Reference Collection 2020 Overview Global References Pia Scherbach | Public Relations
HIGHLIGHTS
UP-HIGH - GREEN
LAKTHA CENTRE PUMPS IN EUROPE’S
TALLEST BUILDING
With a height of 462 metres,
the Lakhta Centre is the
tallest building in Europe and
the 13th tallest building in the
world. It broke ground in
2012, the exterior was
completed six years later. The
FACTS “northernmost skyscraper in
the world” will also serve as
Country: Russia the headquarters of Russian
City: St. Petersburg gas giant Gazprom, which
Segment: Building Services carried out the construction.
Applications: HVAC, Water Capturing the changes in
supply daylight, the main tower’s
Products: Wilo-CronoLine- unique silhouette symbolizes
IL-E, Wilo-Helix VE, a flame, a distinctive feature
Wilo-Stratos-D of Gazprom’s logo. With a
total floor area of over
400,000 m2, Lakhta Centre
comprises four different
facilities.
3 References 2020 10/06/2020
HIGH-EFFICIENCY
FEDERATION TOWER FOR THE HEART OF
MOSCOW’S
BUSINESS CENTRE
The monumental complex
consists of two towers with
different sizes: the more than
370-meter tower with almost
100 floors is called “Vostok“
FACTS (East-Tower), Orient, whereas
the smaller one with over 60
floors and a height of 243
Country: Russia meters is called
City: Moscow “Zapad“(West-Tower),
Segment: Building Services Occident. Beneath the
Applications: HVAC surface, the glass giants
Products: Wilo-Stratos, share a ten-story foundation.
Wilo-CronoLine-IL, Wilo- Products and solutions
VeroLine-IP-E, Wilo- provided by Wilo Russia,
CronoLine-IL-E, Wilo-TOP-S, ensure efficient and reliable
Wilo-VeroNorm NPG, Wilo- heating, air conditioning and
EMU FA, Wilo-EMU KS, Wilo- cooling at the same time.
TOP-Z, Wilo-Multivert MVI,
Wilo-CronoNorm-NL, Wilo-
Star-RS
4 References 2020 10/06/2020
SERVICE SOLUTION
CROKE PARK PROVIDER
Croke Park is a major Gaelic
Athletic Association (GAA)
sports venue located in
Dublin that hosts events for a
number of sports. Since 1884
the site has been used
primarily by the GAA to host
Gaelic games, most notably
the annual All-Ireland finals
FACTS in Gaelic Football and Hurling.
Wilo Ireland Service
Department carries out the
Country: Ireland
maintenance to the various
City: Dublin
booster sets, pressurisation
Segment: Building Services
units and circulating pumps
Applications: Water supply,
on site. They are the
Drainage and sewage
preferred pump supplier and
Products: Wilo-Comfort
pump maintenance provider
COR, Wilo-Comfort COR
due to the high quality, high
Helix VE, Wilo-CronoLine-IL,
efficiency, green product
Wilo-CronoLine-DL, Wilo-
focus and the high level of
Stratos-Z
service back up provided by
Wilo Ireland as required by
the client.
5 References 2020 10/06/2020
GREEN BUILDING
CENTRAL BANK APPROACH
Green Wilo pumps contribute
to the overall efficiency of the
new headquarters - from
heating and cooling to cold
water supply and products for
rainwater harvesting. Central
Bank campus is a green
building, certified by BREEAM,
the world’s leading
FACTS sustainability assessment
method. The bank itself had
set a number of objectives
Country: Ireland
when it came to the
City: Dublin
sustainability of the building –
Segment: Building Services
one of our main requirements
Commercial
was to only provide high-
Applications: HVAC
efficient pumps with
Products: Wilo-Stratos
efficiency class IE4 to ensure
GIGA, Wilo-SiBoost Smart
compliance with BREEAM
Helix VE, Wilo-Drain TP65
criteria. Central Bank set a
number of objectives for the
design of the building: e.g. to
ensure the environmental
sustainability.
Source: William Murphy_Flickr
6 References 2020 10/06/2020
GREEN EFFICIENCY
UNITE STUDENTS IN BETHNAL GREEN
Founded in 1992, Unite
Students (uS) was the first
private provider of purpose-
built student accommodation
in the UK. Today they have
circa 130 properties across
the country and provide a
home for 50,000 students per
FACTS year. Wilo products are in
operation in several uS
Country: England facilities, one of them being
City: London Blithehale Court in London –
Segment: Building Services with energy efficient solutions
Commercial and an extensive service
Applications: Water supply offer, the pump manufacturer
Products: Wilo-SiBoost ensures a reliable operation
Smart HELIX VE within the building. In total,
Wilo UK has provided new
boosters for 11 different sites
in 2018 – another 12 sites
are in the making for 2019
and ongoing.
7 References 2020 10/06/2020
WORLD-CLASS
HONGQIAO AIRPORT TRANSPORT HUB
Hongqiao Airport, the 4th
busiest airport in China, is
located in the west of
Shanghai. With it’s 15 waiting
halls, 18 VIP waiting halls and
15 luggage transmission
systems, the main hub for
domestic activity treats more
FACTS than 8 million passengers
every year. In Terminal T1,
Country: China Wilo takes care of
City: Shanghai professional maintenance and
Segment: Building Services energy saving solutions as
Commercial full package for the reliable
Applications: HVAC operation. This is the first
Products: Wilo-CronoNorm- collaboration with Wilo –
NL, Wilo-Comfort COR-Helix undergoing the renovation of
VE, Wilo-SCP, Wilo-Multivert the air conditioning system,
MVI, Wilo-NLB water supply system and fire
fighting system of the whole
Terminal 1. It's also the pilot
project of WiloCare.
8 References 2020 10/06/2020
USING SOLAR
BAOBAB POWER TO PROVIDE
RUNNING WATER
FOUNDATION Ground water is an important
source for water supplies.
This water can be extracted
from wells and shafts using
submersible pumps. In
remote areas, however,
securing a stable supply of
FACTS energy can often be
problematic, as the power
Country: Ghana grid is usually unstable. Wilo
City: Kissi has adapted an alternative
Segment: Water method which can be used at
Management precisely these locations to
Applications: Water supply obtain energy and provide a
Products: Wilo-Actun OPTI water supply. The solution is
a pump supplied with
electricity generated from
solar power. Solar power is a
free resource that does not
need extensive infrastructure.
9 References 2020 10/06/2020
IMPROVING
SEWA PUMPING SUSTAINABILITY
STATION
The Sharjah Electricity &
Water Authority (SEWA)
distributes and generates
electricity, water and (piped
natural) gas to the nationals
and residents of the Sharjah
Emirate. The Al Falaj pumping
station represents one of
FACTS many energy efficiency
improvement projects. As
Country: United Arab. complete solution provider,
Emirates Wilo makes sure to satisfy
City: Sharjah the customers needs on all
Segment: Water levels. The client’s objectives
Management towards Wilo were energy
Applications: Water supply efficiency, reduction in
Products: Wilo-SCP maintenance and noise as
well as potential energy
saving. The Wilo ME Service
team worked in close
cooperation with the partners
– including a WES & Retrofit
Scope.
