TRAFFIC IMPACT STUDY

E-Commerce Center of
Hampton
Todd Center Shopping Center
1700 Todds Lane, Hampton, Virginia

         PREPARED FOR
             Tower Park Corporation
             735 Thimble Shoals Blvd, Suite 100
             Newport News, Virginia 23606

         PREPARED BY

             4500 Main Street, Suite 400
             Virginia Beach, Virginia 23462
             757.490.0132

             33968.01

             5/26/15 (Updated 7/7/15)
E-Commerce Center of Hampton - Todd Center Shopping Center 1700 Todds Lane, Hampton, Virginia
Table of Contents
Introduction.................................................................................................................................................................................. 1
Background Information ......................................................................................................................................................... 1
       Study Area Roadways ............................................................................................................................... 1
       Proposed Development ........................................................................................................................... 2
Analysis of Existing Conditions ............................................................................................................................................. 6
         Capacity Analysis ........................................................................................................................................ 6
         Existing Queue Conditions ..................................................................................................................... 9
Analysis of Future No-Build Conditions .......................................................................................................................... 10
         Capacity Analysis ...................................................................................................................................... 10
         No-Build Queue Conditions ................................................................................................................. 12
Analysis of Build Conditions ................................................................................................................................................ 13
         Trip Generation ......................................................................................................................................... 13
         Trip Distribution ........................................................................................................................................ 13
         Capacity Analysis ...................................................................................................................................... 20
         Build Queue Conditions ......................................................................................................................... 24
         Summary and Conclusions ................................................................................................................... 25

List of Figures
Figure 1:               Vicinity Map ....................................................................................................................................................... 3
Figure 2:               Existing Lane Configurations ....................................................................................................................... 4
Figure 3:               E-Commerce Center of Hampton Conceptual Site Plan ................................................................... 5
Figure 4:               Trip Distribution ............................................................................................................................................. 15
Figure 5:               2015 AM Peak Hour Volumes ................................................................................................................... 16
Figure 6:               2015 PM Peak Hour Volumes ................................................................................................................... 17
Figure 7:               2020 AM Peak Hour Volumes ................................................................................................................... 18
Figure 8:               2020 PM Peak Hour Volumes ................................................................................................................... 19

E‐Commerce Center of Hampton
Traffic Impact Study                                                                                                                                                                i
E-Commerce Center of Hampton - Todd Center Shopping Center 1700 Todds Lane, Hampton, Virginia
List of Tables
Table 1:     Daily Truck Trip Estimates............................................................................................................................. 2
Table 2:     Existing Measures of Effectiveness at Todds Lane and Aberdeen Road ..................................... 7
Table 3:     Existing Measures of Effectiveness at Mercury Boulevard and Aberdeen Road ...................... 8
Table 4:     Existing Queue Lengths for Aberdeen Road at Mercury Boulevard and Todds Lane ........... 9
Table 5:     2020 No-Build Measures of Effectiveness at Todds Lane and Aberdeen Road ..................... 10
Table 6:     2020 No-Build Measures of Effectiveness at Mercury Boulevard and Aberdeen Road ...... 11
Table 7:     2020 No-Build Queue Lengths ................................................................................................................. 12
Table 8:     Trip Generation ............................................................................................................................................... 13
Table 9:     Trip Distribution ............................................................................................................................................. 14
Table 10:    2015 Build Measures of Effectiveness at Todds Lane and Aberdeen Road ............................. 20
Table 11:    2015 Build Measures of Effectiveness at Mercury Boulevard and Aberdeen Road .............. 21
Table 12:    2020 Build Measures of Effectiveness at Todds Lane and Aberdeen Road ............................. 22
Table 13:    2020 Build Measures of Effectiveness at Mercury Boulevard and Aberdeen Road .............. 23
Table 14:    Future 2015 Build Queue Lengths ........................................................................................................... 24
Table 15:    Future 2020 Build Queue Lengths ........................................................................................................... 24

E‐Commerce Center of Hampton
Traffic Impact Study                                                                                                                                               ii
E-Commerce Center of Hampton - Todd Center Shopping Center 1700 Todds Lane, Hampton, Virginia
Introduction

Todd Center Shopping Center is a 242,387 square foot community shopping center located in
the Coliseum Central Business Improvement District of Hampton, Virginia. The 27-acre property
fronts Todds Lane east of Aberdeen Road. The shopping center is anchored by large retailers
such as Big Lots, Grand Furniture, Hancock Fabrics, Lumber Liquidators, Northern Tool &
Equipment, and OfficeMax.

Todd Shopping Center, LLC proposes to redevelop the northwest corner of the site with the E-
Commerce Center of Hampton, a 94,936 square foot (sf) building offering office, retail, and
mini-warehouse uses. The three uses are envisioned to function in concert with each other
(storing, internet selling, and shipping) as well as independently. The building space is designed
for 4,650 sf of retail for shopping such as a FedEx or UPS counter, 19,337 sf of office space, and
70,949 sf of storage space divided into 429 units.

The City of Hampton requires a traffic impact study for the site in order to assess the potential
impact the land use will have on the existing transportation network.

Background Information

The intersections included in the study area are Mercury Boulevard and Aberdeen Road, and
Todds Lane and Aberdeen Road (see Figure 1), which are both signalized. The shopping center has
multiple driveways on both Todds Lane and on Aberdeen Road. The proposed plan consolidates
some of the driveways such that two driveways, one on Todds Lane and one on Aberdeen Road,
serve the parking area of the study site.

Study Area Roadways

  Todds Lane

  Todds Lane is a four-lane minor arterial north of the study site. The posted speed limit in the
  vicinity of the site is 40 miles per hour (mph). The corridor includes retail, commercial,
  residential, and civic land uses. Bethel Church is directly across the street; however, there are not
  any driveways from the church parking lot on Todds Lane near the study site.

  Aberdeen Road

  Aberdeen Road is a four-lane minor arterial west of the study site. It has a posted speed limit of
  35 mph. Aberdeen Road runs north-south and intersects with Todds Lane and Mercury
  Boulevard. This is the only block Aberdeen Road in the vicinity that serves commercial land uses.
  North and south it is mostly residential.

