backyards, the proportion is 89%.page 24
WESTERN CAPE research report
benefit from any upgrading programmes they may well have an interest in over-stating the length
of time they have lived in their dwellings.
The 2009 GHS asks respondents when (i.e. in what year) their dwellings were originally built29.
The data indicates that 21% of shacks not in backyards were built within the past five years.
At first glance this would appear to be at odds with the statistic cited above that 96% of households
living in shacks not in a backyard were living in that same type of dwelling five years ago.
However, as already noted, that data does not necessarily imply the household lives in the same
dwelling, or in the same location. Further, given the poor condition of many shacks (discussed
in Section 4.6 below) and the vulnerability of many settlements to fire and flooding, it is entirely
plausible that many shacks are completely rebuilt frequently30.
The survey data indicates that shacks not in backyards tend to be older than backyard shacks
as summarised below. This corresponds to trend data relating to main dwelling types which
indicates a higher growth rate for backyard shacks compared to shacks not in a backyard.
As noted this may reflect sampling biases within the data.
cha rt 1 1
Year current dwelling was originally built: western cape
Shack not in backyard 42%
29%
21%
9%*
1940 1990 2000 2005 2009
49%
Shack in backyard
37%
11%*
4%*
1940 1990 2000 2005 2009
House/dwelling on separate stand
54%
25%
13%
4%
1940 1990 2000 2005 2009
Source: GHS 2009 HH.
Note: The survey states that if the year is not known, the best estimate should be given.
Although it is not shown here, this accounts for the very few ‘unspecified’ responses.
* Sample size small (< 40).
29
It would be unsurprising if many households, particularly those that rent their dwellings or those that occupy older dwellings, do not know
when their dwellings were constructed. In such cases, the questionnaire directs respondents to provide a best estimate. There is no indicator in
the data as to whether the household has estimated the answer or knows the answer.
30
The exact survey question is: ‘when was this dwelling originally built?’. Enumerators are instructed to ‘mark the period in which the dwelling
was completed, not the time of later remodeling, additions or conversions. If the year is not known, give the best estimate.’ It is not entirely
clear how a household who has recently rebuilt its shack following its destruction in a fire would answer the question. Does the year in which
this dwelling was originally built refer to the original dwelling or to the rebuilt dwelling?page 25
WESTERN CAPE research report
Data on tenure status can also provide an indication of permanence. The primary survey categories
include rental, ownership (with or without a mortgage or other form of finance) and rent free
occupation. Survey data on tenure from various data sources is summarised below. Broadly
speaking, data from the 2001 Census, the 2007 Community Survey and the 2009 General
Household Survey paint a similar picture. These sources indicate that while rental is relatively
uncommon for shacks not in backyards (in contrast to backyard shacks where rentals dominate),
a sizeable proportion of households say they own their dwelling.
cha rt 1 2
Dwelling tenure across different surveys: western cape
HH lives in an informal dwelling/ HH lives in an informal dwelling/
shack not in backyard: Western Cape shack in backyard: Western Cape
Total number
of households 142,709 110,062 133,952 47,784 84,346 119,421
% proportion
of households
100 – 100 –
8% 4%*
12%
80 – 80 –
43%
45% 52% 52%
53%
60 – 57% 60 –
40 – 40 – 28%
13%*
25%
45%
20 – 35% 20 –
31% 32%
28%
21%
0– 0–
Census 2001 CS 2007 GHS 2009 Census 2001 CS 2007 GHS 2009
Owned Occupied rent-free Rented
Source: Census 2001 (10% sample), Community Survey 2007, GHS 2009; Household databases.
Note: The breakdown of ownership does not include ‘Other’ due to small sample sizes.
* Sample size is less than 40.
Data on tenure status can be difficult to interpret. On the one hand those who say they own
their dwellings may be communicating a strong sense of belonging and permanence despite the
informal nature of the dwelling. On the other hand, they may have title, or official recognition.
Alternatively those who say they own their dwellings may simply be referring to their ownership
of the building materials used to construct their dwellings. While some respondents who own
the physical materials used to build their dwellings, but not the land on which it is located, may
indicate they occupy their dwellings rent free, others may justifiably indicate that they own their
shacks. Data on rentals is also difficult to interpret. Some households who say they rent their
shacks may own the building materials but rent the land; if they were to be evicted from the land
they would still retain possession of the dwelling materials. Other renter households may rent
both the structure and the land.