10 References 2020 10/06/2020TAKING CARE OF
ENSCO JACK UP RIG GIANTS
With a length of over 74
meters and a breadth of
almost 63 meters, the self-
elevating jack up rig is in
operation for offshore
exploration and development
purposes. Designed for
enabling the oil rig base to
FACTS get hoisted up or stay afloat
in the water, the rigs can be
Country: United Arab. adjusted to the changing
Emirates wind and water conditions. To
City: Arabian Gulf guarantee a safe operation on
Segment: Industry the Offshore giants, Wilo-
Applications: Water supply Service provides onshore care
Products: Submersible of constant quality
pump-model K146+NU911T- inspections and overhauling.
2/60
11 References 2020 10/06/2020A LANDMARK
DUBAI OPERA PROJECT
The Dubai Opera on Sheikh
Mohammed Bin Rashid
Boulevard is unquestionably
the cultural centre of Dubai.
The concert hall can seat up
to 2,000 people. The Dubai
Opera is one of the cultural
and architectural landmarks
FACTS of Dubai, if not the entire
Arabian Peninsula. The fact
Country: United Arab. that Wilo was selected to be a
Emirates part of this prestigious
City: Dubai construction project is a
Segment: Building Services particular success, and not
Commercial only in terms of technology
Applications: HVAC and business: As a supplier
Products: Wilo-Helix V, for the Dubai Opera, Wilo
Wilo-Multivert MVI made extensive and close
contacts that extend far
beyond this project.
12 References 2020 10/06/2020OPERATING UNDER
AL-GALALA CITY HIGHEST
REQUIREMENTS
The new City of Galala is
located on the highest mount
plateau in the Red Sea area
between Ain Sokhna and
Zafarana. The plateau sits
over 650 meters above sea
level at its highest elevation.
The city is one of the
FACTS government’s national efforts
to develop the vast and
Country: Egypt empty eastern desert to solve
City: Galala Cairo’s population congestion
Segment: Water and create work and living
Management opportunities for the youth in
Applications: Water supply, addition to generating
irrigation investment opportunities. The
Products: Wilo-SCP, Wilo- new city centers on a
EMU KS balanced approach towards
development and
preservation of the
surrounding pristine
environment.
13 References 2020 10/06/2020SMART PUMPS IN A
SIGNAL IDUNA PARK FOOTBALL TEMPLE
– GERMANY
The SIGNAL IDUNA PARK is a
distinctive feature of
Dortmund’s skyline. With
space for 81,365 fans, the
stadium is the biggest in
Germany - the legendary
south stand is Europe’s
largest standing-only terrace.
FACTS For many years the home of
Borussia Dortmund has
Country: Germany counted on the energy
City: Dortmund efficient, reliable and high-
Segment: Building Services performance products of
Commercial Wilo. From water supply for
Applications: Water supply, the VIP areas, to the
HVAC changing room heating and
Products: Wilo-Stratos the undersoil heating system:
MAXO, Wilo-Comfort COR Wilo product solutions create
Helix VE, Wilo-Multivert MVI, a green environment. Since
Wilo-VeroLine-IP-E 2019, new Wilo-Stratos
MAXO models have been
providing the supply for the
south stand.
14 References 2020 10/06/2020ECO-FRIENDLY
MESSE FRANKFURT PUMPS HELP CREATE
AN ARCHITECTURAL
HIGHLIGHT
„Messe” Frankfurt is using
highly efficient Wilo products
for modern heating, air-
conditioning and cooling
technology in hall 12. Over
70 Wilo pumps are in use on
the Frankfurt trade fair site.
FACTS The tried and tested Wilo-
Stratos and Wilo-Stratos
Country: Germany GIGA high-efficiency pumps
City: Frankfurt ensure optimum heating.
Segment: Building Services Submersible pumps and
Commercial lifting units regulate
Applications: Water supply, sanitation in the hall. The
HVAC Wilo-RexaLift FIT L sewage
Products: Wilo-Stratos lifting unit is easy and flexible
GIGA, Wilo-RexaLift FIT L to install with a choice of
inlets. It guarantees reliable
operation thanks to
trustworthy filling level
monitoring and integrated
thermal motor protection.
15 References 2020 10/06/2020235 METRES OF
ALVEAR TOWER CONSTRUCTION
EXCELLENCE
With 235 metres, Alvear
Tower is the highest
residential tower in Argentina
and the most relevant
development in the City of
Buenos Aires. The mixed-use
development complex
contains several
FACTS condominiums as well as a
five-star hotel. One of the
Country: Argentina main challenges was, due to
City: Buenos Aires the height of the building,
Segment: Building Services how the water would be
Commercial pumped without recurring to
Applications: All really high pressure booster
Products: Wilo-Comfort sets. It was solved by using
COR Helix VE, Wilo- intermediate brake tanks at
CronoNorm NL, Wilo- different stages from where
CronoTwin-DL-E, Wilo- the boosters will be supplying
VeroTwin-DP-E, Wilo- to several floors. The water is
CronoLine-IL-E lifted to those brake tanks
through multistage vertical
pumps.
16 References 2020 10/06/2020SOUTH AMERICA‘S
COSTANERA CENTRE MEGA MALL
The Costanera Centre – also
known as „Gran Torre
Santiago“ - is a 64-story
skyscraper in Santiago. The
tower consists of nearly
700,000 m2 of building space.
The building, that looks as
tall as the Andes, is part of
FACTS the Costanera Centre
complex, which includes a
Country: Chile shopping mall, two hotels and
City: Santiago de Chile additional office spaces. Over
Segment: Building Services 130 Wilo pumps are used in
Commercial the centre for efficient cooling
Applications: HVAC and air-conditioning
Products: Wilo-CronoLine-IL technology. For demanding
conditions from - 2 °C in
winter to a high of +35 °C in
summer, Wilo’s intelligent
system solutions make for a
reliably pleasant climate.
17 References 2020 10/06/2020NEW SAVIOR DURING A
STORM WATER MONSOON
India’s monsoon is both, a
curse and a blessing. While
PUMPING STATION the agriculture depends on
the natural water supply,
Mumbai’s inhabitants and
infrastructure suffer from the
enormous deluge of water.
Nearly thirty Wilo vertical
turbine pumps operate in four
FACTS different water-pumping
stations, facing the challenge
during rainfall season.
Country: India
Wherever the land level is
City: Mumbai
lower than the sea level,
Segment: Water
water logging is bound to
Management
happen. Pumping stations are
Applications: Drainage &
responsible for two main
Sewage
things: they pump out
Products: Wilo-Axial Flow
rainwater and prevent high
Submersible Pump
tides from seeping into the
city. Each pump can push out
6,000 litres of water per
second.
18 References 2020 10/06/2020NEW EFFICIENT SYSTEMS
STATUE OF UNITY FOR WATER SUPPLY
The Statue of Unity
represents a portrayal of the
Indian statesman and
independence activist Sardar
Vallabhbhai Patel. He was the
first Deputy Prime and Home
Minister of independent India
and the chief adherent of
FACTS Mahatma Gandhi during the
non-violent independence
Country: India movement. The total height
City: Narmada of the structure is 240m with
Segment: Water a base of 58m and the statue
Management of 182m. The height was
Applications: Drainage & specifically chosen to match
Sewage the number of seats in the
Products: Wilo-Economy Gujarat Legislative Assembly.