E‐Commerce Center of Hampton
Traffic Impact Study                                                                                 1
E-Commerce Center of Hampton - Todd Center Shopping Center 1700 Todds Lane, Hampton, Virginia
Mercury Boulevard

  Mercury Boulevard is an eight-lane divided principal arterial roadway running east-west through
  Hampton, with a speed limit of 45 mph. There are left and right turn lanes at signalized
  intersections along this corridor. It is heavily developed with commercial land uses in the vicinity
  of the study site.

  Figure 1, presents the project location and the street network serving the site. Figure 2 shows
  the existing lane configurations at the intersections of Todds Lane and Aberdeen Road and
  Mercury Boulevard and Aberdeen Road.

Proposed Development

The E-Commerce Center of Hampton consists of a 94,936 square foot (sf) building offering office,
retail, and mini-warehouse uses. The building space is designed for 3,491 sf of retail for shopping
such as a FedEx or UPS counter, 17,785 sf of office space, and 63,978 sf of storage space divided into
429 units. Two entrances are proposed: one onto Todds Lane and another onto Aberdeen Road, see
Figure 3 for a copy of the site plan. The driveway on Todds Lane is slightly more than 200 feet east of
the Aberdeen Road intersection. The driveway on Aberdeen Road is approximately 360’ north of
Mercury Boulevard and 470’ south of Todds Lane; it generally aligns with Edgewood Drive.

The three uses are envisioned to function in concert with each other (storing, internet selling,
and shipping). As a result of the description of the businesses, the City of Hampton requested
an estimate of truck traffic coming into and out of the site. Truck trip estimates were prepared
referencing the National Cooperative Highway Research Program (NCHRP) Synthesis 298 Truck
Trip Generation Data, 2001, and the ITE Trip Generation Handbook, 2004, see Table 1. In
recognition of the synergy associated with the land uses as described, the truck count was
adjusted by increasing the single-unit trucks and decreasing the combination trucks (tractor
trailer trucks) for the site.

      Table 1: Daily Truck Trip Estimates
                                                         4-Tire           Single     Combination      All
         Land Use           Size         Units       Commercial            Unit         Unit       Commercial
                                                       Vehicles           Trucks       Trucks        Vehicles
        Retail             4,650          SF                4                5            2            10
        Office            19,337          SF               37                8            0            49
        Warehouse         70,949          SF                8                0           15            36
        Truck Trips                                        37                8           15            60
        Adjusted Category Truck Trips                      37               15           2            54
       Reference: Trip Generation Handbook, 2nd Edition, ITE, Washington, DC 2004.

E‐Commerce Center of Hampton
Traffic Impact Study                                                                                            2
E-Commerce Center of Hampton - Todd Center Shopping Center 1700 Todds Lane, Hampton, Virginia
\\vhb\proj\VaBeach\33968.00 Todd Shopping Center\cad\te\planmisc\Vicinity Map.dwg

                                                                                        INTERSTATE

                                                                                          64

                                                                          LYNNHAVEN
                                                                             LAKE

                                      SITE                                          E
                                                                      DS    LAN
                                                                  TOD

                                       L   VD
                                    YB
                                                                   AB

                                 UR
                            RC
                                                                      E
                                                                      RD

                         ME
                                                                          EE
                                                                            N
                                                                              RD

                                                      Figure 1

                                                      Vicinity Map
                                                      Todd Center Shopping Center
   0                 800 FEET                         1700 Todds Lane, Hampton, VA
                                                                                                     July 1, 2015
E-Commerce Center of Hampton - Todd Center Shopping Center 1700 Todds Lane, Hampton, Virginia
\\vhb\proj\VaBeach\33968.00 Todd Shopping Center\cad\te\planmisc\Traffic figures.dwg

                      TODD'S LANE

                                                                          ABERDEEN RD

                      MERCURY BLVD

                                                       Figure 2

                                                       Existing Lane Configurations
                                                       Todd Center Shopping Center
   0             N.T.S.                                1700 Todds Lane, Hampton, VA
                                                                                        July 1, 2015
TABLE OF AREAS
                                                                                                                  GROSS BUILDING FLOOR AREA      94,936 SF
                                                                                                                    FIRST FLOOR                  31,724 SF
                                                                                                                    SECOND FLOOR                 31,606 SF
                                                                                                                    THIRD FLOOR                  31,606 SF
                                                                                                                  USAGE AREA
                                                                                                                    OFFICES                      19,337 SF
                                                                                                                    STORAGE                      70,949 SF
                                                                                                                    RETAIL                       4,650 SF
                                                                                                                  STORAGE UNITS                  429
                                                                                                                  SITE AREA PROPOSED FOR
                                                                                                                                                 3.13 ACRES
                                                                                                                  REZONING
                                                                                                                  PARKING AREA                   70,914 SF
                                        NOTE: ALL DIMENSIONS ARE APPROXIMATE AND BASED ON THE CONCEPTUAL LAYOUT     PARKING SPACES               111 SPACES
                                                                                                                    MIN. PARKING SPACES REQUIRED
                                                                                                                                                  83 SPACES
                                                                                                    TRUE            (OFFICE, STORAGE, AND RETAIL)
                                                                                                    NORTH         LANDSCAPE AREA                 24,468 SF (18% OF TOTAL SITE)
                                                       0          20'     40'      60'       80'                  SIDEWALK AREA                  5,803 SF
                                                       GRAPHIC SCALE

E-COMMERCE CENTER OF HAMPTON                                                                       COPYRIGHT © 2015 BY TOWER PARK CORPORATION
CONCEPT SITE PLAN - REVISED 5.14.2015                                                                                                06/10/2015
Analysis of Existing Conditions

Capacity Analysis

Turning movement counts were provided by the City of Hampton. The counts for Mercury
Boulevard and Aberdeen Road were taken on May 1, 2012 from 6:30 – 8:30 AM, 10:30 AM – 2:00
PM, 3:30 – 5:30 PM, and 6:30 – 7:30 PM. The counts for Todds Lane and Aberdeen Road were taken
on May 3, 2012 from 7:00 – 9:00 AM, 11:00 AM – 12:00 PM, 1:00 – 2:30 PM, 3:30 – 6:00 PM, and
6:30 – 7:30 PM.