Ownership of other dwellings may be an indication of non-permanence and is therefore of
interest. According to the 2009 GHS, for the province as a whole, very few households (roughly
4% of households) say they have another dwelling aside from their main dwelling.page 26
WESTERN CAPE research report
4.5 Housing waiting lists and subsidy housing
According to the 2009 GHS, 48,000 (36%) of Western Cape households in shacks not in backyards
have at least one member on the waiting list for an RDP or state subsidised house. Conversely,
of the 140,000 Western Cape households with at least one member on the housing waiting list,
34% live in shacks not in backyards; 26% live in a dwelling/structure on a separate stand and
22% in a backyard shack. More than 50% of the households in shacks not in backyards have
been on the waiting list for five or more years.
Data from the 2009 GHS explores whether any household members have received a government
housing subsidy. For Western Cape households living in shacks not in backyards a very low
percentage (2%) report having received a subsidy. Of course many households living in informal
settlements that have received a subsidy are unlikely to own up to this.
Data from the same survey can be used to explore how many households who live in shacks not
in backyards might be eligible to obtain a subsidised house. Criteria include a household income
of less than R3,500 per month, a household size of more than one individual, no ownership of
another dwelling, and no previous housing subsidy received. Using these criteria, around 57,000
Western Cape households living in shacks not in backyards (42% of households in this category)
appear to qualify to be on the waiting list.
When interpreting this data it is important to recall the definition of households used in surveys.
Households are not necessarily stable units nor are they necessarily comprised of individuals who
would choose to live together if alternative accommodation was available. It is therefore plausible
that some households may reconstitute themselves if one current household member were to
obtain a subsidised house.
4.6 Health and vulnerability
The 2009 GHS indicates that approximately 11% of individuals who live in a shack not in
a backyard in the Western Cape say they have suffered from an illness or injury in the past
month. This is lower than the disease burden reported by those living in formal dwellings (18%).
Of course the subjective ‘norm’ may differ across communities. More affluent individuals living
in formal dwellings in well-serviced neighbourhoods who are generally in good health may have
a lower ‘sickness threshold’; the symptoms they experience when they report being ill may not
warrant a mention by an individual whose immunity is generally compromised. It should also
be noted that there may be an age skew; those who live in informal settlements are on average
younger. Holding other things constant, one should therefore expect a lower burden of disease
for those living in shacks not in backyards.
Those living in shacks not in backyards are more likely than those who live in formal dwellings
to use public clinics as their primary source of medical help. About 81% walk to their medical
facility and almost everyone takes less than 30 minutes to get there using their usual means of
transport (93%). This is not noticeably different from those who live in formal dwellings. Once
again a word of caution is in order; the data may be biased towards better established dwellings
that have access to facilities.page 27
WESTERN CAPE research report
cha rt 1 3
Access to health facilities: western cape
Primary source of Usual means of Time taken to travel
medical help transport to health to health facility
facility using usual means
Population of transport
totals in
segment 474,387 4,385,822 474,387 4,385,822 474,387 4,385,822
% of
people
100 – 4%* 1%* 2%* 6% 8%
17%
80 – 38% 32%
40%
37%
60 – 1%
4%
77%
15%
40 – 81%
37%
61%
53%
20 – 41%
18% 19%
0–
Shack not Formal Shack not Formal Shack not Formal
in backyard dwelling in backyard dwelling in backyard dwelling
Private doctor/specialist Walkingpage 28
WESTERN CAPE research report
to the durability of the dwelling structure. According to the GHS, 76% of households living in
shacks not in backyards live in dwellings where the conditions of the walls or the roof is weak or
very weak. This is higher than for households who live in backyard shacks (66% have weak or very
weak walls or roofs) and formal housing31 (where the corresponding statistic is 16%).
4.7 Education
In 2001, 10% of Western Cape adults aged 18 and above living in informal settlement EAs had
no schooling; 14% had a Matric and a further 2% completed Technikon, University or other
Post Matric.
According to the 2009 GHS, 77% of adults aged 18 and above living in shacks not in backyards
have not completed matric. 94% of children aged 5 to 18 who live in shacks not in backyards go
to school, equal to the provincial average32.
89% of school-going children who live in shacks not in backyards walk to school. As has been
highlighted above, a word of caution is required in interpreting this data given potential biases in
the sample design towards more established settlements. There is no data to determine whether
these schools were built to service a newly created informal settlement or whether the school
was originally built to meet the needs of more formal communities in the vicinity. In the case of
the latter, the existence of a school may have been part of the impetus for the creation of an
informal settlement.
cha rt 1 4
Usual mode of transport to educational facility by children
aged 5-17 (Live in shacks not in backyard): western cape
Time taken to
15 min+ educational
29%* facilities: walking
% of walking children
9 649* 79 681
11% 89%You can also read