CO, Wilo-Booster Five Hydro Pneumatic
Systems from Wilo are used
for supplying water to all
zones.
19 References 2020 10/06/2020BUILDING SERVICES
SIGNATURE VENUE
BUENOS AIRES Located in the heart of
Buenos Aires, the new arena
ARENA is set to become Argentina‘s
signature sports and
entertainment venue. The
complex, that can hold up to
15,000 visitors, will host
entertainment events, family
shows, festivals, sports and
FACTS music events. The stadium,
eight stories high and 50,736
m2 in area, has a capacity
Country: Argentina
ranging from 4,000 to 11,500
City: Buenos Aires
seated spectators, with the
Segment: Building Services
possibility of expanding to
Commercial
15,000 with an audience
Applications: HVAC
standing on the pitch. It is
Products: Wilo-Comfort
located at 450 Humboldt
COR Helix VE
Street, a few blocks away
from Corrientes and Juan B.
Justo Avenues.
21 References 2020 10/06/2020TAILORED
UNIVERSITY OF SOLUTIONS FIT ALL
REQUIREMENTS
BRITISH COLUMBIA Until 2025 the Okanagan
campus of the UBCO will
undergo various expansions.
The challenge was and is that
Wilo IL-E and Stratos GIGA
pumps cannot be used in
Canada, due to voltage and
FACTS certification requirements.
Therefor, Wilo Canada
Country: Canada equipped and programmed IL
City: Okanagan pumps with Danfoss
Segment: Building Services frequency converters – in
Commercial order to be able to compete
Applications: HVAC with Grundfos (who competed
Products: Wilo-CronoLine- in this project). The benefits
IL, Wilo-Stratos, Wilo-Star-Z for the customer certainly
NOVA are: short communication
channels, very good spare
parts supply as well as
efficient support.
22 References 2020 10/06/2020THE LARGEST DATA
UNICOM DATA WAREHOUSE IN THE
WORLD
CENTRE Guizhou, one of the fastest-
growing provinces in
Southwest China in terms of
GDP growth, is aiming to
become a big data hub. China
Unicom, one of the leading
provincial operations, has
FACTS established the new data
centre in the new district. To
Country: China provide high quality
City: Guizhou communication to the
Segment: Building Services Guizhou province. In 2017, it
Commercial won the 4A global
Applications: HVAC certification of data center
Products: Wilo-CronoNorm- green rating. Wilo China has
NL, Wilo-SCP, Wilo-Comfort provided green energy saving
COR Helix VE solutions, excellent and
reliable products, efficient
and rapid cooperation that
can immediately meet the
customers' requirements.
23 References 2020 10/06/2020EXPANDING
GUANGZHOU BAIYUN EFFICIENCY
The expansion project of
Terminal 2 of Guangzhou
INTERNATIONAL Baiyun International Airport
started in February 2013 and
AIRPORT was officially put into use in
April 2018. After completion,
it will meet the annual
demand for 80 million
passengers, 2.5 million tons
FACTS of cargo and mail throughput,
and 620,000 aircraft
movements. A total of 80
Country: China
WILO SCP horizontal double
City: Guangzhou
suction pumps and 19 WILO
Segment: Building Services
NL horizontal end suction
Commercial
pumps have been installed in
Applications: HVAC
the T2 terminal of Guangzhou
Products: Wilo-SCP,
Baiyun Airport. The maximum
Wilo-CronoNorm-NL
power is up to 160KW and
37KW respectively. The
refrigeration system provides
a strong guarantee to the
880,700 m2 of terminal
building.
24 References 2020 10/06/2020HIGH-EFFICIENT
OLYMPIC STADIUM TRAINING BASE
The national Olympic sports
center, located on the north
CENTRE fourth ring road of Beijing,
was established in 1986 for
the 1990 Asian Games. It is
not only a training base for
national sports athletes, but
also an important place for
holding large-scale sports
FACTS events, as well as for
entertainment. The whole
complex contains an indoor
Country: China
arena, the main stadium, a
City: Beijing
hockey field as well as a
Segment: Building Services
natatorium. The stadium has
Commercial
a floor space of 34,975 m2.
Applications: HVAC
For the 2008 Summer
Products: Wilo-CronoLine-
Olympics, it had undergone a
IL, Wilo-Multivert MVI,
major renovation. Over the
Wilo-SCP, Wilo-CronoNorm-
years, efficiency has also
NL
been improved within the
building.
25 References 2020 10/06/2020NEW EFFICIENCY FOR
OBECNÍ DŮM HISTORICAL
BUILDINGS
The city of Prague has the
goal to reduce energy
consumption of some
buildings by at least 12% per
year – at the same time the
city will also save 37,615
tonnes of CO2 by increasing
FACTS energy efficiency. In order to
significantly reduce the costs
Country: Czech Republic of heating and hot water
City: Prague supply at the Municipal House
Segment: Building Services in Prague, 22 pumps have
Commercial been replaced with high-
Applications: HVAC efficient Wilo products. They
Products: Wilo-Stratos have been chosen due to
MAXO, Wilo-Stratos MAXO-Z their innovative Dynamic
and Wilo-Stratos GIGA-D Adapt Plus function, which
allows additional savings
compared to other modern
pumps.
26 References 2020 10/06/2020NEW WATER HYGIENE
BLACK LION The Black Lion Hospital in
Ethiopia is one of the largest
HOSPITAL public referrals hospital in the
country, having
approximately 370,000-
400,000 patients a year. For
the past 8 years it has faced
challenges with boosting
water to the top floor of the
FACTS building. Staff had to carry
water in buckets to serve all
floors at the top, as the taps
Country: Ethiopia had run dry. With the
City: Addis Ababa installation of the
Segment: Building Services Wilo-SiBoost Smart Helix VE,
Commercial water can now be
Applications: Water Supply conveniently provided to the
Products: Wilo-SiBoost entire building. Since the
Smart Helix VE installation, the hospital
enjoys an odor free, hygienic
environment and it has
greatly reduced the time
previously wasted fetching
water and increased the time
available to serve patients.
27 References 2020 10/06/20205 STARS AT THE
CHALET DES NEIGES FOOT OF THE SLOPES
Arc 2000 is one of the four
sites of the ski resort of Les
Arcs and more broadly of the
ski area of Paradiski. It‘s
located on the northern slope
of the Vanoise massif in
Tarentaise in the east of the
French department of Savoie,
Chalet des Neiges are luxury
FACTS apartment for rentals. These
apartments have been
equipped with Wilo-Stratos,
Country: France
Stratos D and Z for its range
City: Tours en Savoie
effect dedicated to heating
Segment: Building Services
and hot sanitary water
Commercial
applications. The Wilo
Applications: HVAC
solutions bring efficient and
Products: Wilo-Stratos,
environment friendly
Wilo-Stratos-D,
technologies (ECM motor).