To establish traffic volumes for the 2015 No-Build scenario, the existing turning movement counts
provided by the City had a five percent growth rate applied. The resulting values are presented in
Figures 4 and 5 as the “background” volume.

Capacity Analysis results are expressed in terms of Level of Service (LOS). LOS is a qualitative
measurement of traffic operations. It is translated from a measure of delay to drivers in units of
time, seconds per vehicle. The Transportation Research Board’s Highway Capacity Manual (HCM)
defines six levels of service for intersections with LOS “A” representing operating conditions with
minimal constraints on traffic movements and LOS “F” representing extremely congested operating
conditions. LOS “D” is considered the threshold of acceptable operations for an overall intersection.
Exhibit 18-4 of the HCM gives the criteria for signal controlled intersections.

HCM Exhibit 18-4: Level of Service Criteria

Synchro 8.0 was the software tool used in determining the delay, capacity and corresponding level
of service of the study intersections. The results indicate that both the intersections operate at an
overall LOS “D” or better. The delay and LOS information calculated in the analysis are presented in
Tables 2 and 3.

E‐Commerce Center of Hampton
Traffic Impact Study                                                                             6
Table 2: Existing Measures of Effectiveness at Todds Lane and Aberdeen Road

                        Todds Lane and Aberdeen Road ‐ Existing AM
                               Volume to    Control               Approach            Avg. Int.
                                                       Movement             Approach            Intersection
    Approach       Movement     Capacity     Delay                  Delay              Delay
                                                         LOS                  LOS                   LOS
                                 Ratio     (sec/veh)              (sec/veh)          (sec/veh)
                       EBL        0.26        47.8        D
   Todds Lane
                       EBT       0.54        28.0         C         24.6        C
      (EB)
                       EBR       0.16        2.6          A
                       WBL       0.51        48.8         D
   Todds Lane
                       WBT       0.28        19.2         B         23.6        C
      (WB)
                       WBR       0.04        0.1          A                              28.5           C
                       NBL       0.63        56.7         E
  Aberdeen Rd
                       NBT       0.63        56.2         E         34.5        C
      (NB)
                       NBR       0.32        3.5          A
  Aberdeen Rd          SBL       0.62        56.1         E
                                                                    46.5        D
      (SB)             SBTR      0.22        33.1         C

                        Todds Lane and Aberdeen Road ‐ Existing PM
                               Volume to    Control               Approach            Avg. Int.
                                                       Movement             Approach              Intersection
    Approach       Movement     Capacity     Delay                  Delay              Delay
                                                         LOS                  LOS                     LOS
                                 Ratio     (sec/veh)              (sec/veh)          (sec/veh)
                       EBL        0.32        59.7        E
   Todds Lane
                       EBT       0.73        42.9         D         36.4        D
      (EB)
                       EBR       0.21         4.6         A
                       WBL       0.79        60.6         E
   Todds Lane
                       WBT       0.53        23.8         C          30         C
      (WB)
                       WBR       0.14         5.2         A                              38.3           D
                       NBL       0.84        74.2         E
  Aberdeen Rd
                       NBT       0.83        72.5         E         52.4        D
      (NB)
                       NBR       0.30         5.0         A
  Aberdeen Rd          SBL       0.64        73.9         E
                                                                    57.9        E
      (SB)             SBTR      0.34        43.3         D

E‐Commerce Center of Hampton
Traffic Impact Study                                                                                7
Table 3: Existing Measures of Effectiveness at Mercury Boulevard and Aberdeen Road
                   Mercury Boulevard and Aberdeen Road ‐ Existing AM
                               Volume to    Control               Approach            Avg. Int.
                                                       Movement             Approach            Intersection
    Approach       Movement     Capacity     Delay                  Delay              Delay
                                                         LOS                  LOS                   LOS
                                 Ratio     (sec/veh)              (sec/veh)          (sec/veh)
                       EBL        0.48        57.0        E
  Mercury Blvd
                       EBT       0.67        28.5         C         28.7        C
      (EB)
                       EBR       0.17         1.3         A
                       WBL       0.66        64.0         E
  Mercury Blvd
                       WBT       0.50        25.4         C         28.4        C
     (WB)
                       WBR       0.12         1.4         A                              33.1            C
                       NBL       0.82        92.3         F
  Aberdeen Rd
                       NBT       0.47        52.5         D         42.8        D
      (NB)
                       NBR       0.49        14.8         B
  Aberdeen Rd          SBL       0.67        76.5         E
                                                                    60.3        E
      (SB)             SBTR      0.77        55.7         E

                   Mercury Boulevard and Aberdeen Road ‐ Existing PM
                               Volume to    Control               Approach              Avg. Int.
                                                       Movement             Approach              Intersection
    Approach       Movement     Capacity     Delay                  Delay                Delay
                                                         LOS                  LOS                     LOS
                                 Ratio     (sec/veh)              (sec/veh)            (sec/veh)
                       EBL        0.85        85.8        F
  Mercury Blvd
                       EBT       0.91        46.1         D         46.4        D
      (EB)
                       EBR       0.31         4.3         A
                       WBL       0.76        74.4         E
  Mercury Blvd
                       WBT       0.85        40.7         D          42         D
     (WB)
                       WBR       0.17         6.3         A                              48.6            D
                       NBL       0.86        95.7         F
  Aberdeen Rd
                       NBT       0.76        65.8         E         54.5        D
      (NB)
                       NBR       0.62        19.2         B
  Aberdeen Rd          SBL       0.87       101.4         F
                                                                    76.1        E
      (SB)             SBTR      0.92        68.6         E

E‐Commerce Center of Hampton
Traffic Impact Study                                                                                 8
Existing Queue Conditions

SimTraffic was used to estimate the queues at the signalized intersections. SimTraffic uses a hot
spot, 20 feet in length at the top of each lane or approach just prior to the adjacent intersection to
help to identify possible queuing or spillback issues on adjacent intersections. If a vehicle is in that
hot spot and is traveling less than 10 mph, it is assumed to be queued. The queuing and blocking
reports are a result of the average of ten runs.

Table 4 presents the estimate queue lengths for the existing AM and PM hours. Results and
observations of queuing simulations show that the intersections operate within their storage
capacities.

 Table 4: Existing Queue Lengths for Aberdeen Road at Mercury Boulevard and
 Todds Lane
                                                        95th     95th
                                            Link
       Intersection        Movement                   Queue AM Queue PM
                                          Distance
                                                        2015     2015
                               EBT          1764          267          405
                               WBT          876           215          437
    Aberdeen Rd @
                               NBT          546           145          225
     Mercury Blvd
                               SBL          943           132          170
                               SBT          943           161          268
                               EBT          1043          218          284
                               WBT          1842          115          261
    Aberdeen Rd @
                               NBL          650           152          241
      Todds Lane
                               NBLT         650           119          271
                               SBTR         678            75          101

E‐Commerce Center of Hampton
Traffic Impact Study                                                                                 9
Analysis of Future No-Build Conditions

 Capacity Analysis

 To estimate future traffic for the 2020 background traffic, the 2020 No-Build scenario, the existing traffic
 volumes were increased by 1 percent per year for each of the turning movements. The 2020 AM and PM
 No-Build Volumes are presented in Figures 7 and 8, respectively, as the “background” volume.

 Synchro 8.0 was the software tool used in determining the delay, capacity and corresponding level
 of service of the study intersections. The results indicate that both intersections operate at an
 overall LOS D or better. Tables 5 and 6 present the delay and LOS information calculated in the
 analysis for this condition.

Table 5: 2020 No-Build Measures of Effectiveness at Todds Lane and Aberdeen Road
                    Todds Lane and Aberdeen Road ‐ 2020 No Build AM
                                Volume to    Control               Approach              Avg. Int.
                                                        Movement             Approach              Intersection
    Approach       Movement      Capacity     Delay                  Delay                Delay
                                                          LOS                  LOS                     LOS
                                  Ratio     (sec/veh)              (sec/veh)            (sec/veh)
                       EBL         0.33        49.3        D
   Todds Lane
                       EBT        0.58        29.2         C         25.7       C
      (EB)
                       EBR        0.17         2.6         A
                       WBL        0.55        50.5         D
   Todds Lane
                       WBT        0.31        20.1         C         24.6       C
      (WB)
                       WBR        0.04         0.1         A                              29.6          C
                       NBL        0.66        58.7         E
   Aberdeen Rd
                       NBT        0.66        58.2         E          36        D
       (NB)
                       NBR        0.34         4.1         A
   Aberdeen Rd         SBL        0.66        57.9         E
                                                                     46.5       D
       (SB)            SBTR       0.25        31.4         C

                    Todds Lane and Aberdeen Road ‐ 2020 No Build PM
                                Volume to    Control               Approach              Avg. Int.
                                                        Movement             Approach              Intersection
    Approach       Movement      Capacity     Delay                  Delay                Delay
                                                          LOS                  LOS                     LOS
                                  Ratio     (sec/veh)              (sec/veh)            (sec/veh)
                       EBL         0.37        61.0        E
   Todds Lane
                       EBT        0.78        45.5         D         38.7       D
      (EB)
                       EBR        0.23        5.1          A
                       WBL        0.84        65.0         E
   Todds Lane
                       WBT        0.60        26.8         C          33        C
      (WB)
                      WBR         0.16        5.7          A                              40.8          D
                       NBL        0.87        77.8         E
   Aberdeen Rd
                       NBT        0.86        75.1         E         54.8       D
       (NB)
                       NBR        0.31        5.4          A
   Aberdeen Rd         SBL        0.67        76.2         E
                                                                     57.5       E
       (SB)           SBTR        0.37        41.5         D

 E‐Commerce Center of Hampton
 Traffic Impact Study                                                                                   10
Table 6: 2020 No-Build Measures of Effectiveness at Mercury Boulevard and Aberdeen Road

                  Mercury Boulevard and Aberdeen Road ‐ 2020 No Build AM
                                Volume to    Control               Approach              Avg. Int.
                                                        Movement             Approach              Intersection
    Approach         Movement    Capacity     Delay                  Delay                Delay
                                                          LOS                  LOS                     LOS
                                  Ratio     (sec/veh)              (sec/veh)            (sec/veh)
                        EBL        0.50        57.7        E
   Mercury Blvd
                        EBT       0.71        29.7         C         29.9        C
       (EB)
                        EBR       0.18         1.8         A
                        WBL       0.69        65.8         E
   Mercury Blvd
                        WBT       0.53        26.2         C         29.3        C
      (WB)
                        WBR       0.13         1.6         A                              34.4            C
                        NBL       0.85        98.5         F
   Aberdeen Rd
                        NBT       0.48        52.5         D         44.7        D
       (NB)
                        NBR       0.52        16.3         B
   Aberdeen Rd          SBL       0.71        79.3         E
                                                                     62.4        E
       (SB)             SBTR      0.79        57.5         E

                  Mercury Boulevard and Aberdeen Road ‐ 2020 No Build PM
                                Volume to    Control               Approach            Avg. Int.
                                                        Movement             Approach              Intersection
    Approach         Movement    Capacity     Delay                  Delay              Delay
                                                          LOS                  LOS                     LOS
                                  Ratio     (sec/veh)              (sec/veh)          (sec/veh)
                        EBL        0.88        89.8        F
  Mercury Blvd
                        EBT       0.98        54.8         D         53.8        D
      (EB)
                        EBR       0.33        4.2          A
                        WBL       0.81        78.1         E
  Mercury Blvd
                        WBT       0.91        44.9         D          46         D
     (WB)
                        WBR       0.19        6.8          A                              54.1            D
                        NBL       0.91       102.9         F
   Aberdeen Rd
                        NBT       0.79        67.1         E         57.2        E
       (NB)
                        NBR       0.66        21.2         C
   Aberdeen Rd          SBL       0.92       109.8         F
                                                                     83.6        F
       (SB)             SBTR      0.95        75.5         E

 E‐Commerce Center of Hampton
 Traffic Impact Study                                                                                11
No-Build Queue Conditions

SimTraffic was used to estimate the queues at the signalized intersections.