Wilo-VeroLine-IP-E,
The use of these pumps
Wilo-VeroTwin-DP-E,
allows the operator to save
Wilo-Stratos-Z
energy and obtain low
operating costs, thanks to
their variable speed to meet
the needs of the installations.
28 References 2020 10/06/2020SMART EFFICIENCY
CRÉDIT AGRICOLE IN THE FINANCIAL
SECTOR
Crédit Agricole Consumer
Finance S.A. is the market
leader for consumer loans in
France and Europe. As a
subsidiary of the French
banking group Crédit
Agricole, Crédit Agricole
Consumer Finance S.A. is
FACTS also one of the largest
European banks and offers a
Country: France wide range of financial
City: Besancon products and services in 23
Segment: Building Services countries. Through the
Commercial acquisition of Wilo-Stratos
Applications: HVAC MAXO high-performance
Products: Wilo-Stratos circulators, the Crédit
MAXO, Wilo-CronoLine-IL Agricole Franche-Comté's
head office has taken up the
technical challenge of
maximizing its electrical gains
and improving the efficiency
of energy flows and
consumptions.
29 References 2020 10/06/2020SUSTAINABLE PUMP
DATEV CAMPUS TECHNOLOGY
The DATEV IT Campus 111
sets an example for
modernity and sustainability.
The rectangular, four-storey
building complex with a gross
floor area of over 56,000 m2
offers 1,800 DATEV eG
employees a futuristic,
comfortable workplace.
FACTS Around 90 Wilo pumps cover
the areas of heating, air
conditioning and
Country: Germany
refrigeration. The drinking
City: Nuremberg
water pressure booster Wilo-
Segment: Building Services
SiBoost Smart Helix VE is
Commercial
located in a separate cellar
Applications: HVAC
room and ensures a reliable
Products: Wilo-Stratos,
water supply. With the
Wilo-SiBoost Smart Helix VE,
Wilo-CronoLine IL 200, the
Wilo-CronoLine IL-E
largest installed Wilo pump is
also used here. This ensures
a pleasant climate in summer
for the 1,800 DATEV
employees.
30 References 2020 10/06/2020SMART PUMP IN THE
GOLDBECK HEATING CELLAR OF
THE FUTURE
What makes the construction
company GOLDBECK special
are not only the 47 locations
in Germany and Europe. Or
the approximately 90,000
tons of steel that the East
Westphalians process every
FACTS year. At GOLDBECK's
headquarters in Bielefeld, a
Country: Germany special feature is hidden. In
City: Bielefeld the cellar of a new, futuristic
Segment: Building Services extension building 13 Wilo
Commercial pumps are in operation -
Applications: HVAC including twelve brand new
Products: Wilo-Stratos Wilo-Stratos MAXO pumps.
MAXO, Wilo-Stratos GIGA Like a Wilo-Stratos GIGA, the
twelve Smart pumps are used
to heat and cool the office
building.
31 References 2020 10/06/2020FOR MAXIMUM
EBZ BOCHUM ENERGY EFFICIENCY
The "smart heating cellar" in
the new building of the EBZ
in Bochum will show how
energy-efficient technology
can become even more
energy-efficient - thanks to
intelligent networking. An
important part of the
FACTS pioneering research project:
the Wilo-Stratos MAXO. Its
Country: Germany "smart heating cellar" is used
City: Bielefeld to research the efficient
Segment: Building Services generation and distribution of
Commercial heat and cold in buildings.
Applications: HVAC The results should not only
Products: Wilo-Stratos improve the indoor climate in
MAXO, Wilo-Stratos GIGA new buildings, but also
provide tangible research
results on intelligent building
management.
32 References 2020 10/06/2020NEW SMART CITY RELIES
SMART CITY BAD ON PUMP
REPLACEMENT
HERSFELD On a grand scale, the city of
Bad Hersfeld has exchanged
old pumps in municipal
buildings for highly efficient
Wilo pumps and thus made
use of the state pump
subsidy. The result is
FACTS impressive - for the town
treasury and the
Country: Germany environment. 60 new Wilo
City: Bad Hersfeld pumps in a total of 24
Segment: Building Services municipal buildings are now
Commercial operating highly efficiently -
Applications: HVAC from the municipal library, to
Products: Wilo-Stratos the municipal kindergartens
PICO, Wilo-Star-Z NOVA T and the multi-purpose halls in
Bad Hersfeld. And more are
to follow. The municipality is
currently saving 29,000
kilowatt hours of electricity
and more than 17 tonnes of
CO2 every year.
33 References 2020 10/06/2020NEW BRILLIANT - EVEN IN
LVM-CHRYSTAL THE PLANT ROOM
With the “crystal”, the LVM
insurance company
completed the building
complex at its headquarters
in Münster - setting new
standards for sustainable
construction and modern
high-rise architecture. What
FACTS fits in better than pump
technology and service from
Wilo? Every component of the
Country: Germany
building aims for maximum
City: Münster
efficiency: starting with
Segment: Building Services
thermal insulation, through
Commercial
lighting control, to self-
Applications: HVAC
generated energy - thanks to
Products: Wilo-EMUport
the photovoltaic system and
CORE, Wilo-Stratos MAXO
the biogas-powered block-
type thermal power station. It
is clear that such a building
needs efficient and intelligent
pump technology.
34 References 2020 10/06/2020PARTNERS FOR LIFE
NORTHERN LIGHTS The Northern Lights
residential complex, a bold
unique project embodied in
the Hi-tech style, received an
award from the International
Association of Architects
Union 2017. Three towers of
an unusual shape on the
33rd, 37th and 42nd floors
FACTS are similar to the glimpses of
the northern lights embodied
in reality and are one of the
Country: Kazahkstan
most beautiful projects of the
City: Nur-Sultan
capital of Kazakhstan. The
Segment: Building Services
residential complex was
Commercial
designed with the intention
Applications: Water supply
that its inhabitants would be
Products: Wilo-CronoLine-
warm and comfortable 24
IL, Wilo-CronoBloc BL,
hours a day during the harsh
Wilo-CronoNorm-NL,
Astana winters.
Wilo-Helix VE
35 References 2020 10/06/2020NEW THE CITY OF GLASS
NURLY-TAU The multifunctional
complex NURLY TAU is an
BUSINESS CENTRE architectural focus of the
administrative centres of
Almaty and is the one of the
largest social centres in
Kazakhstan. Its unique shape
represents the Zaily Alatau
Mountain. NURLY TAU stands
FACTS for a “city inside a city” –
each element within the
complex was built for the
Country: Kazahkstan
comfort of the staff and
City: Almaty
residents of the building. Wilo
Segment: Building Services
solutions like the
Commercial
Wilo-CronoLine-IL and
Applications: Water supply
Wilo-SiFire reduce life cycle
Products: Wilo-CronoLine-
costs thanks to optimised
IL, Wilo-CronoBloc BL,
efficiency and operate reliably
Wilo-CronoNorm-NL,
in the application of e.g.
Wilo-SiFire
firefighting.
36 References 2020 10/06/2020NEW ALMATYS CULTURAL
PALACE OF THE HOTSPOT
REPUBLIC
The Palace of the Republic is
located in the Almaty City
Centre at the intersection of
Dostyk and Abay Streets and
is one of main and largest
concert halls in not only
Almaty but Kazakhstan, too.