Future No‐Build 2020
Table 7 presents the queues for the future 2020 No‐Build AM and PM peak hours. Both
signalized intersections are within their queuing capacities.

  Table 7: 2020 No-Build Queue Lengths
                                                   95th    95th
                                       Link     Queue AM Queue PM
      Intersection      Movement
                                     Distance    2020 No  2020 No
                                                  Build    Build
                           EBT        1764        277         420
                           WBT        876         231         498
   Aberdeen Rd @
                           NBT        546         137         234
    Mercury Blvd
                           SBL        943         125         179
                           SBT        943         170         302
                           EBT        1043        228         302
                           WBT        1842        126         284
   Aberdeen Rd @
                           NBL        650         159         248
     Todds Lane
                           NBLT       650         135         296
                           SBTR       678          83         105

E‐Commerce Center of Hampton
Traffic Impact Study                                                                  12
Analysis of Build Conditions

Trip Generation

Traffic that may be generated by the proposed redevelopment was established using equations
and rates available through the Institute of Transportation Engineer’s (ITE) Trip Generation, 9th
Edition.

Trip generation for the site was prepared for each individual land use. ITE provides information
for copy, print, and express ship stores (Land Use Code 920), general office buildings (Land Use
Code 710), and mini-warehouses (Land Use Code 151).

Having a mix of land uses in close proximity to each other encourages one trip to the
development combining multiple destinations. The residential and retail component trips are
combined where the origin and destination are within the area and do not use the arterial
street system. Reductions are made to the first stage of the trip generation to calculate the
traffic which leaves the site. This adjustment is termed “Internal Capture.” The internal capture
reductions were taken in accordance to the ITE Trip Generation Handbook.

The trip generation per land use, including internal trips, may be found in Table 8 below.

   Table 8: Trip Generation
                                                   ITE                                       AM Peak Hour          PM Peak Hour
                 Land Use                                     Size      Units Daily
                                                  Code                                    Enter Exit Total Enter Exit       Total
Copy, Print, and Express Ship Store                 920       4,650       SF       581      19          19   38   25   32    57
General Office Building                             710      19,337       SF       213      26          4    30   5    24    29
Mini-Warehouse                                      151        429     UNITS       108       5          4    9    6    6     12
Total Trips                                                                        902      50          27   77   36   62    98
Total Internal Trips                                                               170      10          10   20   14   14    28
Total External Trips                                                              732       40          17   57   22   48    70
Reference: Trip Generation, 9th Edition, Institute of Transportation Engineers, Washington, DC. 2008.

Trip Distribution

Trip distribution was based on the existing traffic patterns and the understanding of the land
uses within the surrounding area.

The site traffic distribution is 20% to/from the east, 15% to/from the west, 5% to the north, and
60% to/from the south. Traffic distribution is expected to be consistent throughout the day, see
Figure 4.

E‐Commerce Center of Hampton
Traffic Impact Study                                                                                                                13
AM and PM trip distributions are shown in Table 9. The resulting 2015 Build AM and PM trip
assignments are provided in Figures 5 and 6, while the 2020 Build AM and PM trip assignments
are provided in Figures 7 and 8, respectively.

The site driveway on Todds Lane has a restricted left turn out so that the exiting traffic must
use the Aberdeen Road driveway to leave the site. Drivers with destinations north on Aberdeen
Road or west on Todds Lane were assigned to use the driveway on Aberdeen Road.

  Table 9: Trip Distribution

                                                                AM                   PM
                   Distribution
                                                        Enter   Exit   Total Enter   Exit   Total
                                                  %      40     17      57    22     48      70
 Aberdeen Rd                          North      5%       2      1      3      1      2      3
 Aberdeen Rd                          South      60%     24     10      34    14     29      43
    Aberdeen Rd                         South    4%       2      1      3      1      2      3

    Mercury Blvd                        East     30%     12      5      17     7     15      22

    Mercury Blvd                        West     26%     10      4      14     6     12      18

 Todds Lane                           East       20%      8      3      11     4     10      14
 Todds Lane                           West       15%      6      3      9      3      7      10

                                         Check 100%      40     17      57    22     48      70

E‐Commerce Center of Hampton
Traffic Impact Study                                                                              14
\\vhb\proj\VaBeach\33968.00 Todd Shopping Center\cad\te\planmisc\Traffic figures.dwg

                                                                5%
                                                                                                                   20%
                              TODDS LANE

                                    15%

                                                                                            SITE

                                                                         ABERDEEN RD

                                                                                                   30%

                         MERCURY BLVD

                           26%
                                                                                       4%

                                                       Figure 4

                                                       Trip Distribution
                                                       Todd Center Shopping Center
   0             N.T.S.                                1700 Todds Lane, Hampton, VA
                                                                                                         July 1, 2015
\\vhb\proj\VaBeach\33968.00 Todd Shopping Center\cad\te\planmisc\Traffic figures.dwg

                                                                50 (0) 50
                                                                91 (2) 93
                                                                12 (0) 12
                                                                                                                         32 (0) 32
                                                                                                                        414 (0) 414
                                                                                                                        104 (0) 104                  (8)
                                 TODDS LANE
                                                                                                                                        (8)
                                                        13 (0) 13
                                                       597 (6) 603

                                                                                                                                              (3)
                                                                                                          173 (3) 176
                                                                                                           31 (1) 32
                                                                                                          139 (0) 139
                                                       136 (0) 136

                                                                                                                                       SITE
                                                                                  (0)                           (4)
                                                                                                                (10)
                                                                                                  (24)
                                                                                    ABERDEEN RD
                                                               (1) 194
                                                               (4) 85

                                                                         82
                                                                         77 (5)

                                                                                                                         81 (12) 93
                                                               193
                                                                81

                                                                                                                       1279 (0) 1279
                                                                                                                        186 (0) 186
                            MERCURY BLVD
                                                     92 (10) 102
                                                   1648 (0) 1648
                                                                                                          82 (0) 82
                                                                                                         193 (2) 191
                                                                                                                       234 (0) 234

                                                    100 (0) 100

 Legend

 Background + (Site) = Total

                                                       Figure 5

                                                       2015 AM Peak Hour Volumes
                                                       Todd Center Shopping Center
   0             N.T.S.                                1700 Todds Lane, Hampton, VA
                                                                                                                                                    July 1, 2015
\\vhb\proj\VaBeach\33968.00 Todd Shopping Center\cad\te\planmisc\Traffic figures.dwg

                                                                65 (0) 65
                                                                78 (1) 79
                                                                11 (0) 11
                                                                                                                                   130 (0) 130
                                                                                                                                   854 (0) 854
                                                                                                                                   249 (0) 249                   (4)
                                 TODDS LANE
                                                                                                                                                   (4)
                                                        23 (0) 23
                                                       661 (3) 664

                                                                                                                                                         (10)
                                                                                                                     313 (7) 320
                                                                                                                      97 (2) 99
                                                                                                                     188 (0) 188
                                                       161 (0) 161

                                                                                                                                                  SITE
                                                                                             (0)                            (9)
                                                                                                                           (29)
                                                                                                             (14)
                                                                                               ABERDEEN RD
                                                               287 (2) 289
                                                               175 (12) 187

                                                                              110 (15) 125

                                                                                                                                   157 (7) 164
                                                                                                                                  2106 (0) 2106
                                                                                                                                   240 (0) 240
                            MERCURY BLVD
                                                    221 (6) 227
                                                   2090 (0) 2090
                                                                                                                    145 (0) 145
                                                                                                                    360 (1) 361
                                                                                                                                  301 (0) 301

                                                    203 (0) 203

 Legend

 Background + (Site) = Total

                                                       Figure 6

                                                       2015 PM Peak Hour Volumes
                                                       Todd Center Shopping Center
   0             N.T.S.                                1700 Todds Lane, Hampton, VA
                                                                                                                                                                July 1, 2015
\\vhb\proj\VaBeach\33968.00 Todd Shopping Center\cad\te\planmisc\Traffic figures.dwg

                                                                55 (0) 55
                                                                96 (2) 98
                                                                16 (0) 16
                                                                                                                              36 (0) 36
                                                                                                                             438 (0) 438
                                                                                                                             113 (0) 113                 (8)
                                 TODDS LANE
                                                                                                                                            (8)
                                                        17 (0) 17
                                                       631 (6) 637

                                                                                                                                                  (3)
                                                                                                              183 (3) 186
                                                                                                               35 (1) 36
                                                                                                              148 (0) 148
                                                       145 (0) 145

                                                                                                                                           SITE
                                                                                      (0)                            (4)
                                                                                                                    (10)
                                                                                                      (24)
                                                                                        ABERDEEN RD
                                                               204 (1) 205
                                                                86 (4) 90

                                                                             87
                                                                             82 (5)

                                                                                                                             86 (12) 98
                                                                                                                           1347 (0) 1347
                                                                                                                            196 (0) 196
                            MERCURY BLVD
                                                     97 (10) 107
                                                   1734 (0) 1734
                                                                                                              87 (0) 87
                                                                                                             201 (2) 203
                                                                                                                           249 (0) 249

                                                    109 (0) 109

 Legend

 Background + (Site) = Total

                                                       Figure 7

                                                       2020 AM Peak Hour Volumes
                                                       Todd Center Shopping Center
   0             N.T.S.                                1700 Todds Lane, Hampton, VA
                                                                                                                                                        July 1, 2015
\\vhb\proj\VaBeach\33968.00 Todd Shopping Center\cad\te\planmisc\Traffic figures.dwg

                                                                70 (0) 70
                                                                83 (1) 84
                                                                15 (0) 15
                                                                                                                                   139 (0) 139
                                                                                                                                   899 (0) 899
                                                                                                                                   263 (0) 263                   (4)
                                 TODDS LANE
                                                                                                                                                   (4)
                                                        27 (0) 27

                                                                                                                                                         (10)
                                                       696 (3) 699

                                                                                                                     332 (7) 339
                                                                                                                     103 (2) 105
                                                                                                                     198 (0) 198
                                                       171 (0) 171

                                                                                                                                                  SITE
                                                                                             (0)                           (9)
                                                                                                                           (29)
                                                                                                             (14)
                                                                                               ABERDEEN RD
                                                               302 (2) 304
                                                               185 (12) 197

                                                                              120 (15) 135

                                                                                                                                   167 (7) 174
                                                                                                                                  2216 (0) 2216
                                                                                                                                   255 (0) 255
                            MERCURY BLVD
                                                    231 (6) 237
                                                   2199 (0) 2199
                                                                                                                    155 (0) 155
                                                                                                                    380 (1) 381
                                                                                                                                  321 (0) 321

                                                    218 (0) 218

 Legend

 Background + (Site) = Total

                                                       Figure 8

                                                       2020 PM Peak Hour Volumes
                                                       Todd Center Shopping Center
   0             N.T.S.                                1700 Todds Lane, Hampton, VA
                                                                                                                                                                July 1, 2015
Capacity Analysis

The 2015 and 2020 Build Condition volumes were analyzed using the Synchro 8.0 software. The
results of the analyses for both AM and PM are provided in Tables 10, 11, 12, and 13.