It was built in 1970 and was
FACTS called “Palace Lenin” back
then. The building was
Country: Kazahkstan opened during the 100th
City: Almaty birth anniversary celebration
Segment: Building Services of Lenin and ever since has
Commercial become the main tourist
Applications: Water supply attraction of Almaty. The
Products: Wilo-CronoLine- composition of the building
IL, Wilo-CronoBloc BL, includes the internal volumes
Wilo-CronoNorm-NL, which are under one roof of
Wilo-Helix VE 10000 sq. meter. The roof
rests on eight concrete walls
and they do not reach the
bottom of the roof and hence
giving a virtual look.
37 References 2020 10/06/2020NEW WILO-PUMPS FOR A
HOSPITAL NUR- NEW HOSPITAL
SULTAN
The government of
Kazakhstan allocated around
12 million Euro for the
construction of a modular
infectious diseases hospital
for patients with COVID-19 in
the city of Nur-Sultan. The
construction of the hospital
FACTS was finished in 13 days, its
total area comprises 7000
Country: Kazahkstan m2. The hospital structure
City: Nur-Sultan erected from modular blocks
Segment: Building Services using the technologies of
Commercial building prefabricated
Applications: Water supply buildings and equipped with
Products: Wilo-Comfort modern means of ensuring
COR-3, Wilo-Helix the safety of medical staff
and patients. Moreover, most
importantly, a medical gas
system includes a cryogenic
station, an oxygen station,
and a compressed air station.
38 References 2020 10/06/2020CITY OF THE FUTURE
PANGYO ALPHADOM Pangyo Alphadom City is a
future-oriented new town,
which is located in
Seongnam, satellite city of
Seoul, capital of South Korea.
It consists out of commercial
buildings such as department
stores & shopping streets,
restaurants, offices, hotels
FACTS and residential buildings. The
project is - in size and value
aspects - a mega real estate
Country: Korea
development project.
City: Pangyo
Moreover, Pangyo Alphadom
Segment: Building Services
City consists of various types
Commercial
of buildings from a
Applications: All
department store to offices.
Products: PUZeN,
Expectation was that water
Wilo-CronoLine-IL, PMT, PD
consumption in various
buildings would be reluctant.
Wilo supplied 130 pumps in
the application of water
supply, HVAC, firefighting and
drainage to meet this
challenge.
39 References 2020 10/06/2020GREEN SOLUTIONS
BOSCH REXROTH FOR A MODERN
PLANT
Bosch Rexroth Korea factory
is an outpost for the East
Asian market, located in
Busan. Facilities for
production, logistic, and
offices were built on over
17,000 m2. Now the factory
represents the Korean
FACTS headquarters of Bosch
Rexroth. It produces
Country: Korea hydraulic power units and
City: Busan control blocks, so they can
Segment: Building Services gain the upper hand in the
Commercial various fields of business and
Applications: All Social Overhead Capital
Products: PUZ, PMT, (SOC) market like water
Wilo-CronoLine-IL, PH, PSW power plants. Wilo provided
all kinds of pumps and
system solutions for the
building. From Water Supply,
HVAC, Fire-fighting to
Drainage as well as
circulation pumps.
40 References 2020 10/06/2020TAILOR-MADE
STARFIELD GOYANG SOLUTIONS
Starfield Goyang is a mega
complex shopping theme
park located in Goyang-si -
near Seoul, capital of Korea.
It is the nations largest
shopping complex with
various malls, restaurants,
hypermarkets, sports and
FACTS entertainment complexes.
The building required tailor-
Country: Korea made heating, ventilation and
City: Goyang air-conditioning solutions as
Segment: Building Services well as experts with deep
Commercial insights into HVAC systems.
Applications: Water supply, Moreover, it demanded
Drainage & Sewage overall pumps and pump
Products: Wilo-CronoLine- system solutions in various
IL, Wilo-Multivert MVI, applications and uses for
Wilo-HiBoost, PMT, PD, PDV shopping malls as well as
sports facilities including a
swimming pool.
41 References 2020 10/06/2020MONGOLIA‘S
ULAANBAATAR TRANSPORT HUB
The New Ulaanbaatar
International Airport (NUBIA)
AIRPORT is being constructed at
Khushigt Valley in Tuv
Province, around 50km south
of Mongolia’s capital city
Ulaanbaatar. Also known as
Khöshig Valley Airport,
construction started in May
FACTS 2013. It was scheduled for
completion by the end of
2016, but delays have
Country: Mongolia
extended this to first half of
City: Ulaanbaatar
2020. The airport will be
Segment: Building Services
capable of handling
Commercial
approximately three million
Applications: HVAC
passengers a year. New
Products: Wilo-CronoLine-IL
infrastructure and reserved
IL, Wilo-SiFire, Wilo-SiBoost
land will enable future
Smart Helix VE,
expansions to serve an
Wilo-VeroLine-IP-E, Sprinkler
estimated 12 million
KM, CC-HVAC
passengers a year.
42 References 2020 10/06/2020BREEAM STAR
LIDL DISTRIBUTION The complex opened its doors
in 2019. With 54,000 m2, it’s
CENTRE one of Europe's largest LIDL
Distribution Centres and
represents the new model for
sustainability. The BREEAM
classification "Outstanding"
proofs that. Wilo has
delivered pumps for pressure
FACTS boosting, heating, cooling
and tap water. The
construction time was only 1
Country: Netherlands
year, so the builders needed
City: Oosterhout
reliable and high-performance
Segment: Building Services
partners, with high-quality
Commercial
energy efficiënt products
Applications: HVAC
combined with first-class
Products: Wilo-Stratos,
service and advice. Wilo's
Wilo-Stratos GIGA,
advice was also welcome
Wilo-CronoLine-IL-E,
concerning the realization of
Wilo-SiBoost Smart Helix VE
the crate washing installation.
To better match the water
supply and water collection,
Wilo advised and engineered
a special break tank.
43 References 2020 10/06/2020NEW FOR CHALLENGING
KORF VIS REQUIREMENTS
In the Netherlands, fish is a
very important export and
consumer products. This year,
the fish processing company
Korf Vis moved into their
newly renovated premises in
Urk. The fish processing
sector faces a relatively large
number of special challenges.
FACTS On the basis of the
company's certifications,
certain rules with regard to
Country: Netherlands
sustainability, hygiene and
City: Urk
food safety must be followed.
Segment: Building Services
ToTec relies on Wilo's pump
Commercial
systems. Because of the
Applications: HVAC, Water
several adjustment options
supply
on the pump itself, they are
Products: Wilo-Stratos,
very suitable for monitoring
Wilo-SiBoost Smart 2 Helix
the water and air quality in
the building. The intelligent
pumps are switched on when
critical limit values are
approaching and adjustments
are required.
44 References 2020 10/06/2020ENERGY SAVING
WARSAW SPIRE SOLUTION
Warsaw Spire is a complex of
office buildings located in the
district of Wola, Warsaw. One
of the tallest office buildings
in Poland and one of the
tallest ones in Europe, it has
been honoured with
prestigious awards. The
object is equipped with
FACTS modern heating, ventilation
and air-conditioning systems
Country: Poland as well as sewage disposal
City: Warsaw and water supply systems.