Table 10: 2015 Build Measures of Effectiveness at Todds Lane and Aberdeen Road

                        Todds Lane and Aberdeen Road ‐ 2015 Build AM
                               Volume to    Control               Approach            Avg. Int.
                                                       Movement             Approach            Intersection
    Approach       Movement     Capacity     Delay                  Delay              Delay
                                                         LOS                  LOS                   LOS
                                 Ratio     (sec/veh)              (sec/veh)          (sec/veh)
                        EBL       0.27        47.9        D
   Todds Lane
                        EBT       0.55        28.4        C         24.9        C
      (EB)
                       EBR        0.16         2.6        A
                       WBL        0.51        48.8        D
   Todds Lane
                       WBT        0.29        19.4        B         23.7        C
      (WB)
                       WBR        0.04         0.1        A                             28.9            C
                       NBL        0.65        57.7        E
  Aberdeen Rd
                       NBT        0.64        57.0        E         35.4        D
     (NB)
                       NBR        0.32         3.7        A
  Aberdeen Rd           SBL       0.65        57.1        E
                                                                    47.2        D
      (SB)             SBTR       0.22        32.6        C

                       Todds Lane and Aberdeen Road ‐ 2015 Build PM
                               Volume to    Control               Approach            Avg. Int.
                                                       Movement             Approach            Intersection
   Approach        Movement     Capacity     Delay                  Delay              Delay
                                                         LOS                  LOS                   LOS
                                 Ratio     (sec/veh)              (sec/veh)          (sec/veh)
                       EBL        0.34        60.1        E
  Todds Lane
                       EBT        0.74        43.4        D         36.9       D
     (EB)
                      EBR         0.21         4.6        A
                      WBL         0.79        60.6        E
  Todds Lane
                      WBT         0.56        25.7        C         31.2       C
     (WB)
                      WBR         0.15         5.3        A                             39.3            D
                      NBL         0.86        75.8        E
  Aberdeen Rd
                      NBT         0.85        73.9        E         53.8       D
     (NB)
                      NBR         0.30         5.0        A
  Aberdeen Rd          SBL        0.64        74.6        E
                                                                    58.2        E
      (SB)            SBTR        0.34        42.9        D

E‐Commerce Center of Hampton
Traffic Impact Study                                                                               20
Table 11: 2015 Build Measures of Effectiveness at Mercury Boulevard and Aberdeen Road

                     Mercury Boulevard and Aberdeen Road ‐ 2015 Build AM
                                Volume to    Control               Approach            Avg. Int.
                                                        Movement             Approach            Intersection
      Approach       Movement    Capacity     Delay                  Delay              Delay
                                                          LOS                  LOS                   LOS
                                  Ratio     (sec/veh)              (sec/veh)          (sec/veh)
                          EBL      0.53        58.4        E
    Mercury Blvd
                          EBT      0.67        28.5        C         29.1       C
        (EB)
                          EBR      0.17         1.3        A
                         WBL       0.66        64.0        E
    Mercury Blvd
                         WBT       0.50        25.4        C         28.2       C
       (WB)
                         WBR       0.14         1.7        A                             33.4            C
                          NBL      0.82        92.3        F
     Aberdeen Rd
                         NBT       0.48        52.8        D         42.9       D
         (NB)
                         NBR       0.49        14.8        B
     Aberdeen Rd          SBL      0.71        79.3        E
                                                                      61         E
         (SB)            SBTR      0.77        55.6        E
                     Mercury Boulevard and Aberdeen Road ‐ 2015 Build PM
                                Volume to    Control               Approach            Avg. Int.
                                                        Movement             Approach            Intersection
      Approach       Movement    Capacity     Delay                  Delay              Delay
                                                          LOS                  LOS                   LOS
                                  Ratio     (sec/veh)              (sec/veh)          (sec/veh)
                          EBL      0.88        88.4        F
    Mercury Blvd
                          EBT      0.92        46.7        D         47.3       D
        (EB)
                          EBR      0.31         4.3        A
                         WBL       0.76        74.4        E
    Mercury Blvd
                         WBT       0.85        41.1        D         42.4       D
       (WB)
                         WBR       0.19         6.7        A                             50.1            D
                          NBL      0.86        96.1        F
     Aberdeen Rd
                         NBT       0.77        66.6        E          55        E
         (NB)
                         NBR       0.62        19.2        B
     Aberdeen Rd          SBL      0.96       118.3        F
                                                                     84.3       F
         (SB)            SBTR      0.94        73.1        E

E‐Commerce Center of Hampton
Traffic Impact Study                                                                                21
Table 12: 2020 Build Measures of Effectiveness at Todds Lane and Aberdeen Road
                          Todds Lane and Aberdeen Road ‐ 2020 Build AM
                                 Volume to    Control               Approach            Avg. Int.
                                                         Movement             Approach            Intersection
       Approach      Movement     Capacity     Delay                  Delay              Delay
                                                           LOS                  LOS                   LOS
                                   Ratio     (sec/veh)              (sec/veh)          (sec/veh)
                          EBL       0.33        49.3        D
      Todds Lane
                          EBT       0.58        29.4        C         25.9        C
         (EB)
                         EBR        0.17         2.6        A
                         WBL        0.55        50.5        D
      Todds Lane
                         WBT        0.31        20.2        C         24.7        C
         (WB)
                         WBR        0.04         0.1        A                              29.9         C
                         NBL        0.68        59.6        E
     Aberdeen Rd
                         NBT        0.67        58.3        E         36.6        D
        (NB)
                         NBR        0.34         4.1        A
     Aberdeen Rd          SBL       0.67        58.3        E
                                                                      46.7        D
         (SB)            SBTR       0.25        31.4        C

                          Todds Lane and Aberdeen Road ‐ 2020 Build PM
                                 Volume to    Control               Approach            Avg. Int.
                                                         Movement             Approach            Intersection
       Approach      Movement     Capacity     Delay                  Delay              Delay
                                                           LOS                  LOS                   LOS
                                   Ratio     (sec/veh)              (sec/veh)          (sec/veh)
                          EBL       0.38        61.5        E
      Todds Lane
                          EBT       0.79        46.2        D         39.3       D
         (EB)
                         EBR        0.23         5.1        A
                         WBL        0.84        64.7        E
      Todds Lane
                         WBT        0.60        27.0        C         33.1       C
         (WB)
                         WBR        0.16         5.7        A                             41.3         D
                         NBL        0.88        79.0        E
     Aberdeen Rd
                         NBT        0.87        76.6        E         56.1       E
         (NB)
                         NBR        0.31         5.4        A
     Aberdeen Rd          SBL       0.67        76.4        E
                                                                      57.4       E
         (SB)            SBTR       0.38        41.1        D

 E‐Commerce Center of Hampton
 Traffic Impact Study                                                                                 22
Table 13:   2020 Build Measures of Effectiveness at Mercury Boulevard and Aberdeen Road
                      Mercury Boulevard and Aberdeen Road ‐ 2020 Build AM
                                  Volume to    Control               Approach            Avg. Int.
                                                          Movement             Approach            Intersection
      Approach        Movement     Capacity     Delay                  Delay              Delay
                                                            LOS                  LOS                   LOS
                                    Ratio     (sec/veh)              (sec/veh)          (sec/veh)
                          EBL        0.56        59.2        E
     Mercury Blvd
                          EBT        0.71        29.8        C         30.2       C
         (EB)
                         EBR         0.18         1.8        A
                         WBL         0.69        65.8        E
     Mercury Blvd
                         WBT         0.53        26.2        C         29.1       C
        (WB)
                         WBR         0.14         1.8        A                             34.6         C
                         NBL         0.85        98.5        F
     Aberdeen Rd
                         NBT         0.49        52.8        D         44.8       D
        (NB)
                         NBR         0.52        16.4        B
     Aberdeen Rd          SBL        0.74        82.2        F
                                                                       63.1       E
         (SB)            SBTR        0.80        57.4        E
                      Mercury Boulevard and Aberdeen Road ‐ 2020 Build PM
                                  Volume to    Control               Approach            Avg. Int.
                                                          Movement             Approach            Intersection
      Approach        Movement     Capacity     Delay                  Delay              Delay
                                                            LOS                  LOS                   LOS
                                    Ratio     (sec/veh)              (sec/veh)          (sec/veh)
                          EBL        0.90        92.4        F
     Mercury Blvd
                          EBT        0.99        57.0        E         55.9       E
         (EB)
                         EBR         0.34         4.2        A
                         WBL         0.81        78.1        E
     Mercury Blvd
                         WBT         0.92        45.9        D         46.7       D
        (WB)
                         WBR         0.20         7.1        A                             56.2         E
                         NBL         0.91       102.9        F
     Aberdeen Rd
                         NBT         0.77        65.9        E         56.6       E
        (NB)
                         NBR         0.65        21.0        C
     Aberdeen Rd          SBL        1.04       135.6        F
                                                                       92.2       F
         (SB)            SBTR        0.97        77.5        E

   E‐Commerce Center of Hampton
   Traffic Impact Study                                                                                23
Build Queue Conditions

Future Build 2015
Table 14 presents the queue lengths for future Build 2015 AM and PM peak hours for both
intersections. The queueing lengths are well within their capacities for the build conditions.
  Table 14: Future 2015 Build Queue Lengths
                                                    95th       95th
                                        Link
      Intersection      Movement                  Queue AM Queue PM
                                      Distance
                                                  2015 Build 2015 Build
                           EBT         1764          272        392
                           WBT         876           224        441
    Aberdeen Rd @
                           NBT         546           143        227
     Mercury Blvd
                           SBL         943           125        179
                           SBT         943           172        288
                           EBT         1043          221        285
                           WBT         1842          116        246
    Aberdeen Rd @
                           NBL         650           152        251
      Todds Lane
                           NBLT        650           120        275
                           SBTR        678            75         98

Future Build 2020

Table 15 presents the queues for the future 2020 Build AM and PM peak hours. Both signalized
intersections are within their queuing capacities.

  Table 15: Future 2020 Build Queue Lengths

                                                     95th       95th
                                         Link
       Intersection      Movement                  Queue AM Queue PM
                                       Distance
                                                   2020 Build 2020 Build
                               EBT      1764          282        426
                               WBT      876           234        492
     Aberdeen Rd @
                               NBT      546           142        243
      Mercury Blvd
                               SBL      943           142        198
                               SBT      943           180        347
                               EBT      1043          232        304
                               WBT      1842          128        274
     Aberdeen Rd @
                               NBL      650           160        258
       Todds Lane
                               NBLT     650           126        299
                               SBT      678            84         99

E‐Commerce Center of Hampton
Traffic Impact Study                                                                             24
Summary and Conclusions

This study performed an evaluation of the No Build and Build scenarios for 2015 and a horizon
year of 2020, AM and PM Peak Hours. The study intersections included in the analyses were
Todds Lane and Aberdeen Road and Mercury Boulevard and Aberdeen Road.

The 2015 and 2020 No Build conditions indicate that the study intersections function overall at
acceptable levels of service (LOS) of “C” in the morning peak hours and “D” in the afternoon.
Some of the movements fall into LOS “E” or “F”; however the volume to capacity (V/C) ratio is
less than one. The LOS in these situations are typically a result of long wait times due to cycle
length. This condition is typically found to be acceptable under these circumstances. Another
measure of effectiveness is the estimated queue length. The queue lengths fall within the
storage capacity of the turn lanes.

The site is estimated to generate 732 daily trips with 57 trips during the morning peak hour and
70 trips during the evening peak hour. Of the 732 trips, 54 truck trips are estimated to access
the site on a daily basis, which is equal to 27 trucks coming into and out of the site daily.

The results show that once the proposed project is built, a slight increase in delay at each
intersection under each scenario can be expected. There is an anticipated change in LOS from
“D” to “E” during the 2020 PM Peak Hour between the No-Build and Build scenarios. A 4%
increase in delay crosses the threshold from “D” to “E” for the overall intersection. The
additional southbound left turn volume from the site in combination of the 1% per year growth
in background traffic shows many of the movements at the intersection pushing close to the
capacity of the intersection.

A review of the simulation modelling and the calculated queue lengths indicate that the
intersection clears during the critical peak hour and that the queue lengths do not spill back
into upstream intersections.

In conclusion, the results of the analyses indicate that the development of the site as proposed
will have modest impact on the intersections within the study area.

E‐Commerce Center of Hampton
Traffic Impact Study                                                                             25
You can also read
Next slide ... Cancel