Segment: Building Services Due to the size and height of
Commercial the building, it was necessary
Applications: Water Supply to meet the challenging
Products: Wilo-Comfort requirements of high
COR Helix VE, Wilo-Stratos, pressures and diversified
Wilo-EMU FA, Wilo-DrainLift, flows. The solutions applied
Wilo-RainSystem AF 400 are unconventional and
required in-depth engineering
expertise, to also apply to the
high safety criteria and strict
energy consumption
standards.
45 References 2020 10/06/2020COMPREHENSIVE
1UA BUILDING PUMPING
SOLUTIONS
A building constructed in the
place of a previous bus depot
made a remarkable change in
the landscape of the area.
From the design phase
through the execution and
service phases, the
investment was being carried
FACTS out under the supervision and
with great support of Wilo.
Country: Poland Installation and
City: Lublin commissioning of the devices
Segment: Building Services was conducted efficiently.
Commercial The service department takes
Applications: HVAC care of all the pumps and
Products: Wilo-CronoBloc auxiliary equipment based on
BL, Wilo-CronoBloc BL-E, a maintenance contract,
Wilo-VeroLine-IP-Z, which gives the end-user
Wilo-VeroLine IP-E, peace of mind and ensures
Wilo-Yonos MAXO high operation standard of
the devices.
46 References 2020 10/06/2020REDUCTION OF
BIOGAS ENVIRONMENTAL
POLLUTION
POWERPLANT
The purpose of the
investment was to build an
ecological heating network in
the municipality of Potęgowo.
It also included modernization
of the existing heating
substations and planned
construction of new
FACTS substations to be installed in
the existing facilities, where
Country: Poland coal-fired boiler rooms were
City: Darzyn going to be closed down. Goal
Segment: Building Services was reducing environmental
Commercial pollution and increasing the
Applications: HVAC use of renewable energy for
Products: Wilo-CronoLine- heating purposes. The biogas
IL-E, Wilo-VeroLine-IP-E plant produces electricity
from organic matter, i.a. agri-
food waste. A byproduct of
this process is heat which the
plant used for its own
purposes.
47 References 2020 10/06/2020NEW CLEAN AND SAFE
ARCHE HOTEL SOLUTIONS FOR THE
HOTEL BUSINESS
The "Arche" hotel is a newly-
built hotel located in Lublin.
Its total surface amounts to
5000 m2. The investment
comprises a hotel building
with a conference room and a
restaurant on the ground
floor, as well as a car park in
FACTS the underground part. At the
planning stage, the design
Country: Poland office signalised the need for
City: Lublin a reliable solution for
Segment: Building Services transporting sewage due to
Commercial the character of the building.
Applications: Drainage & The solution was expected to
Sewage be clean and safe in
Products: Wilo-EMUport operation, including
CORE 20.2-14B preventing staff from having
contact with sewage and
preventing gas emissions,
particularly hydrogen
sulphide.
48 References 2020 10/06/2020GREEN WELLNESS
THERMAL BATH OASIS
BUCHAREST
„Therme Bucuresti“ is located
north of Bucharest, offering a
wellness concept for a
modern and balanced
lifestyle. The thermal bath
has an indoor temperature of
29-30 degrees Celsius and a
water temperature of 33
FACTS degrees – during every single
month of the year. Thermal
water supplies 10 pools, 6
Country: Romania
saunas, 4 wet saunas and 16
City: Bucharest
water slides. While various
Segment: Building Services
Wilo-products supply the
Commercial
25,000 m2 interiors of the
Applications: Water supply,
modern oasis, the Service
Drainage & Sewage
experts generate operational
Products: Wilo-Rexa FIT,
comfort for the customer, due
Wilo-DrainControl
to a high quality maintenance
package.
49 References 2020 10/06/2020AFRICA‘S SUPER
MALL OF AFRICA MALL
The Mall of Africa HVAC was
split into two sections:
Eastern retail run by Total Air
controls and Western retail
run by Improvair (IES). The
mall includes four plant
rooms. DL Twin inline pumps
ranging from 2.2 – 30KW are
FACTS in operation for all major
water applications including
Country: South Africa stores like Edgars, Game,
City: Midrand YDE, Truworths, Checkers,
Segment: Building Services Woolworths, Cinemas and
Commercial restaurants. This design
Applications: HVAC saved the contractors and
Products: Wilo-Cronotwin- quantity surveyors
DL, Wilo-CronoNorm-NL, substantial amounts on
Wilo-CronoNorm-NLG, pipework and valves as only
Wilo-EMU KS, Wilo-EMU FA one incoming and outgoing
pipeline could be used for a
duty/standby system.
50 References 2020 10/06/20201000 PUMPS FOR
LAND OF LEGENDS HIGH EFFICIENCY
The Land of Legends Theme
Park, a unique concept that
blends perfectly in with every
aspect of a holiday, pioneers
a brand new entertainment
concept with impressive
architecture and creativity.
The park has chosen Wilo for
trouble-free service in its
FACTS pump systems. Products such
as Stratos Giga, Helix V, Helix
Excel, Yonos MAXO and
Country: Turkey
RexaLift were used in the
City: Antalya
project, nearly 1000 in total.
Segment: Building Services
Wilo also provides project
Commercial
support and hassle-free after-
Applications: All
sales services. With its vision
Products: Wilo-Yonos
of sustainable quality, Wilo
MAXO, Wilo-Stratos, Wilo-
continues to provide solutions
VeroLine-IPL, Wilo-Stratos
to its after-sales Service and
GIGA, Wilo-Yonos PICO,
Service needs in the Land of
Wilo-Helix V, Wilo-Multivert
Legends Theme Park as well
MVI, Wilo-Rexa PRO,
as its other major projects.
Wilo-RexaLift FIT L,
Wilo-EMU FA
51 References 2020 10/06/2020MIXED ECOLOGICAL
VARYAP MERIDIAN PROJECT
Within the scope of the
Varyap Meridian project,
there are 5 towers of 20 to
60 floors containing a total of
1,500 residences, a business
center with 50,000 m2 rental
space, a 20,000 m2 office
building, a 5-star hotel to be
given to an international
FACTS brand and commercial areas.
Varyap Meridian has been
built with an understanding of
Country: Turkey
holistic sustainability, which is
City: Istanbul
the most accepted approach
Segment: Building Services
in recent years in the
Commercial
international real estate
Applications: HVAC, Water
development sector and
supply
requires design and
Products: Wilo-CronoLine-
implementation in harmony
IL, Wilo-VeroLine-IPL,
with the natural environment.
Wilo-Stratos, Wilo-TOP-Z,
Innovative technologies and
Wilo-Multivert MVI,
the opportunities provided by
Wilo-Comfort COR-MVI,
LEED criteria are returned to
Wilo-DrainLift, Wilo-RexaLift
the landlords as lower dues
and overheads.
52 References 2020 10/06/2020RELIABILITY FOR A
EMAAR MALL SUPER MALL
The shopping and lifestyle
center EMAAR Square Mall is
one of the biggest malls in
Turkey. In accordance to the
diversified needs of the multi-
use complex like Residences,
Heights, The Address
Residence Istanbul, The
FACTS Address Residence Skyview
Istanbul, Wilo Turkey was
Country: Turkey chosen to carry out the
City: Istanbul supply. Wilo pumps and
Segment: Building Services panels are used in all
Commercial heating-cooling-circulation
Applications: HVAC, Water systems, booster systems,
supply wastewater drainage systems
Products: Wilo-Yonos and fire-fighting systems of
MAXO, Wilo-CronoLine-IL, the project, which creates a
Wilo-CronoLine-IL-E, new neighborhood on the
Wilo-CronoNorm-NL, Anatolian side of Istanbul.
Wilo-Helix V, Wilo-Multivert
MVI, Wilo-DrainLift,
Wilo-RexaLift
53 References 2020 10/06/2020A MALL FOR A
YDA CENTRE MODERN ANKARA
The YDA Center project,
launched in Söğütözü, the
heart of Ankara, is preparing
to be among the city’s
symbols due to its
extraordinary architecture
and modern design. In this
large project, water supply is
ensured by Wilo's intelligent
FACTS pressure boosting systems
and the highest technology
standard for 165 metres. The
Country: Turkey
project included fixed-speed
City: Ankara
pumps and frequency
Segment: Building Services
converter control panels to
Commercial
ensure that the circulation
Applications: All
and pressure booster pumps
Products: Wilo-CronoLine-
provide variable capacity
IL, Wilo-VeroLine-IPL, Wilo-
requirements throughout the
VeroLine-IP-E, Wilo-RexaLift
day and do not operate
FIT L2, Wilo-DrainLift,
continuously at the highest
Wilo-Rexa UNI,
capacity. In addition to water
Wilo-Economy CO-Helix V
supply and circulation pumps,
Wilo provided waste water
removal pumps.
54 References 2020 10/06/2020£11,000 SAVINGS
NOBLES HOSPITAL PER ANNUM
Wilo high efficiency pumps
are helping a leading Building
Services Engineer achieve his
ambition of reducing a
Government’s energy bill by
5%, year on year, through
the sharing of the company’s
energy solutions expertise.
FACTS The Wilo DL-E models have
been installed in the various
Sub-heat stations around the
Country: UK
site. Each Sub-heat station
City: Isle of Man
has a pump for Constant
Segment: Building Services
Temperature and one for
Commercial
Variable Temperature
Applications: HVAC
requirements. Already the
Products: Wilo-CronoTwin-
Pathology department, the
DL-E, Wilo-CronoBloc BL
theatres, Intensive Care Unit,
Accident and Emergency and
Fractures clinic and the
Estates and Kitchens areas
have been switched to new
pumps.
55 References 2020 10/06/2020IMPROVING WATER
POPLAR HARCA QUALITY
Poplar Housing and
Regeneration Community
Association (HARCA) owns
and manages around 10,000
homes in East London. Like
many social housing
providers, the organisation
realises the importance of
FACTS clean water in heating
systems to ensure that the
Country: UK systems operate efficiently.
City: London Wilo-SiClean Comfort is
Segment: Building Services integrated into heating
Commercial systems to provide
Applications: HVAC automated circulating water
Products: Wilo-SiClean cleaning. Over the period of
Comfort the trial, the results showed
huge improvement to the
system circulating water – a
large reduction in
conductivity and a reduction
of the iron in the water
samples taken.
56 References 2020 10/06/2020„DRIVING“ A
FRIARGATE LANDMARK BUILDING
The area around Coventry is
undergoing an impressive
transformation as regeneration
comes back. And Wilo UK has
had a major role to play in
providing all the pumps for the
new home of Coventry City
Council. Comprising 3,200,000
sq ft of mixed-use
FACTS development, once completed,
it will deliver a total of 25
efficient and sustainable
Country: UK
buildings, including Grade A
City: London
office buildings, shops,
Segment: Building Services
restaurants, two hotels and
Commercial
new homes, high quality
Applications: HVAC, Water
landscaped public spaces and
Supply
the create 15,000 new jobs.
Products: Wilo-CronoLine-
Wilo provides primary and
IL-E, Wilo-VeroTwin-DP-E,
secondary heating, chilled
Wilo-CronoTwin-DL-E,
water and Cooling water
Wilo-CronoLine-IL
pumps as well as a domestic
cold water booster set.
57 References 2020 10/06/2020WATER MANAGEMENT
OPERATION UNDER
SANAE IV BASE EXTREME
CONDITIONS
Located in Vesleskarvet,
Queen Maud Land, the
research base is part of the
South African National
Antarctic Program (SANAP).
Its research fields include:
Oceanography, biology,
geology and geomorphology.
FACTS The refurbishment included
cold water supply, hot water
Country: Antarctica circulation, snow melter for
City: Queen Maud Land potable water, FCU pumps
Segment: Water and Genset cooling pumps to
Management supply water up to 100°.
Applications: Water supply Compact pressure boosting
Products: Wilo-SiBoost sets – Helix VE with special
Smart Helix VE manifolds (316 s/steel),
special valves and
transducers handle hot water.
All of them highly efficient
(IE4), which results in energy
savings.
59 References 2020 10/06/2020PREMIUM PUMP
WWTP SOLUTION
The WWTP processes the
wastewater from a population
INSTALLATION of over 10,000 people into
sustainable effluent irrigation
to be used in the region. Prior
to the much needed
redevelopment, the WWTP
was under pressure, receiving
almost twice its hydraulic
FACTS capacity. The efficiency of this
particular pump station is
especially important, not only
Country: Australia
due to a quickly growing
City: Emerald
population but also due to the
Segment: Water
frequency of droughts in the
Management
area and the positive impact
Applications: Drainage &
recycled water has during
Sewage
these dramatic environmental
Products: Wilo-EMU FA,
events. The plant required
Wilo-Comfort CO-4HELIX, TR
premium pump solutions that
would not only double their
capacity, but could also be
installed efficiently, operated
easily and maintained locally.
60 References 2020 10/06/2020MINIMISING
WWTP ENVIRONMENTAL
IMPACTS
INSTALLATION
The project has delivered
significant benefits for
residents and businesses
across Kingaroy, allowing for
projected population growth
over the next 20 years,
utilising Australian-first
technology to minimise
FACTS environmental impacts while
delivering high-quality
Country: Australia wastewater with reduced
City: Kingaroy operating costs. Wilo
Segment: Water Australia have succeeded in
Management showing its capability as a
Applications: Drainage & complete solutions provider in
Sewage the water management field.
Products: Wilo-EMU FA, Wilo supplied both
Wilo-Helix VE wastewater transport and
water boosting pumps for this
advanced and exciting
Australian project.
61 References 2020 10/06/2020OPERATIONAL
ZHONGHUAN SUN RELIABILITY
POWER
Inner Mongolia Zhonghuan
Solar Materials Co. Ltd. is a
silicon materials
manufacturer. The Company
mainly manufactures
monocrystalline silicon ingots
and wafers used in solar cells.
They are engaged in green
FACTS projects which focus on
renewable energy cells. Inner
Country: China Mongolia is a high-tech
City: Huhhot enterprise with a provincial
Segment: Water Research & Development
Management centre. It was also honoured
Applications: Drainage & as the autonomous
Sewage intellectual property pilot
Products: Wilo-CronoNorm- enterprise in the region. 148
NL, Wilo-NX high-efficient Wilo-pumps
contribute to the reliable
operation inside the building.
62 References 2020 10/06/2020SERVING THE
METTU UNIVERSITY COMMUNITY
Mettu University (MeU) is
located 600 km outside of the
capitol Addis Ababa, in the
Oromia National Regional
state. MeU required three
sewage transfer stations due
to topographical features of
the university. Wilo proposed
FACTS advanced technology with the
EMUport, including the solid
Country: Ethiopia separation system as well as
City: Addis Ababa social, economical benefits
Segment: Water than a conventional waste
Management water pumping station. High
Applications: Water supply operational reliability, no
Products: FS3000 Wilo- clogging, odor-free, hygienic,
EMUport with solid low maintenance cost, less
separation system space needed, long service
life, no civil construction,
design support, local after
sales service.
63 References 2020 10/06/2020NEW PERFORMANCE AND
RESE LEOVILLE STRENGTH
RESE (Régie d'exploitation
des Services d'Eau de la
Charente-Maritime) manages
operation issues and
governance regarding water
management in the region of
Charente-Maritime in France.
After the installation of 4
FACTS Wilo-Zetos K8 pumps in their
fleet, a fifth Wilo-Zetos K8
Country: France pump in the pump has been
City: Leoville ordered and is being
Segment: Water manufactured. This allowed
Management us to win a secondary market
Applications: Water supply for renewal of a “Pleuger”
Products: Wilo-Zetos K8 pump on the oldest and
largest drilling rig in the
Charente-Maritime (Bouil du
Chambon).
64 References 2020 10/06/2020NEW MODERN WATER
TBILISI WATER TREATMENT
Tbilisi – a multi-ethnic, multi-
cultural, multi-religious city
SUPPLY on the crossroads of history,
a city neither European nor
Asian but a heady blend of
both East and West.Tbilisi
was founded in the 5th
century AD and has attracted
visitors ever since, drawn by
FACTS the hot springs for which the
city is named, by the lively
atmosphere of its cobbled
Country: Georgia
streets and caravanserais or
City: Tbilisi
simply by what Alexandre
Segment: Water
Dumas called the “city of
Management
legend and romance.” Water
Applications: Water supply
supply and
Products: Wilo-EMU FA,
sanitation in Georgia is
Wilo-EMUport,
characterized by
Wilo-CronoNorm-NLG,
achievements and challenges.
Wilo-Sub TWI, Wilo-Zetos
Among itis the improvement
of water services in the
capital, where the water
supply is now continuous and
of good quality
65 References 2020 10/06/2020MODERN STANDARD
UREKI WATER WATER SUPPLY
To significantly reduce the
threat of pollution and
SUPPLY improving the living
conditions, Ureki’s ministry
ordered the creation of a
water treatment facility – as
they never had a centralized
system. It is a large-scale
project and will have an
FACTS enormous impact on the life
on site – by ensuring
continuous water supply. The
Country: Georgia
whole project includes 97
City: Ureki
pumps, 32 sewer pumping
Segment: Water
stations, 3 NLG pumps
Management
Booster Set, 7 borehole
Applications: Water supply,
pumps and control panels. It
Drainage & Sewage
comprises the laying of 65
Products: Wilo-EMU FA,
km water supply pipelines, 55
Wilo-EMUport,
km sewage pipelines, the
Wilo-CronoNorm-NLG,
construction of two reservoirs
Wilo-Sub TWI, Wilo-Zetos
one water supply pumping
station, 31 sewage pumping
stations and the drilling of 7
drinking water wells.
66 References 2020 10/06/2020WATER
KUTAISI WATER REHABILITATION
SUPPLY
Kutaisi is a city that plays a
very important role in
Georgia’s political and
economic life. Still, the city
lacked of a proper water
supply system for the more
than 200k inhabitants. The
water rehabilitation project
FACTS optimises and extends the
municipal sewerage system
Country: Georgia and construct a mechanical
City: Kutaisi biological wastewater
Segment: Water treatment plant in Kutaisi. It
Management is one of the world’s oldest
Applications: Water supply continuously inhabited cities.
Products: Wilo-Actun It was founded around 4
ZETOS K8 millenniums ago. The cradle
of ancient civilization in
Georgia always served as a
main cultural and educational
center of the region.
67 References 2020 10/06/2020SOFT FOREST WATER
WATERWORKS MOOS
15 communities in the
Bavarian Forest are supplied
with soft forest water from
the new waterworks in Moos -
thanks to an innovative
softening process. An
important component of the
ultra-modern plant: 67 Wilo
pumps. It is probably the
most modern waterworks in
FACTS Europe - with an important
goal: it is intended to further
strengthen the security of
Country: Germany supply of healthy drinking
City: Moos water for the people in
Segment: Water Eastern Bavaria. The plant,
Management operated by the
Applications: Water supply “Zweckverband Waldwasser”,
Products: Wilo-Zetos, supplies 15,000 private
CronoBloc BL, Wilo-Helix VE, households south of the
Wilo-Multivert MVI Danube with softened
drinking water - soft forest
water. Up to 400 cubic metres
per hour are fed into the
networks.
68 References 2020 10/06/2020EFFICIENT
DESALINATION DRINKING WATER
PRODUCTION
PLANT Due to water supply problems
on Amorgos, a desalination
plant has been in operation
for years. To upgrade and
optimise the facility, the
project “ACCOMPANYING
WORKS OF DESALINATION
FACTS PLANT IN AEGIALI
AMORGOS” came to tender.
Country: Greece The project was awarded to a
City: Amorgos (Island) construction company and
Segment: Water included the commission of
Management two borehole pumps
Applications: Water supply (50m3/h-77m each), suitable
Products: Wilo-Zetos, to transfer sea water to the
Wilo-SiBoost Smart Helix VE tank of the desalination plant
as well as one booster set
(2x20m3/h-67m) to
distribute the clean water
from the desalination plant.
69 References 2020 10/06/2020FUTURE ENERGY IN
EXPO 2017 BUILDING KAZAKHSTAN
The Kazakhstan Pavilion and
Science Museum, known as
Nur-Alem in the country, is
the iconic, high-performing
centerpiece of the 2017
EXPO. The site has been
transformed into a Post-Expo
development with cultural
FACTS facilities, an office and
research park, and residential
Country: Kazahkstan components that seeks to
City: Nur-Sultan attract international
Segment: Water entrepreneurs. Inspired by
Management & Industry the EXPO-2017 theme,
Applications: Water supply “Future Energy,” the
Products: Wilo-SiBoost Kazakhstan Pavilion and
Smart Helix VE, Science Museum embodies a
Wilo-CronoNorm-NL, futuristic design that is
Wilo-CronoLine-IL-E, optimized to incorporate
Wilo-SiFire sustainable philosophies.
70 References 2020 10/06/2020You can also read
